Regency City Series New York 72 User manual

Regency City Series New York 72
CV72E-NG / CV72E-LP
FRAMING
DIMENSIONS
SPECIFICATIONS
HEAT RELEASE REQUIREMENTS
QR LINK FOR
PDF DIGITAL COPY
OF SPECIFICATIONS:
MUST READ BEFORE
FRAMING
IMPORTANT INFORMATION

6| City Series CV72E
dimensions
7
7
2
2
1
1
"
"
3
3
"
"
1
1
0
011
4
4
"
"
2
2
6
6
1
1
m
m
m
m
1
1
5
511
1
1
6
6
"
"
3
3
8
8
2
2
m
m
m
m
2
2
0
01111
1
1
6
6
"
"
5
5
2
2
6
6
m
m
m
m
7
7
7
7
7
7
1
1
6
6
"
"
1
1
9
9
6
6
7
7
m
m
m
m
3
3
8
81111
1
1
6
6
"
"
9
9
8
8
3
3
m
m
m
m
3
3
8
81111
1
1
6
6
"
"
9
9
8
8
3
3
m
m
m
m
7
7
3
3
8
8
"
"
1
1
8
8
7
7
m
m
m
m
1
1
3
3
"
"
3
3
3
3
0
0
m
m
m
m
Ø
Ø
5
5
"
"
1
1
2
2
7
7
m
m
m
m
8
8
1
1
8
8
3
3
2
2
m
m
m
m
Ø
Ø
8
8
"
"
2
2
0
0
3
3
m
m
m
m
4
4
6
6
"
"
11116688mmmm
2
2
0
0
8
8
5
5
1
1
7
7
m
m
m
m
Dimensions
Note: Height Dimension is taken with leveling legs fully inserted and may vary depending on the height of the leveling legs, when unscrewed or extended.
Dimensions will appear as (inches)" / (metric) mm
throughout this manual. The inches are rounded to the
nearest 1/16" when converted, when greater accuracy
is required, use the metric dimensions.
Note: These units are non-load bearing.
ALL PICTURES / DIAGRAMS SHOWN THROUGHOUT THIS MANUAL ARE FOR ILLUSTRATION PURPOSES ONLY.
ACTUAL PRODUCT MAY VARY DUE TO PRODUCT ENHANCEMENTS.

City Series CV72E | 7
installation
Gas Connection - Back of Unit
Gas Connection - Bottom of Unit
Gas Connection - Side of Unit
tooltip
removable knockouts
17" 5" 5" 5" 17"
36-1/4" 36-1/4"
3-7/8"
20-1/3"
12-1/2"
7"
Front of Unit
Back of Unit
Gas Valve
14-1/2"
Opening at unit base
tooltip
11" 5"
Front of
unit
Back of
unit
3-7/8"
tooltip
Front of Unit
Back of Unit
12-7/8" 5"
2-1/2"
Right Side Left Side

8| City Series CV72E
installation
Electrical Connection - Bottom of Unit
Electrical Connection - Side of Unit
Front of Unit
Back of Unit
20-1/3"
12-1/2"
7"
77-7/16"
Receptacle
Electrical opening
8"
tooltip
2-3/4"
Front of
unit
Back of
unit
4"

City Series CV72E | 31
installation
Ventilation Openings
Regency's patented Cool Wall system releases warmth at ceiling level. This
system reduces excessive radiant heat in front of the replace so you can
enjoy your replace more often.
• Design your own chase vent solution to suit your home
• Use optional front or left & right side chase vent grills
• Release warmth into the room discreetly
Front Exit
The ventilation opening may be placed in front ensuring it meets the 288
square inch opening & is located 0-2" (51mm) from the enclosure ceiling.
SIde Exit
Ventilation openings, when placed on both sides, must be of the same size.
They must be have an equal split (50/50) free air opening to balance air ow.
A ventilation opening may never be on one side only.
The ventilation openings cannot be any smaller than 6" (152mm) wide to
equal the total area of 288 square inches of free open area.
Example: 6" (152mm) wide x 24" (610mm) High = 144 square inches per
side of free open area. A second ventilation grill is installed on the other side
to =100%.
The ventilation openings must be located 0-2" (51mm) from the enclosure
ceiling.
Top Exit
The ventilation opening may be short of the ceiling as shown below.
Minimum opening height must be 2-1/2" (64mm) measured from top of
enclosure to the ceiling and must be in open in front and both sides to
meet the minimum 288 square inches free open air requirement.
Ventilation Opening Locations
The following are examples of how the ventilation openings may be placed
above the replace.
If using the optional heat wave kit, this does not reduce the size of the
ventilation opening. The ventilation opening(s) must be a minimum 288
square inches regardless.
The air travelling through the heat exchanger is heated by the replace and
then directed out the back of the replace. The combined warmed air is then
vented back into the room.
The ventilation opening may be fully open at the top of the enclosure.
This type of ventilation opening would be used when the top of the
enclosure is not visible from above and where the ceiling within the
room is higher than normal. When creating this type of ventilation
opening, measures should be into place to avoid having objects of any
type falling or be thrown into the ventilation opening. Mesh screen or
other preventative measures should be put into place.
The ventilation opening may be placed on top ensuring it meets the
288 square inch opening. This type of ventilation opening would be
used when the top of the enclosure is visible from above and where the
ceiling within the room is higher than normal.

32 | City Series CV72E
installation
Chase Enclosure
Max 3”
(76 mm)
Ceiling Ceiling
Top of chase enclosure
Max 3”
(76 mm)
Stud
Stud
Stud
Stud
40” (1016 mm) Chase Vent
C40 Chase Vent Framing Clearances
Opening for vent
4”-4.5”
(102 mm x 114 mm)
Min 42.25” (1073 mm)
Framed opening must be between 4” (102 mm) and 4.5” (114 mm) tall, and at least 42.25”(1073 mm) wide
to accommodate the chase vent. The top of the chase vent opening must be 3” or less from the top of the
chase enclosure.
40” (1016 mm) Chase Vent
Top of chase enclosure
In the example above, the ceiling does not
meet the requirement as it is higher than
the specied minimum.
Top of chase enclosure is sealed o to
meet the 0-2'' (51mm) requirement.
Top of chase enclosure
Minimum 288sq. inch opening
Minimum 288sq. inch opening
When choosing to install the ventilation openings from the front or both sides, The top of the ventilation opening cannot be any lower than 0-2" (51mm)
from the top of the chase enclosure for all installations.
Minimum height of enclosure from base of appliance is 87" (2210mm).
A minimum 288in2 opening in the enclosure is required to maintain safe operating temperatures. This can be achieved in a number of ways including the
examples shown in this manual.
IMPORTANT:
Exterior wall/Alcove enclosure: When installing into an exterior cavity or alcove enclosure (ceiling, back and sides), regardless of where appliance is
placed within the home, requires the use of either drywall or other means such as plywood, wood studs, etc. to prevent heat from escaping anywhere above
/through the enclosure other than the required grill / ventilation opening.
Internal chase: When installing as an internal chase framing installation ,regardless of where appliance is placed within the home, requires the use of either
drywall or other means such as plywood, on the rear wall of the chase to eliminate heat escaping into the rear wall cavity. If the chase is extended to the
ceiling ,the ceiling will also need to be nished in a manner to prevent heat escaping into oor joist/attic space.
One of the following methods must be used to prevent the heat from escaping.
a. If choosing drywall, ensure that the drywall is butt up tight with no gaps.
b. Plywood, wood studs, etc. installed tightly with no gaps.
As this appliance has been designed with all hot air escaping through the chase enclosure ventilation/grill openings only, if hot air is trapped as a result of
the hot air escaping through joints, crevasses, open studs, or other openings within the enclosure above, this will change the clearances within the enclosure
causing the enclosure to overheat. It is vital that all the hot air from within the enclosure exits through the ventilation openings only.
Ensure that the ventilation openings are made as such to prevent debris, objects from falling into the enclosure.
Warning: DO NOT cover or place objects in front of the ventilation opening air outlet(s).
Max. 2''
(51mm)
Max. 2''
(51mm)

City Series CV72E | 33
installation
Caution Requirements
The top, back and sides of the replace are dened by
standos. The metal ends of the stando may NOT be
recessed into combustible construction.
WARNING
Fire hazard is an extreme risk
if these clearances (air space) to combustible materials are not
adhered to. It is of greatest importance that this replace and vent
system be installed only in accordance with these instructions.
Clearances
The clearances listed below are minimum distances unless otherwise stated:
A major cause of chimney related res is failure to maintain required clearances (air space) to combustible materials. It is of the greatest importance that
this replace and vent system be installed only in accordance with these instructions.
Clearance: single sided Dimension Measured From:
A: Mantel Height (min.) ** Top of Fireplace Opening
B1:From Floor min. 0" Bottom of Fireplace Opening
B2: Opening Height 15-1/16" (383mm) Bottom/Top of Fireplace Opening
C: Sidewall (on one side) 8" (203mm) Side of Fireplace Opening
D: Mantel Depth (max.) **
E: Alcove Width 88" (2135mm) Sidewall to Sidewall (Minimum)
F: Alcove Depth 36" (914mm) Front to Unit (Maximum)
G: Ceiling
(in front of replace)
61-3/4" (1568mm) Top of Fireplace Opening
H: Convection Air Outlet* *288 in2 (1858 cm2)
J: Convection Air Outlet Opening Oset *0-2" (0-51mm) Max. oset from top of chase
enclosure
K: Chase Enclosure (Min.) 87" (2210mm) From base of unit/oor
L: Clearance to Sprinkler Head (Min.) 36" (914mm) Perpendicular from chase grill
Hearth 0" No hearth required
*ALso see previous page for alternate ventilation opening locations.
** See mantel clearances chart in this manual.
Flue Clearances to Combustibles
Horizontal - Top 3"
Horizontal - Side 2"
Horizontal - Bottom 2"
Vertical 2"
Passing through wall/
floor/ceiling - when
restop is used.
1-1/2"
Note: This appliance uses 5" x 8" venting.
Alcove
E
F
D
A
C
B 1
G
B 2
J
H
K
The HeatWave Duct Kit has
dierent clearance and framing re-
quirements, check the HeatWave
manual for details.
*A minimum of 288
square inches of
open area, not lower
than 0-2" from top of
enclosure, required for all
installations
Side view
L
Chase grill
Sprinkler

34 | City Series CV72E
installation
Mantel Clearances
Combustible mantel clearances from top of front facing
are shown in the diagram on the right.
Mantel Leg Clearances
Combustible mantel leg clearances as per diagram:
212 6 4810
0
14
15-1/16"
(382mm)
10
20
26
Top of
Fireplace
Opening
12" (305mm)
1/2" (13mm) Drywall, wood, wood panel, etc.
5-1/8"
(130mm)
To Bottom of
Fireplace
Opening
9”
(229mm)
12" (305mm)
Allowable mantel
MANTEL LEG
leg projection
9" (229mm)
10" (254mm)
5"
(127mm)
7"
(178mm)
12" (305mm)
Allowable mantel
MANTEL LEG
leg projection
9" (229mm)
10" (254mm)
5"
(127mm)
7"
(178mm)

City Series CV72E | 35
installation
Framing Dimensions
NOTE: Framing may be constructed of combustible material (ie. 2 x 4)and does not require steel studs.
Framing
Dimensions Description CV72E
AFraming Height 51" (1295mm)
BFraming Width 78" (1981mm)
C Framing Depth 20-5/8" (524mm)
DMinimum Height to Combustibles 87"(2210mm)
E Corner Wall Depth 82-1/8" (2086mm)
F Corner Facing Wall Width 116-3/16" (2951mm)
G Vent Centerline Height 55-1/4" (1403mm)
I Gas Connection Opening Height 2" (51mm)
J Gas Connection Height 3-7/8" (98mm)
K* Gas Connection Inset-Centre Opening 36-1/4" (921mm)
L Gas Connection Opening Width 5" (127mm)
* See next page for alternate Gas/ Electrical connection options
Note: A combined minimum of
288 square inches of open area
is required for the convection
air outlet to cool the enclosure.
Ensure clearances for Convec-
tion Air Outlets are met.
See clearances CV72E in this
manual as there are dierent
methods as to how this can
be achieved.
Note: This appliance must be
installed on a solid surface
such as a plywood oor which
must be the full width and
depth of the appliance.
With the lift handles adding approximately 4 inches to the overall width of the appliance. In cases where the appliance would need to be raised o the ground
in order to slide it into the framed opening, it is suggested that either the framing width change from 78" to 82" so that the appliance could be easily slid
into position with the handles remaining on the appliance, or alternatively create a platform in front of the framed opening where the lift handles could be
removed prior to sliding the appliance into its nal position. Alternatively, If raised o the ground, the framing could be installed afterwards once appliance
has been put into place and lift handles removed in order to keep the framing width at 78". Ensure that the wood base that the appliance will sit on is strong
enough to support the full weight of this appliance. The overall weight of this appliance is 529 pounds (shipping weight).
Note: Wood studs in back
can be either wood 2'' x 4''
or 2'' x 6''.

36 | City Series CV72E
installation
Chase Vent Installation
919-830b 01.23.18
1
CITY SERIES
CV72E CHASE VENT INSTALLATION
Max 2”
Ceiling Ceiling
Top of chase enclosure
Max 2”
Stud
Stud
Stud
Stud
72” Chase Vent
72” Chase Vent
Opening for vent
5”-5.5”
Min 74.25”
Framed Opening must be between 5” and 5.5” tall, and at least 74.25”wide to accomodate the Chase vent.
The top of the chase vent opening must be 2”or less from the top of the chase enclosure.
