Remington PG4000AU User manual

G4 GRAPHITE SERIES
MULTI GROOM KIT
3 YEAR WARRANTY PG4000AU
To register your product go to
www.remington-products.com.au
www.remington.co.nz
USE & CARE
MANUAL
PLEASE READ
PRIOR TO USE

2
IMPORTANT SAFETY INSTRUCTIONS
When using electrical appliances, basic precautions should
always be observed, including the following.
READ ALL INSTRUCTIONS BEFORE USING
DANGER: As with most electrical appliances, electrical parts are
electrically live even when the switch is off.
For additional protection, the installation of a residual current
device (rcd) having a rated residual operating current not
exceeding 30 mA is advisable in the electrical circuit supplying
the bathroom. Ask your installer for advice.
KEEP AWAY FROM WATER
WARNING: TO REDUCE THE RISK OF BURNS, ELECTROCUTION AND
FIRE OR INJURY TO PERSONS
• Do not place or store the appliance or charging adaptor where it can
fall or be knocked into a sink or bath.
• Do not place in or drop into water or any other liquid.
• If an appliance falls into water, “unplug it” immediately. Do not reach
into the water.
• Unplug the charging adaptor from the electrical outlet immediately after
fully charging.
• Do not use while bathing or in the shower.
• Unplug and switch off this appliance before cleaning it.
• Use this appliance only for its intended use as described in this
manual.
• Do not use attachments not recommended by Remington.
• Never drop or insert any object into any opening of this appliance.
• Keep the cord away from heated surfaces.
• Do not use this appliance with a damaged or broken trimming unit as
injury may occur.
• Always store the charging adaptor in a moisture-free location.
• For household use only.
• This appliance should not be used by children or other persons with
reduced physical, sensory or mental capabilities or lack of experience
and knowledge unless they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the
hazards involved.

3
• This appliance is not a toy. Children shall be supervised to ensure they
do not play with the appliance. Cleaning, use, and maintenance shall
not be made by children without supervision.
• Keep the appliance and the power cord away from edge of tables or
countertops and out of reach of children and persons with reduced
physical, sensory or mental capabilities.
• Do not use on people who are asleep.
• Never operate this appliance if it has a damaged cord or plug, if it is
not working correctly, if the charging adaptor has been damaged or
dropped into water.
• Do not use an extension cord or a voltage converter with this
appliance.
• Do not wrap the cord around the appliance.
• WARNING: For recharging the battery, only use the adaptor supplied
with the appliance.
• Always replace the adaptor with one of the original type.
WARNING - KEEP THE APPLIANCE DRY
Remington strongly recommends that an approved Safety Switch (residual
current device) be installed to protect all bathroom power outlets. Ask an
electrical contractor for advice.
SAVE THESE INSTRUCTIONS

4
PG4000AU G4 GRAPHITE SERIES MULTI GROOM KIT
USE & CARE INSTRUCTION MANUAL
Thank you for purchasing your Remington®G4 Graphite Series Multi-
Grooming Kit. Inside this manual you will find tips on using and caring for
your groomer.
KEY PARTS
1. 30mm Trimmer Head
2. On/Off Switch
3. Charging Indicator Light
4. 2x Clip On Comb Guides
(1.5mm & 3mm)
5. Mini Foil Shaver Head
6. Nose, Ear, Eyebrow Trimmer
Head
7. Adjustable Beard &
Moustache Comb (2-20mm)
8. Micro Stubble & Precision
Trimmer
Also Includes:
• Power Adaptor
• Premium Storage Pouch
1
2
3
5
6
7
8
4

5
Note: The Adjustable Comb Attachments have various length settings.
When first becoming familiar with your G4 Graphite Series Multi Groom Kit,
begin with a higher numbered setting. Adjust cutting length, as desired.
ABOUT YOUR GROOMER
PG4000AU SPECIFICATIONS
Power System Cord/Cordless
Full Charge Time 10 Hours
Run Time 60 Minutes
Indicators LED
Voltage Type Worldwide
Voltage Type: Worldwide Voltage - groomer automatically adapts to and
outlet voltage between 100V and 240V.
Note: Some countries will require the use of a plug adaptor that is not
included with your groomer.
CHARGING
This appliance can be used ‘cordless’ by powering it from its internal
rechargeable battery, or ‘corded’ by connecting it to the charging adaptor
and then the mains power supply. Powering the appliance from the
charging adaptor is useful if the rechargeable battery does not have enough
charge. Be aware however, that frequent use of the cordless mode will
reduce the life of the rechargeable battery.
Before using your trimmer for the first time, charge for 10 hours.
1. 1. Ensure the product is switched off.
2. 2. Connect the charging adaptor to the product and then to the mains.
• When charging, the charge indicator light will light up. The light will go
out when charging is complete.
• Your trimmer cannot be overcharged. However, if it is not going to be
used for an extended period of time (2-3 months), unplug it from the
mains and store.
• To preserve the life of your batteries, let them run out every 6 months
then recharge for 10 hours.
• On a full charge, your beard trimmer will run for up to 60 minutes of
cordless usage.

6
Corded
• Connect the charging adaptor to the product and then to the mains.
• Switch your trimmer on.
• We recommend you let the product charge for a few minutes before
using corded.
HOW TO USE YOUR PERSONAL GROOMER
What attachments to use:
Nose,
Ear,
Eyebrow
Trimmer
Clip On
Combs
Mini
Foil
Shaver
Adjustable
Beard
Comb
Micro
Stubble
&
Precision
Blade
Beard X X X
Beard Line X X
Ear X
Eyebrow X
Moustache X X X
Nape of Neck X X
Nose X X
Sideburns X X X
Body X
Back
Hair X X
ATTACHING THE GROOMING ATTACHMENTS
Ensure that the device is switched off before fitting or removing
attachments.
• To remove, rotate the attachment anti-clockwise until it unlocks and
then lift it off.
• To fit, place the desired attachment on top of the device and rotate the
attachment clockwise to lock it into place.

7
FITTING AND REMOVING FIXED GUIDE COMBS: To Fit
• Hook the front of the guide comb over the teeth of the wide trimmer.
• Press the back of the guide comb down until it clicks into place.
FITTING AND REMOVING FIXED GUIDE COMBS: To Remove
• Lift the tab on the back of the guide comb upwards until it comes free
from the wide trimer head.
FITTING AND REMOVING THE ADJUSTABLE COMB
• To fit, line up the rails on the comb with the slots on the sides of the
groomer and slide the comb downwards onto the groomer.
• To adjust, press and hold the adjustment button on the back of the comb
and slide the comb up or down. Release the button to lock the comb at
that position. The length of cut is indicated by the scale on the side of the
trimmer.
• To remove, press and hold the adjustment button and push the comb up
and off the groomer.
GROOMING TIPS
• Comb facial hair with a fine comb before you start trimming.
• Comb your hair in the direction that it grows so that the hairs are at
their maximum height and facing in the same direction.
• After trimming, lightly go over the trimmed areas with the foil to get a
smooth clean finish.
• Since all hairs do not grow in the same direction, you may want to try
different trimming positions (i.e. upwards, downwards or across) for
better results.
• Hair should be dry and free from any waxes or lotions.
• If hair builds up during use, switch the unit off, remove any attachment
in use and clean any excess hair clippings from the attachment and
groomer.

8
3-Day Stubble, and Body Hair Maintenance: Wide Trimmer with 1.5mm
Fixed Comb or 3mm Fixed Comb, Precision Trimmer
3-Day Stubble Look:
Let your stubble grow to a length that is slightly longer than the look you
are trying to achieve.
1. Fit the 1.5mm fixed comb to the wide trimmer attachment.
2. Run your trimmer through your beard against the direction of hair
growth.
3. Tidy the edges of the stubble using the precision trimmer attachment.
• For more control over the length of your stubble, you can use the
adjustable comb and trim your stubble down in increments starting at
a longer length setting until you get the desired look.
Body Hair Maintenance
1. Let your hair grow to a length that is slightly longer than the look you
are trying to achieve.
2. Fit the 3mm fixed comb to the wide trimmer attachment.
3. Run your trimmer through your body hair against the direction of hair
growth.
Hair Clipping: Wide Trimmer with Adjustable Comb
Step 1: Nape of the neck
1. Fit the wide trimmer and adjustable comb.
2. Set the adjustable comb to 4mm or 6mm.
3. Hold the clipper with the blade teeth pointing upwards. Begin starting
at the centre of the head at the base of the neck.
4. Slowly lift the clipper, working upwards and outwards through the hair,
trimming just a little at a time.
Step 2: Back of the Head
• With the comb set at 12mm or 18mm, cut the hair at the back of the
head.
Step 3: Side of the Head
1. Adjust the comb to a shorter length setting for the areas around the
ears.
2. Increase the length setting on the adjustable comb to gradually
transition the length of hair on the side of the head to the longer hair
on the top of the head.

9
Step 4: Top of the Head
1. Adjust the comb to the longer length settings (up to 20 mm) then cut
the hair on top of the head against the direction in which the hair
normally grows.
2. Always work from the back of the head.
Trim the Sideburns
• To trim the sideburns, adjust the comb to the desired length setting, or
use one of the fixed guide combs.
Short/Long Beard Trimming: Wide Trimmer with Adjustable Comb,
Precision Trimmer
1. Fit the wide trimmer and adjustable comb.
2. Set the adjustable comb to the desired length.
3. Start trimming under the chin following the line of the jaw.
4. Work upwards towards the ear and upper beard line.
5. Tidy the beard edges using the precision trimmer attachment.
Contour Edging and Close Hair Cutting: Wide Trimmer
Contour Edging:
1. Hold the device with the cutting blade (teeth) facing you and at 90
degrees to the skin.
2. Start with the edge of the beard/moustache line and, with the blade
resting lightly against the skin, use slow controlled movements to
create contoured lines.
Close Hair Cutting:
1. Use the fingers of one hand to lift the hair at the base of your head up
off your neck.
2. Your index finger should be covering the roots of the hairs you are
lifting to prevent them from being accidentally cut.
3. Hold the trimmer to the base of your neck with the blade facing up.
Move the trimmer up the neck until it touches your index finger which
is protecting the hair roots.
4. Move your trimmer slowly and keep the hair roots at the base of your
head out of the way of the trimmer.

10
Detailed Nose, Eyebrow and Ear Hair Trimming: Nose, Ear and
Eyebrow Trimmer
Nose and Ear:
1. Fit the nose, ear and eyebrow trimmer.
2. Insert the attachment gently into the nostril or ear.
3. Gently move the attachment in and out while rotating the groomer at
the same time.
• Don’t insert the attachment more than 6mm into the nostril or ear.
Eyebrow:
1. Carefully guide the attachment to remove any stray or longer hairs
from the eybrow.
2. To completely remove hairs, let the attachment touch the skin then
move over the desired area.
Micro Stubble and Precision Trimming: Precision Trimmer
Micro Stubble:
The attachment has Trim Shave Technology which trims hair down to
0.2mm to leave a micro stubble finish.
1. Fit the precision trimmer.
2. Hold the attachment so that the guide on the lower edge of the blade
contacts the skin (in a the same way you as you would hold a wet
razor). The guide on the lower edge of the blade helps to stretch the
skin during trimming.
3. Use motions similar to wet shaving.
Precision Trimming:
1. Hold the precision trimmer attachment perpendicular to the skin.
2. Move it towards or away from the beard hair to achieve the desired
result. Use gentle pressure and controlled movements.
