Renown REN08012-VP User manual

Compact design • Attractive styling • Built in transport wheels
• 9 foot vacuum hoses • Simple easy to use controls
• 24" front mount squeegee assembly • Easy to service design
• Contractor tool kit includes Wet p/u tool, Dry p/u tool, Crevice tool,
Upholstery tool and Dusting brush
REN08012-VP WET & DRY VACUUM
www.GoRenown.com
1-866-412-6726 Tulsa, OK 74105
R

STANDARD FEATURES
• 24-inch front mounted squeegee assembly
• 10-inch stair climbing rear wheels
• On-board tool storage for the following standard tools
– Crevice tool
– Dusting brush
– Wet & dry pick-up tools
– 3 piece stainless steel wand
• 9 foot vacuum hose
• 30" Squeegee assembly
• 24" Dry pick-up squeegee assembly
Power: 1.33 hp
Voltage: 110 volt
Water Lift: 110"
Air Flow: 95 cfm
Capacity: 18 gallons
Weight: 60 lbs
Cable: 50 ft./safety yellow
Dimensions: 39" L
18.5" W
41.5" H
Amp Draw: 8 amps
TABLE OF CONTENTS
Safety Precautions 3
Handle Assembly 4
Machine Operation 5
Machine Maintenance 5-6
Parts List 9-16
Wiring Diagram 17
REN08012-VP WET & DRY VACUUM
www.GoRenown.com
2
OPTIONAL ACCESSORIES
TECHNICAL SPECIFICATIONS
R
7-12
13

www.GoRenown.com
3
REN08012-VP WET & DRY VACUUM
SAFETY PRECAUTIONS
THIS MACHINE MUST BE GROUNDED
Grounding provides a path of least resistance for
electrical current. To reduce the risk of electrical
shock should the machine malfunction, the machine
has a special grounding plug. Do not remove the
grounding pin under any circumstances!
This machine is intended for commercial use. It is
constructed for use in an indoor environment and
is not intended for any other use. Use only
recommended accessories.
All operators shall read, understand and exercise
the following safety precautions:
1. Do not operate machine:
– Unless trained and authorized.
– Unless you have read and understand the
operators manual.
– In flammable or explosive areas.
– With damaged or modified cord or plug.
– If not in proper operating condition.
– In outdoor areas.
– In standing water.
– Without filters in place.
– With the use of unapproved extension cords.
2. Before operating machine:
– Make sure all safety devices are in place and
operating properly.
3. When using machine:
– Mix and handle any chemicals according to
manufacturer’s recommendations.
– Do not run machine over cord.
– Do not pull machine by cord or plug.
– Do not pull cord around sharp edges or corners.
– Do not unplug by pulling on the cord.
– Do not stretch cord.
– Do not handle plug with wet hands.
– Keep cord away from heated surfaces.
– Do not pick-up burning or smoking debris such
as cigarettes, matches or hot ashes.
– Report machine damage or faulty operation
immediately.
4. Before leaving or servicing machine:
– Turn off machine.
– Unplug power cord from outlet.
5. When servicing machine:
– Unplug cord from outlet.
– Use manufacturer supplied or approved
replacement parts.
R

www.GoRenown.com
4
REN08012-VP WET & DRY VACUUM
HANDLE ASSEMBLY
R

REN08012-VP WET & DRY VACUUM
OPERATION OF WET & DRY VACUUM
www.GoRenown.com
5
Read operators manual thoroughly prior to
operating or servicing this machine!
WET PICKUP
1. Remove vacuum head and remove the cloth or
paper filter from vacuum, install the blue bubble
buster filter.
2. While vacuum head is removed, check to make
sure that the float shut-off is unobstructed and
fully functional.
3. Replace vacuum head and latch it in place.
4. Connect vacuum hose to inlet on the front of the
machine body.
5. Attach appropriate accessory tool for the job to be
completed.
6. Plug power cord into a grounded outlet.
Do not use an extension cord in
conjunction with the standard power cord.
7. If using the front-mounted squeegee assembly,
be sure that squeegee is attached to front of
machine.
8. If using the front-mounted squeegee assembly,
lower squeegee to the floor by depressing the top
half of the pedal (rear of the machine) forward with
your foot.
9. Turn power switch to “on” position.
10. During wet pickup, the float shut-off will
automatically prevent water from entering the
recovery tank once the recovery tank is full.
If foam develops in the recovery tank during wet
vacuuming, use de-foamer chemical to help
eliminate the foam. Foam will not activate the
float shut-off, and therefore, may cause vacuum
motor damage.
11. To raise the squeegee assembly back to transport
position, depress the bottom half of the pedal
(rear of the machine) downward with your foot.
Be sure that the handle is properly assembled
on machine body prior to operating machine.
The Renown wet & dry vacuum includes the
GV25014 “bubble buster” blue nylon foam
suppression bag. This bag must be used in all
wet pick-up applications. Failure to use the bag
will void the warranty on the vacuum motor.
DRY PICKUP
1. Remove vacuum head and bubble buster, and be
sure the cloth or paper filter is properly installed.
Do not operate machine without bag or filter
properly installed.
2. Replace vacuum head and latch it in place.
3. Connect vacuum hose to inlet on the front of the
machine body.
4. Attach appropriate accessory tool for the job to be
completed.
5. Plug power cord into a grounded outlet.
Do not use an extension cord in conjunction with
the standard power cord.
6. Turn power switch to “on” position.
7. Check the filter bag periodically to see if it is full.
For optimal performance, replace bag when it is
3/4 full.
DRAINING THE RECOVERY TANK
1. Unplug machine from power outlet.
2. Transport machine to nearest floor drain or bucket.
3. Remove drain hose from rear of machine. Remove
ball plug from drain hose, and drain the contents
of the tank.
4. After the contents have drained, remove the vacu-
um head and rinse recovery tank with clean water.
5. Replace the ball plug on the drain hose and hang
hose back on the rear of the machine.
To prevent odors in the recovery tank,
remove the vacuum head when machine is not
in operation to allow air to circulate.
R

REN08012-VP WET & DRY VACUUM
MAINTENANCE/STORAGE
www.GoRenown.com
6
MAINTENANCE
To keep the machine performing well for many
years, please follow the following maintenance
procedures.
Always confirm that the machine is unplugged
prior to performing any maintenance or repairs.
1. Drain and rinse recovery tank after each use.
2. Clean float shut-off after each use.
3. Check bag to see if it is full after each use.
Replace bag when it is 3/4 full.
4. Clean outside of machine with a mild cleaner.
5. Check power cord for any damage. If any damage
is found, replace power cord with approved cord.
6. Clean squeegee blades with a damp cloth.
Do not use your fingers to wipe the blades.
7. Check vacuum hose for holes and clogs.
8. Lubricate wheels, casters and axles with a water
resistant lubricant every month.
9. Check machine for loose or missing nuts and
bolts, and replace as necessary.
After each use in a wet pick-up application,
remove the GV25014 “Bubble Buster” blue nylon
foam suppression bag and rinse it with clean
water. This will aid in preventing any build-up
which can reduce air flow.
STORAGE
1. Unplug machine from power source.
2. Store in upright position in a dry area.
3. Store with squeegee assembly off the ground.
4. Store with vacuum head off unit so that tank may
breathe.
R

www.GoRenown.com
7
REN08012-VP WET & DRY VACUUM
VACUUM GROUP
R

www.GoRenown.com
REN08012-VP WET & DRY VACUUM
VACUUM GROUP PARTS LIST
DIA PART DESCRIPTION NO
NO NUMBER REQ’D
1 GT10004 HANDLE 1
2 VF40994 READ MANUAL LABEL 1
3 VA21544A SERIAL TAG 1
4 VA20453 DECAL, WARNING 1
5 GT10003B COVER, VAC HEAD 1
6 GT13001 ST5 x 12, PH 3
7 GT10019 UPPER COVER, MOTOR 1
8 GT13004 ST5 x 20, PH 1
9 GT13034 ST5 x 50, PH 4
10 GT13033 ST5 x 44, PH 6
11 VA13470 ST3 x 16, PH 2
12 VA21517 CLAMP, BLOCK 1
13 VA65001 CABLE, POWER 1
14 VA21521 GROMMET, POWER CORD 1
15 VA91346 ON/OFF SWITCH 1
16 GC15002 MOUNTING COVER, MOTOR 1
17 FC25002A MOUNTING PLATE, MOTOR 1
18 VA41032 GASKET, MOTOR 2
19 VA41040 VAC MOTOR, 115V 1
20 GV25002 SEAL PLATE 1
21 GC15004A MOUNTING BASE, MOTOR 1
22 GV15006 GASKET, MOUNTING PLATE 1
23 GV25010 FILTER SCREEN 1
24 GV25013 FILTER 1
25 GV25006 TRUMPET 1
26 GV25003 POLE, BALL 1
27 VF14090 “O” RING 1
28 GV25009 BALL 1
29 GV0014 VACUUM FILTER ASSY 1
30 GV25014 BUBBLE BUSTER 1
R
8
VA21543S

www.GoRenown.com
REN08012-VP WET & DRY VACUUM
TANK GROUP
R
9

REN08012-VP WET & DRY VACUUM
TANK GROUP PARTS LIST
12
DIA PART DESCRIPTION NO
NO NUMBER REQ’D
1VF47035A “RENOWN” LOGO 2
2 VA75001 TANK 1
3 GT13022 NUT, M5, NYLON INSERT 4
4 VF13474A WASHER 6
5 VA21595 CATCH 2
6 VA14010 SCREW, M5 x 20 4
7 VA14004 SELF-TAPPING SCREW, ST4 x 20 4
8 VA13483 WASHER 4
9 VA21514 GASKET 1
10 VA21513A INTAKE 1
11 VA85018 HOSE ASSEMBLY 1
12 VA91342 3.5" CASTER 2
13 VF13600 WASHER 10
14 VF13495 SCREW, M6 x 16 6
15 VA75005 LEAF SPRING 1
16 VA75013 AXLE 1
17 VA85003 KNOB 2
18 VA75006 MOUNTING PLATE, PICK-UP TOOL 1
19 VA75007 BUMPER 2
20 VA85002 BODY, PICK-UP TOOL, 24" 1
VA75008 BODY, PICK-UP TOOL, 30" 1
21 VA13471 SELF-TAPPING SCREW, ST5 x 10 2
22 VA85001 CLAMP, BLADE, 24" 1
VA75009 CLAMP, BLADE, 30" 1
23 VV20501 SCREW, M5 x 14, PH 6
VA85007 BLADE, 24" 2
24 VA75010 BLADE, 30" 2
25 VA13491 SCREW, M8 x 25 2
26 VA85005 LOCK 4
27 VA85004 AXLE, WHEEL 2
28 VA91345-8 WHEEL, 2" 2
29 VF13516 WASHER 8
30 VA14001 LOCK 4
31 VA75001 AXLE, MOUNTING PLATE 1
32 VA75012 PEDAL 1
33 VA75003 AXLE, PEDAL 1
34 VV60113S WASHER 2
35 VA75004 10" WHEEL 2
36 VV10011 CAP, AXLE, WHEEL 2
37 VA14002 SCREW, M10 x 50 6
38 VA75002 HANDLE 1
39 VV10113 CLAMP 2" 1
40 VA93208A DRAIN HOSE 1
41 GV70034 CLAMP, DRAIN HOSE 1
42 VA20104A PLUG DRAIN HOSE 1
www.GoRenown.com
R
10
VA75018

www.GoRenown.com
REN08012-VP WET & DRY VACUUM
ACCESSORIES
R
11

REN08012-VP WET & DRY VACUUM
ACCESSORIES PARTS LIST
www.GoRenown.com
R
12
DIA
NO PART NUMBER DESCRIPTION NO REQ'D
1VA20803 DUSTING TOOL 1
2VA20248 TUBE 2
3VA20209 WAND 1
4GV0040-D DRY PICK-UP TOOL 1
5GV0040-W WET PICK-UP TOOL 1
6VA20207-8 RUBBER BLADES, 400mm 2
7VA20207-5A SEAT, BLADE, 400mm 2
8VA20413 PIN, WHEEL 2
9VA20207-4 SEAT, WHEEL 2
10 VA20207-3 CLIP, FLOOR TOOL ADAPTER 1
11 VA20207-2 FLOOR TOOL ADAPTER(38mm) 1
12 VA20806 CREVICE TOOL 1
13 VA20201 MACHINE END 1
14 VA20202 THREADED INSERT 2
15 VA20203 CLIP RING 2
16 VA20206 ANGLED HOSE END, 38mm 1
17 VA20288 HOSE ASSY 1
VA00001A 24" FRONT MOUNT SQUEEGEE ASSY 1
VA00002 30" FRONT MOUNT SQUEEGEE(OPTIONAL)ASSY 1
VA00005
24" DRY PICK-UP TOOL ASSY(OPTIONAL)
1
18
VA00005
24" DRY PICK-UP TOOL ASSY(OPTIONAL)
1
19 VA75020 CLOTH BAG,DUST(OPTIONAL) 1
20 VA75020-1 CLIP, CLOTH BAG(OPTIONAL) 1

www.GoRenown.com
REN08012-VP WET & DRY VACUUM
WIRING DIAGRAM
13
R

Metal Injection Roto-molded Motors & Vacuum All Wear Labor*
MACHINE Castings Molded Polyethylene Gear Boxes Motors Items
Parts
REN08012-VP
Wet & Dry N/A 3 Years 12 Years N/A 3 Years 1 Year 2 Years
Vacuum
WARRANTY PERIODS
REN08012-VP WET & DRY VACUUM
CUSTOMER SERVICE LOCATIONS
ALABAMA
Montgomery, AL 36116
800-239-3167
COLORADO
Aurora, CO 80011
303-343-1730
FLORIDA
Doral, FL 33126
305-471-0077
Pompano Beach, FL 33064
954-972-1700
West Palm Beach, FL 33406
800-940-0900
GEORGIA
Doralville, GA 30340
800-225-6320
ILLINOIS
Peoria, IL 61612
800-322-5344
Rockford, IL 61109
800-874-0296
Streamwood, IL 60107
800-443-4377
IOWA
Davenport, IA 52806
800-581-1777
Des Moines, IA 50314
515-288-3615
Sioux City, IA 51101
712-255-3580
KANSAS
Wichita, KS 67219
800-475-5177
LOUISIANA
New Orleans, LA 70115
504-899-2358
MASSACHUSETTS
Chelsea, MA 02150
800-262-6333
MINNESOTA
Duluth, MN 55811
218-722-4895
St. Paul, MN 55108
800-327-3528
MISSOURI
Kansas City, MO 64120
816-483-5800
MONTANA
Great Falls, MT 59403
800-843-0249
Missoula, MT 59801
800-843-0249
NEBRASKA
Lincoln, NE 68504
402-466-0748
Omaha, NE 68110
402-453-6644
NEW JERSEY
Winslow, NJ 08095
609-567-9600
NORTH CAROLINA
Huntersville, NC 28078
800-222-2901
OHIO
Cleveland, OH 44114
216-431-8111
OKLAHOMA
Oklahoma City, OK 73179
405-745-7550
Tulsa, OK 74116
918-836-9131
Tulsa, OK 74105
918-743-6030
OREGON
Bend, OR 97402
800-942-4385
Eugene, OR 97402
800-942-4385
Medford, OR 97504
800-942-4385
Salem, OR 97302
800-942-4385
Tualatin, OR 97062
800-942-4385
TEXAS
Houston, TX 77024
713-672-2056
Lufkin, TX 75904
800-535-2704
Paris, TX 75460
800-432-1663
WASHINGTON
Lynnwood, WA 98037
800-488-8185
Pasco, WA 99301
800-843-0249
Port Angeles, WA 98362
360-452-9211
Spokane, WA 99207
800-843-0249
Yakima, WA 98902
509-248-1241
www.GoRenown.com
1-866-412-6726 Tulsa, OK 74105
REN08012
REN08012REN08012
REN08012-
--
-
VP WET & DRY VACUUM
VP WET & DRY VACUUM VP WET & DRY VACUUM
VP WET & DRY VACUUM
FOR PURCHASE, SERVICE AND SUPPORT
FOR PURCHASE, SERVICE AND SUPPORTFOR PURCHASE, SERVICE AND SUPPORT
FOR PURCHASE, SERVICE AND SUPPORT
INFORMATION VISIT www.GoRenown.com
INFORMATION VISIT www.GoRenown.comINFORMATION VISIT www.GoRenown.com
INFORMATION VISIT www.GoRenown.com
R
