REMACO TECHNOLOGIES PRO-L3030 User manual

Screen Width
M8
Countersunk
Screws
M6 Stopper
Screws
M8 Anchors
M8 Long Nuts
For Suspension from Ceiling
Insert these accessories in
between the indicated arrow.
Use these holes
Wall Mount Ceiling Mount Ceiling
Suspension
Pelmet Mount
Side Pelmet Mount
Ceiling
Recessed
Corner Mount
Universal
Bracket
3-Cores
Power
Supply
AC Cable
Details
connection
inside
* For details dimension , please refer to technical specifications at
www.remacotech.com
* For PRO-L3030 to PRO-L3636 2 pieces of universal bracket are provided.
* For PRO-L3939 to PRO-L4343 3 pieces of universal bracket are provided.
.
4-Cores
Control
Cable
Electronics
Screen
Control
(ESC+)
UP
DOWN
STOP
UP
DOWN
UP
STOP
DOWN
>
_
>
IR
Remote
RF
Remote
Warning Caution with main supply and live wires. Install with qualified technician or trained
personnel.
Installation Guide / Manual (PRO-L3030 to PRO-L4343)
PRO-L
V: 10.2
CCOPYRIGHTS 1998 REMACO TECHNOLOGIES PTE LTD Website: www.remacotech.com
Warning
Universal Bracket can be used for any type of installation as shown below.
Brown (to Live)
Blue (to Neutral)
Green (to Earth)
Green
To ESC+
E
UP
DN
N
Motor
Blue
Black
Brown
Green
Brown
Brown
Brown
Blue
Blue
Black
Red
Internally Shorted
To 3-Cores
Power Supply
}
}

Screen Frame
Universal Bracket
35
Power Drill Pin Punch Hammer
M8 Anchor
B) Drill Dia 10mm Holes to a depth 35mm. C) Insert M8 Anchor into the hole.
D) Use pin punch to expand the anchor.
A) Mark the bracket position with the help of universal bracket.
STEP 1
STEP 2 10mm Drill
(Note: Do not drill too deep)
Hook on (NOT slide in)
STEP 3
ESC+ compatible with AVA-300 1-Channel Infrared Remote Control
OPTION-1
AVA-300
Infrared Remote Control
UP
DN STOP COM
CON3
ESC PCB
Board
Down
Up
Stop
Com
Switch S1
LED1
Jumper CH1: open
H2: close
C
UP
DOWN
STOP
UP
DOWN
Down
button
Stop
button
Up
button
ESC+
Down
Up
Neutral Live
AC Power
Input
Motor
A/V Control System
(e.g. AMX / Creston)
AVA-200
Wall Switch
STOP UP
DOWN
Contact Closure
Momentary Contact closure connection (dry contact, normally open, voltage free).
Recommended to set close contact for 1.5sec for best working condition.
Any voltage above 3Vdc voltage will damage this ESC
Suitable to use with control systems (example: AMX, Crestron, Extron, ..etc)
**Warranty void if damaged is caused by inappropriate use
!

Important Note
The upper limit and lower limit of the screen had been preset in factory. Any adjustment to these 2 limit
switches may cause damages to the screen fabric. If adjusted, it will cause the following problems:
a) The screen will roll into the frame and stop by force and not by the Upper Limit switch.
This will cause overheating of motor which unable the screen to operate properly.
b) The depression of the bottom bar onto the fabric will cause horizontal mark on screen surface.
c) Adjusting the Lower Limit of the screen any lower than beyond the STOP sticker may cause the fabric
to drop off
Disclaimer
Any adjustment to these 2 limit switches will void the warranty for the screen and Remaco will hold
no responsibility for any damages to it. Please consult us if it is necessary to do any adjustment to the
limit switch.
STEP 4
End
Pairing ESC+ with AVA-315 1-Ch
Learning Mode
Step1. Press and Hold Switch S1 for 4 seconds.
Step2. Release Switch S1 and motor step-move up/down, LED1 flash slowly.
Step3. Press UP button on the RF remote, motor step-move again and stop.
Step4. LED1 off and “Learning” is completed successfully.
* NOTE: Make sure RF remote control is set close to ESC+ not further 20cm.
**NOTE: If nothing is pressed within 20seconds, the learning mode will disable and back
to normal mode.
Delete Mode
Step1. Press and Hold Switch S1 until the LED1 flash fast.
Step2. Release Switch S1.
Step3. Press Switch S1 again within 7seconds.
Step4. LED1 off, “Delete” mode is completed successfully.
ESC+ compatible with AVA-315 1-Channel Radio Frequency Remote
OPTION-2
AVA-315
Radio Frequency Remote
E) To set screen to your desired “up” and “down” positions.
Bottom View
Lower Limit
Adjust “ - ” : screen roll away from frame
Adjust “ + ” : screen roll into the frame
Screen Frame
STOP
+
-
+
-
Red Knob
Upper Limit
White Knob
Allen Key (# 4mm) to set
limit switch knob
Upper Limit
Lower Limit
Adjust “ - ” : less screen drop
Adjust “ + ” : more screen drop
