Remii WM SLIM Series Assembly instructions

WM SLIM SERIES –REPAIR GUIDE
WM SLIM Series

Table of Content
•Replacing the tray light
•Replacing the flame light
•Replacing the flicker motor
•Replacing the heating element
•Replacing the PCB board
•Replacing the signal receiver
•Replac the touch control panel

Step 1 Push upward to take the front glass off.
Replacing the Tray Light

Step 2
Unscrew the two (2) screws each on
both the left and right hand side to
remove the back glass fixing bars.

Step 3 Unscrew the screw on the right and left hand side

Step 4
Unbuckle the touch control panel and take off the touch control panel assembly.

Step 5
Remove the back glass

Step 6 Remove the tray glass.

Step 7 Unscrew the screws to disconnect the tray light assembly from the fireplace

Step 8 Unbuckle tray light to disconnect the tray
light assembly from the fireplace, remove
and replace.

Replacing the Flame Light
Follow STEPS 1 thru 5 in Replacing the Tray Light to arrive here.

Step 1
Unscrew 2 screws on each on left and
right hand side to remove the flame
stencil.

Step 2 The flame light is located at the back of the flame stencil. Now
you can replace it with a new flame light.

Replacing the Flicker Motor
Follow STEPS 1 thru 5 in Replacing the Tray Light to arrive here.

Step 1
Unscrew 2 screws each on left and right
hand side to take off the flame stencil.

The flicker motor is situated here

Step 2
Unscrew the screw Disconnect the motor
from the rod
Unscrew the screws
to remove the motor
Pull out the wiring and
unplug the motor

Replacing the Heat Assembly
Follow STEPS 1 thru 5 in Replacing the Tray Light, you come to here.

Step 1 Unscrew the screws to disconnect the heat assembly from the fireplace

When the screws are removed the heat assembly can be detached
