Reloop innoFADER Configuration guide

INSTALL INSTRUCTIONS
Reloop Distribution
Global Distribution GmbH
Schuckertstr. 28
48153 Münster / Germany
Fax ++49/251/6099368
Subject to alterations.
Illustrations similar to original product.
Misprints excepted.
Copyright 2015
V1.5
Warning! Dismantling your mixer could invalidate the warranty. If you are
unsure of your ability to safely carry out this work then it is advised that
you leave it to a qualified service technician
Check compatible mixers on www.reloop.com/reloop-rmx-innofader
Safety instructions: Please always make sure the mixer is powered off
and the power plug is unplugged.
CAUTION!
For your own safety, please read this operation manual carefully before
initial operation! All persons involved in the installation, setting-up,
operation, maintenance and service of this device must be appropriately
qualified and observe this operation manual in detail. This product
complies with the requirements of the applicable European and national
regulations. Conformity has been proven. The respective statements
and documents are deposited at the manufacturer.
HOW TO REPLACE THE CROSSFADER:
1Remove the fader cap and the two screws shown in the red
circle. Take off the crossfader plate carefully.
2Remove the two screws shown in the red circle.
3Unplug the crossfader connection cable by slightly pulling
it out of the socket connector, while holding one thumb on
the connection shaft. Please do this very carefully.
4Remove the two screws shown in the red circle. Take off
the mounting plate.
Compatible with Reloop RMX-10/22i/33i/60/80 and all
future Reloop products with INNOFADER compatible logo
IM_RMX_innofader_V1.5_15012015.indd 1 16.07.2015 09:25:20

grey
grey
5 Now,takethemountingplateandxitontheminiInnofader
using the two screws to fasten it. Take the included adapter
cable and insert the 4Pin connection to the mini Innofader
socket.
The mounting plate should be in the correct upside-down
position to match with your mixer.
6Now, plug the other end of the adapter cable to the mixer
connection.
ATTENTION: The grey adapter cable shown in the image
below must be aligned towards the grey cable from the
mixer connection. If the fader doesn‘t work at all you
probably did this wrong.
7Place the mini Innofader into the unit and tighten the screws.
Please be sure the socket connector is oriented to the right
andthemountingplatesitsushandmatchesthemounting
groove.
8Put the crossfader plate on the unit and place the two
screwsshownintheredcircletoxit.Putthefadercapon
the shaft.
9Reconnect power cable to the mixer and power on. The
mini Innofader should now operate correctly. The Reloop
mini Innfofader is already calibrated for perfect sharpness.
If you wish to adjust the CUT IN manually please refer to
further manuals here:
www.reloop.com/reloop-rmx-innofader
