Redline Connect Series Instruction sheet

Virtual Fiber™
Outdoor Wireless TCP/IP Transport
70-00200-02-00 Proprietary Redline Communications © 2014 Page 1of 70 December 3, 2014
Connect Series
Universal Wireless Transport™
(UWT™) System for SCADA
Connect-OWS System
Installation Guidelines
1Important Notices...................................................................9
2System Features...................................................................15
3Site Survey............................................................................26
4Installation ............................................................................38

CONNECT-OWS Installation Guidelines
70-00200-02-00 Proprietary Redline Communications © 2014 Page 2of 70 December 3, 2014
Copyright Information
All rights reserved December 3, 2014. The information in this document is proprietary to
Redline Communications Inc. This document may not in whole or in part be copied,
reproduced, or reduced to any medium without prior consent, in writing, from Redline
Communications Incorporated.
Contact Information:
Redline Communications Inc.
302 Town Centre Blvd.
Markham, ON
Canada L3R 0E8
Web site:
www.rdlcom.com
Email:Inquiries: [e-mail]
Support: [e-mail]
Training: [e-mail]
Document Control:
70-00200-02-00-Redline_Connect-OWS_Installation_Guide-20141203a.doc
Disclaimer
The statements, configurations, technical data, and recommendations in this document
are believed to be accurate and reliable, but are presented without express or implied
warranty. Additionally, Redline makes no representations or warranties, either expressed
or implied, regarding the contents of this product. Redline Communications shall not be
liable for any misuse regarding this product. The information in this document is subject
to change without notice. No part of this document shall be deemed to be part of any
warranty or contract unless specifically referenced to be part of such warranty or
contract within this document.
Software Versions
This manual describes operation using software release v2.25 and may include features
that are different or unavailable in previous software releases.
Some Connect-OWS System features are controlled by options keys and are available
only on specific revisions of hardware systems. Refer to the individual product Release
Notes for information about required software and availability of features.

CONNECT-OWS Installation Guidelines
70-00200-02-00 Proprietary Redline Communications © 2014 Page 3of 70 December 3, 2014
Revision Log
Date
Item
Description of Changes
20141121
All
Created Document

CONNECT-OWS Installation Guidelines
70-00200-02-00 Proprietary Redline Communications © 2014 Page 4of 70 December 3, 2014
TABLE OF CONTENTS
1Important Notices...................................................................9
1.1 Important Deployment Information...................................................................9
1.2 Service & Safety.................................................................................................9
Safety Warnings.............................................................................................9
General Warnings..........................................................................................9
Warning Symbols...........................................................................................9
1.3 Installation Safety............................................................................................10
Professional Installation / Installations Professionnel ...................................10
Safety Precautions.......................................................................................10
Electrocution Hazard / Risque D’électrocution..............................................10
Radio Frequency Safety / Sécurité des Fréquences Radio ..........................11
Personal Safety............................................................................................11
Electrical Safety ...........................................................................................11
Electrical Safety Compliance / Conformité à la Sécurité Electrique..............11
Safety Information........................................................................................12
Lightning Protection / Protection Contre la Foudre.......................................12
1.4 WEEE Product Return Process.......................................................................13
1.5 Service & Warranty Information......................................................................14
2System Features...................................................................15
2.1 Connect-OWS System.....................................................................................17
Console Port (CON).....................................................................................17
Serial Interface Ports (DATA 1 & DATA 2) ...................................................18
Ethernet Ports (ETH 1 & ETH 2) .................................................................18
PoE Port (Ethernet/Power)...........................................................................19
Ethernet Ports (ETH 1 & ETH 2) .................................................................19
DC power Connections ................................................................................20
Ground Lug..................................................................................................20
Dimensions..................................................................................................20
2.2 Connect-OW Power Terminal Block...............................................................21
2.3 Connect-OW Wireless Terminal......................................................................22
Connect-OW with Integrated Antenna..........................................................22
Connect-OWS-ER (Extended Range) with External Antenna.......................22
Ethernet Port................................................................................................22
Ground Lug..................................................................................................23
Connect-OW Dimensions.............................................................................24
2.4 Ethernet Port Weatherproof Gland.................................................................24
2.5 Ethernet Surge Protection Device ..................................................................25
Ethernet Port................................................................................................25
Surge Arrestor Dimensions ..........................................................................25
3Site Survey............................................................................26

CONNECT-OWS Installation Guidelines
70-00200-02-00 Proprietary Redline Communications © 2014 Page 5of 70 December 3, 2014
3.1 General Information.........................................................................................26
3.2 Network Settings..............................................................................................26
3.3 Serial Gateway Settings ..................................................................................27
3.4 Serial Gateway Settings ..................................................................................27
3.5 Radio Management Settings...........................................................................28
Path Profile ..................................................................................................28
RF Interference............................................................................................29
3.6 Site Preparation ...............................................................................................30
General Layout Options ...............................................................................30
Material Requirements.................................................................................31
Review System Grounding Requirements....................................................32
3.7 Environmental Conditions (Cabinet/Shelter) .................................................33
3.8 Connect-OWS Lead-In Ethernet Connection..................................................34
Cable Length................................................................................................34
Surge Suppression.......................................................................................34
Weatherproofing...........................................................................................34
Cable Hangars.............................................................................................34
3.9 Network (Ethernet) Connection ......................................................................35
Cable Length................................................................................................35
Surge Suppression.......................................................................................35
Weatherproofing...........................................................................................35
Cable Hangars.............................................................................................35
3.10 Power Source...................................................................................................36
Isolation .......................................................................................................36
Surge Suppression.......................................................................................36
Power Requirments......................................................................................36
Cable Hangars.............................................................................................36
DC Power Supply Wiring..............................................................................37
4Installation ............................................................................38
Installation Steps..........................................................................................38
4.1 Preparation.......................................................................................................39
4.1.1 Installation Installation Overview.....................................................................39
4.1.2 Materials Supplied by Installer ........................................................................40
4.1.3 Assemble Radio Mounting Bracket .................................................................41
Standard Pole Mount ...................................................................................41
Alternate Mounting Options..........................................................................42
4.1.4 Assemble and Weatherproof Ethernet Port Connection..................................43
Ethernet Port Gland .....................................................................................43
Weatherproof the Ethernet Port....................................................................44
4.2 Install Outdoor Equipment..............................................................................45
4.2.1 Install Connect-OWS on Mast.........................................................................45
Hoist Equipment to Mounting Location.........................................................45
Cable Hangars.............................................................................................46

CONNECT-OWS Installation Guidelines
70-00200-02-00 Proprietary Redline Communications © 2014 Page 6of 70 December 3, 2014
Cable Ties....................................................................................................46
4.2.2 Coarse Antenna Alignment .............................................................................47
Azimuth Alignment.......................................................................................47
Elevation Alignment .....................................................................................47
4.3 Install In-Cabinet Equipment...........................................................................48
4.3.1 Install Connect-OWS Serial Gateway..............................................................48
Mounting Options.........................................................................................49
4.3.2 Install Ethernet Surge Arrestor........................................................................51
Ethernet Jumper Cable ................................................................................52
4.4 Configure Connect-OWS System....................................................................53
4.4.1 Required Materials..........................................................................................53
4.4.2 Accessing Connect-OWS Management Interface ...........................................54
Web Browser ...............................................................................................54
4.4.3 Configure the Serial Gateway .........................................................................55
System Information......................................................................................55
Serial Port Settings ......................................................................................56
Gateway Settings.........................................................................................57
4.4.4 Radio Management Settings...........................................................................58
Install Options Key Upgrade (Optional)........................................................58
Network and RF Settings .............................................................................58
4.5 Review and adjust the radio management parameters as required. Refer to
the information collected during the site survey (3.1 General Information.............58
4.6 Network Settings.....................................................Error! Bookmark not defined.
4.7 Serial Gateway Settings .........................................Error! Bookmark not defined.
4.8 Serial Gateway Settings .........................................Error! Bookmark not defined.
4.9 Configure System Operating Parameters ......................................................61
4.9.1 Required Materials..........................................................................................61
4.9.2 Establish Communications with Test PC.........................................................61
Web Browser ...............................................................................................62
Telnet Access ..............................................................................................63
4.9.3 Install Options Key Upgrade............................................................................63
4.9.4 Network and RF Settings ................................................................................63
4.9.5 Medium/Fine Antenna Alignment ....................................................................65
Using the Web Alignment Tool (Wireless Terminal Only).............................65
Medium Antenna Adjustment Using the Audible Adjustment Tool ................65
Fine Antenna Alignment Using RSSI and SINADR.......................................66
Wireless Terminal Link Status Screen (Wireless Terminal Only)..................67
Wireless Terminal Links Summary Screen (Base station Only)....................68
LIST OF TABLES
Table 1: Notice - Electrical Safety Specifications...........................................................12
Table 2: Avis - Spécifications de sécurité électrique......................................................12
Table 3: Features- Connect-OWS System Components................................................16
Table 4: Features - Pinout CON Port - RS-232..............................................................17

CONNECT-OWS Installation Guidelines
70-00200-02-00 Proprietary Redline Communications © 2014 Page 7of 70 December 3, 2014
Table 5: Features - CON Port LEDs..............................................................................17
Table 6: Features - Pinout for Data1 / Data 2 Port 232/485...........................................18
Table 7: Features - DATA Port LEDs.............................................................................18
Table 8: Features - Pinout for ETH Ports.......................................................................19
Table 9: Features - ETH Port LEDs...............................................................................19
Table 10: Features - Pinout for PoE and ETH Ports ......................................................19
Table 11: Features - ETH Port LEDs.............................................................................19
Table 12: Features - Input Power Connector Pinout......................................................20
Table 13: Features: Ethernet Port RJ-45 Pinout (T568B) ..............................................23
Table 14: Site Survey - General Information Settings....................................................26
Table 15: Site Survey - Network & Syslog Server Settings............................................26
Table 16: Site Survey - Serial Gateway Settings ...........................................................27
Table 17: Site Survey - Serial Gateway Settings ...........................................................27
Table 18: Site Survey - Radio Management Settings.....................................................28
Table 19: Site Survey - Path Profile Data ......................................................................28
Table 20: Site Survey: Operating Temperature Range..................................................33
Table 21: Site Survey: Power Requirements.................................................................36
Table 22: Installation: Installer Supplied Materials.........................................................40
Table 23: Installation: Input Power Connector Pinout ....................................................49
Table 24: Installation: Installer Supplied Materials.........................................................53
Table 25: Configuration: Network and Wireless Settings ...............................................61
Table 26: Installation: Installer Supplied Materials.........................................................61
Table 27: Configuration: Network and Wireless Settings ...............................................63
LIST OF FIGURES
Figure 1: Notice - WEEE Logo.......................................................................................13
Figure 2: Features: Connect-OWS System....................................................................15
Figure 3: Features: Connect-OWS System Components...............................................16
Figure 4: Features: - Connect-OWS Features ...............................................................17
Figure 5: Description - Connect-OWS DATA 1/2 and CON Port Pin Assignment...........18
Figure 6: Description - Connect-OWS ETH 1 and ETH 2 Port Pin Assignment..............18
Figure 7: Description - Connect-OWS ETH 1 and ETH 2 Port Pin Assignment..............19
Figure 8: Features: - Connect-OWS Dimensions...........................................................20
Figure 9: Features - Connect-OWS Power Terminal Block............................................21
Figure 10: Features - Connect-OW (Integrated Antenna) Features ...............................22
Figure 11: Features - Connect-OWS-ER (External Antenna) Ethernet Features............22
Figure 12: Description - Connect-OWS PoE Port Pin Assignment.................................23
Figure 13: Features - Connect-OWS (integrated Antenna) Dimensions: 8 in.................24
Figure 14: Features - Connect-OWS-ER (External Antenna) Dimensions .....................24
Figure 15: Features - Connect-OW/Connet-OW-ER Ethernet Gland.............................24
Figure 16: Features - Ethernet Line Protection Device ..................................................25
Figure 17: Features - Ethernet Line Protection Device Dimensions...............................25
Figure 18: Site Survey - RF Planning Fresnel Zone.......................................................28
Figure 19: Site Survey: Connect-OW Antenna Position.................................................29
Figure 20: Site Survey: Connect-OWS System Layout Options.....................................30
Figure 21: Site Survey: Connect-OWS Site Preparation................................................31
Figure 22: Site Survey: Connect-OWS System Grounding............................................32

CONNECT-OWS Installation Guidelines
70-00200-02-00 Proprietary Redline Communications © 2014 Page 8of 70 December 3, 2014
Figure 23: Site Survey: Connect-OWS Cabinet Equipment ...........................................33
Figure 24: Site Survey: Connect-OWS Lead-In Ethernet Cable.....................................34
Figure 25: Site Survey: Connect-OWS Ethernet Network Connection Survey ...............35
Figure 26: Site Survey: Connect-OWS Power Survey ...................................................36
Figure 27: Site Survey: Connect-OWS Power Input Wiring............................................37
Figure 28: Installation: Connect-OWS System Installation Diagram...............................39
Figure 29: Installation: Site Survey: Connect-OW Mounting Bracket Assembly.............41
Figure 30: Installation: Connect-OW Mounting Bracket Attachment...............................41
Figure 31: Installation: Connect-OW Mounting Bracket Alternative Mounting Options...42
Figure 32: Installation: Connect-OW Mounting Bracket Flat-to-Wall Dimensions...........42
Figure 33: Installation: Connect-OW Ethernet Gland Assembly.....................................43
Figure 34: Installation: Connect-OW Ethernet Port Weatherproofing.............................44
Figure 35: Installation: Connect-OW Equipment Mounted with Cabling.........................45
Figure 36: Installation: Connect-OWS Power Wiring......................................................49
Figure 37: Features: Connect-OWS Mounting Options..................................................49
Figure 38: Installation: Connect-OWS #10 Ground Lug.................................................50
Figure 39: Installation: Connect-OWS Ethernet Surge Arrestor Wiring ..........................51
Figure 40: installation: Ethernet Lightning Protection Device.........................................52
Figure 41: Installation: Ethernet Jumper Cable..............................................................52
Figure 42: Configuration: Connect-OWS System Configuration Block Diagram.............53
Figure 43: Configuration: Connect-OWS System Configuration Using PC.....................54
Figure 44: Configuration: Login Screen .........................................................................54
Figure 45: Configuration: System Information Screen....................................................55
Figure 46: Configuration: Serial Port Settings Screen....................................................56
Figure 47: Configuration: Gateway Settings Screen ......................................................57
Figure 48: Configuration: Product Options Screen.........................................................58
Figure 49: Configuration: Connect-OWS System Configuration Using PC.....................62
Figure 50: Configuration: Login Screen .........................................................................63
Figure 51: Configuration: Product Options Screen.........................................................63
Figure 52: Configuration: Antenna Alignment Tool Screen ............................................65
Figure 53: Configuration: Wireless Terminal Link Status Screen ...................................67
Figure 54: Configuration: Wireless Terminal Links Summary Screen ............................68

CONNECT-OWS Installation Guidelines
70-00200-02-00 Proprietary Redline Communications © 2014 Page 9of 70 December 3, 2014
1 Important Notices
1.1 Important Deployment Information
IMPORTANT: Refer to the RDL-3000 Family User Manual for detailed regulatory
information. Refer to this document before deploying and powering Connect systems in
the field.
1.2 Service & Safety
Safety Warnings
WARNING - MICROWAVE TRANSMISSIONS: Do not operate or work in close
proximity to this equipment without first having proper training or knowledge of
microwave radio operation.
Read this manual and follow all operating and safety instructions.
Installation of the system must be contracted to a professional installer.
Keep all product information for future reference.
The power requirements are indicated on the product-marking label. Do not exceed
the described limits.
The unit must not be located near power lines or other electrical power circuits.
Disconnect the power before cleaning, or when the unit is not be in-use for an
extended period.
The system must be properly grounded to protect against power surges and
accumulated static electricity. The user is responsible for installing this device in
accordance with the local electrical codes: correct installation procedures for
grounding the unit, mast, lead-in wire and discharge unit, location of discharge unit,
size of grounding conductors and connection requirements for grounding electrodes.
General Warnings
Redline recommendations for maximum safety include the following:
Do not operate microwave equipment without first having proper training or
knowledge of microwave radio operation.
Do not operate the microwave equipment without an appropriate antenna port
termination, or antenna.
Do not look into or stand in front of an antenna.
Do not swing or aim an antenna at nearby persons while the equipment is operating.
Check to ensure that the area around the antenna is clear of personnel prior to
turning the transmitter on.
In locations where other antennas are installed, do not proceed with an installation
without first determining the RF/µW exposure risk. Where necessary have the
relevant transmitters turned off or wear a protective suit for the duration of the
installation.
Warning Symbols
These symbols may be encountered during installation or troubleshooting. These
warning symbols mean danger. Bodily injury may result if you are not aware of the safety
hazards involved in working with electrical equipment and radio transmitters. Familiarize
yourself with standard safety practices before continuing.
Chapter 1

CONNECT-OWS Installation Guidelines
70-00200-02-00 Proprietary Redline Communications © 2014 Page 10 of 70 December 3, 2014
WARNING
ELECTRO-MAGNETIC
RADIATION
WARNING
HIGH VOLTAGE
WARNING
HOT SURFACE
DO NOT TOUCH
1.3 Installation Safety
Professional Installation / Installations Professionnel
Redline CONNECT systems require professional installation. The user is responsible to
ensure all building and safety codes are met and the installation is complete and
secure.
The CONNECT system shall be installed according to local Electrical Safety Codes.
For Canadian installations, the entire equipment installation must comply with the
Canadian Electrical Code. For installations in the United States, the entire equipment
installation must be in accordance with Article 810 of the United States National
Electrical Code.
Les appareils CONNECT de Redline doivent être installés par un personnel
professionnel. Le personnel responsable doit s’assurer que l’installation est bien
achevée, et qu’elle répond aux exigences de tous les codes de sécurité.
Le CONNECT doit être installé conformément aux codes locaux de sécurité électrique.
Pour les installations Canadiennes, l'installation de l'équipement au complet doit se
conformer au Code Canadien de l'électricité. Pour les installations aux États-Unis,
l'installation de l'équipement au complet doit être en conformité avec l'article 810 du
Code des États-Unis National Electrical.
Safety Precautions
Installation and service must be done by personnel having technical training and
experience necessary to be aware of hazards during installation and/or service of
outdoors RF equipment. The installation and/or service must be done using procedures
designed to minimize any danger to technical personnel or any other person.
Use safety devices when working on or around the mast. Be aware of the risk of falling
objects. Use provided safety catches when hoisting antennas and radios.
Do not use any components (screws, nuts, etc.) other than those delivered together with
the Redline microwave radio equipment or those recommended by Redline.
Electrocution Hazard / Risque D’électrocution
Warning to Service Personnel
Do not install Redline products near any type of power line. Should the antenna or
related hardware come in contact with power lines, severe bodily harm or death could
result!
