Renesas JP214/RTK-251-SinkAdapter User manual

APPLICATION NOTE
R19AN0246EJ0100 Rev.1.0 Page 1 of 21
Sep.11.23
R9A02G011
JP214/RTK-251-SinkAdapter Instruction Manual
Introduction
The JP214 / RTK-251-SinkAdapter is an evaluation board for Universal Serial Bus Power Delivery (USB
PD). The RTK-251-SinkAdapter is designed with USB PD controller R9A02G011 and Buck-Boost Voltage
Regulator (BB-VR) ISL95338 (substitute product: RAA489800). This document is the instruction manual for
RTK-251-SinkAdapter.
The RTK-251-SinkAdapter supports USB PD 2.0, USB PD 3.1, USB Type-C®Specification. The RTK-251-
SinkAdapter works as USB Type-C®power sink, it converts USB-C input power supplied by Type-C sourcing
device to DC output. Because there are several losses on the cable, BB-VR, and board, USB PD controller
compensates the USB-C input level to achieve the expected DC output. For example, When Type-C
sourcing device supplies up to 20V@5A, RTK-251-SinkAdapter can provide up to 20V@4A to DC output
with these losses. The board also has an operating mode that feed USB-C input directly to the DC output.
Switches connected to the USB PD controller R9A02G011 allows selection of DC output voltage/current and
operating mode.
Target Devices
100W USB Type-C®Input Power Converter: JP214 / RTK-251-SinkAdapter
USB Power Delivery Controller: R9A02G011
Buck-Boost Voltage Regulator: ISL95338 (substitute product: RAA489800)
Part Number
RTK0EUG011D10000BJ
Related Document
Use this document in combination with the following documents.
The related documents indicated in this publication may include preliminary versions. However, preliminary
versions are not marked as such.
R9A02G011 Data Sheet: R19DS0088EJ
R9A02G011 User’s Manual: R19UH0102EJ
E1 Emulator E20 Emulator User’s Manual: R20UT0398EJ
E2 Emulator Lite User’s Manual: R20UT3240EJ
E1/E20 Emulator, E2 Emulator Lite Additional Document for User’s Manual (Notes on
Connection of RL78): R20UT1994EJ
Renesas Flash Programmer V3.12 Flash memory programming software User’s Manual:
R20UT5312EJ
USB Power Delivery Controller VIDWriter Instruction Manual: R19AN0247EJ
ISL95338 Data Sheet: FN8896
RAA489800 Short-Form Data Sheet: R16DO0003EU
ISL85415 Data Sheet: FN8373

R9A02G011 JP214/RTK-251-SinkAdapter Instruction Manual
R19AN0246EJ0100 Rev.1.0 Page 2 of 21
Sep.11.23
Contents
1. Features ..................................................................................................................................4
1.1 Block Diagram ......................................................................................................................................... 4
1.2 Component .............................................................................................................................................. 5
1.2.1 Component layout ................................................................................................................................. 5
1.2.2 Component information ......................................................................................................................... 6
1.3 Function assignment for R9A02G011 on JP214 / RTK-251-SinkAdapter .............................................. 7
2. Function...................................................................................................................................8
2.1 DC Output Voltage & maximum Current setting ..................................................................................... 8
2.2 Mode selection ........................................................................................................................................ 9
3. Board setup and how to use ..................................................................................................10
3.1 Required materials to use this board..................................................................................................... 10
3.2 How to use when connected to a source device................................................................................... 10
3.3 Firmware writing to the R9A02G011 on JP214 / RTK-251-SinkAdapter .............................................. 11
3.3.1 FW generation ..................................................................................................................................... 11
3.3.1.1 Operating Environment ..................................................................................................................... 11
3.3.1.2 Setup the VIDWriter .......................................................................................................................... 11
3.3.1.3 View Description................................................................................................................................ 12
3.3.2 Outline of flash memory writing ........................................................................................................... 14
3.3.2.1 On-board programming ..................................................................................................................... 15
3.3.3 FW writing with Renesas on-chip debugging emulator ....................................................................... 16
FIGURES
Figure 1-1 RTK-251-SinkAdapter block diagram .............................................................................................. 4
Figure 1-2 Highlighted mainly parts on the board ............................................................................................. 5
Figure 2-1 The substitute circuit for output voltage or current........................................................................... 8
Figure 2-2 ByPass / Normal mode enable......................................................................................................... 9
Figure 3-1 Main window for VIDWriter............................................................................................................. 12
Figure 3-2 Main window for VIDWriter after feature selection......................................................................... 13
Figure 3-3 Main window for VIDWriter when press Schematic Setting ........................................................... 14
Figure 3-4 Board connection for programming by on-chip debugging emulator ............................................. 17

R9A02G011 JP214/RTK-251-SinkAdapter Instruction Manual
R19AN0246EJ0100 Rev.1.0 Page 3 of 21
Sep.11.23
TABLES
Table 1-1 The function assigned to R9A02G011 of JP214 / RTK-251-SinkAdapter......................................... 7
Table 2-1 Rotary switch setting value................................................................................................................ 8
Table 2-2 Resistors values for substitute circuit................................................................................................ 8
Table 2-3 Mode switch description .................................................................................................................... 9
Table 2-4 The required Type-C sourcing PD Power(min) on Normal Mode ..................................................... 9
Table 3-1 Evaluation boards for each project.................................................................................................. 12
Table 3-2 Firmware writing method and available writing tool ...................................................................... 15
Table 3-3 Wiring Between R9A02G011GNP and Dedicated Flash Memory Programmer ........................... 16
Table 3-4 Wiring Between R9A02G011GBG and Dedicated Flash Memory Programmer........................... 16

R9A02G011 JP214/RTK-251-SinkAdapter Instruction Manual
R19AN0246EJ0100 Rev.1.0 Page 4 of 21
Sep.11.23
1. Features
RTK-251-SinkAdapter supports the following features.
USB Power Delivery and USB Type-C®
Supports compliant with USB Power Delivery Specification Revision 2.0, USB Power Delivery
Specification Revision 3.1, USB Type-C®Cable and Connector Specification Revision 2.1.
Certified by USB Implementers Forum TID=8528(PSD: Single Port Power Sinking Device)
Power Role: Sink only(SNK)
100W Power Sink (5, 9, 12, 15, 18, 20V)
1 USB Type-C®port
Power Sink voltage: 5 to 20V
Interface
LED indicators
Power Supply Indicator for R9A02G011 (1 LED, green)
Bypass path indicator (1 LED, green)
Normal path indicator (1 LED, green)
Switch
A DC output voltage control to R9A02G011
A DC output current control to R9A02G011
An operation mode selection to R9A02G011
On-chip debugging emulator interface
Renesas on-chip debugging emulator interface to write and debug firmware for R9A02G011
Mode Options
Normal mode: DC output is generated by BB-VR input voltage from Type-C sourcing device
negotiated with the R9A02G011.
ByPass mode: DC output appears directly input voltage from Type-C sourcing device negotiated
with the R9A02G011.
1.1 Block Diagram
Figure 1-1 RTK-251-SinkAdapter block diagram

R9A02G011 JP214/RTK-251-SinkAdapter Instruction Manual
R19AN0246EJ0100 Rev.1.0 Page 5 of 21
Sep.11.23
1.2 Component
1.2.1 Component layout
Figure 1-2 Highlighted mainly parts on the board

R9A02G011 JP214/RTK-251-SinkAdapter Instruction Manual
R19AN0246EJ0100 Rev.1.0 Page 6 of 21
Sep.11.23
1.2.2 Component information
(1) IC
No.
Description
Remark
U1
R9A02G011 (USB Power Delivery Controller)
-
U2
ISL85415 (Wide VIN Synchronous Buck Regulator)
-
U3
ISL95338 (Buck-Boost Voltage Regulator)
-
(2) Connector
No.
Description
Remark
CN1
USB Type-C receptacle
-
CN2
Renesas on-chip debugging emulator interface
-
TB1
DC Jack for power output
-
(3) Switch
No.
Description
Connects to R9A02G011
SW1
Rotary Dip switch for output voltage control
P21
SW2
Rotary Dip switch for output current control
P22
SW3
Dip switch for mode selection
P81, P82
(4) LED
No.
Description
Connects to R9A02G011
D4
Normal path indicator (green)
P73
D5
Bypass path indicator (green)
P72
D6
Power Supply Indicator for R9A02G011, same meaning as V
BUS
Indicator (green)
(5) Test point
No.
Description
Connects to R9A02G011
TP1
SMBus Slave SCL, SDA, alert on R9A02G011
P60, P61, P62
TP2
SMBus Master SCL, SDA, alter on R9A02G011 (SMBus Slave SCL on ISL95338)
P30, P31, P137
TP3
SW1 analog input on R9A02G011
P21
TP4
SW2 analog input on R9A02G011
P22
TP5
V
BUS
(Near USB Type-C receptacle)
-
TP6
GND
-
TP7
+3.3V
-
TP8
VADP (Monitor for BB-VR input)
-
TP9
VSYS (DC output)
-
TP10
Renesas use only
-
TP11
Renesas use only
-

R9A02G011 JP214/RTK-251-SinkAdapter Instruction Manual
R19AN0246EJ0100 Rev.1.0 Page 7 of 21
Sep.11.23
1.3 Function assignment for R9A02G011 on JP214 / RTK-251-SinkAdapter
Table 1-1 shows the functions assigned to R9A02G011 of JP214 / RTK-251-SinkAdapter.
Table 1-1 The function assigned to R9A02G011 of JP214 / RTK-251-SinkAdapter
Pin name
Function
Descriptions
P16
Open
-
P20
VBUSM
V
BUS
voltage monitor input
P21
SW1
Input from Rotary Dip switch for DC output voltage control
P22
SW2
Input from Rotary Dip switch for DC output current control
P31
MSTSDA
SMBus master data input/output (open-drain) connected to ISL95338
P30
MSTSCL
SMBus master clock output (open-drain) connected to ISL95338
P40
TOOL0
Connected to on-chip debugging emulator interface for flash programming.
P61
Pull-up
Pull-up to +3.3V
P60
Pull-up
Pull-up to +3.3V
P62
Pull-up
Pull-up to +3.3V
P32
Open
-
P80
Open
-
P50
Open
-
P51
Open
-
RD1
RD1
Rd resistor 1, Analog pin from CC-PHY.
CC1
CC1
Configuration Channel 1, Analog pin from CC-PHY
CC2
CC2
Configuration Channel 2, Analog pin from CC-PHY
RD2
RD2
Rd resistor 2, Analog pin from CC-PHY.
REG
REGCTX
Regulator capacitance for CC-PHY. Connecting regulator output stabilization capacitance for
internal operation.
VDD
VDD
Power supply (+3.3V)
REGC
REGC
Regulator capacitance. Connecting regulator output stabilization capacitance for internal
operation.
P121
Pull-down
Pull-down
P122
Pull-down
Pull-down
P137
MSTALTB
PROCHOT# signal from ISL95338
RESETB
RESETB
Chip Reset Input (active low)
P70
Open
-
P71
DISCHG
Discharge control for USB Type-C V
BUS
P72
Gate2
Bypass path gate (Gate2/D5) control
P73
Gate1
Normal path gate (Gate1/D4) control
P81
sw_in
Mode switch (SW3) input
P82
sw_in
Mode switch (SW3) input
P17
Open
-

R9A02G011 JP214/RTK-251-SinkAdapter Instruction Manual
R19AN0246EJ0100 Rev.1.0 Page 8 of 21
Sep.11.23
2. Function
2.1 DC Output Voltage & maximum Current setting
DC Output voltage and maximum current is set by SW1 and SW2.
Table 2-1 Rotary switch setting value
SW position
Maximum Current (SW2)
Voltage (SW1)
0
0A
5V
1
1A
9V
2
2A
12V
3
3A
15V
4
4A
18V
5
5A
20V
6
Prohibited (future use)
Prohibited (future use)
7
Prohibited (future use)
Prohibited (future use)
If output voltage and maximum current are fixed, the substitute circuit as shown in Figure 2-1 can be used
instead of the rotary switch.
Figure 2-1 The substitute circuit for output voltage or current
The resistor values in Table 2-2 can be used to define input level of P20 and P21.
Table 2-2 Resistors values for substitute circuit
Position
Resister value (kΩ)
R1 R2
0 4.7 2.7
1 3.3 2.7
2 2.2 2.7
3 1.5 2.7
4 1.2 2.7
5 1 2.7
6 - -
Note: R1 and R2 within a tolerance of +/- 5% must be required.
If user expects to use other DC output and maximum current level, please ask a contact window.

R9A02G011 JP214/RTK-251-SinkAdapter Instruction Manual
R19AN0246EJ0100 Rev.1.0 Page 9 of 21
Sep.11.23
2.2 Mode selection
RTK-251-SinkAdapter have 2 modes. User can select either of them by setting SW3.
Table 2-3 Mode switch description
SW3
Mode name Behavior
1
2
OFF
OFF
Prohibited
NA
OFF
ON
ByPass mode
If the voltage and current set by SW1 and SW2 can be negotiated with
Type-C sourcing device, open Gate2 (LED D5) provide power to DC
output from Type-C VBUS directly.
ON
OFF
Normal mode
Because there are losses on cable, BB-VR and also path on board, if
1.2 times of power (voltage x current that set by SW1 and SW2) can
be negotiated with Type-C sourcing device, open Gate1 (LED D4) and
BB-VR generated the voltage and maximum current to expected value
that set by SW1/SW2 and supply it on DC output.
ON
ON
Prohibited
NA
Figure 2-2 ByPass / Normal mode enable
Table 2-4 The required Type-C sourcing PD Power(min) on Normal Mode
1A
2A
3A
4A
5A
5V
1.2A@5V
2.4A@5V
2A@9V
2.6A@9V
2A@15V
9V
1.2A@9V
2.4A@9V
2.2A@15V
2.9A@15V
2.7A@20V
12V
1.6A@9V
2A@15V
2.9A@15V
2.9A@20V
3.6A1@20V
15V
1.2A@15V
2.4A@15V
2.7A@20V
3.6A1@20V
4.5A1@20V
18V
1.5A@15V
2.9A@15V
3.3A1@20V
4.4A1@20V
20V
1.2A@20V
2.4A@20V
3.6A1@20V
4.8A1@20V
15A cable is required.
DC output power should be limited within USB Type-C sourcing device power budget. For example, if
USB Type-C sourcing device power budget is 60W(3A@20V), Maximum DC output power on this board
under normal mode becomes 4A@12V.

R9A02G011 JP214/RTK-251-SinkAdapter Instruction Manual
R19AN0246EJ0100 Rev.1.0 Page 10 of 21
Sep.11.23
3. Board setup and how to use
3.1 Required materials to use this board
RTK-251-SinkAdapter: 1 unit
USB Type-C Cable: 1pcs (When the expected DC output power is over 54W, 5A cable shall be
required.)
Notes:
This board is BUS-powered Sink and does not require an external power connection.
PLEASE USE THIS BOARD WHEN YOU UNDERSTAND AND AGREE THAT RENESAS DOES NOT
HAVE ANY RESPONSIBILITY, INDEMNIFICATION, OR LIABILITY FOR USE OF THIS BOARD.
3.2 How to use when connected to a source device
1. Connect DC load to DC terminal block (TB1).
2. Selecting the operating mode by mode switch (SW3) if it uses as bypass mode.
If it uses as normal mode, User can use it as default.
3. Selecting the expected output voltage by rotary DIP switch (SW1)
4. Selecting the expected maximum current by rotary DIP switch (SW2)
5. Connect USB Type-C sourcing device to USB Type-C receptacle (CN1) via USB Type-C Cable and
supply power to the board, confirm green LED (D6) lights on.
6. The board supplies power to DC load as selected output voltage and maximum current.
Never change SW1/SW2/SW3 when the Board power is ON.

R9A02G011 JP214/RTK-251-SinkAdapter Instruction Manual
R19AN0246EJ0100 Rev.1.0 Page 11 of 21
Sep.11.23
3.3 Firmware writing to the R9A02G011 on JP214 / RTK-251-SinkAdapter
This section describes how to generate and write the firmware (e.g. Intel HEX file) to the R9A02G011 in an
appropriate method
3.3.1 FW generation
3.3.1.1 Operating Environment
(1) Host PC
Processor: 1 GHz or faster
Main memory: At least 1 Gbyte
Display: Resolution of 1024 x 768 or higher and 65,536 or more colors
(2) Supported OS
Windows 10 (32-bit or 64-bit)
Windows 11 (32-bit or 64-bit)
Remark:
Microsoft.NET Framework 4.6.1 or later has to be installed.
3.3.1.2 Setup the VIDWriter
(1) Install Microsoft .NET Framework 4.6.1 or later.
(2) Uses exe file including in the unzip directory.
This tool can work without installation. DO NOT change directory structure in the unzipped data.

R9A02G011 JP214/RTK-251-SinkAdapter Instruction Manual
R19AN0246EJ0100 Rev.1.0 Page 12 of 21
Sep.11.23
3.3.1.3 View Description
When you run VIDWriter, the window as shown Figure 3-1 will display.
Figure 3-1 Main window for VIDWriter
A) Menu Bar
You can check Tool version and FW package version in “Help” -> “About”.
B) Field to set VID/PID number.
If you want to use your own hexadecimal VID and PID numbers instead of the default
VID/PID(0xFFFF/0x0000) numbers set in this field, overwrite your own numbers in this field.
Otherwise, leave it as VID: FFFF and PID: 0000.
C) Field to select required feature
Choose the features that match your required behavior.in this field. When selected, the
recommended turnkey solution is displayed in Field D.
Table 3-1 Evaluation boards for each project
Maximum power
~100 W
~ 240 W
w/ Battery
TBD
TBD
w/o Battery
JP214 / RTK-251-SinkAdapter
TBD
D) Window for the Renesas recommended turnkey solution
When you select feature, Field D shows the Renesas recommended turnkey solution as shown
Figure 3-2.
A
B
C
D

R9A02G011 JP214/RTK-251-SinkAdapter Instruction Manual
R19AN0246EJ0100 Rev.1.0 Page 13 of 21
Sep.11.23
E) Field to set specific configuration of Renesas' recommended turnkey solution
Select the required settings, such as DC output voltage and maximum current level, from the
drop-down lists in this Field.
When set a specific configuration, Field D indicates the proper physical setting on the evaluation
board. Then, you should set the switches, jumper pins, etc. on the board according to this picture.
Also, if you require to feed USB-C input directly to the DC output on the board, check “Enable
Bypass Mode”,
Figure 3-2 Main window for VIDWriter after feature selection
F) Press the "Schematic Settings" F tab in field D and you will see the recommended turnkey
schematics with appropriated parameters, such as Figure 3-3.
D
C
E

R9A02G011 JP214/RTK-251-SinkAdapter Instruction Manual
R19AN0246EJ0100 Rev.1.0 Page 14 of 21
Sep.11.23
Figure 3-3 Main window for VIDWriter when press Schematic Setting
G) Finally, when you press the "FW data creation" button, a file save dialog will be displayed. The
default storage location is the "My Documents" folder. You can change the save location and file
name of the ROM image as you like.
3.3.2 Outline of flash memory writing
The R9A02G011 supports Serial programming interface as same as RL78 MCU series.
The code flash memory can be rewritten to through serial programming using a flash memory programmer.
The following dedicated flash memory programmers can be used to write data to the flash memory of the
R9A02G011. For details, refer to the related documents of the tools.
- PG-FP6
- E1, E2, E2 Lite, E20 on-chip debugging emulator
Data can be written to the flash memory on-board by using a dedicated flash memory programmer. The
following table shows the relationship between the situation when writing the firmware and the available
writing tool for the writing method using this interface.
D
F
G

R9A02G011 JP214/RTK-251-SinkAdapter Instruction Manual
R19AN0246EJ0100 Rev.1.0 Page 15 of 21
Sep.11.23
Table 3-2 Firmware writing method and available writing tool
Interface
Situations
Available writing tool
Device
Configuration
R9A02G011
Serial
Programming
(TOOL0)
Customer’s
manufacturing
Example,
PG-FP6,
SF2000A made by
Superfly China
ON board
〇
Design debug,
FW update
E1, E2, E2 Lite, E20
on-chip debugging
emulator
ON board
〇
3.3.2.1 On-board programming
The contents of the flash memory can be rewritten after the R9A02G011 have been mounted on the target
system. The connectors that the dedicated flash memory programmer uses must be mounted on the target
system.
Please use Renesas Flash Programmer V3 as programming software. Refer to the following documents.
Renesas Flash Programmer V3.12 Flash memory programming software User’s Manual (R20UT5312EJ)
List of MCUs supported by Renesas Flash Programmer V3 (R20UT3599EJ)
On the development of flash memory programmer by user, refer to RL78 microcontrollers (RL78
Protocol A) Programmer Edition Application Note (R01AN0815EJ).
Flash programing for R9A02G011 is compatible with the RL78 MCU series. Therefore, if user want to use
available flash memory programmer that supports RL78 MCU, we may be able to port the library for that
programmer. Please ask a contact window.

R9A02G011 JP214/RTK-251-SinkAdapter Instruction Manual
R19AN0246EJ0100 Rev.1.0 Page 16 of 21
Sep.11.23
Table 3-3 Wiring Between R9A02G011GNP and Dedicated Flash Memory Programmer
Pin Configuration of Dedicated Flash Memory Programmer
Pin name
Pin No.
R9A02G011GNP
32pin
Signal Name
IO Pin Function HVQFN
PG-FP6
E1, E2, E2 Lite,
E20 on-chip
debugging
emulator
SI/RxD
TOOL0
I/O
Transmit/receive
signal
P40
7
/RESET
RESET
Output
Reset signal
RESETB
25
VDD
VDD
I/O
VDD voltage
VDD
20
GND
GND
-
Ground
GND Pad
GND PAD
FLMD1
EMVDD
-
Driving power for
TOOL0 pin
VDD
20
Table 3-4 Wiring Between R9A02G011GBG and Dedicated Flash Memory Programmer
Pin Configuration of Dedicated Flash Memory Programmer
Pin name
Pin No.
R9A02G011GBG
42pin
Signal Name
IO Pin Function BGA
PG-FP6
E1, E2, E2 Lite,
E20 on-chip
debugging
emulator
SI/RxD
TOOL0
I/O
Transmit/receive
signal
P40
G1
/RESET
RESET
Output
Reset signal
RESETB
A5
VDD
VDD
I/O
VDD voltage
VDD
D4/D5/D6
GND
GND
-
Ground
GND Pad
A1/B1/G6
FLMD1
EMVDD
-
Driving power for
TOOL0 pin
VDD
D4/D5/D6
Remark: Pins that are not indicated in the above table can be left open when using the flash memory
programmer for flash programming.
3.3.3 FW writing with Renesas on-chip debugging emulator
User can write(load) firmware by Renesas on-chip debugging emulator. Since RTK-251-SinkAdapter does
not have full 14 pin connector for the emulator, User shall connect via a converter which is made with the
bundled cable when using Renesas on-chip debugging emulator.
1. Connect conversion connector to CN2 on the board.
2. Connect Renesas on-chip debugging emulator to conversion connector.
3. Connect the emulator to USB port of the PC.

R9A02G011 JP214/RTK-251-SinkAdapter Instruction Manual
R19AN0246EJ0100 Rev.1.0 Page 17 of 21
Sep.11.23
Figure 3-4 Board connection for programming by on-chip debugging emulator
4. Connect USB-C AC adapter to CN1 on the board.
5. Execute the “Renesas Flash Programmer V3.xx.
6. Create a “New Project”.
7. Select the “RL78” in the “Microcontroller”-list box, input an arbitrary name in the “Project Name”
8. Select your on-chip debugging emulator product in the “Tool”-list box.
9. Click the “Tool detail” and select the “None" in the Power Supply, then click “Connect”.
10. Below window appears if new project is created correctly.

R9A02G011 JP214/RTK-251-SinkAdapter Instruction Manual
R19AN0246EJ0100 Rev.1.0 Page 18 of 21
Sep.11.23
Note: Confirm that the Microcontroller can detect “D720251”

R9A02G011 JP214/RTK-251-SinkAdapter Instruction Manual
R19AN0246EJ0100 Rev.1.0 Page 19 of 21
Sep.11.23
11. Check the “Erase”, “Program” and “Verify” in the “Operation Settings”-tab
12. Click the “Start” if you start programming a flash memory data

R9A02G011 JP214/RTK-251-SinkAdapter Instruction Manual
R19AN0246EJ0100 Rev.1.0 Page 20 of 21
Sep.11.23
13. The “OK” is indicated if program is completed successfully.
