REMKO PWL Series User manual

Edition GB – Vo6
REMKO PWL
Ceiling-mounted air unit
Heating/Cooling
Operation · Technology · Spare parts

3
Contents
Made by REMKO
Planning information 4
Safety information 4
Unit description 5
Mounting the unit 6
Mounting examples 7
Electrical connection 8
Hydraulic connection 8
Commissioning 9
Decommissioning 10
Care and maintenance 10
Repair 11
Fan motor 12
Condensate pump 12
Unit dimensions 13
Rating tables/Technical data PWL 101-103 14
Rating tables/Technical data PWL 201-203 16
Rating tables/Technical data PWL 301-303 18
Intended use 20
Customer service and warranty 20
Environmental protection and recycling 20
Exploded view 21
Spare parts list 21
Legend/Operating limits 22
Technical data 23
Carefully read these operating instructions before commissioning/
using the units!
These instructions are part of the unit and must always be kept near
to the site of installation or at the unit.
This operating manual is a translation of the German original.
We reserve the right to make changes; no liability for errors and misprints!

4
REMKO PWL
Safety information
The units were subjected to ex-
tensive material, functional and
quality inspections and tests prior
to delivery.
The units can however constitute
a hazard if used improperly by
untrained persons or not for the
intended purpose.
Always observe the following safe-
ty information:
■The locally applicable building
regulations must be observed.
■The operator is responsible for
correct installation of the units,
correct electrical installation and
safe operation of the units.
■The units must be installed
and operated in a manner that
excludes any risk to persons
through radiated heat.
■The units must only be attached
to constructions or ceilings with
sufficient load bearing capacity.
■Attachment must take place
using suitable anchors to be
attached to the unit.
■Only trained specialists may
install and connect the heating
medium, establish electrical con-
nections and carry out mainte-
nance.
■The units must not be installed,
mounted and operated in loca-
tions subject to fire and explosi-
on hazards or exposed to dust-
laden/aggressive atmospheres.
■The units must be installed out-
side traffic zones, e.g. also the
operating areas of cranes.
Planning information
For an optimal room temperature,
several basic rules must be follo-
wed for room heating and cooling
planning.
Heating mode
The following data is required for
room heating planning:
■Room heat demand
QH(kW)
■Basic room dimensions
(length, width, height)
■Required air change
■Required room temperature
■Required heating medium tem-
perature for flow and return
The air inlet temperature of the
units should not be below 34°C
and not above 42°C.
At an outlet temperature below
34°C, there is a risk of
unpleasant, cool draughts in the
area of workplaces.
If the outlet temperature is abo-
ve 42°C, an increased upcurrent
of hot air will occur in the ceiling
area.
The range of the hot air current is
reduced and the air in the room
is inadequately penetrated by the
hot air current and intermixed.
Undesired “cold air zones“ form
in the room, and in contrast, an
excessive cushion of hot air forms
in the ceiling area.
This causes unnecessary heat
losses.
Cooling mode
The following data is required for
room cooling planning:
■Room cooling load
Qk(kW)
■Basic room dimensions
(length, width, height)
■Required room temperature and
possible relative humidity
■Required cooling medium tem-
peratures for flow and return
To avoid unpleasant draughts at
workplaces, the air outlet tem-
perature in cooling mode should
be maximum 6 – 8 K below the
ambient temperature.
An excessive temperature dif-
ference (> 8 K) can lead to the
formation of unpleasant “cold air
zones”.
The circulated total air volume of
the units per hour should be about
4 to 5 times the room volume.
With inadequate air circulation
volume, the required room climate
is achieved very slowly and with
delay.
An excessive air circulation volume
is preferable since the system is
able to respond more dynamically
and effectively.
The air circulation volume can be
increased using external aids (e.g.
ceiling fans).

5
■The units must only be operated
in a completely assembled and
mounted condition.
■The units must only be opera-
ted within the specified capacity
limits and with the approved
operating media.
■Safeguards, e.g. barriers must
not be removed or rendered
inoperational.
■The units must only be operated
within the specified capacity
limits and with the approved
operating media.
■The air intake grilles must
always be kept free of dirt and
loose objects and the air outlet
must not be closed.
■Never insert foreign objects into
the unit.
■The units must not be exposed
to a direct jet of water.
■Do not operate the units in wet
areas with high humidity (e.g.
car wash).
■All electric cables of the units
must be protected against da-
mage e.g. animals, etc.
Unit description
These units are stationary, indirect-
ly recirculated air cooling/heating
units with copper/aluminium fin
heat exchangers for connection to
a pumped cold/ hot water system
up to max. 90°C.
The units are in an exclusive de-
sign, compact, universal and are
easy to install and service.
NOTE
Perfect functioning of the units
is only ensured when the flow
temperature at the unit inlet
and the pump capacity cor-
respond to the selected unit
classification.
The inner supporting unit con-
struction is made of galvanised
sheet steel.
The heat exchangers have copper
tubes with aluminium fins.
For removal of the produced
condensate in cooling operation,
a ready to connect condensate
pump is provided.
For an optimal air flow, individually
adjustable louvres are provided at
the top of the housing and fully
adjustable louvre segments are
provided at the bottom.
The air discharge direction (hori-
zontal or vertical) can be individu-
ally adjusted to suit the local requi-
rements by changing the direction
of rotation of the fan.
The plastic housing can be deta-
ched completely from the sup-
porting lower housing part by
removing the securing clip. The
integrated securing strips prevent
the cover from falling.
The plastic housing of the units is
made of self-extinguishing material
(fire class V-0).
The heaters comply with the basic
health and safety requirements of
the pertinent EU regulations and
are easy to operate.
The units are suitable for heating/
cooling rooms with high or low
ceilings and where special impor-
tance is attached to exclusivity.
For example in large rooms such
as:
■Exhibition halls
■Sales rooms
■Shopping centres
■Business premises
■Warehouses
■Production halls
■Foremen’s offices
■Large entrance areas
The units must be mounted hori-
zontally on ceilings or roof struc-
tures.
The units are fitted with an aero-
dynamic, powerful two-speed axial
flow fan with 400V/50Hz external
rotor motor as standard.
Help save on energy consump-
tion in stand-by mode! If the
device, system or component
is not in use, we recommend
disconnecting the power sup-
ply. Components with a safety
function is excluded from our
recommendation!
TIP

6
REMKO PWL
The following information must be
observed for safe unit installation:
■The units must be arranged so
that accessed areas and work-
places are not located in the
direct air stream.
■The units must only be moun-
ted on ceilings or roof struc-
tures with sufficient load
bearing capacity.
■The units must be mounted
horizontally and free of stress.
■The heat exchangers must be
connected so that no vibrations
can be transferred from the unit
to the pipe system or vice versa.
■Suitable connection fittings,
shut-off valves, vent valves, etc.
must be mounted locally.
■For mounting on ceilings and
in rooms with low and high
ceilings, the maximum moun-
ting heights of the unit must be
observed.
■Before connecting the units to
an existing hot water heating
system, the boiler and pump
must be checked for sufficient
capacity.
■For maintenance and repairs, a
suitable repair switch (accesso-
ry) must be fitted.
■The gap between the fan im-
peller and unit housing must be
checked for the same distance.
Mounting the unit
Cooling mode
The maximum ranges apply to an
air outlet temperature of 8K below
room temperature and ideal prima-
ry air flow conditions.
Maximum mounting heights and operating limits
The maximum mounting heights depend on the maximum range and direction.
PWL Mounting height and range
in m „vertical“ blowing direction
Mounting height and range
in m „horizontal“ blowing direction
101-3 3.8 / range 2.3 2.5 / range 3.4
201-3 5.5 / range 4.0 3.8 / range 7.9
301-3 7.0 / range 5.5 5.7 / range 7.0
Heating mode
The maximum mounting heights and ranges (at 0.2 m/s) apply to an air
outlet temperature of 20K over the room temperature and ideal condi-
tions of the primary air flow.
PWL max. range in mm
101-3 4.0 1)
201-3 10.0 1)
301-3 9.1 1)
We reserve the right to make dimensional and design changes in the interest of technical advances.
1) Blowing direction horizontal +vertical
max. mounting height
max. range
Ensure that no persons are standing under suspended loads during instal-
lation!
For marking the points of attachment, please use the supplied template
in the packaging. It must be ensured that sufficient space is available
between the unit and ceiling for the media connections.
The adjustable brackets (option) can be individually aligned for adjustment.
Fixed bracket (standard) Adjustable bracket (option)

7
Mounting examples
The unit are designed for use in
rooms with high and low ceilings.
The direction of the air flow can
be individually adjusted to the suit,
the building conditions or personal
requirements by changing the di-
rection of rotation of the fan (pole
reversal).
In this way, the air flow, when
using the units in rooms with low
ceilings, can be controlled horizon-
tally by means of the individually
adjustable air louvres located at
the top of the housing.
This prevents persons being expo-
sed to a direct air stream.
Rooms with low ceilings; horizontal
blowing direction
Rooms with low ceilings; horizontal
blowing direction
Rooms with high ceilings; vertical
blowing direction
Heating and cooling combination options
The triangular shape of the units offers numerous individual mounting arrangements, so that even corner areas
are taken into account.
Window frontage
Window frontage
Cooling mode
Heating mode
We reserve the right to make dimensional and design changes in the interest of technical advances.
Rooms with high ceilings; vertical
blowing direction
Rooms with high ceilings; vertical
blowing direction

8
REMKO PWL
Electrical connections of the unit
must only be established by autho-
rised specialists in compliance with
the applicable regulations of the
local electricity supply company as
well as the VDE installation requi-
rements relating to the unit.
Connection of the units
The units are fitted with two-
speed, 400V three-phase axial
flow fans as standard.
Speed selection takes place with
appropriate control units (accesso-
ry).
Changes in direction take place via
a pole changing switch or special
control unit (accessory).
Motor protection is provided via
integrated thermal contacts in
conjunction with a suitable control
unit (accessory).
Connection of the three-phase
motors to the respective control
units takes place via the associated
electrical wiring diagrams.
ATTENTION
Failure to observe the pertinent
requirements, operating inst-
ructions and electrical wiring
diagrams relating to the unit
can give rise to malfunctions
with consequential damage.
This will invalidate the war-
ranty!
Connection of several units
If necessary, several units (also
different sizes) can be operated
parallel via a control unit (accesso-
ry).
The total capacity of the con-
nected units must not exceed the
maximum switching capacity of
the respective control unit.
For thermal motor protection, the
thermal contacts of all motors
must be connected in series. See
separate wiring diagrams.
Only one external control device
(thermostat, day/night control,
etc.) can always be connected per
control unit.
Terminals in the unit
Fuse protection in the supply to
the control unit must be in compli-
ance with the applicable regulati-
ons.
The connections in the terminal
box must be connected to the
respective control unit (accessory).
Electrical connection
ATTENTION
When the fan is stationary,
the hydraulic supply must be
simultaneously interrupted.
ATTENTION
Only suitably trained specialists
may establish electrical con-
nections.
Connection to the local hy-
draulic system
Prior to connection to the local
hydraulic system, it must be en-
sured that the respective capacity
requirements of the unit can be
provided at all times.
■ Connection of the unit on the
water side must take place local-
ly via suitable pipe fittings and
shut-off valves in the flow and
return.
The use of compensators and
automatic venting devices is
recommended!
■ The connection side at the top
and the flow and return can be
connected as required.
■ The pipe connection thread sizes
is R 1“ internal thread.
■ The fin heat exchangers must be
thoroughly vented after installa-
tion.
Air cushions in the heat exchan-
ger will reduce the heating or
cooling capacity!
Hydraulic connection
Water inlet
Water outlet
NOTE
In order to prevent damage
due to twisting of the con-
necting pipes, a suitable tool
must be used to prevent the
connecting pipes rotating
while tightening the screwed
connections.
5 6 78 9 10 11 12 13 14 15 16 17 18 19 20 21 22
W2 U2V2 TK PE
1 3 42
U1V1 W1 TK PE PE N L13 2
Kondensatpumpe
für Kühlbetrieb
CÖS
N
Potenzialfreier Alarmkontakt
1
Kondensatpumpe Kondensatpumpe

9
Before using for the first time
■ Correct mechanical installation
must be verified.
■ Correct connection to the local
heating system must be veri-
fied.
■ It must be ensured that hot
surfaces are protected against
accidental contact.
■ It must be verified that the
electrical wiring of the units has
been carried out in compliance
with the applicable directives
and standards using the sup-
plied wiring diagrams.
■ The fan space as well as the
inlet and outlet area must be
checked for the presence of
foreign bodies.
■ The fan must be checked for
smooth operation.
■ Switch on the power to the
control unit (accessory) and
switch on the unit via the con-
trol switch of the control unit.
■ The direction of rotation of the
fan must be checked
The direction of rotation can
be changed by interchanging
two phases or using an exter-
nal control unit (accessory).
Commissioning
Draining if there is a risk of
frost
It is not possible to statically drain
the fin heat exchanger completely
in an installed condition.
If necessary, draining is only possi-
ble using compressed air.
Important information about frost
protection
To prevent frost damage, anti-frost
protection must be provided at
temperatures below 0°C.
Where systems in rooms at risk
from frost are not used for ex-
tended periods, under no circum-
stances must “only” water be
present in the heat exchanger.
In such cases, a suitable antifreeze
agent must be added to the hea-
ting medium (water) in a mixing
ratio that is adequate for the place
of use.
The hydraulic capacity loss must
also be taken into account.
■ It should be noted that when
using a speed control (acces-
sory) the power of the control
unit must correspond to the
total power of the connected
motors.
■ It must be ensured that all air
inlets and outlets are open.
ATTENTION
Frost damage to the fin heat
exchanger does not fall under
the warranty!
Water inlet
Water outlet
Draining the
heating/cooling
medium
Venting
Screwed connections
The three louvre segments in the
bottom part of the housing (ver-
tical blowing or suction) can be
individually adjusted via a control.
Air flow
The louvres on the side of the top
part of the housing (horizontal
blowing or suction) can be adju-
sted in 5 degree stages.
ATTENTION
Commissioning can only take
place when it is ensured that
mounting and electrical instal-
lation has been carried out in
compliance with the pertinent
requirements of the EC Direc-
tives.

10
REMKO PWL
Set the switch of the respective
control unit to the „Off“ or „0“
position.
Precautions for extended periods
of non-use
■ Disconnect the electrical con-
nection in all poles.
■ Shut-off the hydraulic connec-
tion.
■ Where there is a risk of frost,
the entire system must be
drained if no suitable antifreeze
agent has been added to the
heating medium (water).
(See also page 9)
Decommissioning
Care and maintenance
ATTENTION
It does not suffice to switch off
the unit only via the switch!
During initial commissioning
During initial commissioning, all
regulating, control and safety
devices must be checked for their
proper functioning and correct
adjustment.
■ The power consumption of the
fan must be measured.
The nominal current must not
exceed the values on the rating
plate at the respective opera-
ting speeds.
■ Check the motor protection
function of the fan.
■ Check the complete system for
de-energised installation and
possible vibrations.
■ Check the heating/cooling
medium supply pipes for correct
connection, tightness and insu-
lation.
■ It must be ensured that no more
condensate is produced as in
this case the condensate pump
is also disconnected from the
supply and no longer operatio-
nal.
■ Wait for the fan to stop.
■ Shut-off the water circuit and
lock to prevent unauthorised
opening.
■ Allow the fin heat exchanger to
cool down.
Cleaning the units
■ The surfaces of the units must
be cleaned only dry or with a
moist cloth and a small amount
of soap solution if necessary.
■ Under no circumstances use
high-pressure cleaners or steam
jet equipment to clean the
mounted unit.
■ Do not use caustic cleaning
agents or those containing
solvents.
■ Only suitable cleaning agents
must be used even to remove
heavy fouling.
■ Clean all air inlets and air outlet
louvres.
■ Clean the fan impeller. If ne-
cessary, remove the motor or
protection grille.
■ Clean the heat exchanger fins
either by blowing out, suction
or with a soft brush.
The units generally require no
maintenance. The units and fin
exchanger surfaces must be vi-
sually inspected every six months
and before the start of the heating
period.
In dust-laden environments, the
units must be inspected at shorter
intervals.
For this purpose, the cover of the
unit must be detached from the
supporting part of the unit by re-
moving the 3 securing clips at the
corners.
For inspection purposes, the cover
must be held under the supporting
part with the aid of holding straps.
The cover can be removed com-
pletely from the unit if required by
loosening the strap adjuster on the
holding straps.
During removal, it must be en-
sured that the suction hose and
condensate pump sensor are also
disconnected from the supporting
part.
Securing clip
Important precautions to be taken
prior to all maintenance
■ The units must be disconnected
from the supply in all poles and
locked to prevent unauthorised
reconnection.

11
ATTENTION
After carrying out all work on
the units, an electrical safety
test must be carried out in
accordance with VDE 0701.
NOTE
Only authorised specialists
may undertake repairs and
maintenance.
Repair
■ If the fin exchanger surface is
covered with grease or sooty
particles, the exchanger ele-
ment can be removed and
cleaned with a steam-jet degre-
aser using low pressure and a
suitable cleaning agent.
■ Remove heavy fouling on the
fan and aluminium fins with a
soap solution.
■ Clean the condensate tank in
the unit housing to remove dirt
deposits.
To ensure complete drainage of
the condensate tank, the suction
opening of the condensate hose
must be fixed at the lowest point
of the cover.
The condensate sensor must be
arranged slightly above the suction
opening.
Bottom edge of sensor = top edge
of suction opening.
Routing must take place as show
in the following diagram.
F = Sensor cable
K = Condensate hose (internal ø 6)
FK
Replacing the fin heat exchanger
1. Remove the cover of the unit
completely.
(See care and maintenance)
2. Disconnect the electrical con-
nection of the fan.
3. Disconnect the hydraulic con-
nection.
4. Remove the bottom support
plate (6 screws).
5. Remove the support plate with
fin exchanger downwards.
6. Carefully re-install the replace-
ment heat exchanger and all
further components in reverse
order.
Fan replacement
1. Remove the cover of the unit.
(See care and maintenance)
2. Disconnect the electrical con-
nection of the fan.
3. Remove the protection grille
with fan from the housing.
4. Carefully refit the new fan in
reverse order.
5. Check the fan impeller for
smooth operation and freedom
of movement with respect to
the fan housing.
6. Re-establish the electrical con-
nection of the motor correctly.
ATTENTION
Prior to carrying out mainte-
nance or repairs, the unit must
always be disconnected from
the mains supply and locked to
prevent unauthorised recon-
nection.
Recommended maintenance interval in normal unit operation
Inspection and possible cleaning of the condensate tank Every six months
Inspection and possible cleaning of the condensate drain Every six months
Functional check of the condensate pump and alarm sensor Every six months
Inspection and possible cleaning of the air grille Annually
Inspection of the electrical connections and earthing Annually
Cleaning of the fin exchanger Annually
Inspection of the fan for smooth operation and function Annually

12
REMKO PWL
We reserve the right to make changes to dimensions and design in the interest of technological advances.
hohe Drehzahl
∆ - Schaltung
niedere Drehzahl
Y - Schaltung
TK W2 U2 V2
TK U1 V1 W1
PE L1 L2 L3
TK W2 U2 V2
TK U1 V1 W1
PE L1 L2 L3
Fan motor 400V, two-speed
Condensate pump
Wiring Diagram
NOTE
All electrical wiring terminals
must be checked for tightness
and retightened if necessary.
NOTE
Prior to using the system, the
function of the condensate
pump must be tested with
respect to the delivery head.
Fill the condensate tank of the
unit housing with water and
test the function of the pump.
Ensure that the pump switches
off after pumping.
ATTENTION
Electrical connection of the
unit must be carried out by
authorised specialists as de-
fined in DIN EN 60335-1 and
VDE 0116.
Standard units: ∆/Y switching and thermal contacts.
Max. flow rate: 50 l/h
Max. delivery head: 20 m
Max. suction head: 7 m
Connection internal Ø: 6 mm
Temperature protection at: 130 °C
0 10 20 30 40 50 60
0
4
8
12
16
20
Förderhöhe in Meter
Liter pro Stunde
The compact condensate pump
must pump out the produced con-
densate in cooling operation.
The pump is a self-priming rotary
diaphragm pump.
The condensate is pumped out via
a flexible PVC condensate hose
with an internal diameter of 6 mm.
Safety information:
■ Disconnect the power supply
before connecting, removing or
replacing the condensate pump.
■ Do not use the condensate
pump for pumping flammable
and potentially explosive liquids
such as petrol, heating oil, sol-
vents, etc.
■ The condensate pump must
only be used for pumping
liquids to which the pump ma-
terial is resistant.
■ Do not use the condensate
pump in potentially explosive
atmospheres.
■ Electrical connection must take
place as shown in the wiring
diagram. Ensure that the power
supply is earthed in compliance
with the statutory require-
ments.
■ Ensure that the condensate
pump is not installed higher
than 7 m (maximum suction
head) above the drip tray outlet
and not deeper than 20 m
(maximum delivery head) be-
low the top of the condensate
drain.
Pump control
Power supply: 230 V/50 Hz
Brown wire: L
Blue wire: N
Green/yellow wire: PE
The mains connection of the pump
must be protected with a 1 A mini-
ature fuse.
Floating alarm contact:
black: common wire
yellow: contact closed in operation/open on
alarm
red: contact open in operation/closed on
alarm
Performance diagram

13
We reserve the right to make changes to dimensions and design in the interest of technological advances.
NOTE
The flow and return can be
connected as required.
Unit dimensions
Dimen-
sions PWL 101-103 HK PWL 201-203 HK PWL 301-303 HK
A 985 mm 1084 mm 1178 mm
B 632 mm 963 mm 1043 mm
C 229 mm 229 mm 229 mm
D 989 mm 1073 mm 1160 mm
H 465 mm 485 mm 504 mm
Condensate pump
Mounting distance between unit and ceiling minimum 80 mm!
217
80
44
H
16
90
D
A
C
90
B
B
B
M 8
View „A“

„A“
Condensate hose
Hydraulic connection R 1“ {

14
REMKO PWL
Type PWL 101-H PWL 102-H PWL 103-H
Type 2-speed 2-speed 2-speed
Speed rpm 920 750 920 750 920 750
Electrical connection V 400/3~N
Frequency Hz 50
Power consumption kW 0.1/0.07
Nominal current A 0.26/0.13
Air capacity m³/h 2030 1685 1960 1610 1885 1530
Sound pressure level1) dB (A) 56 47 56 47 56 47
max. mounting height m 2.8 2.7 2.5
max. range 2) m 3.4 3.2 3.0
Hydraulic connection Inch R 1“ R 1“ R 1“
Water volume l 1.0 1.6 2.5
Weight kg 31 35 38
PWW heating
medium
tL1
°C kW tL2
°C kW tL2 °C kW tL2 °C kW tL2 °C kW tL2 °C kW tL2 °C
50 / 40 °C
0 9.2 13 8.2 13 14.7 21 13.3 23 19.0 28 16.4 30
5 8.0 16 7.2 17 12.9 24 11.7 26 16.7 30 14.4 32
10 6.9 20 6.2 21 11.1 26 10.1 28 14.4 32 12.5 33
15 5.8 23 5.2 24 9.4 29 8.6 31 12.2 34 10.5 35
20 4.7 27 4.2 27 7.6 32 7.1 33 10.0 36 8.7 37
60 / 50 °C
0 11.4 16 10.2 17 18.2 26 16.4 28 23.4 34 20.2 37
5 10.2 19 9.1 20 16.4 29 14.8 31 21.0 37 18.2 39
10 9.1 23 8.1 24 14.6 31 13.2 33 18.7 39 16.2 40
15 8.0 27 7.1 27 12.8 34 11.6 36 16.4 41 14.2 42
20 6.9 30 6.1 31 11.0 37 10.0 39 14.2 45 12.3 44
70 / 50 °C
0 12.0 16 10.7 18 19.5 28 17.8 31 25.4 37 22.0 40
5 10.8 20 9.7 21 17.6 30 16.1 33 23.0 39 19.9 42
10 9.7 24 8.6 25 15.8 33 14.5 36 20.6 41 17.9 44
15 8.5 27 7.6 28 14.0 36 12.9 38 18.3 43 15.9 45
20 7.4 31 6.6 32 12.2 39 11.3 41 16.0 45 13.9 47
80 / 60 °C
0 14.3 20 12.7 21 23.1 33 20.9 36 29.9 44 25.8 47
5 13.1 23 11.7 25 21.2 36 19.2 39 27.4 46 23.7 49
10 11.9 27 10.6 28 19.3 38 17.6 41 25.0 48 21.7 51
15 10.8 31 9.6 32 17.5 41 15.9 44 22.7 50 19.6 52
20 9.6 34 8.6 35 15.7 44 14.3 46 20.4 52 17.6 54
90 / 70 °C
0 16.5 23 14.7 24 26.7 38 24.1 41 34.4 51 29.7 54
5 15.3 26 13.7 28 24.7 41 22.3 44 31.9 53 27.5 56
10 14.1 30 12.6 32 22.8 43 20.6 47 29.4 55 25.4 58
15 13.0 34 11.6 35 21.0 46 19.0 49 27.0 57 23.3 60
20 11.8 37 10.5 39 19.1 49 17.3 52 24.7 59 21.3 61
PWL 101-103 - Heating • Rating tables • Technical Data
We reserve the right to make dimensional and design changes in the interest of technical advances.
tL1 = air inlet temperature/tL2 = air outlet temperature
2) at ∆t20 K (difference in temperature between air inlet and air outlet)
Operation with range restriction

15
tL1 = air inlet temperature/ tL2 = air outlet temperature
Type PWL 101-HK PWL 102-HK PWL 103-HK
Type 2-speed 2-speed 2-speed
Speed rpm 920 750 920 750 920 750
Electrical connection 400/3~N
Frequency Hz 50
Power consumption kW 0.1/0.07
Nominal current A 0.26/0.13
Air capacity m³/h 2030 1685 1960 1610 1885 1530
Sound pressure level1) dB (A) 56 47 56 47 56 47
Hydraulic connection Inch R 1“ R 1“ R 1“
Water volume l 1.0 1.6 2.5
Condensate max. l/h 2.8 2.6 4.3 4.1 6.3 5.7
Weight kg 31 35 38
PKW coolant tL1/r.H.
°C/% kW tL2/r.H. °C/% kW tL2/r.H. °C/% kW tL2/r.H. °C/% kW tL2/r.H. °C/% kW tL2/r.H. °C/% kW tL2/r.H. °C/%
4 / 8 °C
24/60 5.0 19/72 7.1 19/73 7.9 16/80 7.1 16/82 10.6 14/87 9.3 13/89
26/50 5.1 21/63 4.6 20/64 8.0 17/74 7.2 17/75 10.7 14/82 9.4 13/84
28/45 5.5 22/59 5.0 22/60 8.6 18/71 7.7 17/72 11.5 15/79 10.0 14/82
30/40 5.8 23/55 5.3 23/56 9.1 19/67 8.2 18/69 12.2 16/78 10.7 15/79
32/40 6.7 25/55 6.1 24/56 10.5 20/67 9.4 19/69 13.9 16/77 12.2 15/80
6 / 10 °C
24/60 4.2 20/72 3.8 20/72 6.6 17/80 6.0 17/81 9.1 15/87 7.9 14/88
26/50 5.2 23/63 3.9 21/64 6.7 18/74 6.0 18/75 9.1 15/82 8.0 15/84
28/45 4.7 22/59 4.2 22/60 7.3 19/70 7.0 19/69 9.9 16/79 8.7 15/81
30/40 5.0 24/54 4.5 23/55 7.8 20/67 7.0 19/69 10.5 17/77 9.3 16/79
32/40 5.9 25/55 5.3 25/56 9.2 21/67 8.3 20/69 12.3 18/77 10.8 16/79
8 / 14 °C
24/60 2.5 21/71 2.3 21/72 4.1 19/80 3.7 18/81 5.9 17/86 5.3 16/88
26/50 2.6 22/63 2.3 22/64 4.2 20/74 3.8 19/75 6.0 17/82 5.3 17/83
28/45 3.1 23/59 2.7 23/60 4.9 20/71 4.3 20/72 6.8 17/82 6.1 17/81
30/40 3.5 25/54 3.1 24/56 5.6 21/67 4.8 21/69 7.5 18/77 6.6 18/79
32/40 4.2 26/55 3.8 26/56 6.7 23/67 6.0 22/69 9.3 19/77 8.2 19/79
10 / 16 °C
24/60 1.8 21/71 1.6 21/72 3.0 19/80 2.7 19/81 4.0 18/86 3.5 18/88
26/50 2.2 23/61 2.0 22/62 3.7 20/70 3.2 20/72 4.9 18/81 4.3 17/84
28/45 2.7 24/57 2.4 24/58 4.3 21/67 3.8 21/69 5.7 19/79 4.9 18/82
30/40 3.1 25/52 2.7 25/53 4.9 22/63 4.4 22/65 6.5 19/75 5.6 19/79
32/40 3.5 27/54 3.1 26/55 5.6 23/67 4.9 23/69 7.4 20/77 6.6 20/79
12 / 18 °C
24/60 1.4 22/68 1.3 22/69 2.4 20/79 2.1 20/76 3.3 19/83 2.9 18/85
26/50 1.8 23/59 1.6 23/60 3.1 21/66 2.7 21/68 4.1 19/75 3.6 19/77
28/45 2.3 25/55 2.0 24/56 3.7 22/63 3.3 22/65 4.9 20/72 4.3 19/75
30/40 2.7 26/51 2.4 26/51 4.3 23/60 3.8 23/61 5.7 21/70 4.9 20/72
32/40 3.1 27/52 2.7 27/53 4.9 24/63 4.4 24/65 6.5 21/75 5.6 21/78
PWL 101-103 - Cooling • Rating tables • Technical Data
We reserve the right to make dimensional and design changes in the interest of technical advances.
1)
LpA 1m, noise measurement DIN 45635 - 01 - CATEGORY 3

16
REMKO PWL
Type PWL 201-H PWL 202-H PWL 203-H
Type 2-speed 2-speed 2-speed
Speed rpm 920 750 920 750 920 750
Electrical connection V 400/3~N
Frequency Hz 50
Power consumption kW 0.28/0.18
Nominal current A 0.67/0.37
Air capacity m³/h 3110 2580 2900 2400 2850 2350
Sound pressure level1) dB (A) 61 53 61 56 61 56
max. mounting height m 5.5 5.3 5.2
max. range 2) m 7.9 5.8 5.0
Hydraulic connection Inch R 1“ R 1“ R 1“
Water volume l 1.0 1.8 2.9
Weight kg 32 35 38
PWW heating
medium
tL1
°C kW tL2
°C kW tL2 °C kW tL2 °C kW tL2 °C kW tL2 °C kW tL2 °C
50 / 40 °C
0 11.4 10 10.2 11 20.1 19 17.9 21 26.0 25 22.8 27
5 9.8 14 8.8 15 17.6 22 15.7 23 22.8 28 20.0 29
10 8.3 18 7.5 18 15.2 25 13.5 26 19.6 30 17.3 31
15 6.9 22 6.2 22 12.8 28 11.4 29 16.5 32 14.5 33
20 5.4 25 4.9 26 11.0 31 9.3 32 13.5 34 11.9 35
60 / 50 °C
0 14.5 13 13.0 14 24.9 24 22.1 26 32.2 31 28.3 33
5 12.9 17 11.6 18 22.4 27 19.9 28 28.9 34 25.4 35
10 11.4 21 10.2 21 19.9 30 17.7 31 25.7 36 22.5 38
15 9.9 24 8.9 25 17.5 33 15.5 34 22.5 38 19.8 40
20 8.4 28 7.5 29 15.1 35 13.4 37 19.4 40 17.1 42
70 / 50 °C
0 14.5 13 13.0 14 26.6 25 23.7 27 34.5 34 30.4 36
5 12.9 17 11.6 18 24.1 28 21.4 30 31.2 36 27.4 38
10 11.4 21 10.2 19 21.6 31 19.2 33 27.9 38 24.6 40
15 9.9 24 8.9 25 19.1 34 17.0 36 24.7 40 21.8 42
20 8.5 28 7.6 29 16.7 37 14.9 38 21.6 43 19.0 44
80 / 60 °C
0 17.7 16 15.8 17 31.5 30 28.0 32 40.8 40 35.9 42
5 16.1 20 14.4 21 28.9 33 25.7 35 37.4 42 32.9 45
10 14.5 23 13.0 16 26.4 36 23.4 38 34.0 44 30.0 47
15 13.0 27 11.7 28 23.9 39 21.2 41 30.9 47 27.1 49
20 11.5 31 10.3 32 21.4 42 19.0 44 27.7 49 24.3 51
90 / 70 °C
0 20.8 19 18.7 20 36.3 35 32.3 37 47.2 46 41.4 49
5 19.2 22 17.2 24 33.7 38 30.0 40 43.7 48 38.4 51
10 17.7 26 15.8 28 31.1 41 27.7 43 40.3 51 35.4 53
15 16.1 30 14.4 31 28.6 44 25.4 46 37.0 53 32.5 55
20 14.6 34 13.0 35 26.1 47 23.2 49 33.7 55 29.6 57
We reserve the right to make dimensional and design changes in the interest of technical advances.
PWL 201-203 - Heating • Rating tables • Technical Data
tL1 = air inlet temperature/ tL2 = air outlet temperature
2) at ∆t20 K (difference in temperature between air inlet and air outlet)
Operation with range restriction

17
Type PWL 201-HK PWL 202-HK PWL 203-HK
Type 2-speed 2-speed 2-speed
Speed rpm 920 750 920 750 920 750
Electrical connection V 400/3~N
Frequency Hz 50
Power consumption kW 0.28/0.18
Nominal current A 0.67/0.37
Air capacity m³/h 3110 2580 2900 2400 2850 2350
Sound pressure level1) dB (A) 61 53 61 56 61 56
Hydraulic connection Zoll R 1“ R 1“ R 1“
Water volume l 1.0 1.8 2.9
Condensate max. l/h 2.3 2.2 5.6 5.2 7.6 7.1
Weight kg 32 35 38
PKW coolant tL1/r.H.
°C/% kW tL2/r.H. °C/% kW tL2/r.H. °C/% kW tL2/r.H. °C/% kW tL2/r.H. °C/% kW tL2/r.H. °C/% kW tL2/r.H. °C/%
4 / 8 °C
24/60 5.3 26/53 4.9 20/71 10.6 17/79 9.6 16/80 13.9 15/85 12.4 14/87
26/50 5.4 25/53 4.9 21/63 10.7 17/72 9.7 17/74 14.0 15/80 12.5 15/82
28/45 5.9 23/58 5.4 23/58 11.5 19/69 10.4 18/70 15.0 16/77 13.5 15/79
30/40 6.3 22/62 5.8 24/54 12.2 20/65 11.1 19/67 15.9 17/74 14.3 16/78
32/40 7.5 20/70 6.8 26/54 14.0 21/65 12.7 20/67 18.3 18/75 16.4 17/77
6 / 10 °C
24/60 4.3 21/70 3.9 21/71 9.0 18/79 8.1 17/80 11.7 16/85 10.5 15/86
26/50 4.3 22/60 4.0 22/63 9.0 19/72 8.2 18/73 11.8 16/80 10.6 16/81
28/45 4.8 24/58 4.4 23/59 9.9 20/69 8.9 19/70 12.8 17/77 8.9 16/79
30/40 5.3 25/53 4.8 25/54 10.5 21/65 9.5 20/66 13.7 18/74 12.3 17/76
32/40 6.4 27/53 5.8 26/54 12.3 22/65 11.2 21/67 16.1 19/74 14.4 18/76
8 / 14 °C
24/60 2.2 22/68 2.0 22/69 5.6 19/79 5.1 19/80 7.2 18/85 6.5 17/86
26/50 2.8 23/59 2.5 23/60 5.9 20/73 5.2 20/73 7.3 18/80 6.6 18/81
28/45 3.3 25/54 3.0 24/55 6.8 21/69 5.9 21/70 8.7 19/79 7.6 18/79
30/40 3.8 26/50 3.4 26/51 7.6 22/65 6.8 21/67 9.8 20/75 8.4 19/76
32/40 4.3 28/51 3.9 27/52 9.0 23 65 8.2 23/66 11.7 21/74 10.5 20/76
10 / 16 °C
24/60 1.8 22/66 1.6 22/67 4.2 20/78 3.7 19/80 5.3 18/85 4.7 18/87
26/50 2.3 24/57 2.1 24/58 5.1 21/69 4.5 20/70 6.5 19/76 5.7 19/78
28/45 2.8 25/53 2.5 25/54 5.9 22/65 5.3 21/67 7.6 20/73 6.7 19/76
30/40 3.3 27/48 3.0 27/49 6.8 23/61 6.0 22/63 8.7 21/70 7.6 20/72
32/40 3.8 28/50 3.5 29/51 7.6 24/64 6.8 23/67 9.8 21/75 8.6 21/78
12 / 18 °C
24/60 1.3 23/65 1.2 23/65 3.3 21/74 2.9 20/75 4.2 20/79 3.7 19/80
26/50 1.8 24/55 1.6 24/56 4.2 22/65 3.7 21/66 5.4 20/71 4.7 20/72
28/45 2.3 26/51 2.1 26/52 5.1 23/62 4.5 22/63 6.5 21/68 5.7 21/70
30/40 2.8 27/47 2.5 27/48 5.9 24/58 5.3 23/60 7.6 22/65 6.7 21/67
32/40 3.4 29/48 3.0 28/49 6.8 25/61 6.0 24/63 8.7 23/69 7.6 22/72
We reserve the right to make dimensional and design changes in the interest of technical advances.
PWL 201-203 - Cooling • Rating tables • Technical Data
tL1 = air inlet temperature/ tL2 = air outlet temperature
1)
LpA 1m, noise measurement DIN 45635 - 01 - CATEGORY 3

18
REMKO PWL
Type PWL 301-H PWL 302-H PWL 303-H
Type 2-speed 2-speed 2-speed
Speed rpm 920 750 920 750 920 750
Electrical connection 400/3~N
Frequency Hz 50
Power consumption kW 0.36/0.22
Nominal current A 0.84/0.46
Air capacity m³/h 4300 2650 4150 2400 3900 1710
Sound pressure level1) dB (A) 66 59 66 59 68 61
max. mounting height m 7.0 6.5 6.0
max. range 2) m 5.0 7.0 6.2
Hydraulic connection Inch R 1“ R 1“ R 1“
Water volume l 1.1 2.0 3.3
Weight kg 43 46 48
PWW heating
medium
tL1
°C kW tL2
°C kW tL2 °C kW tL2 °C kW tL2 °C kW tL2 °C kW tL2 °C
50 / 40 °C
0 14.7 21 11.1 12 24.0 16 17.2 20 33.7 24 19.1 31
5 12.8 13 9.6 15 20.8 19 15.0 23 29.6 26 16.8 33
10 10.9 17 8.2 19 17.7 22 12.8 25 25.5 29 14.5 34
15 9.0 21 6.8 23 14.7 25 10.6 28 21.5 31 12.2 36
20 7.1 25 5.4 28 11.7 28 8.5 31 17.6 33 10.0 37
60 / 50 °C
0 18.7 12 14.0 15 30.4 20 21.7 25 41.7 30 23.6 38
5 16.7 16 12.5 18 27.1 23 19.4 28 37.5 32 21.2 40
10 14.7 20 11.1 22 24.0 27 17.1 31 33.3 35 18.8 42
15 12.8 24 9.6 26 20.9 30 14.9 33 29.2 37 16.5 43
20 10.9 28 8.2 29 17.8 33 12.8 36 25.2 39 14.3 45
70 / 50 °C
0 18.8 12 14.3 15 31.0 21 22.3 26 44.8 32 25.6 41
5 16.9 16 12.7 19 27.8 24 20.0 29 40.5 34 23.2 43
10 14.9 20 11.3 22 24.6 27 17.8 31 36.3 37 20.8 45
15 13.0 24 9.8 26 21.5 30 15.6 34 32.1 39 18.4 46
20 11.1 28 8.4 29 18.5 33 13.4 37 28.1 41 16.1 48
80 / 60 °C
0 22.9 15 17.2 18 37.5 25 26.9 31 52.9 38 30.1 49
5 20.9 19 15.7 22 34.2 28 24.6 34 48.6 40 27.6 51
10 18.9 23 14.2 25 31.0 31 22.3 37 44.3 43 25.2 52
15 16.9 27 12.8 29 27.8 35 20.0 39 40.1 45 22.8 54
20 15.0 30 11.3 33 24.7 38 17.8 42 35.9 47 20.5 56
90 / 70 °C
0 26.9 17 20.3 21 44.0 29 31.5 36 61.1 43 34.7 56
5 24.9 21 18.7 25 40.7 33 29.1 39 56.6 46 32.1 58
10 22.9 25 17.2 29 37.4 36 26.8 42 52.3 48 29.6 60
15 20.9 29 15.7 32 34.2 39 24.5 45 48.0 51 27.2 61
20 18.9 33 14.0 36 31.0 42 22.2 48 43.8 53 24.8 63
We reserve the right to make dimensional and design changes in the interest of technical advances.
PWL 301-303 - Heating • Rating tables • Technical Data
tL1 = air inlet temperature/tL2 = air outlet temperature
2) at ∆t20 K (difference in temperature between air inlet and air outlet)
Operation with range restriction

19
Type PWL 301-HK PWL 302-HK PWL 303-HK
Type 2-speed 2-speed 2-speed
Speed rpm 920 750 920 750 920 750
Electrical connection 400/3~N
Frequency Hz 50
Power consumption kW 0.36/0.22
Nominal current A 0.84/0.46
Air capacity m³/h 4300 2650 4150 2400 3900 1710
Sound pressure level1) dB (A) 66 59 66 59 68 61
Hydraulic connection Inch R 1“ R 1“ R 1“
Water volume l 1.1 2.0 3.3
Condensate max. l/h 3.0 2.7 4.2 4.1 9.5 6.7
Weight kg 43 46 48
PKW coolant tL1/r.H.
°C/% kW tL2/r.H. °C/% kW tL2/r.H. °C/% kW tL2/r.H. °C/% kW tL2/r.H. °C/% kW tL2/r.H. °C/% kW tL2/r.H. °C/%
4 / 8 °C
24/60 6.9 21/70 5.5 20/72 8.9 18/71 8.4 17/81 17.8 15/84 10.9 15/82
26/50 7.0 22/61 5.5 21/63 11.1 19/70 8.5 18/74 18.0 16/79 11.0 13/86
28/45 7.7 23/57 6.0 23/59 12.1 20/67 9.2 19/71 19.3 17/76 11.8 13/83
30/40 8.2 25/52 6.5 24/55 12.9 22/63 9.9 20/68 20.4 18/73 12.5 14/81
32/40 9.6 26/52 7.6 25/55 15.1 23/63 11.5 21/68 23.5 19/73 14.3 15/82
6 / 10 °C
24/60 5.6 21/70 4.4 20/71 8.9 19/77 6.8 18/80 15.0 16/84 9.3 14/89
26/50 5.7 22/61 4.5 22/63 9.0 20/71 6.9 19/74 15.1 17/78 9.3 14/85
28/45 6.3 24/57 5.0 23/59 10.0 21/67 7.7 20/71 16.5 18/76 10.1 15/83
30/40 6.8 25/52 5.4 24/55 10.8 22/63 8.3 20/68 17.6 18/73 10.8 15/81
32/40 8.3 27/52 6.5 26/55 13.0 23/63 10.0 22/68 29.1 19/73 12.7 16/81
8 / 14 °C
24/60 3.0 22/68 2.3 21/70 8.4 17/81 3.6 19/79 9.4 18/84 6.0 16/89
26/50 3.7 23/58 2.8 23/61 8.5 18/74 4.4 20/70 9.9 18/80 6.1 16/85
28/45 4.3 25/54 3.3 24/56 9.2 19/71 5.2 21/67 11.3 19/77 7.0 17/83
30/40 5.0 26/49 3.8 26/52 9.9 20/68 6.0 22/63 12.8 20/73 7.7 17/81
32/40 5.7 28/51 4.3 27/53 11.5 21/68 6.7 23/66 15.0 21/73 9.5 18/81
10 / 16 °C
24/60 2.4 22/66 1.8 22/68 6.8 18/80 2.9 20/75 7.0 19/84 4.0 17/89
26/50 3.0 24/57 2.3 23/59 6.9 19/74 3.7 21/66 8.5 19/74 4.9 17/85
28/45 3.7 25/53 2.8 25/55 7.7 20/71 4.5 22/63 9.9 20/72 5.7 18/83
30/40 4.4 27/48 3.3 26/50 8.3 20/68 5.2 23/59 11.3 21/68 6.5 18/80
32/40 5.1 28/49 3.8 28/52 10.0 22/68 6.0 24/63 12.8 22/72 7.6 19/81
12 / 18 °C
24/60 1.7 23/65 1.3 23/66 3.6 19/79 2.2 21/71 5.5 20/78 3.2 18/85
26/50 2.4 24/55 1.8 24/57 4.4 20/70 3.0 22/63 7.0 21/69 4.1 19/78
28/45 3.1 26/51 2.3 25/53 5.2 21/67 3.7 23/60 8.5 21/69 4.9 19/76
30/40 3.7 27/47 2.9 27/40 6.0 22/63 4.5 24/56 9.9 22/63 5.7 20/73
32/40 4.4 29/48 3.4 28/50 6.7 23/66 5.3 25/59 11.3 23/68 6.5 20/80
We reserve the right to make dimensional and design changes in the interest of technical advances.
PWL 301-303 - Cooling • Rating tables • Technical Data
tL1 = air inlet temperature/tL2 = air outlet temperature
1)
LpA 1m, noise measurement DIN 45635 - 01 - CATEGORY 3

20
REMKO PWL
NOTE
Operation for any other pur-
pose than that described in
these operating instructions
is not permitted. Failure to
observe this requirement will
result in all liability being
disclaimed and the warranty
rendered invalid.
Customer service and
warranty
A precondition for any warran-
ty claims is that the dealer or his
customer has completed and
returned the enclosed “Warranty
document“ to REMKO GmbH &
Co. KG at the time of sale and
commissioning.
The units were repeatedly tested
for perfect functioning at the
factory.
If problems should occur which
cannot be remedied by trouble-
shooting by the operator, your
specialised dealer or contract part-
ner should be contacted.
Intended use
Disposal of packaging
When disposing of the packaging
material, please think of the envi-
ronment.
Our units are carefully packed for
transport and delivered in sturdy
cardboard packaging on a wooden
pallet, if necessary.
The packaging materials are
environmentally-friendly and can
be recycled.
By reusing packaging materials,
you make a valuable contribution
towards waste reduction and the
conservation of raw materials.
Only dispose of packaging materi-
al at the facilities provided.
Disposal of old unit
The production of our units is sub-
ject to constant quality controls.
Only high-quality materials are
used, the majority of which are
recyclable.
Make your contribution towards
environmental protection by dispo-
sing of your old unit in an environ-
mentally-friendly manner.
Only dispose of your old unit at
an authorised recycling facility or
similar.
NOTE
Adjustments and maintenance
must only be carried out by
authorised specialists.
Environmental
protection and
recycling
ATTENTION
Copyright
Any copying of this docu-
ment in whole or part or use
for purposes other than the
intended is strictly forbidden
without the prior written
permission of
REMKO GmbH & Co. KG .
Due to their design and equip-
ment, the units are intended solely
for heating and cooling purposes
in industrial or commercial use.
The units must only be operated
by suitably trained personnel.
The manufacturer disclaims all
liability for any damage attributed
to failure to observe relevant in-
structions, statutory requirements
applicable at the place of use or
unauthorised changes to the unit.
