Reloop Terminal Mix 8 User manual

ENGLISH
1
TERMINAL MIX 8 QUICK START GUIDE
VERSION 1.0
GET READY FOR TAKE OFF.
Thank you for purchasing the Terminal Mix
8 Reloop‘s new agship performance
controller developed for Serato DJ.
Here are the steps to get started:
1) Visit the link below to get your FREE
copy of Serato DJ
serato.com/dj/license/code
Note:
If you are a PC user, please visit the
Terminal Mix 8 product site on
www.reloop.com and head to the download
section to download and install the PC
ASIO driver. Mac users do not require a
special driver.
2) Now connect the Terminal Mix 8 to your
computer via USB; also connect the
included power supply and run either the
RCA (unbalanced) cables or XLR (balanced)
cables to your speakers or amplier. Don‘t
forget to connect your headphones to one
of the two jack inputs on the front panel.
3) Power on your unit, start the Serato DJ
software and start mixing.
Note:
Make sure, when turning on the power, to
have your master and headphones volume
low and slowly increase.
MAXIMUM CONTROL
SPEAKERS
XLR / RCA
POWER SUPPLY
HEADPHONES
USB CABLE

ENGLISH VERSION 1.0
2
TERMINAL MIX 8 QUICK START GUIDE
GAIN - Input volume for your channel
EQ - Three band graphic equalizer
FILTER - HPF & LPF
DECK LOAD - Loads your selected track to
the deck
SHIFT + DECK LOAD : Activates and
De-activates Fader start
CUE
Turns on headphone monitoring per channel
CHANNEL FADER
Control your channel volume
LED SIGNAL CHAIN
Visaul feedback for the master output or
channel input (Either can be selected on the
rear panel)
CROSS FADER
fade between selected channels assigned to
the front panel
MIXER SECTION
1
2
3
4
5
6
7
8
1
2
3
4
5
67
8

ENGLISH
3
TERMINAL MIX 8 QUICK START GUIDE
VERSION 1.0
MASTER
Dene your output volume
BOOTH
Dene your Booth Volume
PHONES
Headphone volume
CUE MIX
Mixes between your booth and headphone volume
SAMPLER
Push sampler knob to toggle through your sampler
output channels A, B, C, D and Master.
Turn Sampler Volume to set
AREA
Selects through FX, REC and SP6 panels
TRAX ENCODER
Turn TRAX encoder to scroll through your track list
and folders. Push to move forward
VIEW
Selects through different deck layouts
SHIFT view switches between 2 and 4 deck
BACK
Moves back 1 step in track window navigation
PREPARE
Adds highlighted song to prepare bay
SHIFT + PREPARE opens and closes Prepare
window
MASTER AND TRAX SECTION
1
1
2
2
3
3
4
4
5
5
6
6
7
7
88
9
9
++

ENGLISH VERSION 1.0
4
TERMINAL MIX 8 QUICK START GUIDE
SYNC
This will enable the SYNC Function in Serato
SHIFT + SYNC will deactive sync on that deck
STUTTER
Pressing Stutter will trigger your track from
your set CUE point
CUE
Pressing CUE will return to the last set CUE
point. In pause mode, hit CUE to set a CUE
point
SHIFT + CUE
Returns to the beginning of the track
PLAY / PAUSE
Launches your track or pauses it
SHIFT + PLAY
Plays your track in reverse (censor)
DECK
Swaps between decks 1 and 3 or 2 and 4
SHIFT
Enables second layer functions
TRANSPORT
1
1
2
2
3
3
4
4
5
5
+
+

ENGLISH
5
TERMINAL MIX 8 QUICK START GUIDE
VERSION 1.0
SLICER
HOT CUE MODE
LOOP MODE
Slicer Mode: A specied range (or domain) is
divided into eight equal sections, and these eight
sliced sections are assigned to the respective
performance pads.
Pressing SLICER once for the rst mode, is a shif-
ting Slicer Domain.
Pressing SLICER twice, for the second mode is a
xed Slicer Domain or “loop”.
Save and launch up to 8 CUE points per track
SHIFT + DRUM PAD will delete a selected CUE
point
Loop mode can select and launch up to 8 pre saved
loops
Set a loop length using the Loop size encoder, turn
on LOOP by pressing the ON button or,
If no LOOP is saved, hitting a DRUM PAD will save
and store a loop at the current position and length
SHIFT + DRUM PAD deletes a loop slot
To exit loop press ON button again
Pressing LOOP + DRUM PAD will stop an active
loop playing
ROLL
Holding SHIFT + pushing and turning the loop
encoder will launch a drum roll effect
DUAL MODE
Pressing two modes simultaneously will split the
drum pad into two layers. The Left mode will always
be on the top 4 drum pads. The right mode, always
on the bottom 4 drum pads:
COMBO MODES:
SAMPLE /CUE SAMPLE/LOOP CUE/LOOP
PERFORMANCE MODE

ENGLISH VERSION 1.0
6
TERMINAL MIX 8 QUICK START GUIDE
Trigger preset samples, using the DRUM
PADS, from Serato‘s SP6 Sampler unit
When the sample slot is loaded, the drum
pad will light orange
When the sample slot is playing the drum
pad will blink
If the slot is empty, hit the drum pad to
load a sample from your current track
selection
The rst six drum pads are sample slots
1-6 of SP6
Drum buttons 7 and 8 are always lit blue
and switch through sample banks
next/previous
Pressing SHIFT + drum pad will eject a
sample if not playing (pad only lit)
SAMPLER mode button + drum pad
will stop an active playing slot
The Sampler Master volume can be
controlled with the Sampler volume knob in
the master section.
SHIFT + Pushing the sampler volume knob
will toggle through the outputs 1, 2, 3, 4
and M
SAMPLER MODE
+
<
<

ENGLISH
7
TERMINAL MIX 8 QUICK START GUIDE
VERSION 1.0
There are three effects per FX rack which can be
used on thier own or in a chain
FX ASSIGN
Assigns either of the two FX racks to the left or
right active decks
SHIFT + 1 selects through pitch ranges
SHIFT + 2 turns Keylock ON / OFF
SHIFT + FX ON/OFF button navigates through
FX selection (1 press per effect)
JOG
When Jog button is lit, scratch mode is
enabled
SHIFT + JOG
Enables slip mode
SHIFT + Jog wheel
Quickly skip through your track (Fast search)
FX RACKS
JOG WHEEL
11
22
3
3
4
4
5
5
6
6
7
7
8
8

ENGLISH VERSION 1.0
8
TERMINAL MIX 8 QUICK START GUIDE
FRONT & BACK
MIC
Chord Strain Relief
DC IN
Power On
USB PORT
Master (Balanced)
Master (Unbalanced)
Booth RCA
LED Dimmer
LED Chain
Line / Phono select
AUX Input
GND
MIC Level
MIC Tone
Input Routing MIC
Input Routing Phone / Line
Level
Cross Fader channel Select
Cross Fader channel Select
Cross Fader channel Select
Cross Fader channel Select
Headphone Tone
Headphone 3.5mm Jack
Headphone 6.5mm Jack
Cross Fader Curve

GERMAN
9
TERMINAL MIX 8 QUICK START GUIDE
VERSION 1.0
Wir gratulieren Ihnen zum Kauf des Reloop
Terminal Mix 8 Flaggschiff Performance Cont-
rollers, entwickelt für Serato DJ.
Im Folgenden nden Sie die wichtigsten Schrit-
te, um mit Ihrem Gerät loslegen zu können:
1) Unter unten angegebenem Link können Sie
kostenlos Serato DJ herunterladen.
www.serato.com/dj/license/code
Hinweis:
Falls Sie einen PC verwenden, besuchen Sie
bitte zunächst die Seite www.reloop.com und
navigieren Sie zur Download Sektion, um den PC
ASIO Treiber herunterzuladen und zu installie-
ren. Mac User benötigen keine speziellen Treiber.
2) Verbinden Sie nun den Terminal Mix 8 über
USB mit Ihrem Computer. Verbinden Sie eben-
falls das im Lieferumfang enthaltene Netzteil.
Nun sollten Sie den Terminal Mix 8 mit Ihrem
Soundsystem verbinden (entweder über Cinch-
kabel (asymmetrisch) oder XLR (symmetrisch)).
Vergessen Sie nicht, einen Kopfhörer an eine der
2 dafür vorgesehenen Buchsen anzuschließen.
3) Schalten Sie das Gerät ein, starten Sie die
Serato DJ Software und schon können Sie mit
dem Mixen beginnen.
Hinweis:
Vergewissern Sie sich, dass die Master- und
Kopfhörerlautstärke vor Inbetriebnahme auf mi-
nimum eingestellt sind und erhöhen Sie vorsich-
tig die Lautstärke.
MAXIMUM CONTROL
SPEAKERS
XLR / RCA
POWER SUPPLY
HEADPHONES
USB CABLE

GERMAN
10
TERMINAL MIX 8 QUICK START GUIDE
VERSION 1.0
GAIN
Kanallautstärke
EQ
grascher 3-Band Equalizer
FILTER
High Pass Filter & Low Pass Filter
DECK LOAD
Lädt den gewünschten Track auf das gewähl-
te Deck.
SHIFT + DECK LOAD
(De-)aktiviert die Fader-Start Funktion.
CUE
Aktiviert Vorhören über Kopfhörer pro Ka-
nal.
CHANNEL FADER
Reguliert die Kanallautstärke.
LED-SIGNALKETTE
Visuelles Feedback für Master Ausgang oder
Kanaleingang (beides kann auf der Geräte-
rückseite gewählt werden).
CROSSFADER
Hiermit können Sie zwischen den Kanälen
überblenden.
MIXER SECTION
1
2
3
4
5
6
7
8
1
2
3
4
5
67
8
