Redline RDL-3000 SC Instruction sheet

Virtual Fiber™
Outdoor Wireless TCP/IP Transport
70-00204-01-01 Proprietary Redline Communications © 2015 Pahge 1 of 56 May 19, 2015
RDL-3000
Universal Wireless Transport™
(UWT™) System
Edge Wireless Terminal
Installation Guidelines
1Important Notices...................................................................8
2System Features...................................................................14
3Site Survey............................................................................19
4Installation Procedures........................................................29
5Reference..............................................................................47

Edge INSTALLATION GUIDELINES
70-00204-01-01 Proprietary Redline Communications © 2015 Page 2 of 56 May 19, 2015
Copyright Information
All rights reserved May 15, 2015. The information in this document is proprietary to
Redline Communications Inc. This document may not in whole or in part be copied,
reproduced, or reduced to any medium without prior consent, in writing, from Redline
Communications Incorporated.
Contact Information:
Redline Communications Inc.
302 Town Centre Blvd.
Markham, ON
Canada L3R 0E8
Tel: [phone] Toll Free in North America: +1.866.633.6669
Fax: [phone]
Web site:
www.rdlcom.com
Email:Inquiries: [e-mail]
Support: [e-mail]
Training: [e-mail]
Document Control:
70-00204-01-01-Redline_Edge_Installation_Guide-20150515a.doc
Disclaimer
The statements, configurations, technical data, and recommendations in this document
are believed to be accurate and reliable, but are presented without express or implied
warranty. Additionally, Redline makes no representations or warranties, either expressed
or implied, regarding the contents of this product. Redline Communications shall not be
liable for any misuse regarding this product. The information in this document is subject
to change without notice. No part of this document shall be deemed to be part of any
warranty or contract unless specifically referenced to be part of such warranty or
contract within this document.

Edge INSTALLATION GUIDELINES
70-00204-01-01 Proprietary Redline Communications © 2015 Page 3 of 56 May 19, 2015
Revision Log
Date
Item
Description of Change(s)
20131107
2.7
Remove reference to RF jumpers.
20131128
1
Update section 1
20131203
general
Update PoE information
20141021
Fig. 2
Update system components diagram
20150327
General format update
20150519
Add RF-1 and RF-2 designation to drawings.

Edge INSTALLATION GUIDELINES
70-00204-01-01 Proprietary Redline Communications © 2015 Page 4 of 56 May 19, 2015
TABLE OF CONTENTS
1Important Notices...................................................................8
1.1 Deployment Information....................................................................................8
1.2 Service & Safety.................................................................................................8
General Warnings..........................................................................................8
Safety Warnings.............................................................................................8
Warning Symbols...........................................................................................9
1.3 Installation Safety..............................................................................................9
Professional Installation / Installations Professionnel .....................................9
Safety Precautions.........................................................................................9
Electrocution Hazard / Risque D’électrocution..............................................10
Radio Frequency Safety / Sécurité des Fréquences Radio ..........................10
Personal Safety............................................................................................10
Electrical Safety ...........................................................................................10
Electrical Safety Compliance / Conformité à la Sécurité Electrique ..............11
UL Information .............................................................................................11
Lightning Protection / Protection Contre la Foudre.......................................11
1.4 WEEE Product Return Process.......................................................................12
1.5 Service & Warranty Information......................................................................13
2System Features...................................................................14
2.1 System Components .......................................................................................14
2.2 Edge Wireless Terminal...................................................................................15
RF Ports.......................................................................................................15
Ethernet Port................................................................................................15
2.3 Ethernet Port Weatherproof Gland.................................................................16
Ground Lug..................................................................................................16
Edge Dimensions.........................................................................................16
2.4 Configuration and Management .....................................................................18
ClearView NMS Application .........................................................................18
Telnet (CLI)..................................................................................................18
Web Browser (HTTP)...................................................................................18
3Site Survey............................................................................19
3.1 General Information.........................................................................................20
3.2 Network Settings..............................................................................................20
3.3 Radio Management Settings...........................................................................20
Path Profile ..................................................................................................20
RF Interference............................................................................................21
3.4 Site Preparation ...............................................................................................22

Edge INSTALLATION GUIDELINES
70-00204-01-01 Proprietary Redline Communications © 2015 Page 5 of 56 May 19, 2015
General Layout Options ...............................................................................22
Material Requirements.................................................................................23
Review System Grounding Requirements....................................................24
3.5 Environmental Conditions (Cabinet/Shelter) .................................................25
3.6 Edge Lead-In Ethernet Connection.................................................................26
Cable Length................................................................................................26
Surge Suppression.......................................................................................26
Weatherproofing...........................................................................................26
Cable Supports............................................................................................26
3.7 Data (Ethernet) Connection.............................................................................27
Cable Length................................................................................................27
Surge Suppression.......................................................................................27
Weatherproofing...........................................................................................27
Cable Supports............................................................................................27
3.8 Power Source...................................................................................................28
Isolation .......................................................................................................28
Surge Suppression.......................................................................................28
Power Requirments......................................................................................28
Cable Supports............................................................................................28
4Installation Procedures........................................................29
4.1 Preparation.......................................................................................................30
4.1.1 Step 1: Installation Installation Overview.........................................................30
4.1.2 Step 2: Materials Supplied by Installer ............................................................31
4.1.3 Step 3: Review the Site Survey section...........................................................31
4.2 Configure System Operating Parameters ......................................................32
4.2.1 Step 1: Setup Test Bench ...............................................................................32
4.2.2 Step 2: Login with Test PC..............................................................................32
4.2.3 Step 3: Restore Default Settings.....................................................................33
4.2.4 Step 4: Install Options Key..............................................................................33
4.2.5 Step 5: Required Network and Wireless Settings............................................35
4.2.6 Step 6: Change Passwords.............................................................................35
4.3 Install Outdoor Equipment..............................................................................36
4.3.1 Step 1: Assemble Ethernet and RF Port Connections.....................................36
Assemble Ethernet Port Connection.............................................................36
Assemble RF Port Connections ...................................................................37
Weatherproof Ethernet and Antenna Ports...................................................37
4.3.2 Step 2: Assemble Radio Mounting Bracket.....................................................39
Standard Pole Mount ...................................................................................39
Alternate Mounting Options..........................................................................40
4.3.3 Step 3: Install Antenna on Mast ......................................................................41
4.3.4 Step 4: Install Wireless System on Mast .........................................................41
Hoist Equipment to Mounting Location.........................................................41
Cable Supports............................................................................................41
Cable Ties....................................................................................................41

Edge INSTALLATION GUIDELINES
70-00204-01-01 Proprietary Redline Communications © 2015 Page 6 of 56 May 19, 2015
Connect and Weatherproofing Cables..........................................................42
4.3.5 Step 5: Align Antenna .....................................................................................42
Azimuth Alignment.......................................................................................42
Elevation Alignment .....................................................................................43
Medium Adjustment .....................................................................................43
Fine Alignment.............................................................................................43
4.4 Install In-Cabinet Equipment...........................................................................46
4.4.1 Step 1: Install PoE Power Injector...................................................................46
4.4.2 Step 2: Install Ethernet Surge Arrestor............................................................46
5Reference..............................................................................47
5.1 Power Over Ethernet (PoE) Device.................................................................47
5.1.1 DC-DC PoE ....................................................................................................47
Ethernet Port................................................................................................47
PoE Port ......................................................................................................47
LED Indicators .............................................................................................48
DC power Connections ................................................................................48
Ground Lug..................................................................................................49
PoE Dimensions...........................................................................................49
5.1.2 AC-DC PoE.....................................................................................................50
5.2 Ethernet Surge Protection Device ..................................................................52
Ethernet Port................................................................................................52
Surge Arrestor Dimensions ..........................................................................52
LIST OF FIGURES
Figure 1: Notice: WEEE Logo........................................................................................12
Figure 2: Features: Redline System Components .........................................................14
Figure 3: Features: Edge Features................................................................................15
Figure 4: Features: Edge PoE Connector Pinout...........................................................15
Figure 5: Features: Ethernet Port - Metal Weatherproof Connector Assembly...............16
Figure 6: Features: Edge Wireless Terminal Dimensions ..............................................17
Figure 7: Site Survey: RF Planning Fresnel Zone..........................................................19
Figure 8: Site Survey: Edge Antenna Position...............................................................21
Figure 9: Site Survey: System Layout Options...............................................................22
Figure 10: Site Survey: Site Preparation........................................................................23
Figure 11: Site Survey: System Grounding....................................................................24
Figure 12: Site Survey: Cabinet Equipment...................................................................25
Figure 13: Site Survey: Edge Lead-In Ethernet Cable ...................................................26
Figure 14: Site Survey: Network Connection Ethernet Cable.........................................27
Figure 15: Site Survey: Power Wiring............................................................................28
Figure 16: Installation: Edge System Completed Installation .........................................30
Figure 17: Installation: Basic Wiring Configuration for Web/Telnet Access....................32
Figure 18: Installation: Configuration - Login Screen .....................................................33
Figure 19: Installation: Configuration - Product Options Screen.....................................34
Figure 20: Installation: Ethernet Port Gland Assembly...................................................36
Figure 21: Installation: Ethernet/Antenna Port Weatherproofing Procedure...................38

Edge INSTALLATION GUIDELINES
70-00204-01-01 Proprietary Redline Communications © 2015 Page 7 of 56 May 19, 2015
Figure 22: Installation: Mounting Kit - Assemble Bracket Arm........................................39
Figure 23: Installation: Mounting Kit - Attach Arm to Edge.............................................39
Figure 24: Installation: Mounting Kit - Alternative Mounting Methods.............................40
Figure 25: Installation: Mounting Kit - Flat-to-Wall Dimensions......................................40
Figure 26: Installation: Cable Connection and Weatherproofing ....................................42
Figure 27: Installation: Subscriber Link Status Screen...................................................44
Figure 28: Installation: Antenna Alignment Tool Screen ................................................45
Figure 29: Installation: Subscriber Links Summary Screen............................................45
Figure 30: Reference: DC-DC PoE Features.................................................................47
Figure 31: Reference: POE ETH Port Pin Assignment ..................................................47
Figure 32: Reference: DC-DC PoE Power Terminal Block.............................................48
Figure 33: Reference: DC-DC PoE Ground Lug............................................................49
Figure 34: Reference: DC-DC PoE Mounting Dimensions.............................................49
Figure 35: Reference: AC-DC PoE - Indoor Power Module Pinout ................................50
Figure 36: Reference: AC-DC PoE Mounting Dimensions.............................................51
Figure 37: Reference: Ethernet Line Protection Device .................................................52
Figure 38: Reference: Ethernet Line Protection Device Dimensions..............................52
Figure 39: Reference: Ethernet Line Protection Device - Pole Mount............................53
Figure 40: Reference: Ethernet Line Protection Device Dimensions - Pole Mount.........53
Figure 41: Reference: Redline 2 ft Parabolic Antenna Mounting Dimensions ................54
Figure 42: Reference: Redline 3 ft Parabolic Antenna Mounting Dimensions ................54
Figure 43: Reference: Redline 4 ft Parabolic Antenna Mounting Dimensions ................55
LIST OF TABLES
Table 1: Notice: Electrical Safety Specifications............................................................11
Table 2: Avis: Spécifications de sécurité électrique .......................................................11
Table 3: Features: Redline System Components...........................................................14
Table 4: Features: Polarization of Wireless Terminals with Integrated AntennaError! Bookmark not defined.
Table 5: Features: Ethernet Port RJ-45 Pinout (T568B) ................................................15
Table 6: Site Survey: General Information Settings .......................................................20
Table 7: Site Survey: Network & Syslog Server Settings ...............................................20
Table 8: Site Survey: Radio Management Settings........................................................20
Table 9: Site Survey: Path Profile Data..........................................................................20
Table 10: Site Survey: Operating Temperature Range..................................................25
Table 11: Site Survey: Power Requirements.................................................................28
Table 12: Installation: Installer Supplied Materials.........................................................31
Table 13: Installation: Operation with No Options Key...................................................34
Table 14: Installation: Edge Parameter Settings............................................................35
Table 15: Reference: Pinout for POE and ETH Ports ....................................................48
Table 16: Reference: DC-DC PoE LED Indicators.........................................................48
Table 17: Reference: DC-DC PoE Power Connections .................................................48

Edge INSTALLATION GUIDELINES
70-00204-01-01 Proprietary Redline Communications © 2015 Page 8 of 56 May 19, 2015
1 Important Notices
1.1 Deployment Information
IMPORTANT: Refer to the RDL-3000 Family User Manual for detailed regulatory
information. Refer to this document before deploying and powering RDL-3000 family
systems in the field.
1.2 Service & Safety
General Warnings
Redline recommendations for maximum safety include the following:
Do not operate microwave equipment without first having proper training or
knowledge of microwave radio operation.
Do not operate the microwave equipment without an appropriate antenna port
termination, or antenna.
Check to ensure that the area around the antenna is clear of personnel prior to
turning the transmitter on.
Do not look into or stand in front of an antenna.
Do not swing or aim an antenna at nearby persons while the equipment is operating.
Where a structure or rooftop has existing antennas installed, do not proceed with an
installation without first determining the RF/µW exposure risk. Where necessary
have the relevant transmitters turned off or wear a protective suit for the duration of
the installation.
Safety Warnings
Installation of the system must be contracted to a professional installer.
PoE power adapter caution:
Warning to Service Personnel:48 VDC
Customer equipment including personal computers, routers, etc., must be connected
only to the INPUT (DATA) port on the PoE unit.
Only the outdoors Ethernet interface cable connecting to the unit can be safely
connected to the OUTPUT (DATA & POWER) connector. Connecting customer
premises Ethernet equipment directly to the OUTPUT (DATA & POWER) connector
on the Power-over-Ethernet power adapter may damage customer equipment.
Read this manual and follow all operating and safety instructions.
Keep all product information for future reference.
The power requirements are indicated on the product-marking label. Do not exceed
the described limits.
The unit must not be located near power lines or other electrical power circuits.
Disconnect the power before cleaning, or when the unit is not be in-use for an
extended period.
Chapter 1

Edge INSTALLATION GUIDELINES
70-00204-01-01 Proprietary Redline Communications © 2015 Page 9 of 56 May 19, 2015
The system must be properly grounded to protect against power surges and
accumulated static electricity. The user is responsible for installing this device in
accordance with the local electrical codes: correct installation procedures for
grounding the unit, mast, lead-in wire and discharge unit, location of discharge unit,
size of grounding conductors and connection requirements for grounding electrodes.
Warning Symbols
These symbols may be encountered during installation or troubleshooting. These
warning symbols mean danger. Bodily injury may result if you are not aware of the safety
hazards involved in working with electrical equipment and radio transmitters. Familiarize
yourself with standard safety practices before continuing.
WARNING
ELECTRO-MAGNETIC
RADIATION
WARNING
HIGH VOLTAGE
WARNING
HOT SURFACE
DO NOT TOUCH
1.3 Installation Safety
Professional Installation / Installations Professionnel
Redline RDL-3000 systems require professional installation. The user is responsible to
ensure all building and safety codes are met and the installation is complete and
secure.
The RDL-3000 system shall be installed according to local Electrical Safety Codes.
For Canadian installations, the entire equipment installation must comply with the
Canadian Electrical Code. For installations in the United States, the entire equipment
installation must be in accordance with Article 810 of the United States National
Electrical Code.
Les appareils RDL-3000 de Redline doivent être installés par un personnel
professionnel. Le personnel responsable doit s’assurer que l’installation est bien
achevée, et qu’elle répond aux exigences de tous les codes de sécurité.
Le RDL-3000 doit être installé conformément aux codes locaux de sécurité électrique.
Pour les installations Canadiennes, l'installation de l'équipement au complet doit se
conformer au Code Canadien de l'électricité. Pour les installations aux États-Unis,
l'installation de l'équipement au complet doit être en conformité avec l'article 810 du
Code des États-Unis National Electrical.
Safety Precautions
Installation and service must be done by personnel having technical training and
experience necessary to be aware of hazards during installation and/or service of
outdoors RF equipment. The installation and/or service must be done using procedures
designed to minimize any danger to technical personnel or any other person.
Use safety devices when working on or around the mast. Be aware of the risk of falling
objects. Use provided safety catches when hoisting antennas and radios.
Do not use any components (screws, nuts, etc.) other than those delivered together with
the Redline microwave radio equipment or those recommended by Redline.

Edge INSTALLATION GUIDELINES
70-00204-01-01 Proprietary Redline Communications © 2015 Page 10 of 56 May 19, 2015
Electrocution Hazard / Risque D’électrocution
Warning to Service Personnel:48 VDC
This product is intended to be connected to a power source as per IEEE 802.3at (42.5
- 57.0 VDC), which must be electrically isolated from any AC sources and reliably
connected to Earth ground. Do not install Redline products near any type of power line.
Should the antenna or related hardware come in contact with power lines, severe bodily
harm or death could result!
Attention au personnel du service: 48V CD
Ce produit est destiné à être connecté à une source d'énergie selon la norme IEEE
802.3at (42,5 à 57,0 VDC), qui doit être isolé électriquement de toutes les sources de
courant alternatif et fiable relié à la masse de la Terre. Ne pas installer les produits
Redline près n'importe quel type de ligne électrique. Si votre antenne ou du matériel
connexe entrer en contact avec des lignes électriques, des blessures graves ou la mort
pourraient en résulter!
Radio Frequency Safety / Sécurité des Fréquences Radio
The installer of this radio equipment must ensure that the antenna is located or pointed
such that the antenna does not emit RF fields in excess of the general population limits
as defined by:
FCC CFR 47, Part 2.1091
http://www.gpo.gov/fdsys/pkg/CFR-2009-title47-vol1/pdf/CFR-2009-title47-vol1-sec2-
1091.pdf
FCC OET Bulletin 65, Radio frequency radiation exposure evaluation for fixed
devices
http://transition.fcc.gov/Bureaus/Engineering_Technology/Documents/bulletins/oet65
/oet65c.pdf
Health Canada limits for the general population; consult Safety Code 6, obtainable
from Health Canada’s website:
http://www.hc-sc.gc.ca/ewh-semt/pubs/radiation/radio_guide-lignes_direct-eng.php
Santé Canada limite pour la population générale; consulter le Code de sécurité 6,
disponible sur le site Web de Santé Canada:
http://www.hc-sc.gc.ca/ewh-semt/pubs/radiation/radio_guide-lignes_direct-fra.php .
Personal Safety
WARNING: HOT SURFACE. DO NOT TOUCH.
The radio platform is rated for operation at extreme ambient temperatures. When
operating in high temperature conditions, the chassis surface area can be higher than
the ambient temperature and personal thermal protection should be employed for any
maintenance or inspection activity.
Electrical Safety
The equipment meets the requirements for class I EN 60950-1 (protection against
electric shock).
All external circuits are TNV-1 (as defined in EN 60950-1).

Edge INSTALLATION GUIDELINES
70-00204-01-01 Proprietary Redline Communications © 2015 Page 11 of 56 May 19, 2015
All equipment must be grounded before the power cable is connected.
For electrical safety the DC power supply shall have reinforced insulation to the
mains supply.
Electrical Safety Compliance / Conformité à la Sécurité Electrique
The RDL-3000 system hardware has been tested for compliance to the electrical safety
specifications listed in the following table.
Table 1: Notice: Electrical Safety Specifications
Class I
EN 60950-1
All External Circuits
TNV-1 as defined in EN 60950-1
All equipment must be grounded
Le RDL-3000 du matériel a été testé pour la conformité aux normes de sécurité
électriques indiquées dans le tableau suivant:
Table 2: Avis: Spécifications de sécurité électrique
Classe I
EN 60950-1
Tous les circuits externes
TRT-1 tel que défini dans la norme EN
60950-1
Tous les équipements doivent être mis à la terre
UL Information
The suitability of the supplied Ethernet cable is subject to the approval of Authority
Having Jurisdiction and must comply with the local electrical code.
The equipment must be properly grounded according with NEC and other local
safety code and building code requirements.
Reminder to all the BWA system installers: Attention to Section 820-40 of the NEC
which provides guidelines for proper grounding and, in particular, specifies that the
cable ground shall be connected to the grounding system of the building, as close to
the point of cable entry as is practical.
RDL-3000 system must be installed in compliance with relevant articles in National
Electrical Code-NEC (and equivalent Canadian Code-CEC) including referenced
articles 725, 800 and 810 in NEC.
RF coaxial cable connecting an antenna to the RDL-3000 system must comply with
the local electrical code.
To meet the over-voltage safety requirements on the telecommunications cables, a
minimum 26 AWG telecommunication line cord must be used.
Pour être en conformance avec les exigences finies de sûreté de sur-tension sur les
câbles de télécommunications un fil de télécommunication ayant un calibre minimum
de 26 AWG doit être utilisé.
Lightning Protection / Protection Contre la Foudre
When installed, this equipment is to be connected to a Lightning/Surge Protection
Device that meets all applicable national safety requirements. Before Ethernet cables
enter buildings, voltages shall be clamped down to SELV by approved type primary
protectors.
WARNING: The information provide in this user manual consists of general
recommendations for installation the system equipment. The wireless equipment must
be installed by a qualified professional installer who is knowledgeable of the
requirements of installing outdoor radio equipment and follows local and national codes

Edge INSTALLATION GUIDELINES
70-00204-01-01 Proprietary Redline Communications © 2015 Page 12 of 56 May 19, 2015
for electrical grounding and safety. Failure to meet safety requirements and/or use of
non-standard practices and procedures may result in personal injury and/or damage to
equipment.
The system must be properly grounded to protect against power surges and
accumulated static electricity. The user is responsible to install this device in accordance
with the local electrical codes: correct installation procedures for grounding the unit,
mast, lead-in wire and discharge unit, location of discharge unit, size of grounding
conductors and connection requirements for grounding electrodes.
All outdoor wireless equipment is susceptible to surge damage from a direct hit or
current induced from a near strike. A direct lightning strike may cause serious damage
even if recommended guidelines are followed. Installing surge protection and following
grounding practices detailed in local and national electrical codes can minimize
equipment damage, service outages, and chance of serious injury.
The major reasons for surge damage can be summarized as:
Poorly grounded antenna sites
Improperly installed surge protection equipment
A lighting protection system provides a means by which the energy may enter earth
without passing through and causing damage to parts of a structure. A good grounding
system disperses most of the surge energy from a lightning strike away from the building
and equipment. Improperly grounded connections are a source of noise that can cause
malfunctions in sensitive equipment. The remaining energy on the Ethernet cable shield
and conductors can be directed safely to ground by installing a surge arrestor in series
with the cable. A surge protection system does not prevent lightning strikes, but protects
equipment by providing a low resistance path for the discharge of energy safely to
ground. If surge protection is required for the system, the following general industry
practices are provided as a guideline only:
The AC wall outlet ground for the indoor POE adapter should be connected to the
building grounding system.
Install a surge arrestor in series with the Ethernet cable at the point of entry to the
building. The grounding wire should be connected to the same termination point
used for the tower or mast.
Provide direct grounding connections from the RDL-3000 system, the mounting
bracket, and the antenna to the common building ground bus. Use the grounding
screws provided for terminating the ground wires.
L’installation exige aussi que l’appareil soit branché à un parafoudre qui répond à
toutes les normes nationales de sécurité.
1.4 WEEE Product Return Process
In accordance with the WEEE (Waste from Electrical and Electronic Equipment)
directive, 2002/96/EC, Redline Communications equipment is marked with the logo
shown below. The WEEE directive seeks to increase recycling and re-use of electrical
and electronic equipment. This symbol indicates that this product should not be disposed
of as part of the local municipal waste program. Contact the local sales representative
for additional information.
Figure 1: Notice: WEEE Logo

Edge INSTALLATION GUIDELINES
70-00204-01-01 Proprietary Redline Communications © 2015 Page 13 of 56 May 19, 2015
1.5 Service & Warranty Information
Refer all repairs to qualified Service personnel. Removing the cover panel or
modifying any part of this device will void the factory warranty.
Locate the serial numbers and record these for future reference. Use the space
below to affix serial number stickers. Also, record the MAC address identified on the
unit product label.
Redline does not endorse or support the use of outdoor cable assemblies: i) not
supplied by Redline, ii) third-party products that do not meet Redline's cable and
connector assembly specifications, or iii) cables not installed and weatherproofed as
specified in the RDL-3000 Installation Guidelines manual for each product model.
Refer to the Redline Limited Standard Warranty and RedCare Service agreements.
WEEE Product Return Process
In accordance with the WEEE (Waste from Electrical and Electronic Equipment)
directive, 2002/96/EC, Redline Communications equipment is marked with the logo
shown above. The WEEE directive seeks to increase recycling and re-use of
electrical and electronic equipment. This symbol indicates that this product should
not be disposed of as part of the local municipal waste program. Contact the local
sales representative for additional information.

Edge INSTALLATION GUIDELINES
70-00204-01-01 Proprietary Redline Communications © 2015 Page 14 of 56 May 19, 2015
2 System Features
2.1 System Components
The RDL-3000 Edge wireless terminal (subscriber) is designed and manufactured by
Redline Communications, a world leader in design and production of outdoor wireless
TCP/IP transport for mission critical applications.
Figure 2: Features: Redline System Components
Table 3: Features: Redline System Components
#
Description
1
RDL-3000 Edge wireless terminal (subscriber).
2
Lightweight mounting kit includes the mounting bracket with assembly hardware. Fits 25-
105 mm (1.0-4.25 in) mast pipe or mounts on a flat surface. RF jumper cables (N-type
connectors, 50 Ohm) are included with each mounting kit.
3
Subscriber antenna (narrow beamwidth).
4
Ethernet cable line protection (LP) unit.
5
Cat-5e shielded outdoor Ethernet cable terminated with RJ-45 connector each end.
Connection from Edge to PoE plus PoE to local area network 91 m (300 ft) max.
6
AC: single AC 110/220 VAC auto-detect
DC: single DC 20-60 VDC auto detect
7
The PoE power cord must be ordered separately (AC PoE only). Cords are available
terminated as NA, EU, or UK type.
Note: All items must be specified individually as part of each system order.
Chapter 2

Edge INSTALLATION GUIDELINES
70-00204-01-01 Proprietary Redline Communications © 2015 Page 15 of 56 May 19, 2015
2.2 Edge Wireless Terminal
The Edge wireless terminal provides the Ethernet and wireless interfaces necessary to
provide secure reliable data transport.
Figure 3: Features: Edge Features
RF Ports
The two RF ports (N-type F connectors) conduct RF signals between the Edge and the
antenna system (ordered separately). The Edge can be operated using a SISO (single
antenna) or MIMO (multiple antenna) system. RF jumper cables are included with
Redline mounting kits.
Ethernet Port
The Ethernet port (RJ-45 / F connector) receives DC power and provides Ethernet
connectivity with the local network. The Ethernet port connects to the PoE adapter using
a weatherproof CAT-5e Ethernet cable.
Figure 4:Features: Edge PoE Connector Pinout
Table 4: Features: Ethernet Port RJ-45 Pinout (T568B)
Pin
Description
1, 2
Data Pair 1
3, 6
Data Pair 2
4, 5
+Ve (in)
7, 8
-Ve (in)

Edge INSTALLATION GUIDELINES
70-00204-01-01 Proprietary Redline Communications © 2015 Page 16 of 56 May 19, 2015
Notes:
1. The PoE does not amplify the Ethernet signal. The maximum total length of the
Ethernet cable is 100 m (330 ft). For example, 91 m (~300 ft) from the Edge to
the PoE and 9 m (~30 ft) from the PoE to the local network equipment.
2. PoE Interoperability: Type 2: 30 W over two pairs, Alternative B: Pairs 4/5 & 7/8
2.3 Ethernet Port Weatherproof Gland
A weatherproof gland is provided for the Edge Ethernet port. The Edge Ethernet port
must have this gland installed and properly weatherproofed.
Figure 5: Features: Ethernet Port - Metal Weatherproof Connector Assembly
Ground Lug
A ground-lug is provided on the Edge chassis. Use this connection to terminate a
grounding wire. All Edge systems must be properly grounded to protect against power
surges and accumulated static electricity.
Edge Dimensions
The Edge dimensions are: 307 x 245 x 60 mm (12.1 x 9.65 x 2.3 in).

Edge INSTALLATION GUIDELINES
70-00204-01-01 Proprietary Redline Communications © 2015 Page 17 of 56 May 19, 2015
Figure 6: Features: Edge Wireless Terminal Dimensions

Edge INSTALLATION GUIDELINES
70-00204-01-01 Proprietary Redline Communications © 2015 Page 18 of 56 May 19, 2015
2.4 Configuration and Management
The following methods are available to monitor and configure the Edge system.
ClearView NMS Application
The Edge can be configured and monitored using the SNMP-based Redline ClearView
NMS. The Redline Management Suite is a set of applications designed to assist
provisioning, monitoring and administration of the Redline components deployed in
Radio Access Networks (RANs). Contact your Redline representative or visit the Redline
website for further information about the Redline ClearView NMS application.
Telnet (CLI)
Use a standard Telnet client to access all settings and statistics necessary to configure
and monitor the operation of the Edge. Use the following steps to monitor and configure
the Edge.
Using CLI, open a Telnet session to the unit IP address.
When the command prompt screen appears, login to the Edge. The factory default
credentials are:
username: admin
password: admin
The Telnet session is logged out automatically when no commands are received (idle)
for a period of ten minutes. Use the following command to exit immediately from the CLI:
logout [ENTER]
The Edge supports two concurrent Telnet sessions. The first admin session opened has
full read/write capabilities. If a second session is opened, it has read-only access.
Web Browser (HTTP)
Use a standard Web browser to access all settings and statistics necessary to configure
and monitor the operation of the Edge. To monitor and configure the Edge using HTTP,
open a Web browser (Internet Explorer 6 or higher recommended) and enter the unit IP
address. For new systems, the default IP address is 192.168.25.2. The following login
dialog should be displayed:
The default username is 'admin' and the default password is 'admin'. There is no logout
command on the Web interface.

Edge INSTALLATION GUIDELINES
70-00204-01-01 Proprietary Redline Communications © 2015 Page 19 of 56 May 19, 2015
3 Site Survey
It is recommended to perform a site survey before installing the Edge system. The data
accumulated during this process is necessary to understand the operating
characteristics and obtain the best performance from the wireless system.
The site survey should identify the optimum location for mounting the wireless terminal.
For maximum performance, there should be a direct line of sight between all
communicating wireless systems. A clear line-of-sight (LOS) path requires clearance
above natural and man-made objects by at least 60% of the First Fresnel zone. Each
antenna should be positioned to provide maximum clearance in the first Fresnel zone of
the direct signal path.
Figure 7: Site Survey: RF Planning Fresnel Zone
The wireless terminal also functions under optical line-of-sight (OLOS) conditions; where
a clear straight line path exists between the two end points, but the first Fresnel zone is
not clear of obstacles. If the optical path is completely blocked, it may be possible to
establish a non line-of-sight (NLOS) path using RF signal reflections, such as a common
reflective structure (e.g., large building) that is LOS for the antennas of communicating
units.
For best results:
-Mount the antenna in a location that provides an unobstructed view of the horizon.
-Avoid mounting the antenna close to metal objects that may block/reflect the signal.
-To minimize susceptibility to radio interference, the antenna should generally be
located at least 1 m (~3.25 ft) away from any another high frequency system
antennas (e.g., microwave, GSM, CDMA, 3G) and should not be mounted within the
main beamwidth of any active (radiating) antenna system.
Chapter 3

Edge INSTALLATION GUIDELINES
70-00204-01-01 Proprietary Redline Communications © 2015 Page 20 of 56 May 19, 2015
3.1 General Information
The General Information fields uniquely identify each installed system. It is
recommended to record this information prior to installation.
Table 5: Site Survey: General Information Settings
Setting
Radio Management
Name
Details
Location
Contact
3.2 Network Settings
The Edge must be assigned a unique IP addresses before it is connected to the base
station and the local area network (LAN). When DHCP is enabled, the remaining
settings are populated automatically by the DHCP server.
Table 6: Site Survey: Network & Syslog Server Settings
Setting
Radio Management
DHCP Enable
IP Address
Subnet Mask
Default Gateway Address
Ethernet Mode
3.3 Radio Management Settings
The following table contains the minimum set of parameters required to configure the
wireless interface.
Table 7: Site Survey: Radio Management Settings
Parameter
Value
System Name
TCP/IP Address
Channel Size
RF Freq.
Tx Power
Antenna Gain (DFS only)
Path Profile
The path profile should include the following information:
Table 8: Site Survey: Path Profile Data
Site Location
Antenna Height
Antenna Azimuth
Antenna Elevation
Expected RSSI
