Remington HC5356 User manual

Gift Set - Clipper
HC5356

2
Thank you for buying your new Remington® product. Please read these
instructions carefully and keep them safe. Remove all packaging before use.
F IMPORTANT SAFETY INSTRUCTIONS
Warning – for additional protection the installation of a residual current device
(RCD) with a rated residual operating current not exceeding 30mA is advisable in
the electrical circuit supplying the bathroom. Ask an electrician for advice.
1 This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been supervised/instructed and
understand the hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be done by children unless they
are older than 8 and supervised. Keep the appliance and cable out of reach
of children under 8 years.
2 An appliance should never be left unattended when plugged into a power
outlet, except when charging.
3 Keep the power plug and cord away from heated surfaces.
4 Do not immerse the appliance in liquid; do not use it near water in
a bath-tub, basin or other vessel; and don’t use it outdoors.
5 Make sure the power plug and cord do not get wet.
6 Do not plug or unplug the appliance with wet hands.
7 Do not use the product with a damaged cord. A replacement can be
obtained via our International Service Centres.
8 Do not twist or kink the cable, or wrap it round the appliance.
9 Store the product at a temperature between 15°C and 35°C.
10 Do not use attachments other than those we supply.
11 Always remember to turn on the groomer before you insert it into your nose
or ear to avoid injury.
13 This appliance is not intended for commercial or salon use.
14 Suitable for cleaning under an open water tap.
ENGLISH

3
CKEY FEATURES
1 On/o switch 6 Charging indicator light
2 Blade set 7 Micro USB port
3 2 attachment guide combs 8 Micro USB cable (not shown)
4 Quick wash release buttons 9 Adaptor (not shown)
5 Hair thinner mechanism
NOSE AND EAR TRIMER
10 Detail trimmer
11 On/o switch
12 Battery compartment
ENGLISH
GBDNLFEIDKSFINPSKCZ
HUN
PLRUTRROGRSL
AE HR
UA
12
11
10
1
7
6
5
4
2
3

4
CGETTING STARTED
,CHARGING YOUR APPLIANCE
•Before using your hairclipper for the rst time, charge for 14-16 hours.
•Ensure the product is switched o.
•Connect the charging adaptor to the product and then to the mains. The
charging indicator will illuminate.
•Charging display light will stay on after the battery is fully charged.
•If the product is not going to be used for an extended period time (2 – 3
months), unplug it from the mains and store.
•Fully recharge your hairclipper when you would like to use it again.
•To preserve the life of your batteries, let them run out every 6 months then
recharge for 14-16 hours.
,CHARGING VIA STANDARD ELECTRICAL SOCKET
•Ensure the product is switched o.
•Connect the charging adaptor to the product and then to the mains.
•When charging the LED indicator will illuminate.
•Allow 14-16 hours for a complete charge.
,USB
•Connect your USB cable to the USB port on your power source.
•Connect the USB cable to your appliance.
,CORDED USE
•Connect the charging adaptor to the product then to the mains.
•When the cord is connected to the mains, a charging LED light is displayed
on the hairclipper.
,CAUTION
•Extended mains only use will result in the reduction of the battery life.
,WARNING
•The appliance can not be operated in corded mode while connected to a PC
via the USB port.
,CORDLESS USE
•When the unit is switched on and fully charged, the product can be used in
cordless mode for 40 minutes.
ENGLISH

5
,TRIMMER
,INSERTING BATTERIES
•Your appliance requires 1 ‘AA’ alkaline battery .We recommend that you
use VARTA® batteries.
•Make sure the product is turned o.
•Rotate the battery compartment cap approximately ¼ turn anti-clockwise
then pull o.
•Insert 1 “AA” alkaline battery so that the (+) and (-) marks on the battery
face the same mark in the battery compartment.
•Place cap back on unit using the alignment marks and rotate clockwise
until the cap snaps into place.
,NOTE: Your trimmer will not work if the batteries are inserted incorrectly.
F INSTRUCTIONS FOR USE
,BEFORE STARTING THE CUT
•Inspect the clipper making sure that it is free from hair and dirt.
•Seat the person so that their head is approximately at your eye level.
•Before cutting, always comb the hair so it is tangle free and dry.
Comb Position Short Comb Long Comb
1 3mm 24mm
2 6mm 27mm
3 9mm 30mm
4 12mm 33mm
5 15mm 36mm
6 18mm 39mm
7 21mm 42mm
,Note: 1mm length is achieved without any combs.
,TO ATTACH A COMB
•Hold the comb with its teeth upward.
•Align the rails on comb with the slots on the clipper body, and slide the
comb down.
•Slide it onto and along the clipper blade until the front of the comb rmly
sits against the clipper blade.
ENGLISH
GBDNLFEIDKSFINPSKCZ
HUN
PLRUTRROGRSL
AE HR
UA

6
,TO REMOVE THE COMB
•Press and hold the release button and holding the clipper with the blades
facing away from you, rmly push the comb upward and away from the
blades.
•Each comb attachment is marked accordingly on its outside middle surface
(3-21 mm & 24-42 mm).
,INSTRUCTIONS FOR CUTTING HAIR
•For even cutting, allow the comb attachment/blade to cut its way through
the hair. Do not force it through quickly. If you are cutting for the rst time,
start with the maximum comb attachment.
,STEP 1 – Nape of the neck
•Set the comb to 3mm or 6mm.
•Hold the clipper with the blade teeth pointing upwards. Begin starting at
the centre of the head at the base of the neck.
•Slowly lift the clipper, working upwards and outwards through the hair,
trimming just a little at a time.
,STEP 2 – Back of the head
•With the comb set at 12mm or 18mm, cut the hair at the back of the head.
,STEP 3 – Side of the head
•Set the comb to 3mm or 6mm, trim sideburns. Then change the setting to
9mm and continue to cut the top of the head.
,STEP 4 – Top of the head
•Use the longer length comb attachment and set it to 24mm or 27mm then
cut hair on top of the head against the direction in which the hair normally
grows.
•For longer hair on top, use the longer length comb attachment (24 – 42mm)
to achieve the desired style.
•Always work from the back of the head.
,STEP 5 – The nishing touches
•Use the clipper without an attachment comb for close trimming around the
base and sides of the neck.
•To produce a clean straight line at the sideburns, reverse the hair clipper.
•Place the reversed clipper at right angles to the head, tips of the blades
lightly touching the skin and then work downwards.
ENGLISH

7
,SHORT TAPERED STYLES – “FLAT TOPS” & SHORT CUTS
•Starting with the longest guide comb attached (24-42mm), cut from the
back of the neck to the crown. Hold the guide comb at against the head
and slowly move the clipper through the hair.
•Use the same procedure from the lower side to the upper side of the head.
Then cut the hair against the direction in which it grows and level with the
sides.
•To give a “at top” look, the hair on top of the head must be cut over the
top of a at comb.
•Use a closer guide comb to taper the hair down to the neckline as desired.
,HAIR TEXTURE MECHANISM
•Simply adjust the hair texture mechanism by sliding the button at the top
of the hair clipper.
•Blending dierent length areas. Select the proper length guard to blend.
Slide out the hair texture mechanism (guard) which allows you to blend /
thin out the area.
•Textured cut – Slide out the hair texture mechanism (guard) to give an all
over textured cut.
,TRIMMER
•To turn on, twist the battery cover to the right.
, TO DEFINE THE BEARD/MOUSTACHE LINE
•Hold the trimmer with the trimmer blade facing you.
•Start with edge of beard/moustache line and gently lower the trimmer
blade onto your skin. Use motions towards edge of beard/moustache line
to trim to desired locations in facial area and away from beard in neck area.
,TRIMMING EDGE OF SIDEBURNS
•Hold the trimmer with the trimmer blade facing you.
•Start with edge of sideburn, and with the trimmer blades resting lightly
against your skin, use motions towards edge of sideburn line to trim the
desired locations in facial area.
•To switch o, twist the battery cover to the left aligning the body of the
trimmer.
C CARE FOR YOUR HAIRCLIPPER
•Your clipper is tted with high quality blades.
ENGLISH
GBDNLFEIDKSFINPSKCZ
HUN
PLRUTRROGRSL
AE HR
UA

8
•To ensure long lasting performance of your clipper, clean the blades and
unit regularly.
•Always keep the attachment guide comb on the trimmer blade.
,AFTER EACH USE
•Ensure the appliance is switched o and unplugged from the mains before
cleaning.
•Brush the accumulated hair from the blades. Do not submerge the clipper in
water.
•To clean the unit, wipe with a damp cloth and dry immediately.
,WASHABLE CLEANING
•The QUICK WASH SYSTEM is designed to maximise the eciency of
washable cleaning.
•Click the buttons located on the sides of the hair clipper head; the blades
will slide out and the blade set can be easily cleaned under the tap.
•Once the blades are cleaned the blades are locked into place by pushing the
blade set towards the hair clipper head and will snap into place.
•Do not run the entire unit under the tap, only the blade set is meant to be
submerged in water.
•Suitable for cleaning under an open water tap.
,Note: Ensure the clipper is turned o when cleaning.
,EVERY SIX MONTHS
•At regular intervals the blade set should be removed and cleaned.
•Remove the 2 screws retaining the xed blade with a screwdriver. Do not
remove blade set.
•Brush out hairs from between the blades with soft cleaning brush. Do not
remove the lubricating grease from the blades. It is not necessary to remove
the small moving blade from the unit.
•If the moving blade has been removed this can be re-tted by slotting the
blade holder over the pin in the centre of the interior product head. The
groove on the blade, just below the teeth, rests on a metal plate at the
opposite side to the screw holes. The xed blade is tted with the raised
prole pointing outwards and xed with the 2 screws.
•If the blades are not correctly aligned, cutting eciency will be impaired.
•Place a few drops of cutter or sewing machine oil onto the blades. Wipe o
excess oil.
ENGLISH

9
C CARE FOR YOUR TRIMMER
•Care for your appliance to ensure a long lasting performance.
•The easiest and most hygienic way to clean the appliance is by rinsing the
appliance head after use with warm water.
•Keep the switch in the “o” position when not in use.
,AFTER EACH USE
•Rinse the accumulated hair from the cutters and shake of excess water.
•To clean the unit, wipe with a damp cloth and dry immediately.
•This product is suitable for use in the shower and for cleaning under water.
,CLEANING
•Only the attachment guide combs and trimmer blade may be removed
from the product for cleaning.
•Cleaning should be done with a soft brush.
•Suitable for cleaning under an open water tap.
•Do not use harsh or corrosive cleaners on the units or their cutters.
BATTERY REMOVAL
•The battery must be removed from the appliance before it is scrapped.
•The appliance must be disconnected from the supply mains when
removing the battery.
•Ensure that the clipper is discharged of all power and disconnected from
the mains
•Lift or pry the USB port cover plate on the bottom of the clipper.
•Lift or pry the deco plate on the lower portion of the clipper and unscrew 1
screw located on the back housing of the clipper.
•Lift or pry the clipper halves apart, exposing the battery chamber.
•Lift or pry the USB connector and lift or pry the cover plate on the bottom
of the battery chamber.
•Remove the battery and printed circuit board assembly from the battery
chamber.
•Cut the tabs on both ends of the battery and remove it from the printed
circuit board.
•The battery is to be disposed of safely.
ENGLISH
GBDNLFEIDKSFINPSKCZ
HUN
PLRUTRROGRSL
AE HR
UA

10
H ENVIRONMENTAL PROTECTION
To avoid environmental and health problems due to hazardous
substances in electrical and electronic goods, appliances marked with this
symbol must not be disposed of with unsorted municipal waste, but
recovered, reused or recycled.
ENGLISH
