Renishaw PH20 User manual

PH20 installation and user's guide
Document part number H-1000-5209-04-D
PH20 installation and user's guide
www.renishaw.com
Issued 03 2019
1

General information
© 2010 ‐ 2019 Renishaw plc. All rights reserved.
This document may not be copied or reproduced in whole or in part, or transferred to any other media or language, by any means, without
the prior written permission of Renishaw.
The publication of material within this document does not imply freedom from the patent rights of Renishaw plc.
Disclaimer
RENISHAW HAS MADE CONSIDERABLE EFFORTS TO ENSURE THE CONTENT OF THIS DOCUMENT IS CORRECT AT THE DATE OF
PUBLICATION BUT MAKES NO WARRANTIES OR REPRESENTATIONS REGARDING THE CONTENT. RENISHAW EXCLUDES LIABILITY,
HOWSOEVER ARISING, FOR ANY INACCURACIES IN THIS DOCUMENT.
Trademarks
RENISHAW® and the probe emblem used in the RENISHAW logo are registered trademarks of Renishaw plc in the UK and other countries.
apply innovation is a trademark of Renishaw plc.
All brand names and product names used in this document are trade names, service marks, trademarks, or registered trademarks of their
respective owners.
Windows XP, Windows 2000, Vista, Windows 7 and Windows 10 are registered trade names of the Microsoft Corporation.
All trademarks and trade names are acknowledged.
WEEE
The use of this symbol on Renishaw products and/or accompanying documentation indicates that the product should not be mixed with the
general household waste upon disposal. It is the responsibility of the end user to dispose of this product at a designated collection point for
waste electrical and electronic equipment (WEEE) to enable reuse or recycling. Correct disposal of this product will help save valuable
resources and prevent potential negative effects on the environment. For more information, please contact your local waste disposal service
or Renishaw distributor.
Warranty
Renishaw plc warrants its equipment for a limited period (as set out in our Standard Terms and Conditions of Sale) provided that it is installed
exactly as defined in associated Renishaw documentation.
Prior consent must be obtained from Renishaw if non-Renishaw equipment (e.g. interfaces and/or cabling) is to be used or substituted. Failure
to comply with this will invalidate the Renishaw warranty.
Claims under warranty must be made from authorised service centres only, which may be advised by the supplier or distributor.
PH20 installation and user's guide
www.renishaw.com
Issued 03 2019
2

Care of equipment
Renishaw probes and associated systems are precision tools used for obtaining precise measurements and must therefore be treated with
care.
Changes to Renishaw products
Renishaw reserves the right to improve, change or modify its hardware or software without incurring any obligations to make changes to
Renishaw equipment previously sold.
Packaging
To aid end user recycling and disposal the materials used in the different components of the packaging are stated here:
Packaging component Material 94/62/EC code 94/62/EC number
Outer box Non-corrugated fibreboard PAP 21
Bag Low density polyethylene LDPE 04
Label Polyethylene terephthalate PET 01
Patents
Features of the PH20 system and associated products, equipment and techniques are the subjects of one or more of the following patents and
patent applications:
CN100464156 EP1307710 IN250931 JP5095211 US6860637
CN101405564 EP1668317 IN292511 JP5276434 US7228641
CN101469966 EP1877728 INWO2007/107776 JP5350216 US7568373
CN101711343 EP1989504 INWO2011/135298 JP5539865 US7783445
CN101772690 EP2002206 INWO2012/010836 JP5578752 US7809523
CN102859316 EP2140318 JP5676186 US8001859
CN103003658 EP2162701 JP5706158 US8336219
EP2167911 JP5715995 US8474148
EP2559965 JP5739286 US8601701
EP2564152 JP6013533 US8756973
EP2596319 US8939008
EP3333537 US9052177
US9377284
PH20 installation and user's guide
www.renishaw.com
Issued 03 2019
3

Product compliance
EU declaration of conformity
Contact Renishaw plc or visit www.renishaw.com/EU for the full EU declaration.
FCC (USA only)
Information to user (47 CFR 15.105)
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC rules. These
limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to
cause harmful interference, in which case you will be required to correct the interference at your own expense.
Information to user (47 CFR 15.21)
The user is cautioned that any changes or modifications not expressly approved by Renishaw plc or authorised representative could void the
user's authority to operate the equipment.
Equipment label (47 CFR 15.19)
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause undesired operation.
REACH regulation
Information required by Article 33﴾1﴿ of Regulation ﴾EC﴿ No. 1907/2006 ﴾“REACH”﴿ relating to products containing substances of very high
concern (SVHCs) is available at:
www.renishaw.com/REACH
China RoHS
Contact Renishaw plc or visit www.renishaw.com/ChinaRoHS for the full China RoHS tabulation.
PH20 installation and user's guide
www.renishaw.com
Issued 03 2019
4

Safety
CAUTION: Before unpacking and installing the PH20 system, the user should carefully read the safety instructions below and
ensure that they are followed at all times by all operators. Operators must be trained in the use and application of the PH20 system
and accompanying products, in the context of the machine it is fitted to, before being allowed to operate that machine.
Please ensure that you understand all safety instructions. Familiarisation with the PH20 system components is recommended.
CAUTION: Permanent magnets are used in some components of the PH20 system and associated products. It is important to keep
them away from items which may be affected by magnetic fields, e.g. data storage systems, pacemakers and watches etc.
Operation and maintenance
The product is only to be used with the appropriate Renishaw controller.
Installation of the PH20 system must be performed by trained personnel.
DO NOT edit any of the system files directly, the appropriate commissioning software package should only be used by trained personnel.
It is recommended that the power is removed before performing any maintenance operations.
Maintenance is restricted to procedures described in the maintenance section.
PH20 installation and user's guide
www.renishaw.com
Issued 03 2019
5

Warnings
Beware of unexpected movement. The user should remain outside of the full working envelope of probe head and stylus. The machine
supplier should ensure the user is aware of the full working envelope of the system.
In all applications involving the use of machine tools or CMMs, eye protection is recommended.
It is the machine supplier's responsibility to ensure that the user is made aware of any hazards involved in operation, including those
mentioned in Renishaw product documentation, and to ensure that adequate guards and safety interlocks are provided.
Refer to the machine supplier's operating instructions.
Take care to avoid collisions between the head and workpiece or CMM table.
DO ensure that the head is mounted as rigidly as possible in the CMM's quill.
DO ensure that the head is moved clear of any obstruction before requesting a position change.
DO NOT apply force to any moving parts of the head.
DO NOT move the head axes by hand when locked or unlocked.
The product and the system components contain no user serviceable parts. No attempt should be made to disassemble any part of the
product. In the event of a problem please contact your supplier for assistance.
The cables must meet Renishaw specifications. Incorrect cabling could cause damage to the equipment.
Under certain circumstances the probe signal may falsely indicate a probe-seated condition. Do not rely on probe signals to stop machine
movement.
Probe trigger override will prevent machine backing off in the event of a probe collision.
The probe joint is designed to release the stylus module in the event of a crash.
The product has direct drive motors and the lowest risk reaction to an E-STOP is to perform a fast stop followed by holding position. As such,
the head motors will remain live, even if the E-STOP button is depressed
The PH20 head must be transported in Renishaw supplied packaging.
This equipment is not suitable for use in a potentially explosive atmosphere.
PH20 installation and user's guide
www.renishaw.com
Issued 03 2019
6

International safety instructions
BG ‐ ПРЕДУПРЕЖДЕНИЕ
Моля, обърнете на приложение 1 и прочетете инструкциите за безопасност на вашия собствен език, преди за разопаковате и
монтирате този продукт.
CZ ‐ VÝSTRAHA
Před rozbalením a instalací tohoto výrobku si přečtěte bezpečnostní pokyny ve vlastním jazyce uvedené v příloze 1.
DA - ADVARSEL
Læs sikkerhedsinstrukserne i Appendix 1 FØR udpakning og installation af dette produkt.
DE - WARNHINWEIS
Bevor Sie dieses Produkt auspacken und installieren, konsultieren Sie bitte Anhang 1 und lesen Sie die Sicherheitshinweise in Ihrer Sprache.
EL ‐ ΠΡΟΕΙΔΟΠΟΙΗΣΗ
Γυρίστε στο Κεφάλαιο 1 και διαβάστε τις οδηγίες ασφαλείας στη δική σας γλώσσα προτού ανοίξετε αυτό το προϊόν για να το
εγκαταστήσετε.
ES - ADVERTENCIA
Consulte el apéndice 1 y lea las instrucciones de seguridad en su idioma antes de desempaquetar e instalar este producto.
ET - HOIATUS
Palun vaadake 1. lisa ning lugege enne selle toote lahtipakkimist ja paigaldamist ohutusjuhend läbi.
FI - VAROITUKSIA
Lue liitteessä 1 olevat omalla kielelläsi kirjoitetut turvaohjeet ennen tämän tuotteen pakkauksen avaamista ja asentamista.
FR - AVERTISSEMENT
Consulter l'annexe 1 et les instructions de sécurité dans votre propre langue avant de déballer et d'installer ce produit.
GA - RABHADH
Téigh chuig aguisín 1 agus déan na treoracha sábháilteachta a léamh i do theanga féin le do thoil sula ndéantar an táirge seo a dhíphacáil
agus a shuiteáil.
PH20 installation and user's guide
www.renishaw.com
Issued 03 2019
7

HR - NAPOMENA
Prije nego što proizvod izvadite iz ambalaže i ugradite ga, otvorite Prilog 1 i pročitajte sigurnosne upute na svom jeziku.
HU – FIGYELMEZTETÉS
A termék kicsomagolása és telepítése előtt olvassa el az 1. számú függelékben található, az Ön anyanyelvén hozzáférhető biztonsági
utasításokat.
IT - AVVISO
Prima di aprire ed installare questo prodotto, leggere le istruzioni di sicurezza nella vostra lingua riportate nell'Appendice 1.
JA ‐ 警告
この製品を箱から取り出し設置する前に、付録 1 に記載された安全性に関する注意書きをお読みください。
LT – ĮSPĖJIMAS
Prieš išpakuodami ir įdiegdami produktą, turite grįžti prie 1 priedo ir perskaityti nurodymus dėl saugos savo kalba.
LV – BRĪDINĀJUMS
Pirms šī izstrādājuma izsaiņošanas un uzstādīšanas izskatiet 1. pielikumā sniegtās drošības instrukcijas savā valodā.
MT - TWISSIJA
Jekk jogħġbok mur f'appendiċi 1 u aqra l‐istruzzjonijiet tas‐sigurtà fil‐lingwa tiegħek qabel ma toħroġ dan il‐prodott mill‐ippakkjar u
tinstallah.
NL - WAARSCHUWING
Ga naar appendix 1 en lees de veiligheidsinstructies in uw eigen taal, voordat u dit product uitpakt en installeert.
PL ‐ OSTRZEŻENIE
Przed rozpakowaniem i zainstalowaniem tego produktu prosimy o zapoznanie się z Dodatkiem 1 i przeczytanie zaleceń dotyczących
bezpieczeństwa w danym języku.
PT ‐ ADVERTÊNCIA
Você deve retornar ao Anexo 1 e ler as instruções de segurança em seu idioma antes de desembalar e instalar este produto.
RO - AVERTISMENT
Înainte de a desface ambalajul şi a instala acest produs, vă rugăm să căutaţi Anexa 1 şi să citiţi cu atenţie instrucţiunile de siguranță, în limba
română.
PH20 installation and user's guide
www.renishaw.com
Issued 03 2019
8

SK ‐ VÝSTRAHA
Pred rozbalením a inštaláciou tohto produktu si pozrite prílohu 1 a prečítajte si bezpečnostné pokyny vo vašom jazyku.
SL - OPOZORILO
Preden izdelek vzamete iz embalaže in ga vgradite, odprite Prilogo 1 in preberite varnostna navodila v svojem jeziku.
SV - VARNING
Gå till bilaga 1 och läs säkerhetsinstruktionerna på ditt eget språk innan du packar upp och installerar denna produkt.
TW ‐ 警告
在拆開和安裝本產品之前，請翻頁至附錄 1 閱讀母語的安全指示。
中文 — 警告
在拆包和安装本产品之前，请翻到附录1，阅读中文版安全说明。
PH20 installation and user's guide
www.renishaw.com
Issued 03 2019
9

Environmental conditions
Storage Operating
Temperature ‐25 °C to +70 °C +10 °C to +40 °C
Humidity 0% to 80% (non-condensing) 0% to 80% (non-condensing)
PH20 installation and user's guide
www.renishaw.com
Issued 03 2019
10

References and associated documents
The following Renishaw documents are referred to in this document or may be a source of further relevant information. They can easily be
acquired from Renishaw web site www.renishaw.com.
Title Document number
Technical specifications guide: Styli and accessories H-1000-3200
Installation guide: UCC2 H-1000-5223
Installation guide: UCC T5 H-1000-7573
Installation guide: SPA3 H-1000-7566
Installation and user's guide: MCU H-1000-5182
Installation and user guide: TP20 H-1000-5008
PH20 installation and user's guide
www.renishaw.com
Issued 03 2019
11

System description
PH20 is a dynamic measuring head and probe system from Renishaw. It is a revolutionary product designed to maximise measurement
throughput whilst maintaining high system accuracy for basic entry level measurement systems.
PH20 incorporates Renishaw's long established TP20 probe system into a revolutionary motorised head system to give unprecedented touch-
trigger measurement capability. Unlike conventional touch-trigger measurement methods which rely on increased speed of the CMM's 3 axes
to measure quickly, PH20 uses head motion to minimise dynamic errors introduced by machine motion at high measurement speeds.
Key features:
Infinite positioning - not restricted to defined index angles
Rapid head touches - where the CMM is stationary and the head moves and takes a touch point (UCC T5 systems only)
Rapid 5-axis moves - synchronised motion of the head and CMM between measurements
Components
PH20 head
TCR20 (module change rack with tip datum artefact)
TP20 stylus modules (excluding extended force)
UCC T5 or UCC MT5 PH20 CMM controller kit
Connections
The PH20 head and CMM system are operated through the UCCserver which uses I++DME command protocol to communicate between the
system application software and the Renishaw controller. The CMM and PH20 head are controlled by the appropriate Renishaw controller, via
its standard connections.
System functionality
The PH20 system is compatible with either the UCC T5 or UCC MT5 controller. Both systems offer infinite positioning and 5-axis motion but
rapid head-touch measurement is only possible with a UCC T5 PH20 system.
PH20 installation and user's guide
www.renishaw.com
Issued 03 2019
12

Specification
Standard force
module Medium force module Low force module 6-way module EM1 module EM2 module
Dimension A
(mm) 21 21 21 25 71 96
Net weight: 810 g
PH20 installation and user's guide
www.renishaw.com
Issued 03 2019
13

PH20 head axis range
The PH20 head has two rotary axes (A and B) and is normally mounted on the CMM quill to create a 5-axis measuring system. The PH20 B-
axis is mounted on the CMM quill and can rotate continuously in both directions. The A‐axis, which is orthogonal to the B‐axis, has ±115° of
travel. The head can only be mounted in the vertical orientation shown below.
PH20 installation and user's guide
www.renishaw.com
Issued 03 2019
14

TP20 stylus modules
PH20 has an integrated TP20 body that is capable of touch-trigger measurement when used with a suitable stylus module. The probe design
utilises the existing range of the TP20 stylus modules, however the TP20 extended force module is not suitable for use on PH20.
Each probe module, which houses the kinematic switching touch sensor mechanism, carries the stylus assembly and provides overtravel in
the X, Y and +Z axes ﴾–Z is offered when using the TP20 6‐way probe module﴿. Incorporating an M2 stylus mounting, each probe module is
compatible with Renishaw's comprehensive range of M2 styli.
Designed to minimise the possibility of probe module misalignment generating a probe ‘seated' signal, the probe module is held in position
by a magnetically retained, highly repeatable kinematic coupling. Electrical contact pins conduct the probe sense voltage through the coupling.
PH20 installation and user's guide
www.renishaw.com
Issued 03 2019
15

Trigger force options
The standard force probe module is suitable for most applications (when used with the recommended stylus range), but sometimes the
effects of stylus length and mass, combined with machine acceleration and vibration, can cause the probe to false trigger (these are referred
to as ‘false triggers'﴿.
To allow the PH20 to be used on co-ordinate measuring machines where acceleration forces or vibration would otherwise result in spurious
triggers, a choice of higher force probe modules is available. A low force probe module is also available for measurement of delicate
materials. Refer to the applications guide later in this document for information on how to select the correct probe module for your
application.
The type of probe modules supplied with your probe will be clearly marked on each probe module's front ring. The probe modules also carry
a colour-coded front cap as follows:
Low force (LF) probe module (green cap)
Standard force (SF) probe module (black cap)
Medium force (MF) probe module (grey cap)
6-way (6W) probe module (blue cap)
Extension module 1 standard force (EM1 STD) (black cap)
Extension module 2 standard force (EM2 STD) (black cap)
NOTE: The extended force module is not suitable for use with the PH20 system.
TP20 module kits
The following TP20 probe module kits are available from your supplier for use with PH20:
TP20 probe module kit (probe module only) Part number
Low force probe module A-1371-0392
Standard force probe module A-1371-0270
Medium force probe module A-1371-0271
6-way probe module A-1371-0419
EM1 STD probe module A-1371-0430
EM2 STD probe module A-1371-0431
EM1 STD and EM2 STD probe modules A-1371-0432
PH20 installation and user's guide
www.renishaw.com
Issued 03 2019
16

Manually mounting / removing the stylus modules to / from PH20
It is not recommended to manually remove and refit a probe module to PH20. If it is absolutely neccessary to manually remove the probe
module from PH20 it should only be done in certain orientations. Please see the image below.
To fit the probe module and stylus onto the probe body, carry out the following procedure:
1. Visually examine the mating faces of both the probe module and the probe head for cleanliness; where necessary, clean the mating
surfaces using the CK200 cleaning kit (supplied).
2. Align the probe module to the PH20 using the reverse of the method used to remove it manually. Ensure the three alignment marks on
both the probe module and probe body are correctly aligned, allow the probe module to engage the probe body under magnetic force.
PH20 installation and user's guide
www.renishaw.com
Issued 03 2019
17

Manually mounting / removing the stylus from the stylus module
To fit a stylus onto the probe module, carry out the following procedure:
NOTE: For advice on both stylus and probe module selection, refer to the applications guide later in this publication.
1. Ensuring that you have selected the correct probe module for your given application (see probe module selection later in this guide), screw
the threaded end of your chosen stylus into the M2 stylus mount of the probe module and hand-tighten to secure.
2. Using the type S7 stylus tools provided, or type S20 spanner if fitting a stylus from the Renishaw GF range, fully hand-tighten the stylus
into the stylus mount to achieve the recommended tightening torque of between 0.05 Nm and 0.15 Nm (maximum permissible torque is
0.3 Nm).
TCR20 rack kit
The TCR20 rack, which can be easily mounted onto a CMM, is designed to securely hold stored probe modules for automatic changing.
TCR20 protects stored probe modules from airborne contaminants that may be present within the working environment and also features an
integrated tip datum artefact.
PH20 installation and user's guide
www.renishaw.com
Issued 03 2019
18

PH20 stylus selection
NOTE: Choosing the best stylus for a given application is an important factor in achieving optimum probe performance. For further
information on the full range of Renishaw styli, please refer to Renishaw's styli and accessories brochure (H-1000-3200) which can
be ordered from your supplier or downloaded from Renishaw's web site, www.renishaw.com.
When selecting a stylus, it is important that the stylus length is kept to the minimum required to access all features to be measured,
and that the stylus type offers the maximum possible stiffness. Factors that affect stiffness are:
Joints in the styli: these tend to reduce rigidity and should therefore be kept to the absolute minimum
Stem diameters: that are governed by the ball tip diameter of the stylus
Stem material: that can be stainless steel, ceramic or graphite fibre
It is also important to ensure that the stylus ball diameter chosen is as large as is practical. This not only ensures that the stylus will be as stiff
as possible, but also reduces the stylus's susceptibility to surface form and surface finish.
Owing to the modular construction of the TP20, when selecting and using styli the following criteria should be applied:
Work only within the recommended stylus limits for each probe module (refer to 'Recommended stylus limits' below)
Always use the shortest possible stylus
If using larger styli than those recommended for use with each probe module, always conduct trials to establish the effect on measuring
performance
Minimise the mass of styli by using either ceramic or graphite fibre stems
PH20 installation and user's guide
www.renishaw.com
Issued 03 2019
19

Recommended stylus limits
Owing to the modular construction of the TP20 probe, it is recommended that the limits shown in the following figures are applied when
selecting styli to be used.
The low force probe module
The low force probe module has the following recommended stylus limits:
Steel and carbide styli up to 30 mm long
No star or cranked styli
The standard force probe modules (SF, EM1 and EM2)
The standard force probe modules (SF, EM1 STD and EM2 STD) can be used with the following range of styli:
Steel and carbide styli up to 40 mm long
Renishaw graphite fibre (GF) type styli up to 50 mm long
Star and cranked styli up to 20 mm offset
PH20 installation and user's guide
www.renishaw.com
Issued 03 2019
20
