Regency P36D-NG2 Quick start guide

Models: P36D-NG2
P36D-LPG2
Owners &
Installation
PLEASE KEEP THESE INSTRUCTIONS
FOR FUTURE REFERENCE
Manual
01/06/14
LISTINGS AND CODE APPROVALS
Thesegasapplianceshavebeentestedin
accordance with AS4553, NZS 5262 and
have been certified by theAustralian Gas
Association for installation and operation
as described in these Installation and
Operating Instructions.
Your unit should be serviced annually
by an authorised service person.
918-552c
WARNING:
Improperinstallation,adjustment,alteration,
serviceormaintenancecancauseinjuryor
propertydamage. Refer tothis manual. For
assistanceoradditionalinformationconsult
an authorised installer, service agency or
the gas supplier.
FOR YOUR SAFETY
Do not store or use gasoline or other
flammablevapoursandliquidsinthevicinity
of this or any other appliance.
Installation and service must be performed
byanauthorisedinstaller,serviceagencyor
the gas supplier.
P36D Gas Log Fireplace
FOR YOUR SAFETY
What to do if you smell gas:
Do not try to light any
appliance
Do not touch any electrical
switch: do not use any
phone in your building.
Immediately call your gas
supplierfromaneighbour's
phone. Follow the gas
supplier's instructions.
If you cannot reach your
gas supplier, call the fire
department.

Regency®P36D Gas Log Fireplace
2
TO THE NEW OWNER:
Congratulations!
Youaretheownerofastate-of-the-artGasLogFireplaceby FPIFIREPLACEPRODUCTSINTERNATIONAL.
The P36D has been designed to provide you with all the warmth and charm of a wood fireplace at the flick
of a switch. The model P36D has been approved by the Australian Gas Association for both safety and
efficiency. As it also bears our own mark, it promises to provide you with economy, comfort and security for
many trouble free years to follow. Please take a moment now to acquaint yourself with these instructions
and the many features of your Regency®Fireplace.
36"(914mm)
36" (914mm)
33"(838mm)
17-1/8"(435mm)
30-1/2"(775mm)
32-1/2"(826mm)
37"(940mm)
37"(940mm)

Regency®P36D Gas Log Fireplace 3
TABLE OF CONTENTS
OPERATING INSTRUCTIONS
Optional Fan Installation..............................................30
Optional Fan Removal.................................................30
Normal Operating Sounds Of Gas Appliances............31
Operating Instructions .................................................31
Shutdown Procedure...................................................31
First Fire ......................................................................31
Lighting Procedure ......................................................31
Copy Of The Lighting Plate Instructions......................32
MAINTENANCE
Maintenance Instructions.............................................32
Gold-Plated & Brass Louvres or Trim..........................33
Log Replacement ........................................................33
Thermopile / Thermocouple.........................................33
Glass Gasket...............................................................33
Door Glass...................................................................33
Removing Valve...........................................................34
Installing Valve.............................................................34
PARTS LIST
Main Assembly ............................................................35
Burner Assembly & Log Set.........................................36
Bay Front Assembly.....................................................37
Flush Front Assembly..................................................38
Premium Flush Front Assembly...................................39
WARRANTY
Warranty......................................................................43
DATA BADGE
Data Badge....................................................................4
INSTALLATION
Important Message........................................................5
Before You Start ............................................................5
General Safety Information............................................5
Installation Checklist......................................................5
Clearances ....................................................................6
Locating Your Gas Fireplace .........................................6
Manufactured Mobile Home Additional Requirements ..6
Combustible Mantels.....................................................7
Mantel Leg Clearances..................................................8
Framing and Finishing...................................................8
Unit Assembly Prior to Installation.................................9
Flueing Introduction.......................................................9
Exterior Flue Termination Locations............................10
Flueing.........................................................................11
Simpson Dura-Vent Flueing.........................................12
Simpson Dura-Vent Flueing Components List.............12
Flueing Arrangements - Horizontal Terminations.........13
Flueing Arrangements - Horizontal Terminations.........14
Flueing Arrangements - Vertical Terminations.............15
Horizontal Terminations..............................................17
Vertical Terminations ...................................................18
Gas Line Installation....................................................20
Pilot Adjustment...........................................................20
Aeration Adjustment ....................................................20
Gas Pipe Pressure Testing..........................................20
Optional Brick Panels..................................................21
Log Set Installation......................................................21
Standard Flush Door ...................................................23
Premium Flush Front Installation.................................24
Option 1: Wall Switch ..................................................27
Option 2: Remote Control............................................27
Option 3: Wall Thermostat ..........................................27
Thermostat Wire Table ................................................27
Wiring ..........................................................................28

Regency®P36D Gas Log Fireplace
4
DATA BADGE
Thisisacopyofthelabelthataccompanieseach
P36D Gas Fireplace. We have printed a copy
of the contents here for your review.
DO NO T
DO NO T
DO NO T
DO NO T
DO NO T
DO NO T
OPERATE THIS APPLIANCE BEFORE READING THE
INSTRUCTIONS BOOKLET.
PLACE ARTICLES ON OR AGAINST THIS APPLIANCE
STORE CHEMICALS OR FLAMMABLE MATERIALS
SPRAY AEROSOLS IN THE VICINITY OF THIS
APPLIANCE WHILE IN OPERATION.
OPERATE WITH PANELS, COVERS OR GUARDS
REMOVED FROM THIS APPLIANCE.
ENCLOSE THIS APPLIANCE.
MODIFY THIS APPLIANCE.
NEAR THIS APPLIANCE.
DO NO T
908-602a
(Australia Only)
Thelabelislocatedonthefrontinsidebaseofthe
unit, visible when the bottom louvre is open. DATA BADGE NOTE: Regency®units are constantly being improved. Check the label on
the unit and if there is a difference, the label on
the unit is the correct one.

Regency®P36D Gas Log Fireplace 5
INSTALLATION
CHECKLIST
1) Locate appliance
a) Locate Your Gas Fireplace
b) Clearances
c) Combustible Mantels
d) Framing & Finishing
2) Assemble Top Standoffs and Top Facing
Support and Side Nailing Strips, refer to
section"UnitAssemblyPriortoInstallation".
(NOTE: must be done before installing unit
into fireplace.)
3) Installflue(Refertosection"SimpsonDura-
vent Flueing").
4) Make gas and electrical connections. Test
the pilot. Must be as per diagram. Refer to
section "Pilot Adjustment."
5) Installstandardandoptionalfeatures. Refer
to the following sections:
a. Brick Panels
b. Log Set
c. Flush Door
d. Premium Flush Front
e. Bay Door
f. Hampton®Cast Faceplate
g. Hampton®Cast Grills
h. Wall Switch
i. Remote Control
j. Wall Thermostat
k. Fan
6) Final check.
Before leaving this unit with the customer,
the installer must ensure that the appliance is
firing correctly and operation fully explained
to customer.
This includes:
1) Clockingtheappliancetoensurethecorrect
firingrate(ratenotedonlabel30,000Btu/h)
after burning appliance for 15 minutes.
2) Ifrequired,adjustingtheprimaryairtoensure
that the flame does not carbon. First allow
the unit to burn for 15-20 min. to stabilize.
CAUTION:Anyalteration tothe product that
causes sooting or carboning that results
in damage is not the responsibility of the
manufacturer.
INSTALLATION
IMPORTANT MESSAGE
SAVE THESE INSTRUCTIONS
The P36D-NG or P36D-LPG Room Sealed
Fireplace must be installed in accordance with
AS5601-2004 and NZS 5261 5261 and these
instructions. Carefully read all the instructions
in this manual first. Consult the "authority
having jurisdiction" to determine the need for
a permit prior to starting the installation. It is
the responsibility of the installer to ensure
this fireplace is installed in compliance with
manufacturer's instructions and all applicable
codes.
BEFORE YOU START
NOTE: NOT INTENDED AS A FIREPLACE
INSERT.
GENERAL SAFETY
INFORMATION
1) The appliance shall be installed in
accordance with the manufacturer's
installation instructions,local gas fitting
regulations, municipal building codes,
water supply regulations, electrical wiring
regulations, with AS5601-2004 (AGA
gas installation code) NZS 5261 (New
Zealand).
2) Installation and repair should be done
ONLY by an authorised person.
3) THISAPPLIANCEISNOTINTENDEDASA
FIREPLACEINSERT.DONOTCONNECT
TO MASONARY FLUE.
4) This appliance must be connected to
the specified flue and termination cap
to the outside of the building envelope.
Never flue to another room or inside a
building. Make sure that the flue is fitted
as per Flueing instructions.
5) Inspect the flueing system annually for
blockage and any signs of deterioration.
6) Flueingterminalsshall notbe recessedinto
a wall or siding.
7) Any safety glass removed for servicing
must be replaced prior to operating the
appliance.
8) To prevent injury, do not allow anyone who
is unfamiliar with the operation to use the
fireplace.
9) Wearglovesandsafetyglassesforprotection
while doing required maintenance.
10) Be aware of electrical wiring locations in
walls and ceilings when cutting holes for
termination.
11) Under no circumstances should this
appliancebemodified.Partsthathavetobe
removed for servicing should be replaced
prior to operating this appliance.
12) Installationandanyrepairstothisappliance
should be done by an authorised service
person.Anauthorisedservicepersonshould
becalled toinspect thisapplianceannually.
Make it a practice to have all of your gas
appliances checked annually.
13) Do not slam shut or strike the glass door.
14) Under no circumstances should any solid
fuels (wood, paper, cardboard, coal, etc.)
be used in this appliance.
15) The appliance area must be kept clear and
free of combustible materials, (gases and
other flammable vapours and liquids).
INSTALLATION AND REPAIR SHOULD
BE DONE BY A AUTHORISED SERVICE
PERSON. THE APPLIANCE SHOULD BE
INSPECTED BEFORE USEANDAT LEAST
ANNUALLYBYANAUTHORISEDSERVICE
PERSON. MORE FREQUENT CLEANING
MAY BE REQUIRED DUE TO EXCESSIVE
LINT FROM CARPETING, BEDDING
MATERIAL, ETC. IT IS IMPERATIVE THAT
CONTROL COMPARTMENTS, BURNERS
AND CIRCULATING AIR PASSAGEWAYS
OF THE APPLIANCE BE KEPT CLEAN.
DUE TO HIGH TEMPERATURES, THE
APPLIANCE SHOULD BE LOCATED OUT
OFTRAFFICANDAWAYFROMFURNITURE
AND DRAPERIES.
WARNING: FAILURE TO INSTALL THIS
APPLIANCECORRECTLYWILLVOIDYOUR
WARRANTYAND MAY CAUSEA SERIOUS
HOUSE FIRE.
CHILDREN AND ADULTS SHOULD BE
ALERTED TO THE HAZARDS OF HIGH
SURFACETEMPERATURES,ESPECIALLY
THE FIREPLACE GLASS, AND SHOULD
STAY AWAY TO AVOID BURNS OR
CLOTHING IGNITION.
YOUNG CHILDREN SHOULD BE
CAREFULLY SUPERVISED WHEN THEY
ARE IN THE SAME ROOM AS THE
APPLIANCE.
CLOTHING OR OTHER FLAMMABLE
MATERIAL SHOULD NOT BE PLACED ON
OR NEAR THE APPLIANCE. DO NOT USE
AEROSOLS IN THE VICINITY OF THIS
APPLIANCE.

Regency®P36D Gas Log Fireplace
6
INSTALLATION
Clearances for Bay or Flush Front
NOTE: The minimum floor clearance must
be maintained from the top surface of the
carpeting, tile, etc.
Minimum Clearance from Top of Unit to:
Mantel* Minimum 7" (177mm)
Ceiling from top of unit. 32" (1016mm)
Side Wall Clearance
Bay or Flush Front 6" (152mm)
Horizontal Flue Clearances
Top 2" (51mm)
Side 1-1/2"(38mm)
Bottom 1-1/2"(38mm)
Vertical Flue Clearances 1-1/4" (32mm)
Alcove Clearances**:
Max. Depth 36" (914mm)
Min. Width 48" 1219mm)
Min. Height 72" 1829mm)
* see mantle clearance instructions
(Refer to section "Combustible Mantels" &
"Mantel Leg Clearances."
CLEARANCES
The clearances listed below are Minimum
distances unless otherwise stated:
A major cause of chimney related fires is
failure to maintain required clearances (air
space) to combustible materials. It is of the
greatest importance that this fireplace and
flue system be installed only in accordance
with these instructions.
Clearance to Combustibles from:
Back 0" (0mm)
Side 0" (0mm)
Floor 0" (0mm)
Diagram 1
LOCATING YOUR
GAS FIREPLACE
1) When selecting a location for your stove,
ensure that the clearances outlined on this
page are met.
2) Provide adequate clearances for servicing.
3) The appliance must be installed on a flat,
solid,continuoussurface(e.g.wood,metal,
concrete).Thismaybethefloor,orraisedup
on a platform to enhance its visual impact.
If the appliance is going to be installed
on carpeting, combustible linoleum tile or
othercombustiblematerialotherthanwood
flooring, the appliance must be installed on
a metal or wood panel extending the full
width and depth of the appliance.
4) The P36D CoAxial Flue Gas Fireplace can
beinstalledinarecessedpositionorframed
out into the room as in A, B, C, D. See
Diagram 1.
6) The P36D Co Axial Flue Gas Fireplace is
approved for alcove installations, which
meet the clearances listed on this page.
7) Werecommendthatyouplanyourinstallation
on paper using exact measurements for
clearances and floor protection before
actually installing this appliance. Have an
authorized inspector, dealer, or installer
review your plans before installation.
Note: For flue terminations see section
"Exterior Flue Termination
Locations."
MANUFACTURED
MOBILE HOME
ADDITIONAL
REQUIREMENTS
1) Ensure that structural members are not cut
or weakened during installation.
2) Ensure proper grounding using the #8
ground lug provided. See section "Wiring."
A) Flat on Wall
B) Flat on Wall Corner
C) Recessed into Wall/Alcove
D) Corner
5) This appliance is Listed for bedroom
installationswhenusedwithaListedMillivolt
Thermostat. Some areas may have further
requirements, check local codes before
installation.
WARNING
Fire hazard is an
extreme risk
if these clearances
are not adhered to.

Regency®P36D Gas Log Fireplace 7
INSTALLATION
Because of the extreme heat this fireplace emits, the mantel clearances are critical.
Combustible mantel clearances from top of unit are shown in Diagrams 1 & 2.
COMBUSTIBLE MANTELS
These drawings are to scale at 1:6 (one inch = 6 inches) Mantel can be installed anywhere in shaded area or higher using the above scale. Note: Ensure the paint that is used on the mantel and the facing is "heat resistant" or the paint may discolour.
Note: A non-combustible mantel may be installed at a lower height if the framing
is made of metal studs covered with a non-combustible board.
Diagram 1 Diagram 2

Regency®P36D Gas Log Fireplace
8
INSTALLATION
Note: 40-1/2" (1029mm) is the minimum
height for both flex termination or
Simpson Dura-Vent flueing.
Note: The unit does not have to be
completely enclosed in a chase. The
clearance on top of the unit is 0" to
thestandoffssocombustiblebuilding
materials can be laid directly on top
of the standoffs. You must maintain
1-1/2" (38mm) clearance from the
flueto combustiblematerials forflex
(1-1/4" for Simpson Dura-Vent ).
5) Use steel studs for framing where the
1-1/2" (38mm) clearance from the flue to
combustiblematerialcannotbemaintained,
e.g. front top header.
MANTEL LEG
CLEARANCES
Combustible mantel leg clearances as per
diagram below:
FRAMING AND
FINISHING
1) Determine the total thickness of facing
material (e.g. drywall plus ceramic tiles) to
allow the finished surface to be flush with
the front of the unit. Total facing thickness
canvaryfrom1/2"(13mm)to1-1/4"(32mm)
thick.
Maximum
38mm
projection
at 51mm
minimum
clearance.
3) For exterior walls, insulate the enclosure to
the same degree as the rest of the house,
apply vapour barrier and drywall, as per
local installation codes. (Do not insulate
the fireplace itself.)
4) The top of the unit must not be closer than
32" (813mm) to the ceiling.
2) Frame in the enclosure for the unit with
framing material.
Install Side Nailing Strips, Top Facing
Support, and Top Standoffs before
unit is slipped into position. See "Unit
Assembly Prior to Installation" section
for assembly details.
NOTE:
When using the Premium Flush Front
option, a finishing trim (962mm cover)
needs to be installed to cover the
spacers.
Maintain a physical gap between lining
andspacers2-5mm.(5mmclearanceto
framing each side).
Standard Framing Dimensions
A B C D
36-1/4" 37-1/4" 17-3/8" 46-1/2"*
921mm 946mm 432mm 1182mm*
Framing Dimensions with
Premium Flush Front Option
A B C D
37-1/4" 37-1/4" 17-3/8" 46-1/2"*
944mm 946mm 432mm 1182mm*
* 'D' is Minimum height to combustible ma-
terials including the Minimum 2-1/2" (64mm)
Top clearance to the Horizontal Flue, see flue
clearances in section "Clearances."
Premium Flush Front Framing
Do not use combustible material as lining (eg.
timber) around the fireplace as shown in the
shaded area in the diagram below.

Regency®P36D Gas Log Fireplace 9
INSTALLATION
FLUEING
INTRODUCTION
The P36D uses the "balanced flue" technology
CoAxial system. The inner liner flues products
of combustion to the outside while the outer
liner draws outside combustion air into the
combustion chamber thereby eliminating the
needtouseheatedroomairforcombustionand
losing warm room air up the chimney.
Note: These flue pipes must not be
connected to any other appliance.
The gas appliance and flue system must be
flued directly to the outside of the building,
and never be attached to a chimney serving a
separate solid fuel or gas burning appliance.
Each Co Axial Flue gas appliance must use
it's own separate flue system. Common flue
systems are prohibited.
Beforetheunitisslidintoposition,installthe
provided spacers to the side of the fireplace
as follows;
1) Align the screw locations on spacer with
screw locations on the side of the firebox
and secure in place using 3 screws.
2) Repeat for other side.
NOTE: The side nailing strips are to be in-
stalled to the spacer after the spacer
is attached to the unit.
Spacer
Left Side Shown
Premium Flush Front
Spacer Installation
Side
Nailing Strips
"C" Screw Position:
For a facing material depth of 1-1/4" (32mm),
the top facing support must be reversed.
UNIT ASSEMBLY
PRIOR TO
INSTALLATION
TheTopFacingSupport,theSideNailingStrips
and the 2 Top Standoffs must be correctly
positioned and attached to the top before unit
is slipped into position.
Top Standoff Assembly
The top standoffs are shipped in a flat position
and must be folded into shape and attached.
1) Removethestandoffsfromthefireplacetop.
2) Takeeachstandoffandbendintothecorrect
shape. Bend up at the bend lines until the
screw holes in the standoff and the pre-
punched screw holes on the fireplace top
line up.
3) Attach the standoff securely to the top with
2screwsperstandoff(onoppositecorners).
Top Facing Support
Side Nailing Strips
Determine the total thickness of facing material
(e.g. drywall plus ceramic tiles) to allow the
finished surface to be flush with the front of the
unit. Total facing thickness can vary from 1/2"
(13mm) to 1-1/4" (32mm) thick.
The Top Facing Support can be mounted in 3
different positions depending on the thickness
of the facing material.
2) Fold out the two nailing strips on each side.
Screw
Position Facing Material Depth
A 1/2" / 13mm
B 7/8" / 22mm
C*1-1/4" / 32mm
*For "C" screw position the top facing
support is reversed.
1) Mount Top Facing Support using the 3
suppliedscrewsintothethreepre-punched
screwholes on the top front of the unit. Use
holepositionsA, B, or C depending on your
facing depth.

Regency®P36D Gas Log Fireplace
10
INSTALLATION
EXTERIOR FLUE TERMINATION LOCATIONS
Minimum clearances required for balanced flue terminals or
the flue terminals of outdoor appliances
according to AS5601-2004 (AGA gas installation code) or NZS 5261 (New Zealand)
Minimum
Clearance (mm)
a Below eaves, balconies or other projections:
- Appliances up to 50 MJ/h input 300
- Appliances over 50 MJ/h input 500
b From the ground or above a balcony 300
c From a return wall or external corner 500
d From a gas meter (M) 1000
e From an electricity meter or fuse box (P) 500
f From a drain or soil pipe 150
g Horizontal from any building structure (unless appliance is approved
for closer installation) or obstruction facing a terminal 500
h From any other flue terminal, cowl or combustion air intake 500
j Horizontally from an openable window, door, or non-mechanical air inlet, or
any other opening into a building, with the exception of sub-floor ventilation
(see also Note (I)):
- Appliances up to 150 MJ/h input 500
- Appliances over 150 MJ/h input 1500
k Vertically below an openable window, door, or non-mechanical air inlet,
or any other opening into a building, with the exception of sub-floor ventilation
(see also Note (I)): see table below
NOTES:
(I) For mechanical air inlets, including spa blowers, the clearance 'j' and 'k' shall be 1500 mm in all cases.
(II) All distances shall be measured vertically or horizontally along the wall to a point in line with the nearest par to of the terminal.
(III)Prohibited area below electricity meter or fuse box extends to ground level.
(IV)A flue terminal of this type shall not be located under a roofed area unless the roofed area is fully open on at least two sides and a free flow
of air at the appliance is achieved.
Clearance 'k' in mm
Space Heaters All Other Appliances
Up to 50 MJ/h Up to 50 MJ/h input Over 50 MJ/h input Over 150 MJ/h input
input to 150 MJ/h input
150 500 1000 1500

Regency®P36D Gas Log Fireplace 11
INSTALLATION
FLUEING
Regency®Direct Vent System (Flex)
Horizontal Terminations Only
These flueing systems, in combination with the P36D Room Sealed Gas Fireplace, have been tested and listed as a Direct Vent type flue system
by theAustralian GasAssociation. The location of the termination cap must conform to the requirements in the Flue Terminal Locations diagram in
section "Exterior Flue Termination Locations."
Regency®Direct Vent (Flex) System
Termination Kit (Part # 946-515) includes all
the parts needed to install the P36D with a
maximum run of 1200mm.
1) 175mm dia. flexible liner (1200mm length)
2) 100mm dia. flexible liner (1200mm length)
3) spring spacers (4)
4) thimble (2)
5) AstroCap termination cap (1)
6) screws (12)
7) tube of Mill Pac (1)
8) plated screws (8)
9) screws #8 x 1-1/2" Drill Point, Stainless
Steel (4)
If longer runs are needed, the Regency®
DirectVentsystem(Flex)#946-516includes
all the parts needed to install the P36D with
a maximum 3.0m run.
1) 175mm dia. flexible liner (3.0m length)
2) 100mm dia. flexible liner (3.0m length)
3) spring spacers (7)
4) thimble (2)
5) AstroCap termination cap (1)
6) screws (12)
7) tube of Mill Pac (1)
8) plated screws (8)
9) screws #8 x 1-1/2" Drill Point, Stainless
Steel (4)
Notes:
1) Liner sections should be continuous without any joints or seams.
2) Only Flex pipe purchased from Regency®may be used for Flex installations.
3) If you are installing the P36D into a Regency®Mantel Kit, use the minimum horizontal vent height (centre-line of 1029mm). Remember
to include the mantel base in your calculations and to maintain the 32mm clearance (38mm with Flex) to the underside of the mantel
top.
6-7/8"
(173mm)
dia. Flue pipe
4" (102mm)
dia. flue pipe
spring spacer
Termination Cap
(Part# 946-578/P)
AstroCap
(patented)
Wall Thimble

Regency®P36D Gas Log Fireplace
12
INSTALLATION
Simpson Dura-Vent
Co-Axial Flue GS
SIMPSON DURA-VENT FLUEING COMPONENTS LIST
All Simpson Dura-Vent components are available directly from Regency®.
Part # Description Part # Description Part # Description
SIMPSON DURA-VENT FLUEING
Horizontal or Vertical Terminations
TheSimpsonDura-VentCoAxialFlueSystemoffersacompletelineofcomponentpartsforinstallationofbothhorizontalandverticalinstallations.Many
items are offered in decorative black, as well as galvanized finish. We recommend using the galvanized finish for installation with the P36D.
The minimum components required for a basic
horizontal termination are:
1 Horizontal Termination Cap
1 90oElbow
1 Flue Adaptor
1 Wall Thimble
1 Length of pipe to suit wall thickness
(see chart)
971 Horiz. Termination Kit includes: 90o
black elbow, wall thimble cover, horiz. square
termination cap, 24" black pipe, and 11" -14"
5/8" adjustable black pipe.
970 Basic Horiz. Termination. Kit includes:
90
oblackelbow,wallthimblecover,horiz.
square termination cap.
978 Vert. Termination Kit includes 0/12 -
6/12 pitch adjustable flashing, storm
collar, low profile term. cap.
908B 6" Pipe Length - Black
907B 9" Pipe Length - Black
906 12" Pipe Length - Galv.
906B 12" Pipe Length - Black
904 24" Pipe Length - Galv.
904B 24" Pipe Length - Black
903 36" Pipe Length - Galv.
903B 36" Pipe Length - Black
902 48" Pipe Length - Galv.
902B 48" Pipe Length - Black
911B 11"-14 5/8" Adjustable Pipe Length
- Black
917B 17"- 24" Adjustable Length - Black
945 45O Elbow - Galv.
945B 45OElbow - Black
945G 45O Elbow - Swivel - Galv.
945BG 45OElbow - Swivel - Black
990 90O Elbow - Galv.
990B 90OElbow - Black
990G 90O Elbow - Swivel - Galv.
990BG 90OElbow - Swivel - Black
991 High Wind Termination Cap (Vertical)
980 Vertical Termination Cap
984 Horizontal Square Termination Cap
985 Horiz. Square High Wind
Termination Cap
982 Snorkel - 14" Rise Termination Cap
981 Snorkel - 36" Rise Termination Cap
940 Wall Thimble - Support/Box
941 Cathedral/Ceiling - Support/Box
3951 Brass Trim for Wall Thimble/Ceiling
Sup.
963 Firestop Spacer
943 Flashing 0/12-6/12
943S Flashing 7/12-12/12
953 Storm Collar
950 Vinyl Siding Standoff
988 Wall Strap
942 Wall Thimble
Parts not supplied by Dura-Vent
946-506/P Flue Guard (Optional)
510-994 Dura-Vent Flue Adaptor
640-530/P Riser Flue Terminal
946-205 VinylSidingShieldforRiserFlue
Terminal
If a Vinyl Siding Standoff is required (it must
be used with vinyl siding), measure to outside
surface of wall without siding and add 2
inches.
Flat Wall Installation
Wall Thickness
(mm) Vent Length Required (mm)
102mm - 140mm 152mm
178mm - 216mm 229mm
254mm - 292mm 305mm
229mm - 368mm 279mm - 371mm Adj. Pipe
381mm - 599mm 432mm - 607mm Adj.
Corner Installation
Wall Thickness
(mm) Vent Length Required (mm)
83mm - 172mm 279mm - 371mm Adj. Pipe
197mm - 412mm 432mm - 610mm Adj. Pipe
189mm - 222mm 152mm + 310mm
229mm + 229mm
108mm - 146mm 152mm + 229mm
Wall thickness is measured from the back
standoffs to the inside mounting surface of
terminationcap.Forsidingotherthanvinylfurring
strips may be used, instead of the vinyl siding
standoff, to create a level surface to mount the
flueterminal.TheTerminalmustnotberecessed
intosiding.Measurethewallthicknessincluding
furring strips.

Regency®P36D Gas Log Fireplace 13
INSTALLATION
FLUEING ARRANGEMENTS - HORIZONTAL TERMINATIONS
SIMPSON DURA-VENT DIRECT VENT GS SYSTEM and
REGENCY®DIRECT VENT SYSTEM (FLEX)
The diagram shows all allowable combinations of vertical runs with horizontal terminations, using one 90oelbow (two 45o elbows equal
one 90oelbow).
Note: Must use optional flue adapter (Part # 510-994) when using Simpson Dura-Vent pipe.
Simpson Dura-Vent
4" (102mm) inner diameter
6-5/8" (168mm) outer diameter
Regency®Flex Vent
4" (102mm) inner diameter
6-7/8" (175mm) outer diameter
• Maintain clearances to combustibles as listed in section "Clearances."
• Horizontal flue must be supported every 3 feet (0.9 meters).
• Firestops are required at each floor level and whenever passing through a wall.
Aflueguardshouldbeusedwhenever
the termination is lower than the
specified minimum or as per local
codes.
Note: Regency®Co Axial Flue System
(Flex) is only approved for
horizontal terminations.

Regency®P36D Gas Log Fireplace
14
FLUEING ARRANGEMENTS - HORIZONTAL TERMINATIONS
SIMPSON DURA-VENT DIRECT FLUE GS SYSTEM and
REGENCY®CO AXIAL FLUE SYSTEM (FLEX)
The diagram below shows examples of horizontal termination arrangements using two 90oelbows (two 45o elbows equal one 90oelbow).
Note: 1) A maximum of two 90oelbows are permitted.
2) A minimum of 6 ft. (1.8m) vertical from base of unit is required if two 90oelbows are used.
3) Minimum distance between elbows is 2 ft. (0.6m).
4) Determine the permitted range of horizontal termination arrangements by using chart in section "Simpson Dura-vent
Flueing." and deducting 3 ft. (0.9m) from the maximum horizontal distance for the second 90oelbow.
Simpson Dura-Vent
4" inner diameter
6-5/8" outer diameter
• Maintain clearances to combustibles as listed in section "Clearances."
• Horizontal flue must be supported every 3 feet (0.9 meters).
• Firestops are required at each floor level and whenever passing through a wall.
A flue guard should be used whenever the
terminationislowerthanthespecifiedminimum
or as per local codes.
Iflength"B"isincreased,length"A"mustbe
decreased by a corresponding amount.
INSTALLATION

Regency®P36D Gas Log Fireplace 15
INSTALLATION
FLUEING ARRANGEMENTS - VERTICAL TERMINATIONS
SIMPSON DURA-VENT CO AXIAL FLUE GS SYSTEM
• Vent must be supported at offsets.
• Firestops are required at each floor level and whenever passing through a wall.
• Maintain clearances to combustibles.
Note: Must use optional rigid pipe adaptor when using Simpson Dura-Vent pipe (Part # 510-994).
The shaded area in the diagram shows all allowable combinations of straight vertical and offset to vertical terminations, using two 90oelbow, with
Simpson Dura-Vent flue systems for Propane and Natural Gas.

Regency®P36D Gas Log Fireplace
16
TheP36Disapprovedfora 37ft.(11.3m) straightvertical, withSimpson
Dura-Vent Co Axial Flue GS flue systems for LPG and NG, as per the
diagram 3.
The shaded area in the diagram 3 shows all allowable combinations of
straight vertical and offset to vertical terminations with Simpson Dura-
Vent Co Axial Flue GS flue systems for LPG and NG. Maximum two
45oelbows allowed.
• Flue must be supported at offsets
• Firestops are required at each floor level and whenever passing
through a wall.
• Maintain clearances to combustibles as listed in section
"Clearances."
Diagram 3
INSTALLATION

Regency®P36D Gas Log Fireplace 17
INSTALLATION
Diagram 5
8) Slide the appliance and flue assembly
towards the wall carefully inserting the
flue pipe into the flue cap assembly. It is
important that the flue pipe extends into
the flue cap sufficient distance so as to
result in a minimum pipe overlap of 1-1/4
inches.Securetheconnectionbetweenthe
flue pipe and the flue cap by attaching the
two sheet metal strips extending from the
flue cap assembly into the outer wall of the
flue pipe. Use the two sheet metal screws
provided to connect the strips to the pipe
section. See Diagram 4.
9) Install wall thimble in the center of the
10" square and attach with wood screws
(Diagram 5).
HORIZONTAL
TERMINATIONS
Install the flue system according to the
manufacturer's instructions included with
the components.
1) Set the unit in its desired location. Check
to determine if wall studs or roof rafters
are in the way when the flueing system is
attached. If this is the case, you may want
to adjust the location of the unit. Rough in
the gas preferably on the right side of the
unit and the electrical (junction block is on
the left side) on the left.
2) CoAxialFlue pipeandfittings are designed
with special twist-lock connections to
connecttheflueingsystemtotheappliance
flue outlet. A twist-lock appliance adaptor
is an available option that must be used in
conjunctionwiththeSimpsonDura-VentCo
Axial Flue GS system.
3) Put a bead of silicone inside the outer
section of the adapter and a bead of Stove
Mate on the inner collar. Slip the adapter
over the existing inner and outer flue collar
and fasten to the outer collar only with the
3 supplied screws (drilling pilot holes will
make this easier). Level the fireplace and
fastenittotheframingusingnailsorscrews
through the nailing strips.
4) Assemble the desired combination of pipe
and elbows to the appliance adaptor and
twist-lock for a solid connection.
Note:
a) Twist-lockprocedure:Fourindentations,
locatedon thefemaleendsofpipesand
fittings, are designed to slide straight
onto the male ends of adjacent pipes
and fittings, by orienting the four pipe
indentations so they match and slide
in to the four entry slots on the male
ends,Diagram1.Pushthepipesections
completely together, then twist-lock
one section clockwise approximately
one-quarter turn, until the two sections
arefullylocked.Thefemalelockinglugs
will not be visible from the outside, on
the Black Pipe or fittings. They may be
located by examining the inside of the
female ends.
Diagram 1
b) Horizontalrunsoffluemustbesupported
everythreefeet.Wallstrapsareavailable
for this purpose.
5) Markthewallfora254mmx254mm square
hole. The center of the square hole should
line up with the centerline of the horizontal
pipe. Cut and frame the 10 inch square
hole in the exterior wall where the flue will
be terminated. If the wall being penetrated
isconstructed of non-combustible material,
i.e.masonryblockorconcrete,a7"(178mm)
dia. (7-1/2"(191mm) dia. for flex) hole is
Diagram 2
flue adaptor.
Note:
a) Thehorizontal run of flue must be level,
or have a 1/4 inch rise for every 1 foot
of run towards the termination. Never
allow the flue to run downward. This
couldcausehightemperaturesandmay
present the possibility of a fire.
b) The location of the horizontal flue
terminationonanexteriorwallmustmeet
all local and national building codes,
and must not be blocked or obstructed.
For External Flue Terminal Locations,
see diagram in section "Exterior Flue
Termination Locations."
6) The arrow on the flue cap should
be pointing up. Insure that the 1-1/2"
clearances to combustible materials are
maintained. Install the termination cap,
diagram 5.
The four wood screws provided should
be replaced with appropriate fasteners for
stucco, brick, concrete, or other types of
sidings.
Note: If installing termination on a siding
covered wall, a vinyl siding standoff
or furring strips must be used to
ensure that the termination is not
recessed into the siding.
7) Before connecting the horizontal run of
flue pipe to the flue termination, slide the
Wall Thimble (Part # 620-926) over the flue
pipe.
Note: Applysealant"Mill-Pac"toinnerpipe
andhightemperaturesiliconesealant
to outer pipe on every
twist-lock joint.
acceptable.
Note: With
Dura-Vent,
theminimum
height is
achieved by
installing a
90oelbow
directlytothe
Diagram 4
Diagram 3

Regency®P36D Gas Log Fireplace
18
Offset Chart
Galvanizedpipeisdesirableabovetheroofline
duetoitshighercorrosionresistance.Continue
toaddpipesectionsthroughtheflashinguntil
theheightofthefluecap meets theminimum
heightrequirementsspecifiedinDiagram5or
local codes. Note that for steep roof pitches,
the verticalheight mustbe increased. A poor
draft, or down drafting can result from high
wind conditions near big trees or adjoining
roof lines, in these cases, increasing the flue
height may solve the problem.
7) Ensure flue is vertical and secure the base
of the flashing to the roof with roofing rails,
slide storm collar over the pipe section and
seal with a mastic.
8) Install the vertical termination cap by twist-
locking it.
Note: Anyclosetsorstoragespaces,which
the flue passes through must be
enclosed.
Diagram 3
Diagram 5
Diagram 1
Diagram 2
Note: Apply sealant "Mill-Pac" to inner
pipe and high temperature silicone
sealant to outer pipe on every twist-
lock joint.
VERTICAL
TERMINATIONS
1) Maintain the 1-1/4"
clearances (air spaces)
to combustibles when
passing through ceilings,
walls, roofs, enclosures,
attic rafter, or other nearby
combustible surfaces.
Do not pack air spaces
with insulation. Check
section "Simpson Dura-
vent Flueing" for the
maximum vertical rise of
the flueing system and the
maximumhorizontaloffset
limitations.
2) Setthegasapplianceinitsdesiredlocation.
Dropaplumbbobdownfromtheceilingtothe
positionoftheapplianceflueexit,andmark
the location where the flue will penetrate
the ceiling. Drill
a small hole at
his point. Next,
drop a plumb
bob from the
roof to the hole
previouslydrilled
in the ceiling,
and mark the
spot where
the flue will
penetrate the
roof. Determine
if ceiling joists,
roof rafters or
other framing
3) A Firestop spacer must be installed in the
floor or ceiling of every level. To install the
Firestop spacer in a flat ceiling or wall,
cut a 10 inch square hole. Frame the hole
as shown in Diagram 3 and install the
firestop.
4) Assemble the desired lengths of pipe and
elbows. Ensure that all pipes and elbow
connections are in the fully twist-locked
position and sealed.
5) Cut a hole in the roof centered on the small
drilledhole placed in the roof in Step 2.The
hole should be of sufficient size to meet
the minimum requirements for clearance
to combustibles of 1-1/2". Slip the flashing
undertheshingles(shinglesshouldoverlap
half the flashing) as per Diagram 4.
Roof Pitch Minimum Flue Height
Feet Meters
flat to 7/12 2 0.61
over 7/12 to 8/12 2 0.61
over 8/12 to 9/12 2 0.61
over 9/12 to 10/12 2.5 0.76
over 10/12 to 11/12 3.25 0.99
over 11/12 to 12/12 4 1.22
over 12/12 to 14/12 5 1.52
over 14/12 to 16/12 6 1.83
over 16/12 to 18/12 7 2.13
over 18/12 to 20/12 7.5 2.29
over 20/12 to 21/12 8 2.44
Diagram 4: The upper half of the flashing is
installed under the roofing material and not
nailed down until the chimney is installed.
This allows for small adjustments.
6) Continue to assemble pipe lengths.
Note: If an offset is necessary in the attic
to avoid obstructions, it is important
to support the flue pipe every 3 feet,
to avoid excessive stress on the
elbows, and possible separation.
Wall straps are available for this
purpose (Diagram 2).
will obstruct the flueing system. You
may wish to relocate the appliance or to
offset,asshowninDiagram2toavoidcutting
load bearing members.
INSTALLATION

Regency®P36D Gas Log Fireplace 19
Conversion Kit #513-968 from NG to LPG
THIS CONVERSION MUST BE DONE BY A QUALIFIED GAS FITTER IF IN DOUBT DO NOT DO THIS CONVERSION !!
1) Shut off the gas supply.
2) Remove the louvers (and bay door if it is
installed).
3) Open the flush door and remove the door.
4) Remove the logs and embers (if used).
5) Remove the 2 screws holding the Burner
Remove the 2 screws, push Burner Assembly
to the left and lift out.
6) Pull off the pilot cap to expose the pilot
orifice.
7) Unscrew the pilot orifice with the allen key;
then replace with the LPG pilot orifice and
the pilot cap, provided in the kit.
8) Remove burner orifice with a 1/2" wrench.
Useanother wrench to holdontothe elbow
behind the orifice. Discard orifice.
Burner Orifice
9) Reinstall new burner orifice LPG stamped
#52 and tighten.
10) Turn control knob to the “OFF” position.
Fig.1
11) Remove the black
protection cap by hand
from the hi-low knob
(Fig.1).
Fig.2
14) Flip the screw (Fig. 3).
Fig.4
Fig.3
15) UsingtheAllen wrench
as shown in Fig.4,
rotate the screw clock-
wise until snug, do not
overtighten.
12) Inserta5/32”or4mmAllen
wrenchintothehexagonal
key-way of the screw
(Fig. 2), rotate it counter-
clockwiseuntilitisfreeand
extract it.
13) Check that the screw is
clean and if necessary
remove dirt.
Conversion Kit Contains:
Qty. Part # Description
1 910-037 LPG Injector
(Pilot Orifice)
1 904-390 Burner Orifice #52
1 918-590 Decal "Converted
to LPG"
1 908-528 Red "LPG" label
1 904-529 5/32" Allen Key
1 918-546 Instruction Sheet
Assembly to the firebox base. Push the Burner
Assembly to the left and lift out.
WARNING!
Do not over tighten the screw.
Recommended to
grip the wrench by the short side.
16) Verify that if the conversion is from NG to
LPG,thescrew mustbere-assembledwith
the red o-ring visible (Fig. 5).
LPG Configuration
Red o-ring visible
Fig.5
17) Re-assemble the
blackprotectioncap
(Fig. 6).
Fig.6
WARNING!
Also check that the pilot and main
burner injectors are appropriate for
the gas type.
19) Attach clear label "This unit has been
converted to LPG" near or on the serial
# decal.
20) Replace yellow "NG" label with red "LPG"
label.
21) Check for gas leaks.
22) Check inlet and outlet pressures.
23) Check operation of flame control.
24) Check for proper flame appearance and
glow on logs.
18) Reverse step 2).
INSTALLATION

Regency®P36D Gas Log Fireplace
20
GAS PIPE PRESSURE
TESTING
The appliance must be isolated from the gas
supply piping system by closing its individual
manual shut-off valve during any pressure
testing of the gas supply piping system at
test pressures equal to or less than 1/2 psig.
(3.45 kPa). Disconnect piping from valve at
pressures over 3.45 kPa.
The manifold pressure is controlled by a
regulator built into the gas control, and should
be checked at the pressure test point.
Note: To properly check gas pressure, both
inlet and manifold pressures should
becheckedusingthevalvepressure
ports on the valve.
1) Make sure the valve is in the "OFF"
position.
2) Loosen the "IN" and/or "OUT" pressure
tap(s), turning counterclockwise with a
1/8" wide flat screwdriver.
3) Attach manometer to "IN" and/or "OUT"
pressure tap(s) using a 5/16" ID hose.
P36D-NG System Data
For 0 to 4500 feet altitude
Burner Inlet Orifice Sizes: #37( 2.65mm)
Max. Input Rating 33 Mj/h
Supply Pressure min. 1.13 kPa
Manifold Pressure
(High) 1.0 kPa
Electrical: 240 V A.C. System.
Circulation Fan: variable speed 130 CFM.
Log Set: Ceramic fibre, 7 per set.
Flue System: Simpson Dura-Vent Direct
Flue System or Regency®Direct
Flue System (Flex)
P36D-LPG System Data
For 0 to 4500 feet altitude
Burner Inlet Orifice Sizes: #52 (1.61 mm)
Max. Input Rating 31 Mj/h
Supply Pressure min. 2.75 kPa
Manifold Pressure
(High) 2.60 kPa
Electrical: 240 V A.C. System.
Circulation Fan: variable speed 130 CFM.
Log Set: Ceramic fibre, 7 per set.
Flue System: Simpson Dura-Vent CoAxial
Flue System
PILOT ADJUSTMENT
Periodically check the pilot flames. Correct
flame pattern has three strong blue flames:
1 flowing around the thermopile, 1 around
the thermocouple and 1 flowing across the
burner (it does not have to be touching the
burner).
Note: Ifyouhaveanincorrectflamepattern,
contact your Regency®dealer for
further instructions.
Incorrect flame pattern will have small,
probably yellow flames, not coming into
proper contact with the rear burner or
thermopile or thermocouple.
AERATION
ADJUSTMENT
The air shutter can be adjusted by moving the
adjustingwireupordown.Thewireisaccessed
throughthebottomlouvreopening.Opentheair
shutter for a blue flame or close for a yellower
flame. The burner aeration is factory set but
may need adjusting due to either the local gas
supplyoraltitude.Thisadjustmentisperformed
by the gas fitter.
Minimum Air Shutter Opening:
5 mm NG
6.4 mm LPG
CAUTION:Carbonwillbeproducedifairshutter
is closed too much.
Note: Any damage due to carboning
resulting from improperly setting
theaerationcontrols isNOT covered
under warranty.
Closed - Tall yellow
Open - Short Blue
GAS LINE
INSTALLATION
The gas line can be brought through either the
right or the left side of the appliance. The gas
valve is situated on the right hand side of the
unit and the gas inlet is on the right hand side
of the valve.
Note: If the gas line is being installed from
theleft side, be sureto leave room to
accommodate servicing of the fan.
The gas line connection may be made of
rigid pipe, copper pipe or an approved flex
connector. (If you are using rigid pipe, ensure
that the valve can be removed for servicing.)
Sincesomemunicipalities haveadditional local
codesit is alwaysbestto consult with yourlocal
authorities and theAS5601-2004 or NZS 5261
installation code.
When using copper or flex connectors use only
approved fittings. Always provide a union so
that gas lines can be easily disconnected for
servicing. Flare nuts for copper lines and flex
connectors are usually considered to meet this
requirement.
Important:Alwayscheckforgasleakswitha
soapandwatersolutionorgasleakdetector.
Do not use open flame for leak testing.
INSTALLATION
