Reedog VS8 User manual

DOG
TRAINING
COLLAR
Model: VS8

Not for use with aggressive dogs. Do not use this product if your dog is aggressive, or if
your dog is prone to aggressive behavior. Aggressive dogs can cause severe injury and
even death to their owner and others. If you are unsure whether this product is appropriate
for your dog, please consult your veterinarian or a certified trainer.
For use with dogs over 6 months of age and over 8 lbs.
DO NOT use when the dog or the collar is wet.
Your dog when receiving stimulation. If this SHOULD NOT VOCALIZE OR PANIC
happens, the stimulation level is too high and you need to go back to the previous
level and repeat the process.
DO NOT charge the device near any flammable substances.
DO NOT press and hold the Warning Tone Button, Vibration Button and Vibration Boost
Button too often for more than 10 seconds to avoid physical or psychological damage to
your dog.
For dog use Not for use on children.ONLY.
This is not a toy, and should only be operated by a responsible adult.
WARNING
CAUTION
Before your first training, please read and follow the instructions in this manual carefully.
The cautions below will help keep your dog safe and comfortable. Millions of dogs are
comfortable when they wear stainless steel contacts, while some dogs are sensitive to
contact pressure.
It is vitally important that you and your dog remain safe while learning during on
-leash training. Your dog should be on a strong leash (do not attach the leash to the
Training Collar), long enough for him to attempt to chase an object, but short enough for
him not to reach a road or other hazard. You must also be physically strong enough to
restrain your dog when he tries to chase.
DO NOT leave the collar on the dog for more than 12 hours per day.
When possible re-position the collar on the dog's neck every 1 to 2 hours.
Check the fit to prevent excessive pressure; follow the instructions in this manual.
Examine the contact area daily for signs of a rash or a sore.
If a rash or sore is found, discontinue the use of the collar until the skin has healed.
If the condition persists beyond 48 hours, see your veterinarian.
Receiver collar meets IP67 waterproof rating, it can be submerged in water up to 1
meter for up to 30 minutes. If submerged and wet, please do not use it.
Risk of skin damage. Proper collar fitment is important. A collar worn for too long or
made too tight on the dog's neck may cause skin damage. Ranging from redness to
pressure ulcers; this condition is commonly known as bed sores.
Never connect an extra leash to the collar; it will cause excessive pressure on the
contacts.
Clean the dog's neck area and the contact probes of the collar weekly with a damp
cloth.
I. Important Safety Information:
01

Charge the Receiver and the Remote Transmitter for 2-3 hours with the double-headed
Micro-USB cable from the package box.
Note: The charger, power bank and other charging devices shown in the above
picture are not included in the box.
1
2
Let your dog stand on four feet or lay down fully. Fit the Receiver to your dog by leaving one
finger space between the collar and your dog's neck. Center the contact points underneath
your dog's neck, touching the skin.
II. Quick Start Guide
02

Turn on the Receiver by pressing and holding the Power Button for 2 seconds with a
3
4
Turn on the Remote Transmitter by pressing and holding the On/Off (Channel) Button
for 2 seconds.
03
vibration to indicate that the Receiver turns on. The Battery Bar Indicator turns off after
15 seconds of being on, and then the green Indicator continues to blink regularly.

Warning Tone Command: Press the Warning Tone Button, and the Receiver will deliver a
warning tone (both the green Indicator on the Remote Transmitter and the Receiver light up
6
Vibration Command: Press the Vibration Button, and the Receiver will deliver vibration
5
The green
Indicator lights up
04
simultaneously). The Beep level is 1-8 adjustable. Adjust the Warning Tone Level by pressing
the Level Up/Down Button.
The green
Indicator lights up
(both the green Indicator on the Remote Transmitter and the Receiver light up simultaneously).
The Vibration level is 1-3 adjustable: L (Light), M (Medium), and H (High). Adjust the Vibration
Level by pressing the Level Up/Down Button.

Vibration Boost Command: Press the Vibration Boost Button, and the Receiver will deliver
7
8
Switch the channel by pressing the On/Off (Channel) Button. This Remote Training Collar
can train up to 2 dogs.
Dog 1 Dog 2
05
The red
Indicator lights up
a boosted vibration (the red Indicator on the Remote Transmitter and the green Indicator on
the Receiver light up simultaneously). The intensity of the Vibration Boost remains constant.

1.Press and hold the Power Button on the Receiver for 2 seconds to turn it on. Turn on the
Remote Transmitter by pressing and holding the On/Off (Channel) Button for 2 seconds;
2.Press the Power Button on the Receiver 3 times to enter the Pairing Mode. You will hear a
beeping tone and the Indicator becomes solid green. You will now have 10 seconds to finish
9
the pairing;
Please refer to “Vl. Paring Up” on page 15 for more details.
Steps to pair the Remote Transmitter to the Receiver:
06
3.Press the Beep Button, Vibration Button, or Vibration Boost Button on the Remote Transmitter,
and Receiver will respond correspondingly indicating that the pairing process is completed.

Remote Transmitter Receiver
Charging Cable
User Manual
III. Package Content
07

(1)The icons “red lock” and “battery bar” will be displayed when the Remote
Transmitter is set to the locked state.
(2)The Remote Transmitter will go into sleep mode if there is no operation in
30 seconds.
IV.Product Overview
Warning Tone Mode
Vibration Mode
The Locked State
Remote Transmitter Battery
Warning Tone Level
Channel 1 Channel 2
Remote Transmitter
Keypad Lock
Level Up/Down Button
On/Off (Channel) Button
Warning Tone Button
Vibration Button
Indicator
Charging Port
Display Screen
08
Vibration Boost Button
Vibration Level
(High, Medium, Light)
Level Up/Down Activation
for Warning Tone

Contact Points
Charging Jack
Speaker
Power Button
Indicator
The Remote Training Collar is easy to use with an advanced digital display that
tells you the exact stimulation level you are using.
How the System Works
Receiver
The Remote Training Collar assists you in controlling your dog without a leash.
At the push of a button, your Remote Transmitter sends a signal activating your
dog's Receiver. He receives a safe but annoying stimulation. He'll quickly learn
the association between his behavior and your correction, and soon you'll have
a better-behaved dog.
The Remote Training Collar has been proven safe, comfortable, and effective
for both small and large dog breeds.
If using the Remote Training Collar consistently and correctly, any basic obedience
commands can be taught and will help correct any misbehavior that your dog
exhibits.
09
Battery Bar
Indicator

V. Setting Up
1.Charge the Product
Charge both the Receiver and the Remote Transmitter with the charging cable
in the package box until their Indicator becomes solid green which will take
around 2-3 hours.
Note:
(1)The charger, power bank and other charging devices shown in the above picture are not
included in the box.
(2)Use the charging cable in the package when charging. Other charging cables may not be
suitable for this Bark Collar, which may cause electric damage.
(3)The Remote Training Collar supports If charged with an ONLY a 5V-rated power source.
improper charger:
Receiver—deliver a rapid warning tone and stop charging automatically
Remote Transmitter—stop charging automatically with the Indicator rapidly blinking in red
10

2.Turn On/Off the Product
Turn on/off the Remote Transmitter by pressing and holding the On/Off
(Channel) Button for 2/3 seconds.
Turn on the Receiver by pressing and holding the Power Button for 2 seconds
Turn off the Receiver by pressing and holding the Power Button for 3 seconds
with a long beeping, as the green LED Indicator light stops blinking.
11
with vibration, as the green LED Indicator light blinks regularly after the Battery
Bar Indicator is on for 15 seconds.

VI. Training Modes
1.Warning Tone Mode
Press the Warning Tone Button and the Receiver will deliver a warning tone. It
will cut off automatically if you press and hold the Warning Tone Button for 10
seconds. There is a total of 8 levels of Warning Tone for training which you can
2.Vibration Mode
Press the Vibration Button and the Receiver will deliver a vibration. It will cut off
automatically if you press and hold the Vibration Button for 10 seconds. There is
a total of 3 levels of Vibration for training (L for Light, M for Medium, and H
3.Vibration Boost Mode
Press the Vibration Boost Button and the Receiver will deliver a boosted vibration.
It will cut off automatically if you press and hold the Vibration Boost Button for 10
12
adjust by selecting the Warning Tone Button and pressing the Level Up/Down
Button.
for High) which you can adjust by selecting the Vibration Button pressing the
Level Up/Down Button.
seconds.

4.Switching Channels
Press the On/Off (Channel) Button to choose the Receiver you want to control
if you have paired up two Receivers.
5.Sleep Mode
The Remote Transmitter will enter sleep mode to save battery power if there
is no operation for 30 seconds.
VII. Fitting the Receiver
IMPORTANT:
The proper fit and placement of your Receiver are important for effective training.
To assure a proper fit, please follow these steps:
1.Make sure that the Receiver is turned off.
2.Let your dog stand on four feet or lay down fully (A).
3.Place the Receiver on your dog's neck close to the ears. Center the Contact
Points underneath your dog's neck, touching the skin (B).
Note: It is sometimes necessary to trim the hair around the Contact Points to
make sure that contact is consistent.
4.The Receiver should fit snugly, yet loose enough to allow one finger to fit
the strap and your dog's neck (C).
5.Allow your dog to wear the collar for several minutes then recheck the fit.
Check the fit again as your dog becomes more comfortable with the Receiver.
C
AB
6. To attach the collar to the Receiver, please follow the following steps as
instructed to thread the strap.
13

CAUTION：
It is sometimes necessary to trim the hair around the Contact Points to make
sure that contact is consistent.
DO NOT shave the dog's neck as this may increase the risk of skin irritation.
Check the fit regularly to make your dog more comfortable with the collar.
VIII.Pairing Up
1.Press and hold the Power Button on the Receiver for 3 seconds to turn it on.
Turn on the Remote Transmitter by pressing the On/Off (Channel) Button for 2
seconds.
2.Press the Power Button on the Receiver 3 times to enter the Pairing Mode.
You will hear a Beeping tone and the LED Indicator light becomes solid green.
You will now have 10 seconds to finish the pairing.
14
If you feel the Receiver is not responding to the Remote Transmitter, follow these
steps to pair them up.

3.Press the Warning Tone Button, Vibration Button, or Vibration Boost Button on the
Remote Transmitter, and the Receiver will respond correspondingly indicating that
the pairing process is completed.
The Receiver is paired to the Remote Transmitter by the factory default setting.
If you find the Receiver does not respond to the Remote Transmitter when you
get the product or during use, please follow the above steps to pair the Receiver
Tips:
15
to the Remote Transmitter again.

Remote Transmitter Indicator:
Fully Charged
Receiver Indicator：
Fast blinking indicates the Receiver is on charge
Blinking at high speed indicates the Receiver
battery is low
Solid green Battery Bar indicates the Receiver is
fully charged
Slowly blinking indicates the Receiver is on
X. Training Tip
Find the best stimulation for your dog
Important: Always start at the lowest level and work your way up.
The Remote Training Collar has 8 types of Warning Tones, 3 levels of Vibration
(Light, Medium, and High), and the Vibration Boost with a constant intensity.
For Warning Tones, there are 8 types of Tones, with only frequency differences
between the different types. For Vibration, level L is the lowest; level H is the
This allows you to choose the Stimulation level that is best for your dog. Once you
have placed the Receiver on your dog, it is time to find the Stimulation Level that
is best for him. This is called the Recognition Level.
A slight change in your dog's behavior, such as looking around in curiosity, scratching
at his collar, or flicking his ears, indicates the Recognition Level that is best for
your dog.
Follow the steps below to find your dog's Recognition Level:
1.Starting at the lowest level, press the Warning Tone/Vibration/Vibration Boost
Button continuously for 1 to 2 seconds.
Note: When the Warning Tone/Vibration/Vibration Boost Button is held down for 10
consecutive seconds, the Remote Transmitter will "time out", and you must release and
press the button again before additional stimulation can be delivered.
2. If your dog shows no reaction, repeat the Stimulation Level several times
before moving up to the next level.
IX. Indicator Definitions
Charging The Green Indicator light blinks slowly
The Green Indicator light becomes solid
Press A Green Indicator light comes up
A Green Indicator light comes up
Press
A Red Indicator light comes up
Press
16
A Green Indicator light comes up when any of the
three functions is activated
highest.

3. Y O UR D O G SH O ULD N OT V O CAL IZE O R PA NIC W HEN R ECE I VIN G
S TIM U L ATIO N . I F TH I S H A PPE N S , THE S T I MULAT I ON LEV E L I S TOO
H I G H A N D Y O U N E E D T O G O B A C K TO T H E P R E V I O U S L E V E L A N D
REPE AT T HE PR O C ESS .
4. Move up through the Stimulation Level until your dog reliably responds to
the stimulation.
5. If your dog continues to show no response at the highest level of the Warning
Tone and Vibration, or Vibration Boost, check the fit of the Receiver. Then go back
to #1 and repeat the process. If this still does not yield any results, your dog's hair
will need to be trimmed around the Contact Points.
If, after completing all of these steps, your dog still does not indicate he is feeling
the stimulation, please contact our customer service.
How to Maximize the distance?
Terrain, weather, vegetation, transmission from other radio devices, and other
factors will affect the maximum range.
Hold the Remote Transmitter in a horizontal position away from your body to
achieve optimum range. For maximum signal strength, keep the device properly
charged.
*Avoid touching the antenna or the range may decrease substantially.
XI. Frequently Asked Questions
Q: Is the Stimulation safe for my dog?
A: While the Stimulation is unpleasant, it is harmless to your dog. Electronic
training devices require interactio n and training from the owner to achieve
desired results.
Q: Is the Receiver waterproof?
A: Yes. The Receiver meets the IP67 waterproof rating, but make sure to keep
the area dry when charging.
Note: Remote Transmitter is not waterproof.
17
Q: How long can I continuously deliver stimulation to my dog?
A: The maximum amount of time you can press the Warning Tone/Vibration/
Vibration Boost Button and deliver stimulation to your dog continuously is 10
seconds. After this, the Remote Transmitter will time out, and these stimulation
buttons must be released and pressed again.
Q: What should I do if my dog's neck becomes red and irritated?
A: Stop using the product immediately for at least 48 hours. If the condition persists
beyond 48 hours, please consult your veterinarian.

2.The Receiver will not turn on.
Make sure the Receiver has been charged. For the initial charge, be sure to
charge it for 4 hours. Subsequent charges only take 2-3 hours.
If the indicator is blinking rapidly, fully charge the Receiver.
If the first two solutions did not resolve your problems, please check the “Pairing
Up” section on page 13.
3.The Receiver is not responding to the Remote Transmitter.
Verify the Receiver is on.
XII.Trouble Shooting
1.My dog does not respond when I press a button.
Make sure the Receiver has been turned on.
If your range has reduced from the first time you used the Remote Training Collar,
the battery(-ies) may be low in either the Remote Transmitter or Receiver.
Many factors can impact the amount of range you have with the Remote Training
Collar. For a list of these factors, see "How to Maximize the Distance" on page 18.
Increase the Stimulation Level. Refer to "Find the best stimulation for your
dog" on page 17 for more information.
NOTE: If the Indicator does not flash, recharge the Receiver and re-test.
If the Indicator still does not flash, please contact our customer service.
Increase the Stimulation Level. Refer to "Find the best stimulation for your dog"
on page 17 for more information.
Make sure the Receiver's are placed snugly against your dog's skin. Prongs
Refer to "Fitting the Receiver" on page 14 for more information.
Q: Will I get a maximum range with the Remote Training Collar?
A: The range of the Remote Training Collar will vary according to terrain, weather,
vegetation, as well as transmission from other radio devices. See "How to Maximize
the Distance" on page 18 for tips on maximizing your range.
18
Q: Once my dog is trained and has been obeying my commands, will he
have to continue to wear the Receiver?
A: Probably not. You may need to reinforce training with the Receiver from time
to time.
Q: Ho w o ld do es my do g hav e to be befor e u si ng th e R em ote Tra ining
Co llar?
A: Your dog should be able to recognize basic obedience commands such as
Sit'' or “Stay''. Dogs should be at least 6 months old before using the Remote
Training Collar.
Q: When should I recharge the Remote Transmitter and Receiver?
A: The low battery bar symbol on the Remote Transmitter Screen flashes at high
speed, indicating the need for charging; The Battery Bar Indicator on the Receiver
flashes at high speed, indicating the need for charging.
Q: Can I attach a leash to the Receiver?
A: No. This may cause the Contact Points to be pulled too tightly against the dog's
neck. If needed, please use a separate collar.
Make sure the Receiver's Prongs are placed snugly against your dog's skin.
Refer to "Fitting the Receiver" on page 13 for more information.

NOTE:
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications.
However, t here is no guarante e that in terference will not occu r i n a specific
installation. If interference does occur to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and the receiver.
Connect the equipment to an outlet on a circuit different from that to which the
receiver is connected.
Consult customer care, the dealer, or an experienced radio/TV technician for
help.
The device has been evaluated to meet general RF exposure requirement.
Model: VS8
Made in China
Version: V1.0
19
XIII. FCC Statement
USA
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
intentional or unintentional radiator changes or
modifications not expressly approved by the party
responsible for compliance could void the user's
authority to operate the equipment.
