Reed Instruments R9200 User manual

Microwave
Leakage
Detector
Instruction
Manual
R9200
REED Instruments
1-877-849-2127 | [email protected] | www.reedinstruments.com

2
Table of Contents
Introduction ................................................................................................ 2
Product Quality........................................................................................... 2
Safety ......................................................................................................... 3
Features...................................................................................................... 3
Included...................................................................................................... 3
Specications..........................................................................................3-4
Instrument Description ............................................................................... 4
Operating Instructions................................................................................ 5
Microwave Oven Safety Standards............................................................ 5
Battery Replacement.................................................................................. 5
Applications................................................................................................ 6
Accessories and Replacement Parts ......................................................... 6
Product Care .............................................................................................. 6
Product Warranty ....................................................................................... 6
Product Disposal and Recycling ................................................................ 7
Product Support......................................................................................... 7
Introduction
Thank you for purchasing your REED R9200 Microwave Leakage Detector.
Please read the following instructions carefully before using your instrument.
By following the steps outlined in this manual your meter will provide years
of reliable service.
Product Quality
This product has been manufactured in an ISO9001 facility and has been
calibrated during the manufacturing process to meet the stated product
specications.
REED Instruments
1-877-849-2127 | [email protected] | www.reedinstruments.com

3
Safety
Never attempt to repair or modify your instrument. Dismantling your
product, other than for the purpose of replacing batteries, may cause
damage that will not be covered under the manufacturer's warranty.
Servicing should only be provided by an authorized service center.
Features
• Detectsverylowlevelsofmicrowaveleakage
• Quickresponseandhighaccuracy
• Designedforone-handedoperation
• Audible(beep)andvisual(ashingLED)alarmsat5mW/cm2
• 4-digit,backlitLCDdisplay
• Maxholdfunctionandlowbatteryindicator
• Zerobuttonforquickadjustment
Included
• SoftCarryingCase
• Battery
Specifications
MeasuringRange: 0to9.99mW/cm2
Accuracy: ±1mW/cm2
Resolution: 0.01mW/cm2
OperatingFrequency: 2.4GHz
Display: 4-digit LCD
Backlit Display: Yes
Alarm: Audible(buzzer)andVisual(LEDLight)
AlarmLimit: 5mW/cm2
MaxHold: Yes
ZeroButton: Yes
continued...
REED Instruments
1-877-849-2127 | [email protected] | www.reedinstruments.com

4
ResponseTime: 2xpersecond
PowerSupply: 9VBattery
Low Battery Indicator: Yes
Product Certications: CE
OperatingTemperature: 32to122°F(0to50°C)
StorageTemperature: 14to140°F(-10to60°C)
OperatingHumidityRange: 10to90%
Dimensions: 6.3x2.4x1.7"(160x60x42mm)
Weight: 5.3oz(151g)
Instrument Description
1. Sensor
2. Warning/OverIndicator
3. LCD Display
3
4 6
5
4. MaxButton
5. Power Button
6. Backlight/ZeroButton
REED Instruments
1-877-849-2127 | [email protected] | www.reedinstruments.com

5
Operating Instructions
1. Turn the meter on by pressing the POWER button.
2. Whilepoweringon,thewarning/overalarmwillbeepand
blink simultaneously.
3. Upon start up, hold the /ZERO buttontoperformazeroadjustment.
4. The LCD will now display a measurement value of 0.00
5. Totakeameasurement,placethemeter2"fromthedoorsealsor
the front glass of the microwave.
6. Press the MAXbuttontothedisplaytheMaximumvalueduringthe
measurement process.
7. To turn the meter off, press the POWER button.
Microwave Oven Safety Standards
IntheU.S.,checkwithTheFoodandDrugAdministration(FDA),while
inCanada,checkwithHealthCanadaformicrowaveovensafety
standardswithregardtoleakagerequirements.TheFDA'slastupdate
in2017limitstheamountofmicrowaveleakageto5milliwatts(mW)of
microwaveradiationpersquarecentimeteratapproximately2inches
from the oven surface. This limit is far below the level known to harm
people. Microwave energy also decreases dramatically as you move
away from the source of radiation. Be sure to be up to date in regards
to the current standards and regulations for the appropriate country
before using this device. REED Instruments will not be held
responsibleforanydamagetotheequipmentorpersonalinjuryin
regards to the use of this meter or in the correct interpretation of the
appropriate safety standards. The user assumes full safety
responsibility at all times.
Battery Replacement
When the low battery icon appears on the LCD display, you will need to
replace the batteries. Remove the battery cover using a Phillips head
screwdriver,insertanew9Vbatteryandsecurethecover.
REED Instruments
1-877-849-2127 | [email protected] | www.reedinstruments.com

6
Applications
• Verifyingleakageonmicrowaveoven
Accessories and Replacement Parts
CA-52A Soft Carrying Case
Don't see your part listed here? For a complete list of all accessories and
replacement parts visit your product page on www.reedinstruments.com.
Product Care
To keep your instrument in good working order we recommend the following:
• Storeyourproductinaclean,dryplace.
• Changethebatteryasneeded.
• Ifyourinstrumentisn'tbeingusedforaperiodofonemonthorlonger
please remove the battery.
• Cleanyourproductandaccessorieswithbiodegradablecleaner.Donot
spraythecleanerdirectlyontheinstrument.Useonexternalpartsonly.
Product Warranty
REED Instruments guarantees this instrument to be free of defects in
materialorworkmanshipforaperiodofone(1)yearfromdateofshipment.
During the warranty period, REED Instruments will repair or replace, at no
charge, products or parts of a product that proves to be defective because
of improper material or workmanship, under normal use and maintenance.
REED Instruments total liability is limited to repair or replacement of the
product. REED Instruments shall not be liable for damages to goods,
property, or persons due to improper use or through attempts to utilize the
instrumentunderconditionswhichexceedthedesignedcapabilities.In
order to begin the warranty service process, please contact us by phone at
1-877-849-2127 or by email at [email protected] to discuss the
claim and determine the appropriate steps to process the warranty.
REED Instruments
1-877-849-2127 | [email protected] | www.reedinstruments.com

7
Product Disposal and Recycling
Please follow local laws and regulations when disposing or recycling your
instrument. Your product contains electronic components and must be
disposed of separately from standard waste products.
Product Support
Ifyouhaveanyquestionsonyourproduct,pleasecontactyourauthorized
REED distributor or REED Instruments Customer Service by phone at
1-877-849-2127 or by email at [email protected].
Please visit www.REEDINSTRUMENTS.com for the most
up-to-date manuals, datasheets, product guides and software.
Product specifications subject to change without notice.
All rights reserved. Any unauthorized copying or reproduction of
this manual is strictly prohibited without prior written permission
from REED Instruments.
