Reed Manufacturing SC59 User manual

1. Place cutter on ground with pressure screw facing up and fully extend the chain
underneath the pipe.
2. Fully open chain jaws by turning the pressure screw counter-clockwise until it stops.
3. Wrap chain around pipe and connect the closest link to the upper jaw.
Check to ensure that the excess chain comes out the top of the hooks and
into the clear.
5. Apply enough pressure to handle to mark pipe. Rotate pipe slightly and mark
again until you have a series of marks to form a line around the pipe.
(If you are cutting pipe that is held solid, it will be easier to apply pressure
and rotate the cutter back and forth to form a line.)
6. Stand on one handle and exert down pressure on the other to finish the cut.
SC59 Soil Pipe Cutter
Operating Instructions
Warning: The high pressure exerted by cutter
can cause cut piece to fly with great force.
Reed Manufacturing Company
1425 West 8th St. Erie, PA 16512-1321 800-666-3691 or 814-452-3691 www.reedmfgco.com
REED MFG.CO.
ERIE PA. U.S.A.
REED MFG. CO. ERIE U.S.A.
4. Tighten pressure screw until handle ends are about 45°apart.
1209-50348
Pressure
Screw
1. Place cutter on ground with pressure screw facing up and fully extend the chain
underneath the pipe.
2. Fully open chain jaws by turning the pressure screw counter-clockwise until it stops.
3. Wrap chain around pipe and connect the closest link to the upper jaw.
Check to ensure that the excess chain comes out the top of the hooks and
into the clear.
5. Apply enough pressure to handle to mark pipe. Rotate pipe slightly and mark
again until you have a series of marks to form a line around the pipe.
(If you are cutting pipe that is held solid, it will be easier to apply pressure
and rotate the cutter back and forth to form a line.)
6. Stand on one handle and exert down pressure on the other to finish the cut.
SC59 Soil Pipe Cutter
Operating Instructions
Warning: The high pressure exerted by cutter
can cause cut piece to fly with great force.
Reed Manufacturing Company
1425 West 8th St. Erie, PA 16512-1321 800-666-3691 or 814-452-3691 www.reedmfgco.com
REED MFG.CO.
ERIE PA. U.S.A.
REED MFG. CO. ERIE U.S.A.
4. Tighten pressure screw until handle ends are about 45°apart.
1209-50348
Pressure
Screw

Pipe Capacity
Catalog Item Inches Actual Length Weight
No. Code Nom. Ø mm in mm lbs kg
SC59-6 08059 1 1/2-6 160 43 1,092 23.8 10.8
SC59-8 08060 1 1/2-8 212 43 1,092 25.6 11.6
SC59-10 08061 1 1/2-6 268 43 1,092 27.4 12.5
SC59-12 08062 1 1/2-12 317 43 1,092 29.2 13.3
SC59-15 08063 1 1/2-15 403 43 1,092 31.0 14.1
SINGLE STROKE
1209-50348
Maximum Pipe Capacities
(determined by maximum pressure applied):
• Extra heavy cast iron soil pipe........... 2-4” (62-125mm)
• Service weight cast iron soil pipe...... 2-8” (62-212mm)
• Concrete pipe.................................... 4-6” (125-160mm)
• No-Hub®cast iron soil pipe.............. 1 1/2-8” (38-212mm)
• Clay pipe........................................... 2-15” (62-403mm)
Extension chains available to increase capacity of smaller cutters.
SC59 Soil Pipe Cutters
ACCESSORIES
Catalog Item
No. Code Description
SCEXT 40336 10” Extension Chain with 8 pitches at 1.25” per pitch
TW516 02298 5/16“ Torque Wrench
TW38 02300 3/8“ Torque Wrench
Reed also offers the
SC49 series as
“Ratchet Style” Soil
Pipe Cutters for close
quarters work.
Pipe Capacity
Catalog Item Inches Actual Length Weight
No. Code Nom. Ø mm in mm lbs kg
SC59-6 08059 1 1/2-6 160 43 1,092 23.8 10.8
SC59-8 08060 1 1/2-8 212 43 1,092 25.6 11.6
SC59-10 08061 1 1/2-6 268 43 1,092 27.4 12.5
SC59-12 08062 1 1/2-12 317 43 1,092 29.2 13.3
SC59-15 08063 1 1/2-15 403 43 1,092 31.0 14.1
SINGLE STROKE
1209-50348
Maximum Pipe Capacities
(determined by maximum pressure applied):
• Extra heavy cast iron soil pipe........... 2-4” (62-125mm)
• Service weight cast iron soil pipe...... 2-8” (62-212mm)
• Concrete pipe.................................... 4-6” (125-160mm)
• No-Hub®cast iron soil pipe.............. 1 1/2-8” (38-212mm)
• Clay pipe........................................... 2-15” (62-403mm)
Extension chains available to increase capacity of smaller cutters.
SC59 Soil Pipe Cutters
ACCESSORIES
Catalog Item
No. Code Description
SCEXT 40336 10” Extension Chain with 8 pitches at 1.25” per pitch
TW516 02298 5/16“ Torque Wrench
TW38 02300 3/8“ Torque Wrench
Reed also offers the
SC49 series as
“Ratchet Style” Soil
Pipe Cutters for close
quarters work.
