Remington HC6550 User manual

HC6550
Vacuum Hair Clipper

2
Thank you for buying your new Remington® product. Please read these
instructions carefully and keep them safe. Remove all packaging before use.
F IMPORTANT SAFEGUARDS
1 This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been supervised/instructed and
understand the hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be done by children unless they are
older than 8 and supervised. Keep the appliance and cable out of reach of
children under 8 years.
2 Do not immerse the appliance in liquid; do not use it near water in a
bath-tub, basin or other vessel; and don’t use it outdoors.
,WARNING: Keep the body of the appliance dry.
3 Keep the power plug and cord away from heated surfaces.
4 Make sure the power plug and cord do not get wet.
5 An appliance should never be left unattended when plugged into a power
outlet, except when charging.
6 Do not use attachments other than those we supply.
7 Do not twist or kink the cable, or wrap it round the appliance.
8 Do not use the appliance if it is damaged or malfunctions.
9 Do not use the product with a damaged cord. A replacement can be
obtained via our International Service Centres.
10 Store the product at a temperature between 15°C and 35°C.
11 This appliance is not intended for commercial or salon use.
ENGLISH

3
CKEY FEATURES
1 On/o switch
2 Blade set
3 Vacuum intake
4 11 attachment guide combs
5 Charging indicator
6 Easy removable vacuum chamber
7 Vacuum chamber release button
8 Travel pouch (not shown)
9 Adaptor (not shown)
10 Cleaning brush (not shown)
11 Oil bottle (not shown)
ENGLISH
GBDNLFEIDKSFINPSKCZ
HUN
PLRUTRROGRSI
AE HR
UA
4
1
2
3
5
6
7

4
CVACUUM FEATURE
The Vacuum technology captures the majority of head hair
as it is cut. The hairs are vacuumed into an easy empty
vacuum chamber located on the front of the clipper. It is
recommended that you empty the vacuum chamber one it
becomes full by pushing the vacuum chamber release
button, pulling the chamber away from the clipper (See
Figure A) and emptying the trimmings into a bin.
To reattach the bin, angle the bin down towards the blade to
engage the single latch near the blade. Then rotate the back
end until the release latch is reengaged and clicks into place
CGETTING STARTED
,CHARGING YOUR APPLIANCE
,Note: It is recommended to fully charge your appliance before using for the
rst. Please refer to the charge times shown in this book.
•Ensure the product is switched o.
•This appliance should be supplied with approved safety isolating adaptors
HKP18-1201200dV (EU), HKP18-1201200dB (UK) with the output capacity of
12 Vdc; 1.2A (adaptor output).
•The adaptor automatically adjusts to a main voltage between 100V and 240V.
•Connect the charging adaptor to the product then to the mains.
,CHARGE LEVEL INDICATORS
Charge Level Indicator
Charging LED ash slowly
Empty LED ash rapidly
Fully Charged LED solid
•Run time from fully charged is up to 60 mins.
•Charge time from empty is 4 hours.
•To preserve the life of your batteries, let them run out every 6 months then
recharge for 4 hours.
ENGLISH
Fig. A

5
F INSTRUCTIONS FOR USE
• Forcordeduseconnecttheproducttotheadaptor,thentothemains.
,Caution: Extended mains only use will result in the reduction of the battery
life.
• Cordlessuse–whentheproductisswitchedonandfullychargeditcanbe
used in cordless mode for up to 60 minutes.
• Switchtheproductonbyslidinguptheon/oswitch.
,BEFORE STARTING THE CUT
• Inspecttheclippermakingsurethatitisfreefromhairanddirt.
• Seatthepersonsothattheirheadisapproximatelyatyoureyelevel.
• Beforecutting,alwayscombthehairsoitistanglefreeanddry.
Guide Comb Cutting Length
0 (Grade 0) 1.5mm
1 (Grade 1) 3mm
2 (Grade 2) 6mm
3 (Grade 3) 9mm
4 (Grade 4) 12mm
5 (Grade 5) 16mm
6 18mm
7 22mm
8 25mm
• Eachcombattachmentismarkedaccordinglyonitsoutsidemiddlesurface.
• Usetheclipperwithoutanyxedcombsfortrimminghairclosetotheskin.
• Thiswilltrimhairto1mm,holdingtheclippersothebladesare 
perpendicular to the skin will trim hair to 0.5mm.
,TO ATTACH A COMB
• Hookthefrontedgeofthecombtothefrontteethofthewidetrimmer
blade. Then push the back of the comb down until it snaps in place.
,TO REMOVE THE COMB
•Push up the back of the comb until it clicks o the clipper blade.
ENGLISH
GBDNLFEIDKSFINPSKCZ
HUN
PLRUTRROGRSI
AE HR
UA

6
,INSTRUCTIONS FOR CUTTING HAIR
,Vacuum Feature
•To maximise the amount of hair clippings collected in the vacuum, please
do not move the clipper too quickly when clipping from the sides to the
crown of the head.
•This vacuum chamber is capable of collecting 2.25g of hair, this equates to
6mm of hair growth.
•A typical 1 month’s growth of (12mm) haircut would require the bin being
emptied 2-3 times in total when cutting the hair.
•Ensure you monitor the bin whilst cutting your hair to maximise the
eciency of the vacuum performance. Empty the bin before it gets full to
ensure hair clippings continue to be eectively collected in the vacuum
chamber.
•When cutting hair, always keep the unit on when holding the clipper upside
down.
•For optimum performance do not trim hair 18mm or longer with one pass of
the clipper.
•When cutting hair 18mm or longer use a nger on your free hand in between
the comb and clipper to guide hair into the blade by applying slight pressure.
As you move the clipper up to cut, your nger will help keep the longer hairs
from slipping away before they can be cut. If the hair extends well past the
hair collection chamber opening, place your nger on top of the chamber
near the opening.
•For even cutting, allow the comb attachment/blade to cut its way through
the hair. Do not force it through quickly. If you are cutting for the rst time,
start with the maximum comb attachment.
,STEP 1 – Nape of the neck
•Set the comb to 3mm or 6mm.
•Hold the clipper with the blade teeth pointing upwards. Begin starting at the
centre of the head at the base of the neck.
•Slowly lift the clipper, working upwards and outwards through the hair,
trimming just a little at a time.
,STEP 2 – Back of the head
•With the comb set at 12mm or 18mm, cut the hair at the back of the head.
,STEP 3 – Side of the head
•With the comb set at 3mm or 6mm, trim sideburns. Then change to the
longer 9mm guide comb and continue to cut up to the top of the head.
ENGLISH

7
,STEP 4 – Top of the head
•With the 18mm or 22mm guide comb attached, cut hair on top of the head
against the direction in which the hair normally grows.
,Note: For longer desired lengths of more than 22mm, place nger over hair
and guide into the guide comb and blade to better guide the hairs
trimmings into the vacuum chamber.
•Always work from the back of the head.
,STEP 5 – The nishing touches
• Usetheclipperwithoutaguidecombforclosetrimmingaroundthebase
and sides of the neck.
• Toproduceacleanstraightlineatthesideburns,reversethehairclipper.
• Placethereversedclipperatrightanglestothehead,tipsoftheblades
lightly touching the skin and then work downwards.
,SHORT TAPERED STYLES – “FLAT TOPS” & SHORT CUTS
• Startingwiththelongestguidecombattached(25mm),cutfromtheback
of the neck to the crown. Hold the guide comb at against the head and
slowly
move the clipper through the hair.
• Usethesameprocedurefromthelowersidetotheuppersideofthehead.
• Thencutthehairagainstthedirectioninwhichitgrowsandlevelwiththe
sides.
• Togivea“attop”look,thehairontopoftheheadmustbecutoverthetop
of a at comb.
• Useacloserguidecombtotaperthehairdowntothenecklineasdesired.
C CARE FOR YOUR HAIRCLIPPER
• Toensurelonglastingperformanceoftheclipper,cleanthebladesandunit
regularly.
• Ensuretheapplianceisswitchedoandunpluggedfromthemainsoutlet
before cleaning
• Donotuseharshorcorrosivecleanersontheunitsortheircutters.
• Cleaningshouldbedonewithasoftbrush.
,AFTER EACH USE
• Brushtheaccumulatedhairfromtheblades.
• Tocleantheunit,wipewithadampclothanddryimmediately.
,Note: To maintain the eective vacuum performance of the clipper,
regularly brush or rinse ne hairs in the mesh panel found at the base of the
vacuum chamber.
ENGLISH
GBDNLFEIDKSFINPSKCZ
HUN
PLRUTRROGRSI
AE HR
UA

8
• Themeshpanelishingedandcanbeswungopenwhenthechamberis
removed from the clipper.
• Ensurethemeshpanelisdrybeforere-usingtheclipper.
• We recommend oiling the blades after cleaning with a little sewing machine
oil.
,WASHABLE CLEANING
,NOTE: Only the blades on this clipper and the mesh panel of the vacuum
chamber can be washed under running water.
•To remove the blades ensure the unit is o. Grab underneath the blade with
your thumb and push the top of the blade away from the clipper.
•Use enough force to move the blade o the retaining snaps and rotate the
blade o the bottom tab. Pull the blade away from the clipper.
•To reattach once the blades are cleaned and dry, align the bottom of the
blade with the bottom blade housing tab and push down onto the retaining
snaps until the blade clicks into place.
•Do not run the entire unit under the tap, only the blade set is meant to be
submerged in water.
•Place a few drops of cutter or sewing machine oil onto the blades. Wipe o
excess oil.
BATTERY REMOVAL
•The battery must be removed from the appliance before it is scrapped.
•The appliance must be disconnected from the supply mains when removing
the battery.
•Ensure the clipper is discharged of all power.
•Remove vacuum chamber and blade.
•Using a small screwdriver, remove 3 screws top of clipper where the vacuum
chamber was.
•Using a small screwdriver, remove 2 screws bottom of unit near the back
(plug end).
•Pry the top housing starting from the back (plug end). There are snaps
helping to hold down the housing at the side grips on both sides. Once the
snaps are disengaged then rotate housing up this will allow the panel to be
removed o the latches near the front (blade end).
•The PCB and batteries are located underneath this panel.
•Cut or break the wire stamps on the both end of the batteries and remove
the batteries.
•The battery is to be disposed of safely.
ENGLISH

9
H ENVIRONMENTAL PROTECTION
To avoid environmental and health problems due to hazardous
substances in electrical and electronic goods, appliances marked with
this symbol must not be disposed of with unsorted municipal waste, but
recovered, reused or recycled.
ENGLISH
GBDNLFEIDKSFINPSKCZ
HUN
PLRUTRROGRSI
AE HR
UA

10
Vielen Dank, dass Sie sich für den Kauf dieses Remington® Produkts entschieden
haben.
Lesen Sie diese Bedienungsanleitung aufmerksam durch und bewahren Sie sie
auf. Entfernen Sie die Verpackung vor dem Gebrauch vollständig.
F WICHTIGE SICHERHEITSHINWEISE
1 Dieses Gerät ist für die Nutzung von Kindern ab 8 Jahren sowie von
Personen mit eingeschränkten physischen, sensorischen oder geistigen
Fähigkeiten oder Mangel an Erfahrung und Wissen geeignet, wenn ihnen
die Handhabung erklärt wurde/ sie dabei beaufsichtigt werden und ihnen
die damit verbundenen Gefahren bewusst sind. Kinder dürfen nicht mit
dem Gerät spielen. Reinigung und Pege dürfen nicht von Kindern
durchgeführt werden, es sei denn sie sind älter als 8 Jahre und werden
dabei beaufsichtigt. Bewahren Sie das Gerät und das Kabel außer
Reichweite von Kindern unter 8 Jahren auf.
2 Tauchen Sie das Gerät nicht in Flüssigkeiten. Verwenden Sie es
nicht in der Nähe einer Badewanne, einem Behälter oder
anderen Gefäßen, die Wasser enthalten, und verwenden Sie es
nicht im Freien.
,WARNHINWEIS: Achten Sie darauf, dass das Gerät trocken bleibt.
3 Bringen Sie den Netzstecker und das Netzkabel nicht mit beheizten
Oberächen in Berührung.
4 Achten Sie darauf, dass der Netzstecker und das Netzkabel nicht nass
werden.
5 Lassen Sie das an das Stromnetz angeschlossene Gerät auf keinen Fall
unbeaufsichtigt, ausgenommen, wenn es gerade aufgeladen wird.
6 Verwenden Sie nur das von uns zur Verfügung gestellte Zubehör.
7 Achten Sie darauf, dass Sie das Kabel nicht knicken oder verdrehen. Wickeln
Sie es auch nicht um das Gerät.
8 Verwenden Sie das Gerät nicht, wenn es beschädigt ist oder nicht richtig
funktioniert.
9 Um eine mögliche Gefährdung auszuschließen, sollte das Gerät nicht
genutzt werden, wenn das Kabel Beschädigungen aufweist. Ersatz kann
durch das Service Center / Kundendienst zur Verfügung gestellt werden.
10 Bewahren Sie das Gerät zwischen 15 °C und 35 °C auf.
11 Dieses Gerät ist nicht für die gewerbliche Nutzung geeignet.
DEUTSCH
