Regency Horizon HZ42STEPV Quick start guide

WARNING:
Iftheinformationintheseinstructionsarenotfollowedexactly,
a fire or explosion may result causing property damage,
personal injury or loss of life.
FOR YOUR SAFETY
Do not store or use gasoline or other flammable vapors and
liquids in the vicinity of this or any other appliance.
Installation and service must be performed by a qualified
installer, service agency or the gas supplier.
FOR YOUR SAFETY
What to do if you smell gas:
Do not try to light any appliance
Do not touch any electrical switch:
do not use any phone in your
building.
Immediately call your gas supplier
from a neighbour's phone. Follow
the gas supplier's instructions.
If you cannot reach your gas
supplier, call the fire department.
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
918-949
Regency Horizon™HZ42STEPV
Gas Fireplace
06/29/11
Owners &
Installation Manual
www.regency-fire.com
Tested by:
Installer
Installer
: Please complete the details on the back cover
: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
MODELS: HZ42STEPV-NG Natural Gas
HZ42STEPV-LP Propane

2Regency Horizon™ HZ42STEPV Gas Fireplace 2
To the New Owner:
Congratulations!
You are the owner of a state-of-the-art Gas Fireplace by REGENCY®. The HZ42STEPV
has been designed to provide you with all the warmth and charm of a fireplace at the flick
of a switch. The model HZ42STEPV has been approved by Warnock Hersey/Intertek for
both safety and efficiency. As it also bears our own mark, it promises to provide you with
economy, comfort and security for many trouble free years to follow. Please take a moment
now to acquaint yourself with these instructions and the many features of your Regency®
Fireplace.

Regency Horizon™ HZ42STEPV Gas Fireplace 33
MANUFACTURED MOBILE HOME REQUIREMENTS
INFORMATION FOR MOBILE/MANUFACTURED HOMES AFTER FIRST SALE
This Regency®product has been tested and listed by Warnock Hersey/Intertek as a Direct Vent Wall Furnace to the following
standards: VENTED GAS FIREPLACE HEATERS ANSI Z21.88a-2007 / CSA 2.33a-2007 and GAS-FIRED APPLIANCES FOR
USE AT HIGH ALTITUDES CAN / CGA 2.17-M91.
ThisDirectVentSystemAppliancemustbeinstalledinaccordancewiththemanufacturer'sinstallationinstructionsandtheManufactured
Home Construction and Safety Standard, Title 24 CFR, Part 3280, or the current Standard of Fire Safety Criteria for Manufactured
Home Installations, Sites, and Communities ANSI/NFPA 501A, and with CAN/CSA Z240-MH Mobile Home Standard in Canada.
This appliance installation must comply with the manufacturer's installation instructions and local codes, if any. In the absence of
local codes follow the current National Fuel Gas Code,ANSI Z223.1 and the current National Electrical Code ANSI/NFPA70 in the
U.S.A., and the current CAN/CGA B149 Gas Installation Code and the current Canadian Electrical Code CSA C22.1 in Canada.
This appliance comes equipped with a dedicated #8 Ground Lug for attachment of the ground wire to the steel chassis as applicable
to local codes.
The appliance, when installed, must be electrically grounded in accordance with local codes or, in the absence of local codes, with
the National Electrical Code, ANSI/NFPA 70, or the Canadian Electrical Code, CSA C22.1.
This appliance may only be installed in an aftermarket permanently located, manufactured (U.S.Aonly) or mobile home, where not
prohibited by local codes.
This appliance can only be used with the type of gas indicated on the rating plate. This appliance is not convertible for use with
other gases.
Ensure that structural members are not cut or weakened during installation.

4Regency Horizon™ HZ42STEPVPV Gas Fireplace
TABLE OF CONTENTS
SAFETY LABEL
Copy of Safety Decal.....................................................5
REQUIREMENTS
MA Code - CO Detector.................................................6
DIMENSIONS
Unit Dimensions ............................................................7
INSTALLATION
Important Message ......................................................8
Before You Start ............................................................8
General Safety Information............................................8
Installation Checklist......................................................9
Locating Your Gas Fireplace .........................................9
Clearances ..................................................................10
Non-Combustible Requirements .................................10
Mantel Leg Clearances................................................11
Mantel Clearances.......................................................11
Unit Assembly Prior To Installation..............................12
Standoff Assembly...............................................12
Horizontal vent Deflector installation...........................12
Nailing Strips........................................................12
Framing & Finishing.....................................................13
Framing dimensions....................................................14
Framing dimensions with negative vent Run ..............15
Vent Restrictor Position...............................................16
Gas Power Vent Installation ........................................17
Rigid Pipe only.............................................................17
Exterior Vent Termination Requirements.....................18
Venting Arrangements for Horizontal Terminations .....19
Pipe connection from terminal to unit..........................22
Power vent wiring diagram..........................................25
4” x 6-5/8” Rigid Pipe Cross Reference Chart.............26
High Elevation Gas Line Installation............................28
Pilot Adjustment...........................................................28
Gas Pipe Pressure Testing..........................................28
886 S.I.T. Valve Description.........................................28
Aeration Adjustment ....................................................28
Optional fan Wiring Diagram ......................................29
Without ProFlame GTMF system................................29
Optional Remote Control.............................................30
Optional accent lighting Wiring Diagram ....................30
Wall mount receiver installation...................................31
Battery installation......................................................33
GT remote Installation.................................................33
GTM remote installation ..............................................34
GTMF remote installation............................................35
Optional Reflective Panel Installation..........................37
Optional light Installation .............................................38
Glass Crystals or optional ceramic stones ..................41
Optional Pebble /crystal Installation for Firebox Base.42
Glass door Installation.................................................43
Faceplate Installation...................................................44
OPERATING INSTRUCTIONS
Operating
Instructions..................................................................46
First Fire ......................................................................46
Lighting
Procedure....................................................................46
Shutdown ....................................................................46
Procedure....................................................................46
Normal Operating
Sounds of
Gas Appliances............................................................46
Maintenance Instructions.............................................47
General Vent
Maintenance................................................................47
Glass Gasket...............................................................47
Glass Door...................................................................47
Glass Replacement .............................................47
Copy of Lighting Plate Instructions..............................48
Glass Door Removal ...................................................49
Valve Tray Replacement..............................................50
Main Assembly ............................................................52
Accessories.................................................................53
The Warranty: Limited Lifetime ...................................55
WARRANTY

Regency Horizon™ HZ42STEPV Gas Fireplace 5
SAFETY LABEL
Thisisacopyofthelabelthataccompanieseach
HZ42STEPV-NG and HZ42STEPV-LP Direct
Vent Gas Fireplace. We have printed a copy of
the contents here for your review.
NOTE: Regency®units are constantly being
improved. Check the label on the unit and if
there is a difference, the label on the unit is the
correct one.
FortheState of Massachusetts, installation
and repair must be done by a plumber or
gasfitter licensed in the Commonwealth of
Massachusetts.
FortheStateofMassachusetts,flexiblecon-
nectorsshallnotexceed36inchesinlength.
For the State of Massachusetts, the appli-
ances individual manual shut-off must be a
t-handle type valve.
The State of Massachusetts requires the
installation of a carbon monoxide alarm in
accordancewithNFPA720andaCOalarm
withbatterybackupinthesameroomwhere
the gas appliance is installed.
DO NOT REMOVE THIS LABEL / NE PAS ENLEVER CETTE ÉTIQUETTE
376
376
DOOR SEAL: Please
check that the door is
properly sealed
FPI Fireplace Products International Ltd. Delta, BC, Canada
Minimum Clearances to Combustibles /
Degagement Minimum De Materiaux Combustibles
Serial No./ No de serie
918-950
MAY BE INSTALLED IN MANUFACTURED (MOBILE) HOMES AFTER FIRST SALE.
Listed:
Certified for/Certifi e pour:
Tested to:
VENTED GAS FIREPLACE HEATER /
CANADA and U.S.A.
FOYER AU GAZ À ÉVACUATION
é
CAN/CGA-2.17-M91,ANSI Z21.88a-2007/CSA 2.33a-2007
4001172
Electrical supply / Électrique 115VAC, 2.5 A, 60Hz.
NOT FOR USE WITH SOLID FUELS. /
NE PAS UTILISER AVEC DU COMBUSTIBLE SOLIDE.
Made in Canada/ Fabrique au Canada
Duplicate S/N
(See Instruction Manual for
detailed instructions)
ÉÉ
é
QUIP A L'UISINE POUR GAZ PROPANE
CONCU POUR ETRE POELE: Mod le HZ42STEPV-LP
PROPANE GAS: Model HZ42STEPV-LP
Minimum supply pressure
Manifold pressure high
Manifold pressure low
Orifice size
Minimum input
Maximum input
Altitude
NATURAL GAS: Model HZ42STEPV-NG APPAREIL FONCTIONNANT AU NATURAL GAS
CONCU POUR ETRE POELE: Mod le HZ42STEPV-NG
Pression d'allimentation minimum
Pression à la tubulure d' chappement lev e
Pression à la tubulure d' chappement basse
Grandeur de l'injecteur
D bit minimum selon
D bit maximum selon
l'altitude
Calorifique
Calorifique
é
ééé
é
é
é
5.0" (1.25 kPa)
3.5" (0.87 kPa)
1.6" (0.40 kPa)
#40 DMS
0-4500 ft/pi (0-1372 m)
WC/C.E.
WC/C.E.
WC/C.E.
17,500 Btu/h (5.13 kW)
26,000 Btu/h (7.62 kW)
Pression d'allimentation minimum
Pression à la tubulure d' chappement lev e
Pression à la tubulure d' chappement basse
Grandeur de l'injecteur
D bit minimum selon
D bit maximum selon
l'altitude
Calorifique
Calorifique
ééé
é
é
é
12“ WC/C.E (2.98 kpa)
WC/C.E.
WC/C.E.
19,500 Btu/h (5.71 kW)
24,500 Btu/h (7.18 kW)
10" (2..49 kPa)
6.4" (1.60 kPa)
#53 DMS
0-4500 ft/pi (0-1372 m)
Minimum supply pressure
Manifold pressure high
Manifold pressure low
Orifice size
Minimum input
Maximum input
Altitude
D
E
F
A
B
C
Side Walls
A 8” (203mm)
B 22” (559mm)
C 13" (330mm)
D 13” (330mm)
E 84" (2133mm)
F 36" (914mm)
Ceiling
Min. Mantel Height
Max. Mantel Depth
Alcove Width
Alcove Depth
This appliance must be installed in accordance with local codes, if any; if none, follow the National Fuel Gas Code, ANSI Z223.1, or Natural Gas and Propane Installation Code, CSA B149.1.
This appliance must be installed in accordance with the Standard CAN/CSAZ240 MH, Mobile Housing, in Canada, or with the Manufactured Home Construction and Safety Standard, Title 24 CFR, Part 3280, in
the United States, or when such a standard is not applicable,ANSI/NCSBCSA225.1/NFPA501A, Manufactured Home Installations Standard orANSI A119.2 ou NFPA 501C Standard for Recreational Vehicles
This appliance is only for use with the type of gas indicated on the rating plate and may be installed in an aftermarket, permanently located, manufactured (mobile) home where not prohibited by local codes. See
owner's manual for details. Listed for use with Power Vent Kit #946-705.
Installer l'appareil selon les codes ou règlements locaux, ou, en l'absence de tels règlements, selon les codes d'installationANSI Z223.1, National Fuel Gas Code ou CSA-B149.1 en vigueur.
Installer l'appareil selon la norme CAN/CSA-Z240, Série MM, Maison mobiles ou CAN/CSA-Z240 VC, Véhicules de camping, ou la norme 24 CFR Part 3280, Manufactured Home Construction and Safety
Standard. Si ces normes ne sont pas pertinentes, utilisez la norme ANSI/NCSBCS A225.1/NFPA 501A, Manufactured Home Installations Standard, ouANSI A119.2 ou NFPA501C Standard for Recreational
Vehicles. Homologué avec terminaison à évacuation mécanique 946-705
This vented gas fireplace heater is not for use with air filters. Ne pas utiliser de filtre à air avec ce foyer au gaz à évacuation.
FOR USE WITH GLASS DOORS CERTIFIED WITH THE APPLIANCE ONLY
Cet appareil doit être utilize uniquement avec le type de gaz indiqué sur la plaque signalétique. Cet appareil peut être installé dans une maison préfabriquée ou mobile (É.-U. seulement) installée à demeure si
les règlements locaux le permettent. Voir la notice de l'utilisateur pour plus de renseignements. Cet appareil ne peut pas être utilisé avec d'autres gaz sauf si une trousse de conversion certifiée est fournie.
POUR UTILISATION UNIQUEMENTAVEC LES PORTES EN VERRE CERTIFIÉESAVEC L'APPAREIL

6Regency Horizon™ HZ42STEPV Gas Fireplace
REQUIREMENTS
5.08: Modifications to NFPA-54, Chapter 10
(2) Revise 10.8.3 by adding the following additional requirements:
(a) For all side wall horizontally vented gas fueled equipment installed in every dwelling, building or structure used in whole or in part for
residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than
seven (7) feet above finished grade in the area of the venting, including but not limited to decks and porches, the following requirements shall
be satisfied:
1. INSTALLATION OF CARBON MONOXIDE DETECTORS. At the time of installation of the side wall horizontal vented gas fueled
equipment, the installing plumber or gasfitter shall observe that a hard wired carbon monoxide detector with an alarm and battery back-up is
installed on the floor level where the gas equipment is to be installed. In addition, the installing plumber or gasfitter shall observe that a battery
operated or hard wired carbon monoxide detector with an alarm is installed on each additional level of the dwelling, building or structure
served by the side wall horizontal vented gas fueled equipment. It shall be the responsibility of the property owner to secure the services of
qualified licensed professionals for the installation of hard wired carbon monoxide detectors
a. In the event that the side wall horizontally vented gas fueled equipment is installed in a crawl space or an attic, the hard wired carbon
monoxide detector with alarm and battery back-up may be installed on the next adjacent floor level.
b. In the event that the requirements of this subdivision can not be met at the time of completion of installation, the owner shall have a period of
thirty (30) days to comply with the above requirements; provided, however, that during said thirty (30) day period, a battery operated carbon
monoxide detector with an alarm shall be installed.
2. APPROVED CARBON MONOXIDE DETECTORS. Each carbon monoxide detector as required in accordance with the above provisions
shall comply with NFPA 720 and be ANSI/UL 2034 listed and IAS certified.
3. SIGNAGE. A metal or plastic identification plate shall be permanently mounted to the exterior of the building at a minimum height of eight
(8) feet above grade directly in line with the exhaust vent terminal for the horizontally vented gas fueled heating appliance or equipment. The
sign shall read, in print size no less than one-half (1/2) inch in size, "GAS VENT DIRECTLY BELOW. KEEP CLEAR OF ALL
OBSTRUCTIONS".
4. INSPECTION. The state or local gas inspector of the side wall horizontally vented gas fueled equipment shall not approve the installation
unless, upon inspection, the inspector observes carbon monoxide detectors and signage installed in accordance with the provisions of 248 CMR
5.08(2)(a)1 through 4.
(b) EXEMPTIONS: The following equipment is exempt from 248 CMR 5.08(2)(a)1 through 4:
1. The equipment listed in Chapter 10 entitled "Equipment Not Required To Be Vented" in the most current edition of NFPA 54 as adopted by
the Board; and
2. Product Approved side wall horizontally vented gas fueled equipment installed in a room or structure separate from the dwelling, building or
structure used in whole or in part for residential purposes.
(c) MANUFACTURER REQUIREMENTS - GAS EQUIPMENT VENTING SYSTEM PROVIDED. When the manufacturer of Product
Approved side wall horizontally vented gas equipment provides a venting system design or venting system components with the equipment, the
instructions provided by the manufacturer for installation of the equipment and the venting system shall include:
1. Detailed instructions for the installation of the venting system design or the venting system components; and
2. A complete parts list for the venting system design or venting system.
(d) MANUFACTURER REQUIREMENTS - GAS EQUIPMENT VENTING SYSTEM NOT PROVIDED. When the manufacturer of a
Product Approved side wall horizontally vented gas fueled equipment does not provide the parts for venting the flue gases, but identifies
"special venting systems", the following requirements shall be satisfied by the manufacturer:
1. The referenced "special venting system" instructions shall be included with the appliance or equipment installation instructions; and
2. The "special venting systems" shall be Product Approved by the Board, and the instructions for that system shall include a parts list and
detailed installation instructions.
(e) A copy of all installation instructions for all Product Approved side wall horizontally vented gas fueled equipment, all venting instructions,
all parts lists for venting instructions, and/or all venting design instructions shall remain with the appliance or equipment at the completion of
the installation.
MA Code - CO Detector
(for the State of Massachusetts only)

Regency Horizon™ HZ42STEPV Gas Fireplace 7
DIMENSIONS
UNIT DIMENSIONS
18-7/8”
479mm
15”
381mm
36-1/2”
927mm
12-7/8”
327mm
1-1/2”
38mm
36”
914mm
48-3/4”
1238mm
30-13/16”
783mm
41-3/16”
1046mm
3”
76mm
1-1/2”
38mm
48-11/16”
1237mm
23-5/8”
600mm
28-5/8”
727mm
12”
305mm
½”
13mm
21-5/8”
549mm

8Regency Horizon™ HZ42STEPV Gas Fireplace
INSTALLATION
10) Be aware of electrical wiring locations in walls
andceilingswhen cuttingholesfortermination.
11) Under no circumstances should this appliance
be modified. Parts that have to be removed for
servicing should be replaced prior to operating
this appliance.
12) Installation and any repairs to this appliance
should be done by an authorized service per-
son. A professional service person should be
called to inspect this appliance annually. Make
it a practice to have all of your gas appliances
checked annually.
13) Do not slam shut or strike the glass door.
14) Under no circumstances should any solid fuels
(wood, paper, cardboard, coal, etc.) be used in
this appliance.
15) The appliance area must be kept clear and
freeofcombustiblematerials,(gasesandother
flammable vapours and liquids).
Emissions from burning wood or gas could
contain chemicals known to the State of
California to cause cancer, birth defects or
other reproductive harm.
IMPORTANT MESSAGE
SAVE THESE
INSTRUCTIONS
TheHZ42STEPVDirectVentFireplacemustbe
installed in accordance with these instructions.
Carefullyreadall the instructionsinthismanual
first.Consultthe"authorityhavingjurisdiction"to
determinethe need for a permitpriorto starting
the installation. It is the responsibility of the
installer to ensure this fireplace is installed in
compliancewithmanufacturersinstructionsand
all applicable codes.
BEFORE YOU START
Safeinstallationandoperationofthisappliance
requires common sense, however, we are
required by the Canadian Safety Standards
and ANSI Standards to make you aware of
the following:
GENERAL SAFETY
INFORMATION
1) Theapplianceinstallationmustconformwithlo-
calcodesor,intheabsenceoflocalcodes,with
the current Canadian or National Gas Codes,
CAN1-B149orANSIZ223.1InstallationCodes.
2) The appliance when installed, must be electri-
cally grounded in accordance with local codes,
orintheabsenceoflocalcodeswiththecurrent
NationalElectricalCode,ANSI/NFPA70orCSA
C22.1 Canadian Electrical Code.
3) See general construction and assembly in-
structions. The appliance and vent should be
enclosed.
4) Thisappliancemustbeconnectedtothespeci-
fied vent and termination cap to the outside of
the building envelope. Never vent to another
room or inside a building. Make sure that the
vent is fitted as per Venting instructions.
5) Inspecttheventingsystemannuallyforblockage
and any signs of deterioration.
6) Venting terminals shall not be recessed into a
wall or siding.
7) Any safety glass removed for servicing must
be replaced prior to operating the appliance.
8) To prevent injury, do not allow anyone who is
unfamiliarwiththeoperationtousethefireplace.
9) Wear gloves and safety glasses for protection
while doing required maintenance.
CLOTHING OR OTHER FLAMMABLE
MATERIAL SHOULD NOT BE PLACED
ON OR NEAR THE APPLIANCE.
CHILDREN AND ADULTS SHOULD BE
ALERTED TO THE HAZARDS OF HIGH
SURFACE TEMPERATURES, ESPE-
CIALLY THE FIREPLACE GLASS, AND
SHOULD STAY AWAYTO AVOID BURNS
OR CLOTHING IGNITION.
INSTALLATION AND REPAIR SHOULD
BE DONE BY AN AUTHORIZED
SERVICE PERSON. THE APPLIANCE
SHOULD BE INSPECTED BEFORE
USE AND AT LEAST ANNUALLY BY A
PROFESSIONAL SERVICE PERSON.
MORE FREQUENT CLEANING MAY
BE REQUIRED DUE TO EXCESSIVE
LINT FROM CARPETING, BEDDING
MATERIAL,ETC.IT IS IMPERATIVETHAT
CONTROL COMPARTMENTS,BURNERS
AND CIRCULATING AIR PASSAGEWAYS
OF THE APPLIANCE BE KEPT CLEAN.
DUE TO HIGH TEMPERATURES, THE
APPLIANCE SHOULD BE LOCATED
OUT OF TRAFFIC AND AWAY FROM
FURNITURE AND DRAPERIES.
WARNING: FAILURE TO INSTALL THIS
APPLIANCE CORRECTLY WILL VOID
YOUR WARRANTY AND MAY CAUSE A
SERIOUS HOUSE FIRE.
YOUNG CHILDREN SHOULD BE CARE-
FULLY SUPERVISED WHEN THEY ARE
IN THE SAME AREA AS THE APPLI-
ANCE. TODDLERS,YOUNG CHILDREN
AND OTHERS MAY BE SUSCEPTIBLE
TO ACCIDENTAL CONTACT BURNS. A
PHYSICAL BARRIERS IS RECOMMEND-
ED IFTHERE ARE AT RISK INDIVIDUAL
INTHE HOUSE. TO RESTRICT ACCESS
TO A FIREPLACE OR STOVE, INSTALL
AN ADJUSTABLE SAFETY GATE TO
KEEP TODDLERS, YOUNG CHILDREN
AND OTHER AT RISK INDIVIDUALS OUT
OF THE ROOM AND AWAY FROM HOT
SURFACES.

Regency Horizon™ HZ42STEPV Gas Fireplace 9
INSTALLATION
This includes:
1) Clocking the appliance to ensure the correct
firing rate (rate noted on label 26,000 Btu/h
(NG), after burning appliance for 15 minutes.
2) If required, adjusting the primary air to ensure
that the flame does not carbon. First allow the
unit to burn for 15-20 min. to stabilize.
CAUTION: Any alteration to the product that
causessootingorcarboningthatresultsindam-
ageisnottheresponsibilityofthemanufacturer.
INSTALLATION
CHECKLIST
1) Locate appliance
a) Room location (Refer to "Locating Your
Gas fireplace" section)
b) Clearances to Combustibles (Refer to
"Clearances" section)
c) Mantle Clearances (Refer to "Mantel
Clearances" section)
d) Framing&FinishingRequirements (Refer
to "Framing & Finishing" section)
e) Venting Requirements (Refer to "Venting"
section)
2) Make electrical connections for Power Vent
System and for unit. 120V power is required
to operate unit / power vent system.
3) Assemble Top and Side Standoffs (Refer to
"Unit Assembly Prior to Installation).
4) Slide unit into place.
5) Install vent (Refer to "Venting Arrangement"
sections).
6) Make gas connections (Refer to "Gas Line
Installation section).
7) Make electrical connections to receptacle
supplied with unit (recommended).
8) Install 4 AA batteries into battery pack.
9) Testthepilot(Referto"PilotAdjustment"section).
10) Test Gas Pressure (Refer to "Gas Pipe Pres-
sure Testing" section).
11) Install standard and optional features. Refer
to the following sections:
a) Optional Accent Light Installation
b) Glass Crystals/ Optional Ceramic
Stones
c) Optional Firebox Base Pebbles
d) Optional Reflective Panels
e) Faceplate
f) Remote Control or Wall Thermostat
12) Wall Mounted ON/OFF Switch:
Use the toggle wall switch supplied with the
manualpackage.Useofa“decor”switchcauses
higher resistance which is a problem on gas
fireplaces.
13) Final check.
Before leaving this unit with the customer, the
installer must ensure that the appliance is firing
correctly and operation fully explained to
customer.
LOCATING YOUR
GAS FIREPLACE
1) When selecting a location for your fireplace,
ensure that the clearances are met as outlined
in the "Clearances" section.
2) Provide adequate clearances for servicing.
3) The appliance must be installed on a flat, solid,
continuoussurface(e.g.wood,metal,concrete).
Thismaybethefloor,orraiseduponaplatform
to enhance its visual impact. If the appliance is
going to be installed on carpeting, combustible
linoleumtileorothercombustiblematerialother
than wood flooring, the appliance must be
installed on a metal or wood panel extending
the full width and depth of the appliance.
4) The Direct Vent Gas Fireplace can be installed
as follows:
Model # Position
A) HZ42STEPV: See Thru
B) HZ42STEPV: See Thru
5) ThisapplianceisListedforbedroom installations
when used with a Listed Millivolt Thermostat.
Some areas may have further requirements,
check local codes before installation.
6) The HZ42STEPV Direct Vent Gas Fireplace is
approved for alcove installations, which meet
the clearances listed on this page.
7) Werecommendthatyouplanyourinstallationon
paperusingexactmeasurementsforclearances
andfloorprotectionbeforeactuallyinstallingthis
appliance.Haveaqualifiedinspector,dealer,or
installer review your plans before installation.
Note: For Exterior Vent Termination
Locations see section "Exterior Vent
Termination Locations."
Glass
36" min.
(914mm)
36" min.
(914mm)
4-1/2” min. (114mm)
Glass
A
B
36"min.
(914mm) 36"min.
(914mm)
36"min. walkway (914mm)
Glass Glass
HZ42 ST - SEE THRU
HZ42 ST - SEE THRU
HZ42STEPV - SEE THRU
HZ42STEPV - SEE THRU

10 Regency Horizon™ HZ42STEPV Gas Fireplace
INSTALLATION
Caution Requirements
The top, back and sides of the fireplace are defined by
standoffs. The metal ends of the standoff may NOT be
recessed into combustible construction.
WARNING
Fire hazard is an extreme risk
if these clearances (air space) to combustible materials are not
adhered to. It is of greatest importance that this fireplace and vent
system be installed only in accordance with these instructions.
CLEARANCES
The clearances listed below are Minimum distances unless otherwise stated:
Amajorcauseofchimney related fires isfailuretomaintain required clearances (airspace)tocombustible materials. It isofthegreatest importance
that this fireplace and vent system be installed only in accordance with these instructions.
F
B
C
Installed Close
to Ceiling
NON-COMBUSTIBLE REQUIREMENTS
Flue Clearances to Combustibles
Horizontal - Top 3"
Horiztonal - Side 2"
Horiztonal - Bottom 2"
Vertical 2"
Passing through wall/
floor/ceiling - when
firestop is used. 1-1/2"
F
B
E
D
A
Installed Close
to Floor
G
Clearance: Dimension Measured From:
A: Mantel Height (min.) 13" (330mm) Top of Fireplace Opening
B: Sidewall (on one side) 8" (203mm) Side of Fireplace Opening
C: Ceiling
(room and/or alcove) 22" (559mm) Top of Fireplace Opening
D: Mantel Depth (max.) 13" (330mm) 22" Above Fireplace Opening
E: Alcove Width 84" (2134mm) Sidewall to Sidewall (Minimum)
F: Alcove Depth 36" (914mm) Front to Back Wall (Maximum)
G: Finished Floor 25-3/4" (654mm) Top of Fireplace Opening
Note 0" (0mm) No Hearth Required
34 -5/8” (984mm)
6 - 3/8"
(162mm)
21-3/4”
(552mm)
12-7/8"
(327mm)
57" (1448mm)
Non-combustible
Material
Non-combustible Material
Non-combustible Material
Metal Stud (header)
on edge
Metal Stud
on edge
Metal Stud
on edge
21-3/4”
41-7/16”
Non-combustible material
always wider at vent end
Note:
9-3/8”
(238mm)
Non-combustible Material
4-1/4”
(108mm)
Vent End

Regency Horizon™ HZ42STEPV Gas Fireplace 11
INSTALLATION
MANTEL CLEARANCES
Note: Ensurethepaintthatisusedonthemantel
and the facing is "heat resistant" or the
paint may discolour.
MANTEL LEG CLEARANCES
Combustible mantel leg clearances as per diagram:
4"
Allowable mantel
leg projection
1.5" (38mm)
9-1/2”(241mm)
Non-Combustible
7”
4"
1.5" (38mm)
MANTEL LEG
9-1/2”(241mm)
Non-Combustible
7”
4"
Allowable mantel
leg projection
1.5" (38mm)
MANTEL LEG
7”
4"
7”
1.5" (38mm)
9-1/2” (241mm)
16.5” (419mm)
Allowable mantel
leg projection
Allowable mantel
leg projection
9-1/2” (241mm)
13.5” (343mm)
16.5” (419mm)
13.5” (343mm)
16.5” (419mm)
13.5” (343mm)
9-1/2” (241mm)
9-1/2” (241mm)
13.5” (343mm)
16.5” (419mm)
2
0
12 64
810
Top of
Fireplace
Opening
0
14
To Unit
Base
1" (25mm)
22”
13”
25-3/4”
10
20
26
Combustible Material
2
0
12 64
810
Top of
Fireplace
Opening
Standoff
Metal Stud
(On Edge)
0
14
Non-combustible
Facing
1" (25mm)
13”
10
20
26
2
0
12
6
4
8 10
Top of
Fireplace
Opening
12" (305mm)
0
14
To Unit
Base
1" (25mm) 21-1/2”
13”
25-3/4”
10
20
26
12" (305mm)
21-1/2”
Due to the extreme heat this fireplace emits, the
mantelclearances arecritical. Combustiblemantel
clearances from top of front facing are shown in the
diagram on the right.
Note: A non-combustible mantel may be
installed at a lower height if the framing
is made of metal studs covered with a
non-combustible board.

12 Regency Horizon™ HZ42STEPV Gas Fireplace
INSTALLATION
HORIZONTAL VENT DEFLECTOR INSTALLATION
NAILING STRIPS
The side, top and bottom nailing strips come attached to the unit. There
are 3 plates on each side and 2 on the bottom - 8 in total. They can be
foldedoutasrequired. Thebottomnailingstripissecuredtotheunfinished
floor - if installing the unit directly on the floor.
Note: This installation is only required for horizontal terminations.
If any rise is used when venting this unit - the deflector and
extender are not required.
1) The deflector and extender are shipped on top of the firebox.
Slide the deflector out from under the nailing strip and lift the
extender up off the nailing strip.
2) Remove the 3 screws near the vent outlet on the firebox - as shown
below.
3) Install the deflector near the vent outlet - secure with the same
3 screws. Ensure flange on deflector is facing downward.
4) Install the extender on top of the deflector with 2 screws -
slide the extender until it touches the outside wall - tighten
screws to secure. Extender can be adjusted to max. 15-1/2".
Nailing Strips
Standoff
UNIT ASSEMBLY
PRIOR TO
INSTALLATION
TheStandoffsandNailingStripsmustbecorrectlypositionedandattached
to the firebox before unit is slid into position.
STANDOFF ASSEMBLY
The side, top and rear standoffs are shipped in a flat position and must
be folded into shape and attached.
1) Remove the standoffs from the fireplace.
2) Take each standoff and bend into the correct shape. Bend up at the
bend lines until the screw holes in the standoff and the pre-punched
screw holes on the fireplace side line up.
3) Attach the standoff securely to the side with 2 screws per standoff (on
opposite corners).
Nailing Strips shown folded out.
IMPORTANT NOTE
Framing depth measurement is noted with the
side & top nailing strips set as far forward on
the firebox as possible. The nailing strips can
be adjusted back up to 1” to allow for varying
thicknesses in non-combustible material & wall
finishes.
Deflector extender Deflector
Flange

Regency Horizon™ HZ42STEPV Gas Fireplace 13
INSTALLATION
Note: When constructing the framed opening, please ensure there is
access to install the gas lines when the unit is installed.
2) The unit does not have to be completely enclosed in a chase. You must
maintain clearances from the vent to combustible materials: See "Clear-
ances" section. Combustible materials can be laid against the side and
back standoffs and the stove base.
3) Non-combustible material (ie. tile, slate, etc) may be brought up to and
overlap the unit (top and bottom) ensuring that the maximum thickness
does not go beyond the 1-1/2" as shown in the diagram below. The
faceplate will not be able to be mounted if the finished material is beyond
1-1/2".
FRAMING & FINISHING
1) Frame in the enclosure for the unit with framing material.
IMPORTANT: Vertical studs and the header must be metal.
Note:
Dependingon the material used for finishing,thenailingstrips must be set ac-
cordinglysothatthefinishedmaterialisalwaysatthe1-1/2"edgeoftheflange.
4) If material such as brick, stone, etc. extends past the faceplate depth,
when finishing around the faceplate, the minimum opening dimensions
noted below must be adhered to ensuring for the removal of the faceplate
and for the safe operation of this appliance.
Finished
Material Nailing Strip Position
1/2" 1"
1" 1/2"
1-1/2" 0" (flush)
Unit
Nailing Strip
1” Forward
Unit
Nailing Strip
½” Forward
Unit
Nailing Strip
Flush w/unit
Factory Set
5) For material such as brick, stone, etc that extends less than 1-1/2" ,
the minimum opening dimensions noted below must be adhered, when
finishing around the faceplate. This is to ensure the longevity of the
finishing material and for the safe operation of this appliance.
41-7/8”
21-3/4”
Unit shown without faceplate

14 Regency Horizon™ HZ42STEPV Gas Fireplace
INSTALLATION
FRAMING DIMENSIONS
B
C
All studs
are metal
(on edge)
A
Finished
Floor
H
Note: All studs on top and sides of unit must be on edge.
Note: Gas hookup is on vent side of unit.
1/2” 1/2”
IMPORTANT:
1/2" gap required between
faceplate and finished wall.
Dangerous operating
conditions will occur if this is
not adhered to.
HZ42STEPV Framing Dimensions
A * Framing Depth * 15" (381mm)
**minus 2X the finished material thickness
B Framing Height 36-3/4" (933mm)
C Framing Width 50" (1270mm) Horizontal or Vertical Vent
D Gas Connection Height 4-1/2" (114mm)
E Gas Connection Inset 2-7/8" (73mm)
F Gas Connection Opening Width 4-5/8" (117mm)
G Gas Connection Opening Height 2" (51mm)
H Minimum Height to Combustibles 40-1/2" (1029mm)
* Framing depth measurement is noted with nailing strips (top & sides) set as far forward on the firebox
as possible. The nailing strips can be adjusted back up to 1" (on both sides) to allow for varying
thicknesses in non-combustible material and wall finishes.
**Finished material thickness includes: non combustible material, tile slate, etc.
(example framing = 13" - if 1" thick finishing material is used on both sides)

Regency Horizon™ HZ42STEPV Gas Fireplace 15
INSTALLATION
FRAMING DIMENSIONS WITH NEGATIVE VENT RUN INSTALLATIONS
HZ42STEPV Framing Dimensions with Negative Run
A * Framing Depth * 15" (381mm)
**minus 2x the finished material thickness
B Framing Height 36-3/4" (933mm)
C Framing Width 50" (1270mm) Horizontal or Vertical Vent
D Framing Width - negative vent off end of unit 63" (1600mm)
E Framing Width - installed as an island with a
negative run off end of unit
75" (1905mm)
** All other dimensions from the previous page remain the same for these installations.
B
C
A
D
Wood Studs
B
C
A
E
Wood Studs Wood Studs
Note: All studs on top and sides of unit must be on edge.
All studs metal - unless otherwise indicated.
Framing as an island with a negative vent run off the end of
the unit.
Parts required for a negative vent run
Framing for a negative vent run off the end of the unit.
Rigid pipe adaptor 45°elbow 90°elbow

16 Regency Horizon™ HZ42STEPV Gas Fireplace
INSTALLATION
Vent restriction is required for certain venting installations, see the diagrams in the "Venting
Arrangements" section to determine if they are required for your installation.
The Vent Restrictor plate is located on the inside top of the firebox.
To set the vent restriction as indicated in the venting arrangements diagrams, refer to the following instructions;
1) Remove the glass door.
2) Remove the screws that hold the vent restrictor plate in place.
3) Adjust the vent restrictor plate to the required vent restrictor position as per the diagrams shown.
4) Once the vent restrictor plate is in the required position, secure with screws.
VENT RESTRICTOR POSITION
SET 1
THIS HOLE SETS THE
VENT RESTRICTOR
3/4”1-1/4”
SET 2
THIS HOLE SETS THE
VENT RESTRICTOR
1-3/4”
SET 3
THIS HOLE SETS THE
VENT RESTRICTOR

Regency Horizon™ HZ42STEPV Gas Fireplace 17
INSTALLATION
GAS POWER VENT INSTALLATION
RIGID PIPE ONLY
Firestop Spacer
(w/Power vent kit)
BX Cable
(sold separately)
Rigid Pipe Adaptor
(included w/unit)
Frame Assembly
(w/Power vent kit)
Power Vent Terminal
(946-705)
Slip Section
(sold separately)
POWER VENT SYSTEMS ARE FOR USE WITH RIGID PIPE ONLY.
See venting in this manual for detailed instructions.
4" x 6-5/8" Rigid pipe lengths
(sold separately)
946-705 Power Vent Kit with Vent Terminal
Parts Required
1 510-994 Rigid Pipe adaptor included with unit
146
DVA-08A 8-1/2" Slip section - or sold separately
146
DVA-16A 16" Slip section sold separately
1911-046 Power Vent Fan included w/power vent kit
1 Firestop included w/power vent kit
946-706 20' 5-wire BX cable - or sold separately
946-707 60' 5-wire BX cable sold separately
amount required
for install
4"x 6-5/8" Rigid Pipe sold separately
1 946-705 Power Vent Kit sold separately
The Power Vent System is a Direct Vent Terminal designed to allow installation of gas appliances where typical vent configurations cannot be achieved.
These installation instructions must be used in conjunction with the appliance and appropriate Power Vent components installation instructions.
120 Volt power supply is required to operate this system (see Electrical Installation section in this manual).
Clearances listed in these Instructions supersede those in the appliance's Installation Instructions.
Models Equipped with Surefire Ignition
The power vent system can only be used with units that have been tested with the Regency Power Vent system.
Downward vertical vent runs are permitted with the Surefire Ignition system. See vent configuration in this manual.

18 Regency Horizon™ HZ42STEPV Gas Fireplace
INSTALLATION
EXTERIOR VENT TERMINATION REQUIREMENTS
Minimum Clearance Requirements Canada1USA2
AClearance above grade, veranda, porch, deck, or balcony 12"(30cm) 12"(30cm)
BClearance to window or door that may be opened 12"(30cm) 9" (23cm)
CClearance to permanently closed window **
DVertical clearance to ventilated soffit located above the terminal within a horizontal distance of 2 feet (61cm)
from the center line of the terminal (check with the local code)
12"(30cm) 12"(30cm)
EClearance to unventilated soffit 8"(20cm) 8"(20cm)
FClearance to outside corner: with Regency Power Vent Cap Termination Cap. 6"(15cm) 6"(15cm)
GClearance to inside corner: with Regency Power Vent Cap Termination Cap 6"(15cm) 6"(15cm)
HClearance to each side of center line extended above meter/regulator assembly 36"(90cm)a*
JClearance to service regulator vent outlet 36"(90cm) *
KClearance to non-mechanical air supply inlet to building or the combustion air inlet to any other appliance 12"(30cm) 9" (23cm)
LClearance to a mechanical air supply inlet #3' (91cm) above if within 10' (3m) horizontally. 72"(1.8m) 36"(90cm)b
MClearance above paved sidewalk or a paved driveway located on public property 84"(2.1m)┼*
NClearance under veranda, porch, deck, or balcony 12"(30cm)‡*
1In accordance with current CSA B149.1, Natural Gas and Propane Installation Code
2In accordance with the current ANSI Z223.1/NFPA 54, National Fuel Gas Code
┼A vent shall not terminate directly above a sidewalk or paved driveway which is located between two single family dwellings and serves both dwellings
‡ Permitted only if veranda, porch, deck, or balcony is fully open on a minimum of two sides beneath the floor
*Clearance in accordance with local installation codes and the requirements of the gas supplier
a3 feet (91cm) within a height of 15 feet (4.5m) above the meter / regulator assembly
b3 feet (91cm) above - if within 10 feet (3m) horizontally

Regency Horizon™ HZ42STEPV Gas Fireplace 19
INSTALLATION
Horizontal (Feet)
0
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
Restrictor Setting
#3 - 1-3/4” open
Restrictor Setting
#1 - 0.75” open
Restrictor Setting
#2 - 1-1/4” open
-2
-4
-6
Vertical (Feet)
0246810 12 14 16 18 20 22 24 26 28 30 32 34 36 38 40 42 44 46 48 50 52
0246810 12 14 16 18 20 22 24 26 28 30 32 34 36 38 40 42 44 46 48 50 52
-7 ft. max
Maximum total vent length = 50' + six - 90° elbows.
One 90° elbow = two 45° elbows.
Maximum total negative vent length = 10' (from centerline of pipe).
Restrictor setting 1 - Max. up to six- 90° elbows.
Restrictor setting 2 - Max. up to five- 90° elbows.
Restrictor setting 3 - Max. up to four- 90° elbows.
Note: Must be terminated horizontally. Vertical terminations are not permitted.
The gas power vent systems is designed to allow the installation of a gas appliance when typical vent configurations (shown in this manual) are not
possible.
Note: Must be terminated horizontally. Vertical terminations are not permitted.
VENTING ARRANGEMENTS FOR HORIZONTAL TERMINATIONS
(RIGID PIPE 4" X 6-5/8" - MUST USE RIGID PIPE ADAPTOR #510-994)

20 Regency Horizon™ HZ42STEPV Gas Fireplace
INSTALLATION
11-3/4”
11-3/4”
Determine
the correct
height
WARNING
ELECTRICAL CONNECTIONS SHOULD ONLY BE
CARRIED OUT BY A QUALIFIED AND LICENSED
ELECTRICIAN
POWER VENT TERMINAL INSTALLATION
Note: Optional 5 wire BX cable comes in 20' or 60' lengths as required.
Wires are color coded for ease of installation.
1) Frame in opening for the Power Vent Terminal by first determining the
correct height - frame in an 11-3/4" x 11-3/4" opening.
3) Install the Power Vent outer frame with 4 screws - screw locations
shown below.
Important: Orient the frame so the BX cable will pass through in the lower
left corner.
4) Remove the plate from the bottom right corner of the frame by removing
2 screws from the inside of the frame.
7) Feed a length of BX cable through - (approx. 18") the plate and tighten
the strain relief grommet to the plate.
2) Feed the BX cable through the firestop - ensure protective grommet is in
place before feeding the cable through.
Protective grommet
Firestop
5) Install a strain relief grommet through the plate as shown below.
6) Unravel the BX cable - to expose approx. 7" of wire. Install a wire
protector where the metal of the BX cable and the wire meet.
Wire protector
Strain Relief
