Remington G2 Graphite Series User manual

G2 GRAPHITE SERIES
MULTI GROOM KIT
3 YEAR WARRANTY PG2000AU
To register your product go to
www.remington-products.com.au
www.remington.co.nz
USE & CARE
MANUAL
PLEASE READ
PRIOR TO USE

2
IMPORTANT SAFETY INSTRUCTIONS
When using electrical appliances, basic precautions should
always be observed, including the following.
READ ALL INSTRUCTIONS BEFORE USING
DANGER: As with most electrical appliances, electrical parts are
electrically live even when the switch is off.
For additional protection, the installation of a residual current
device (rcd) having a rated residual operating current not
exceeding 30 mA is advisable in the electrical circuit supplying
the bathroom. Ask your installer for advice.
KEEP AWAY FROM WATER
WARNING: TO REDUCE THE RISK OF BURNS, ELECTROCUTION AND
FIRE OR INJURY TO PERSONS
• Do not place or store the appliance or charging adaptor where it can
fall or be knocked into a sink or bath.
• Do not place in or drop into water or any other liquid.
• If an appliance falls into water, “unplug it” immediately. Do not reach
into the water.
• Unplug the charging adaptor from the electrical outlet immediately after
fully charging.
• Do not use while bathing or in the shower.
• Unplug and switch off this appliance before cleaning it.
• Use this appliance only for its intended use as described in this
manual.
• Do not use attachments not recommended by Remington.
• Never drop or insert any object into any opening of this appliance.
• Keep the cord away from heated surfaces.
• Do not use this appliance with a damaged or broken trimming
attachments as injury may occur.
• Always store the charging adaptor in a moisture-free location.
• For household use only.
• This appliance should not be used by children or other persons with
reduced physical, sensory or mental capabilities or lack of experience
and knowledge unless they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the
hazards involved.

3
• This appliance is not a toy. Children shall be supervised to ensure they
do not play with the appliance. Cleaning, use, and maintenance shall
not be made by children without supervision.
• Keep the appliance and the power cord away from edge of tables or
countertops and out of reach of children and persons with reduced
physical, sensory or mental capabilities.
• Do not use on people who are asleep.
• Never operate this appliance if it has a damaged cord or plug, if it is
not working correctly, if the charging adaptor has been damaged or
dropped into water.
• Do not use an extension cord or a voltage converter with this
appliance.
• Do not wrap the cord around the appliance.
• WARNING: For recharging the battery, only use the adaptor supplied
with the appliance.
• Always replace the adaptor with one of the original type.
WARNING - KEEP THE APPLIANCE DRY
SAVE THESE INSTRUCTIONS

4
PG2000AU G2 GRAPHITE SERIES MULTI GROOM KIT
USE & CARE INSTRUCTION MANUAL
Thank you for purchasing your Remington®G2 Graphite Series Multi-
Grooming Kit. Inside this manual you will find tips on using and caring for
your groomer.
KEY PARTS
1. 30mm Trimmer Head
2. Groomer Handle
3. On/Off Switch
4. Charging Indicator Light
5. 1.5mm & 3mm Fixed Comb
6. Nose, Ear, Eyebrow Trimmer
Head
7. Adjustable Comb
Attachment (2-20mm)
Also Includes:
• Power Adaptor
• Pouch
1
3
2
4
6
5
7

5
Note: The Adjustable Comb Attachment has various length settings. When
first becoming familiar with your groomer, begin with a higher numbered
setting. Adjust cutting length, as desired.
ABOUT YOUR GROOMER
PG2000AU SPECIFICATIONS
Power System Cordless (Rechargeable)
Full Charge Time 16 Hours
Run Time 40 Minutes
Indicators LED
Voltage Type Worldwide
Voltage Type: Worldwide Voltage - groomer automatically adapts to and
outlet voltage between 100V and 240V.
Note: Some countries will require the use of a plug adaptor that is not
included with your groomer.
CHARGING
Before using your trimmer for the first time, charge for 16 hours.
1. Ensure the product is switched off.
2. Connect the charging adaptor to the product and then to the mains.
• When charging, the charge indicator light will light up.
• Your trimmer cannot be overcharged. However, if it is not going to be
used for an extended period of time (2-3 months), unplug it from the
mains and store.
• To preserve the life of your batteries, let them run out every 6 months
then recharge for 16 hours.
• On a full charge, your beard trimmer will run for up to 40 minutes of
cordless usage.

6
ATTACHING AND REMOVING THE GROOMING HEADS
• Ensure that the groomer is switched off before fitting or removing
heads.
• To remove, rotate the head anti-clockwise until it unlocks and then lift
off.
• To fit, place the desired head on top of the groomer and rotate head
clockwise to lock into place.
ATTACHING AND REMOVING ADJUSTABLE COMB ATTACHMENT
• The Adjustable Comb attachment has 10 Length settings: 2-20mm
(in increments of 2mm). Begin with a higher numbered setting. Adjust
cutting length as desired once you are familiar with using the groomer,
it is better to select a longer hair length setting in order not to trim too
much hair.
• To fit, line up the rails on the comb with the slots on the sides of the
groomer and slide the comb downwards onto the groomer.
• To adjust, press and hold the adjustment button on the back of the
comb and slide the comb up or down. Release the button to lock the
comb at that position. The length of cut is indicated by the scale on the
side of the groomer.
• To remove, press and hold the adjustment button and push the comb
up and off the groomer.
ATTACHING AND REMOVING FIXED COMBS
• To fit, hook the front of the fixed comb over the teeth of the 30mm
trimmer head.
• Press the back of the fixed comb down until it clicks into place.
• To remove, lift the tab on the back of the fixed comb upwards until it
comes free from the 30mm trimmer head.

7
GROOMING TIPS
Hair Clipping: 30mm Trimmer Head With Adjustable Comb (2-20mm)
• Hair should be dry and free of lotions or other liquids.
• Comb outward to obtain maximum height / length and facing in the
same direction.
Step 1: Nape of the neck
1. Using a hand-held mirror is necessary if self-trimming.
2. Fit the 30mm trimmer head and adjustable comb.
3. Set the adjustable comb to 4 mm or 6 mm.
4. Hold the groomer with the blade teeth pointing upwards. Begin
starting at the centre of the head at the base of the neck.
5. Slowly lift the groomer, working upwards and outwards through the
hair, trimming just a little at a time.
Step 2: Back of the head
• With the adjustable comb set at 12 mm or 18 mm, cut the hair at the
back of the head.
Step 3: Side of the head
1. Adjust the comb to a shorter length setting for the areas around the
ears.
2. Increase the length setting on the adjustable comb to gradually
transition the length of hair on the side of the head to the longer hair
on the top of the head.
Step 4: Top of the head
1. Adjust the comb to the longer length settings (up to 20 mm) then cut
the hair on top of the head against the direction in which the hair
normally grows.
2. Always work from the back of the head.
Trim the sideburns
• To trim sideburns, adjust the comb to the desired length setting, or use
one of the clips on comb.

8
3-Day Stubble, and Body Hair Maintenance; 30mm Trimmer Head With
1.5mm or 3mm Fixed Comb
Let your stubble grow to a length that is slightly longer than the look you
are trying to achieve.
1. Fit the 1.5 mm fixed comb to the wide trimmer attachment.
2. Run your trimmer through your beard against the direction of hair
growth.
• For more control over the length of your stubble, you can use the
adjustable comb and trim your stubble down in increments starting at
a longer length setting until you get the desired look.
Beard / Moustache: 30mm Trimmer Head With Adjustable Comb
(2-20mm)
1. Use a small comb to straighten hairs for trimming.
2. Fit the 30mm trimmer head and adjustable comb.
3. Set the adjustable comb to the desired length.
4. Start trimming under the chin following the line of the jaw.
5. Work upwards towards the ear and upper beard line.
Contour Edging: 30mm Trimmer Head
1. Hold the groomer with the cutting blade (teeth) facing you and at 90
degrees to the skin.
2. Start with the edge of the beard/moustache line and, with the blade
resting lightly against the skin, use slow controlled movements to
create contoured lines.
Close Hair Cutting: 30mm Trimmer Head
1. Use the fingers of one hand to lift the hair at the base of your head up
off your neck.
2. Your index finger should be covering the roots of the hairs you are
lifting to prevent them from being accidentally cut.
3. Hold the groomer to the base of your neck with the blade facing up.
Move the groomer up the neck until it touches your index finger which
is protecting the hair roots.
4. Move your groomer slowly and keep the hair roots at the base of your
head out of the way of the groomer.

9
Ears: Nose, Ear, Eyebrow Trimmer Head
1. Fit the nose, ear, eyebrow trimmer head onto the groomer handle.
2. When trimming inner ears, avoid inserting the groomer more than
6mm into ear canal.
3. Turn the groomer on.
4. Insert the groomer’s cutting unit gently into the ear canal.
5. Rotate the groomer in a circular motion while gently moving in and out
of ear canal.
Eyebrows: Nose, Ear, Eyebrow Trimmer Head
1. Carefully guide the head to remove any stray or longer hairs from the
eyebrow.
2. For best results, do not use the groomer to define entire eyebrow.
Nose: Nose, Ear, Eyebrow Trimmer Head
1. Turn the groomer on.
2. Carefully insert the groomer’s cutting unit no more than 6mm into
nostril.
3. Rotate the groomer in a circular motion while gently moving in and out
of nose.
CLEANING, CARE & MAINTENANCE
Note: Always clean the groomer heads and attachment immediately after
use to ensure maximum performance and a proper operating life.
Clean Combs and Trimmer Heads With a Soft Brush (not included)
• With the head removed from the handle, gently brush out hair clippings
from the cutting system and top of groomer handle.
Clean Heads With Water
• With the head removed from the handle, rinse ONLY under warm
running water. Do NOT use hot water as this might cause damage.
Note: The groomer handle should not be rinsed.

10
This product is not suitable for bath or shower.
This product conforms to radio frequency interference requirements
Any product purchased and used commercially carries a limited 90 Day Warranty.
Oiling Blades & Cautions
• Rinsing attachments under water will require a re-lubrication of the
cutting blades once per month. Using only light grade oils (e.g. sewing
machine oil), simply place one or two drops lightly over cutters with
fingertip. Wipe away all excess
Note: Do not lubricate the foil shaver with oil as it is permanently lubricated.
BATTERY DISPOSAL
Note: The battery is not intended to be removed or replaced under normal
use.
• The PG2000AU contains a nickel metal hydride battery. Once the
trimmer has reached the end of its life, to ensure proper disposal of
the product, please take the appliance to a recycling centre, where the
internal rechargeable battery should be removed by a professional and
recycled separately.
• For more information about recycling of electrical and battery operated
appliances, please contact your local council office or your household
waste disposal service.
Caution: Do not put in the fire or mutilate your batteries when disposing as
they may burst and release toxic materials. Do not short circuit as it may
cause burns.
We suggest you use local waste management centres to recycle this
product at end of life.
