Redmi Buds 3 Lite User manual

Redmi Buds 3 Lite
User Manual

Connect the charging cable to the charging case and keep the
earbuds inside the case to charge simultaneously.
When the charging case is not fully charged, its indicator is white.
When it is fully charged, its indicator is o.
Product Overview
Illustrations of product, accessories, and user interface in the user manual
are for reference purposes only. The actual product and functions may
vary due to product enhancements.
EarbudsCharging Case
Charging
Indicator
Charging
Port Charging
Contact Points
Indicator
Multi-function
Touch Area
Read this manual carefully before use, and retain it for future reference.
Charging
Before use, please remove the protective film from the contact points
on both earbuds and fully charge the charging case and the buds.
Microphone
Protective Film
Ear hook (install
with the leer
facing downwards)

Turning On
Turning O
Make sure the charging case is not out of baery. Place both
earbuds in the charging case and the indicators on them will turn
white. The earbuds will automatically disconnect and start charging,
and turn o once being fully charged.
When the earbuds enter the pairing state and are out of the
charging case, they will be automatically turned o if not
connecting to any device within 10 minutes.
Wearing
Gently place the earbud into your ear canal, then adjust it to a
comfortable position.
During calls, make sure to point the primary microphone towards
your mouth for clearer calls.
Note: The M-size ear tips and L-size ear hooks are pre-installed on
the earbuds. If they are not suitable, please replace them with a
proper size.
Make sure the charging case is not out of baery with earbuds in it.
The earbuds will automatically turn on when removed from the
charging case.

Connection
First time connection
Open the lid and take out the earbuds. When the indicators on
both earbuds slowly blink white, it means the earbuds can be
connected. Enable the Bluetooth function on your phone, and then
search and tap "Redmi Buds 3 Lite" to connect the earbuds.
Connecting to other devices
Disable the Bluetooth connection of the paired phone or reset the
earbuds to connect to other devices.
Reset Earbuds
If the earbuds cannot connect properly, please carry out the
following steps to reset them. Make sure the charging case is not out
of baery before reset. Open the lid of the charging case and place
both earbuds in the case. Press and hold the multi-function touch
areas on both earbuds for at least five seconds and then release.
Indicators on both earbuds will blink white three times, indicating the
earbuds have been reset successfully. (The connection records
between the le and right earbuds, and the earbuds and the phone
have been cleared.)
Note: If the earbuds cannot be connected, place them back into the
charging case, close the lid and repeat the above operation.
Press and hold both earbuds for 5 secondssimultaneously

Function Overview
Answer/End calls
Double tap the le/right earbud's multi-function touch area to answer
a call; and tap the le/right earbud's multi-function touch area three
times to decline or hang up the call.
Play/Pause music
Press and hold the le/right earbud's multi-function touch area to
pause/play the audio.
Play next track
When playing audio, double tap the earbud's multi-function touch
area to play the next track.
Answer a second call
Double-tap the le/right earbud's multi-function touch area to put
the ongoing call on hold and answer the incoming call. Aer
answering the second incoming call, double-tap the multi-function
touch area to switch between the two calls. And tap the le/right
earbud's multi-function touch area three times to hang up the
current call and answer the call on hold.
Multi-function Touch Area

Wake up the phone's voice assistant
When wearing the earbuds (not during a call), tap the multi-func-
tion touch area three times to wake up the voice assistant.*
* The device connected to the earbuds needs to support the
voice assistant function.
Switch between single/dual bud mode
When both buds are connected successfully, they are in dual-bud
mode. If place one of the buds back into the charging case and close
its lid, the other bud will automatically enter the single-bud mode.
When removing the second bud from the charging case, the
dual-bud mode will automatically be restored again.
Once the earbuds are taken out of the charging case, they will
automatically connect to the most recently used Bluetooth device. If
the earbuds are not connected to any device, they will automatically
enter the awaiting connection mode.
Automatic connection
When the device's Bluetooth is disabled or when it manually
disconnects from the earbuds, the earbuds will automatically enter
the awaiting connection state. If no device is connected within 10
minutes, the earbuds will turn o automatically.
Disconnected

Note: Once the weather is cold outdoors and your hands become dry,
the buds may not function when touching them.
When the earbuds are connected to the phone (not during a call),
simultaneously press and hold the multi-function touch areas of
the le and the right earbuds to enable the low latency mode. Once
the low latency mode is enabled, simultaneously press and hold the
multi-function touch areas of the le and the right earbuds or put
both earbuds into the charging case to disable the low latency
mode.
Low latency mode

Specifications
Name: Wireless Earphones
Model: M2110E1
Frequency Band: 2402–2480 MHz
Max RF Output Power: < 20 mW
Earbuds
Dimensions: 24.5 × 16.7 × 24.6 mm
Wireless Range: 10 m (in an obstacle-free environment)
Input: 5 V
= 50 mA
Wireless Connectivity: Bluetooth® 5.2
Charging Case
Model: M2110E1
Dimensions: 60 × 46 × 23.7 mm
Input: 5 V
= 300 mA
Output: 5 V
= 150 mA
Storage Temperature: 0 °C to 45 °C
Operating Temperature: 0 °C to 45 °C
Service Life: 1 year

Important Safety Information
The product has a built-in baery that can not be removed or
replaced. To avoid damage to the baery or the product, do not
disassemble or modify the baery by yourself. The baery can only
be replaced by the authorized service providers and must be
replaced with the same type. Replacement of a baery with an
incorrect type may defeat a safeguard (such as catching fire,
explosion and leakage of corrosive electrolyte). Do not dispose of
used baeries with household waste. Disposal of this product and
the used baeries shall comply with local laws and regulations.
Do not aempt to disassemble, repair or modify the product, as
this may cause fire or even completely damage the product.
Keep the product's indicator away from the eyes of children and
animals while the product is in use.
Do not disassemble, puncture or crush the product nor expose it
to fire.
Please stop using the product immediately and seek medical
assistance if the contact area on your skin shows signs of redness
or swelling.
To prevent possible hearing loss, do not use high volume for
long periods of time.
This product is not a toy and may contain small parts. Please keep
them out of the reach of children.
Disposal of a baery into fire or a hot oven or water or other
liquids or mechanically crushing or cuing of a baery, that can
result in an explosion.
Leaving a baery in an extremely high temperature surrounding
environment that can result in an explosion or the leakage of
flammable liquid or gas.
A baery subjected to extremely low air pressure that may
result in an explosion or the leakage of flammable liquid or gas.
Product information and certification marks are located in the
Charging Case.
= The symbol indicates DC voltage.
The Bluetooth® word mark and logos are registered trademarks
owned by Bluetooth SIG, Inc. and any use of such marks by Xiaomi
Inc. is under license. Other trademarks and trade names are those
of their respective owners.

Hereby, Dongguan Yingsheng Electronic Technology Co., Ltd.
declares that the radio equipment type M2110E1 is in compliance
with Radio Equipment Regulations 2017. The full text of the UKCA
declaration of conformity is available at the following internet
address: hps://www.mi.com/uk/service/support/declaration.html
EU DECLARATION OF CONFORMITY
Hereby, Dongguan Yingsheng Electronic Technology Co., Ltd.
declares that the radio equipment type M2110E1 is in compliance with
Directive 2014/53/EU. The full text of the EU declaration of conformity
is available at the following internet address:
hp://www.mi.com/global/service/support/declaration.html
All products bearing this symbol are waste electrical and
electronic equipment (WEEE as in directive 2012/19/EU) which should
not be mixed with unsorted household waste. Instead, you should
protect human health and the environment by handing over your
waste equipment to a designated collection point for the recycling of
waste electrical and electronic equipment, appointed by the
government or local authorities. Correct disposal and recycling will
help prevent potential negative consequences to the environment
and human health. Please contact the installer or local authorities for
more information about the location as well as terms and conditions
of such collection points.
WEEE Information

Complles With
IMDA Standards
DB106135
77150/SDPPI/2021
9003 CIDF15000056
Manufactured for: Xiaomi Communications Co., Ltd.
Manufactured by: Dongguan Yingsheng Electronic Technology Co., Ltd.
(a Mi Ecosystem company)
Address: Suite 204, 4th Block, No. 86 Hongtu Road, Nancheng
District,Dongguan, Guangdong, China.
For further information, please go to www.mi.com
User Manual Version: V1.0
Importer:
Beryko s.r.o.
Na Roudné 1162/76, 301 00 Plzen
www.beryko.cz
