Regner IN-LINE ACTUATOR SERIES User manual

RA67
IN-LINE ACTUATOR SERIES
User Manual
www.regner.es

RA67 IN-LINE ACTUATOR SERIES USER MANUAL
© MARCH 2020 | Regner Engineering SLU | All rights reserved
Specifications are subject to change without notice.
It is the responsibility of the user to determine the suitability of REGNER® products for a specific application.
No part of this publication may be reproduced without written permission from Regner Engineering SLU.

RA67 IN-LINE ACTUATOR SERIES
3
00. Contents
01. Preface.................................................................. 4
02. Safety ................................................................... 4
03. Warranty............................................................... 5
04. Specications ....................................................... 6
05. Installation ........................................................... 9
06. Maintenance ......................................................... 10
07. Troubleshooting.................................................... 11
08. Application Policy................................................. 11
09. Contact ................................................................. 11

RA67 IN-LINE ACTUATOR SERIES
4
02. Safety
Please read the following safety information careful-
ly and make sure that everyone using, connecting or
installing the actuator has the necessary skills and
information, as well as access to this user manual.
02.01. Safety Guidelines
• Only properly qualified personnel can perform me-
chanical and electrical installation of the actuator.
• Do not mount, dismount or perform maintenance
work while the actuator is in operation.
• Check that the actuator is correctly mounted
before operating the device.
• Make sure that the connection bolts can withstand
the wear and that they are safely secured before
operating the device.
• Check that the actuator can move freely through-
out the whole working area before operating the
device.
• Use the actuator only within the specified working
limits.
• Check that the actuator is connected to a power
supply with the correct voltage and current source
before operating the device.
• Switch off the main power supply when the
actuator is not in use to prevent unintentional
operation.
• Do not exert force on the side of the actuator.
• Make sure that the cable cannot be pressed upon,
pulled or subjected to any other stress.
• Never unplug any cables or connectors during
operation or with power on.
• Stop using the actuator immediately if it seems
faulty or broken.
• Never try to open the actuator, as that will com-
promise the sealing and the proper functioning of
the device.
• Do not kick or step on the actuator.
• Check the actuator and joints for extraordinary
wear periodically.
• Keep out of reach of children.
01. Preface
Thank you for choosing a REGNER® electric linear
actuator. REGNER® actuators are high-tech products,
carefully designed and manufactured in Europe. We
use premium raw materials and we continue to work
on developing better actuators to respond to the
demands of our customers.
This manual will provide you with operational, main-
tenance and safety information about the actuator.
We urge you to read this manual carefully and to
follow its recommendations to make sure that the
actuator is used properly and to its full potential.
The REGNER® team

RA67 IN-LINE ACTUATOR SERIES
5
03. Warranty
All REGNER® products have a warranty against
manufacturing defects. The warranty period begins
on the purchase date of the product. The seller is
responsible for nonconformities that become appar-
ent within the time stipulated by the applicable law.
03.01. Warranty Exclusions
REGNER® is entitled to deny any warranty if:
• The actuator has not been used correctly or its
usage specifications (load, temperature, duty cycle,
voltage, current, etc.) have not been respected.
• The actuator has not been maintained correctly.
• The actuator has been manipulated.
• The actuator has been exposed to violent or abra-
sive treatment.
Nonconformities due to reasonable wear and tear
of the actuator over time (such as faded paint) are
excluded from warranty.
REGNER® reserves the right to request the return
of all allegedly defective products for testing and
verification.
Any additional warranty obligations for parts
replaced free of charge or for any service provided
without charge under this warranty shall be exclud-
ed. The warranty period for parts replaced under
warranty will end on the expiry date of the warranty
period of the main product.
02.02. Symbols Used
Important safety information is described under the
following two symbols:
WARNING!
Failure to follow these instructions can result in
serious personal injury.
CAUTION!
Failure to follow these instructions can result in the
actuator being damaged or destroyed.

RA67 IN-LINE ACTUATOR SERIES
6
04. Specications
04.01. Label
WARNING: Improper use may cause damage or injury.
Only to be opened by authorized personnel.
Power Rating:
Duty Cycle:
Max. Current:
Batch. No.:
24 V
Max. 10%, 2min/20min
7.0 A
181017
Stroke:
IP Class:
Max. Load:
155 mm
20
6000 / 4000 N
RA67 6000.155.158.370.M10.AEL
www.regner.es
01. RA67 6000.155.369.350
• RA67: actuator type
• 6000: max. load (N)
• 155: stroke length (mm)
• 157: retracted length, center to center (mm)
• 370: cable length (mm)
• M10: mounting hole diameter
• AEL: feedback option (Analogic Encoder feedback
& Limit switches)
02. Actuator specifications
Basic specifications and actuator features.
03. Batch No.: XXXXXX
Identification number assigned to a particular lot
of products that enables REGNER® to control their
quality and trace their constituent parts.
04. Symbols
Symbol Norms
WEEE Directive 2002/96/EC
Compliance to all relevant CE directives
Protection against electric shock, Class
III appliance
04.02. Components
5
6
7
8
1
3
2
4
1. Track
2. Track mounting screw
3. Nut
4. Spindle
5. Housing
6. Electronic board
7. Cable
8. Rear mounting hole

RA67 IN-LINE ACTUATOR SERIES
7
04.03. Specications
Actuator Specifications
Max. Load 6000 N push
4000 N pull
Lead 4 mm
Max. Speed (No load) 7.2 mm/s
Max. Current 7.0 A
Starting Current 8.0 A
Power Supply 24 VDC
Limit Switches At stroke end points
Stroke 155 mm
Duty Cycle 10 % (2 min out of 18 min)
Mechanical Specifications
Housing Material PA6 30%GF
Aluminum
Color Black
Connectors Power: Inconnect
D50754 IPG-8202-PS
Feedback: Molex
43025-0400
Environtment Specifications
IP Rating IP 20
Operating Temperature +5ºC to +40ºC
Storage Temperature -30ºC to +70ºC
Position Feedback Specifications
Supply Voltage 5 VDC
Output Analog Output
0.3 - 3.0 VDC ± 3%
Different feedback options for easy integration
The RA-67 features a microprocessor and up to four
customizable feedback options. The actuator can be
equipped with a hall effect encoder with position
memory and digital output and it can convert the
output signal to an analog signal (hall potentiome-
ter) thanks to its advanced electronics. Furthermore,
there is available a pulse hall PWM tracking option
and an innovative spindle revolutions count system.
Lastly, the RA-67 also presents integrated limit
switches to increase safety and reliability.
04.04. Force Curves
Use in the dashed area is not recommended.
The above values are with a room temperature of 20 °C.
Speed (mm/s)
Force (N) Force (N)
Push Pull
Speed - Force
Current (A)
Current - Force
1K 2K 3K 4K 5K 6K 7K0
0
2
4
6
8
0
2
4
6
8
1K 2K 3K 4K 5K 6K 7
K
0
04.05. Electronic Limit Switches (ELS)
When the actuator reaches its fully extended or
fully retracted positions, an electronic limit switch
automatically cuts off the current to prevent dam-
age to the motor. When it reaches either stroke end
point, the actuator can move only in the opposite
direction, until it is separated from the limit and it
can resume its normal function and move freely in
either direction.

RA67 IN-LINE ACTUATOR SERIES
8
04.06. Dimensions
11058
158 Stroke
174
Retracted length (center to center): 214 + stroke
51
96
46
87
32 55
37
45
M10
32
Ø 10.2
All measurements are in mm.
05. Installation
05.01. Mechanical Installation
To install the RA67 actuator, simply slip a 10mm pin
through the rear mounting hole and use two M10
screws to fasten the track to the moving part of your
assembly. The actuator should be installed so that
the force of the load is exerted on the center of the
axis of the actuator. Excessive off-center loads may
cause bending and lead to premature failure.
To prevent premature wear, make sure that the
mounting pins are fixed at both ends, are solid, and
do not have excessive free play. However, the actua-
tor must be able to rotate around the pivot points, as
this will allow the actuator to move freely along the
full stroke length, both in the development phase
and during normal operation. Examine the area
around the housing and see that no components
can get trapped and damage the application and
the actuator.

RA67 IN-LINE ACTUATOR SERIES
9
CAUTION!
• Mounting pins must have the correct dimensions
and limited free play.
• Any bolts and nuts used for the installation must
be made of high-quality steel.
• Do not apply an excessive torque on the mounting
bolts to avoid stressing the fixtures.
WARNING!
If the actuator is used in an application that may
cause personal injury, it is the responsibility of the
application manufacturer to introduce the necessary
safety measures to prevent personal injury in case
of failure.
WARNING!
REGNER® actuators are not designed to be used in
the following applications: aircraft, explosive envi-
ronments, nuclear power generators, and offshore
installations.
Electrical Installation
• Voltage must be switched off when installing anc
connecting the actuator.
• Make sure that the power supply and the cables
can handle the maximum motor current.
• The electronic limit switches will automatically
switch off the actuator when the rod reaches the
ends of the stroke or if an excessive load occurs
mid-stroke.
• Connect the actuator using the right counterpart
connectors in your application.
Power supply
Inconnect D50754 IPG-8202-PS
1. Motor -
2. Motor +
12
Position feedback
Molex 43025-0400
1. -
2. Feedback Signal
3. Feedback 5 VDC
4. Feedback 0 VDC
12
34
CAUTION!
• Make sure the leads and cables leading to the
motor can handle the maximum motor current.
• For additional protection, use a fuse between the
actuator and the power source.
• Do not work on the actuator or the wiring with the
power switched on!
Hall Potentiometer position feedback
• The potentiometer may operate with voltages up
to 5 VDC. Do not use a higher voltage.
• Standard output: Analog output 0.3 - 3.0 VDC ±
3%.

RA67 IN-LINE ACTUATOR SERIES
10
06. Maintenance
The actuator is a closed unit and does not require
internal maintenance. In fact, the actuator is not to
be opened by unauthorized personnel. However,
some external maintenance must be performed on
a regular basis:
• Clean the actuator with a dry cloth to remove dust
and dirt.
• Inspect the actuator for mechanical damage or
wear.
• Inspect the actuator’s attachment points, cables,
rod ends, housing, and connector, and check that
the device works correctly.
07. Troubleshooting
Symptom Possible cause Action
The motor pro-
duces no sounds
or the rod does
not move.
1. Actuator
not properly
connected to the
power supply.
2. Burned fuse.
3. Damaged
cable.
A. Check the con-
nection to the
power supply or
the control unit,
if any.
B. Please contact
REGNER®.
Excessive electrici-
ty consumption.
1. Misaligned or
excessive load.
A. Align or re-
duce the load.
B. Run the
actuator with no
load.
C. Please contact
REGNER®.
The motor runs
but the spindle
does not move.
1. Damaged
gearing system
or spindle.
A. Please contact
REGNER®.
The actuator
cannot lift a full
load.
1. Misaligned or
excessive load.
2. Insufficient
power supply.
3. Current cut off
due to excessive
load.
4. Damaged
motor.
A. Wait for the
overcurrent pro-
tection system to
reset (5 minutes).
A. Align or re-
duce the load.
B. Check the
power supply.
C. Please contact
REGNER®.
The motor runs
too slowly, does
not run with full
force or runs in
smaller steps.
1. Excessive load.
2. Voltage drop
in the cable (long
cables may affect
performance).
3. Current cut off
due to excessive
load.
A. Wait for the
overcurrent pro-
tection system to
reset (5 minutes).
B. Reduce the
load.
C. Check the
power supply.
The actuator
cannot hold the
load.
1. Excessive load. A. Reduce the
load.

RA67 IN-LINE ACTUATOR SERIES
11
There is no
feedback from the
Hall sensor.
1. Actuator
not properly
connected to the
power supply.
2. Burned fuse.
3. Damaged
cable.
A. Check the con-
nection to the
power supply or
the control unit,
if any.
B. Please contact
REGNER®.
The output signal
from the Hall
sensor is out of
range.
1. Incorrect
power supply.
A. Check and cor-
rect the power
supply.
B. Please contact
REGNER®.
08. Application Policy
REGNER® products can be used in a wide range of
applications in health care, household or industrial
equipment, for example. REGNER® cannot know and
check all the conditions in which REGNER® products
are installed and used. The suitability and functional-
ity of a REGNER® product, as well as its performance
in a variety of conditions, can only be verified by
testing, and it shall ultimately be the responsibility
of the customer using a REGNER® product.
REGNER® is solely responsible that REGNER® prod-
ucts comply with the established specifications,
whereas it remains the responsibility of the custom-
er to ensure that a specific REGNER® product can be
used for a specific application.
09. Contact
For technical assistance, please contact the REGNER®
Technical Department at [e-mail].

*RA57ACTUATOR*
Ripollès, 4 | 17181 Aiguaviva (Girona) SPAIN | Tel. [phone] | Fax [phone]
[e-mail] | www.regner.es
