Reed Instruments R6013-NIST User manual

Pocket Size
Moisture
Detector
Instruction
Manual
R6013
www. .com [e-mail]1.800.561.8187

2
Table of Contents
Introduction ................................................................................................ 3
Product Quality........................................................................................... 3
Safety ......................................................................................................... 3
Features...................................................................................................... 3
Specications............................................................................................. 4
Included...................................................................................................... 4
Display Description .................................................................................... 4
Operating Instructions.............................................................................5-6
Getting Started ...................................................................................... 5
Changing the Electrodes (Pins) ............................................................. 5
Built-in Measurement Verification.......................................................5-6
Built-in Battery Check ........................................................................... 6
Battery Replacement.................................................................................. 6
Auto Power OFF......................................................................................... 7
Applications................................................................................................ 7
Accessories and Replacement Parts ......................................................... 7
Product Care .............................................................................................. 7
Product Warranty ....................................................................................7-8
Product Disposal and Recycling ................................................................ 8
Product Support......................................................................................... 8
www. .com [e-mail]1.800.561.8187

3
Introduction
Thank you for purchasing your REED R6013 Pocket Size Moisture
Detector. Please read the following instructions carefully before using your
instrument. By following the steps outlined in this manual your detector
will provide years of reliable service.
Product Quality
This product has been manufactured in an ISO9001 facility and has been
calibrated during the manufacturing process to meet stated product
specications. If a certicate of calibration is required please contact the
nearest authorized REED distributor or authorized Service Center. Please
note an additional fee for this service will apply.
Safety
Never attempt to repair or modify your instrument. Dismantling your
product, other than for the purpose of replacing batteries, may cause
damage that will not be covered under the manufacturer’s warranty.
Servicing should only be provided by an authorized service center.
Features
• Measureswoodandbuildingmaterialmoisture
• Detectsmoistureinsawntimber,sheetrock,cardboard,plaster,
concrete and mortar
• Compactsizewithbeltclip
• Durableimpact-proofplastichousing
• Built-inmeasurementvericationandbatterycheck
• Replaceablepins
• Lowbatteryindicatorandautoshut-off
www. .com [e-mail]1.800.561.8187

4
Specifications
Measuring Ranges: Wood: 6 to 44% Moisture Content
Materials: 0.2 to 2.0% Moisture Content
Accuracy: Wood: ±1%
Materials: ±0.05%
Resolution: Wood: 1%
Materials: 0.1%
Sensor Type: Contact Pins
Display: LCD(Bargraph)
Replaceable Pins: Yes
AutoShut-off: Yes(after15mins)
LowBatteryIndicator: Yes
Power Supply: 3 CR2032 batteries
Product Certications: CE
OperatingTemperature: 32to104°F(0to40°C)
StorageTemperature: 14to140°F(-10to60°C)
Operating Humidity Range: 0 to 85%
Dimensions: 5.1x1.6x1"(130x40x25mm)
Weight: 3.5oz(100g)
Included
• ProtectiveCap
• Batteries
Display Description
TheLCDdisplaystwoscales:
1. Thewoodscale( )indicateswoodmoisturefrom6to44%.
2. Thebuildingmaterialsscale( )indicatesmoisturecontentfrom
0.2 to 2.0%.
www. .com [e-mail]1.800.561.8187

5
Operating Instructions
Getting Started
1. Remove the protective cap to expose the electrodes.
2. The meter automatically switches ON when the cap is removed.
3. Secure the cap on the bottom side of the meter.
4. Press the measuring electrodes as far as possible into the material.
5. Read the measurement values on the display.
6. Once testing is nished, re-attach the cap and the instrument will
automatically power off.
Changing the Electrodes (Pins)
In order to replace your electrode pins, follow steps 1 through 7 below:
1. Using a Phillips-head screwdriver remove the 5 screws on the back
of the instrument.
2. Remove the battery compartment to expose the batteries.
3. Remove the batteries.
4. Remove the housing lid.
5. Using a Phillips-head screwdriver remove the 4 screws located at the
top of the electronic plate.
6. Remove and replace the electrode pins.
7. Reinstall the electronic plate, housing lid, batteries and
battery compartment.
Built-in Measurement Verification
Makecontactwithtestpins1and2(asshownbelow)whicharelocated
on the top of the protective cap.
continued...
T
B
1
3 4
2
www. .com [e-mail]1.800.561.8187

6
During the verication process, the meter should measure as follows:
1. Wood: 27% ±2%
2. Building Materials: 1.25% ±0.1%
If during the verication process the meter does not read within these
parameters, your instrument should be sent in for servicing.
Built-in Battery Check
Makecontactwithtestpins3and4(asshownbelow)whicharelocated
on the top of the protective cap.
During the verication process, the meter should measure as follows:
1. Wood: >44%
2. BuildingMaterials:>2.05%(Displayhastobefull)
If during the battery check process the meter does not read within these
parameters, the batteries will need to be replaced.
Battery Replacement
If the instrument does not automatically turn on when the protective cap
isremoved,theLCDdisplaysthe , or the Battery Check fails, the
batteries should be replaced as follows:
1. Remove the Phillips head screw on the battery compartment located
on the back of the meter.
2. Remove the batteries.
3. Installthree(3)newCR-20323Vbatteries.
4. Secure the battery compartment with the Phillips head screw.
T
B
1
3 4
2
www. .com [e-mail]1.800.561.8187

7
Auto Power OFF
In order to conserve battery life, the meter will automatically turn off after
approximately 15 minutes. To turn the meter back on press and release
the yellow cutoff switch located between the electrodes. Always secure
the protective cap when the instrument is not in use.
Applications
• ConstructionandBuildingProjects
• RemediationandRestoration
• Woodworking
Accessories and Replacement Parts
R6013-P Replacement Pin
Don't see your part listed here? For a complete list of all accessories and
replacement parts visit your product page on www.reedinstruments.com.
Product Care
To keep your instrument in good working order we recommend the following:
• Storeyourproductinaclean,dryplace.
• Changethebatteryasneeded.
• Ifyourinstrumentisn’tbeingusedforaperiodofonemonthorlonger
please remove the battery.
• Cleanyourproductandaccessorieswithbiodegradablecleaner.Donot
spray the cleaner directly on the instrument. Use on external parts only.
www. .com [e-mail]1.800.561.8187

8
Product Warranty
REED Instruments guarantees this instrument to be free of defects
inmaterialorworkmanshipforaperiodofone(1)yearfromdateof
shipment. During the warranty period, REED Instruments will repair or
replace, at no charge, products or parts of a product that proves to be
defective because of improper material or workmanship, under normal
use and maintenance. REED Instruments total liability is limited to repair
or replacement of the product. REED Instruments shall not be liable for
damages to goods, property, or persons due to improper use or through
attempts to utilize the instrument under conditions which exceed the
designed capabilities. In order to begin the warranty service process,
please contact us by phone at 1-877-849-2127 or by email at
[email protected] to discuss the claim and determine the appro-
priate steps to process the warranty.
Product Disposal and Recycling
Please follow local laws and regulations when disposing or recycling your
instrument. Your product contains electronic components and must be
disposed of separately from standard waste products.
Product Support
If you have any questions on your product, please contact your authorized
REED distributor or REED Instruments Customer Service by phone at
1-877-849-2127 or by email at [email protected].
Please visit www.REEDINSTRUMENTS.com for the most
up-to-date manuals, datasheets, product guides and software.
Product specifications subject to change without notice.
All rights reserved. Any unauthorized copying or reproduction of
this manual is strictly prohibited without prior written permission
from REED Instruments.
