ResMed RCM1 User manual

User guide
(RCM1)
English | Français | Deutsch | Italiano | Nederlands | Svenska | Suomi | Dansk | Norsk | Español
Português | Polski | Česky | Български | Hrvatski | Eesti keel | Ελληνικα | Magyar | Íslenska | Latviski
Lietuvių k. | Română | Русский | Slovenčina | Slovenščina |Türkçe | ةيبرعلا | یسراف | תירבע | ودرا
User guide

Compatible device*
AirView
AirView
RCM
A
1 2 3
4
5
6 8
B
1
2
3
4
C
7
D
*Dispositif Compatible / Kompatibles Gerät / Apparecchio compatibile / Compatibel apparaat / Kompatibel utrustning / Yhteensopiva laite / Kompatibelt apparat /
Kompatibel enhet / Dispositivo compatible / Equipameto compatível / Zgodny urządzeniami / Kompatibilní zařízeními / Съвместимо устройство / Kompatibilan
proizvod / Ühilduv seade / Συμβατή συσκευή / Kompatibilis készülék / Samhæft tæki / Saderīga ierīce / Suderinamas prietaisas / Dispozitiv compatibil /
Совместимое устройство / Kompatibilné zariadenie / Združljivi pripomočki / Uyumlu cihaz / قفاوتملا زاهجلا/ راگزاس هاگتسد/ םאות ןקתה / سئاويڈ گنہآ مہ

E
F G

English 1
ENGLISH
Introduction
Refer to illustration A.
ResMed Connectivity Module (RCM) provides cellular connection between a compatible ResMed
ventilation device and the ResMed AirView™system.
RCM sends therapy and device data recorded in the ventilation device to the cloud-based AirView
system from home, wirelessly and automatically, to assist the remote display of patient data.
RCM also sends data to AirView on demand when requested via AirView (eg, for remote display and
troubleshooting).
Compatible devices
RCM is compatible with the following ventilation devices:
• Astral™100/150
• Stellar™100/130/150.
Intended use
RCM is intended to be used in the home environment, for the collection and transmission of
respiratory data to AirView. RCM will not control any clinical devices, nor provide interpretation of
data.
RCM is not intended for use on an aircraft.
General warnings and cautions
The following are general warnings and cautions. Specific warnings, cautions and notes appear with
the relevant instructions in the guide.
WARNING
• Only use the power supply unit and plug blade attachments provided with RCM.
• Beware of electrocution. Do not immerse RCM or any of its components in water. Always
unplug RCM before cleaning and make sure that all parts are dry before plugging it back in.
• Do not open or modify the device. There are no user serviceable parts inside. Repairs and
servicing should only be performed by an authorized ResMed service agent.
• The device should not be used adjacent to or stacked with other equipment. If adjacent or
stacked use is necessary, the device should be observed to verify normal operation in the
configuration in which it will be used.
• The use of cables other than those specified for the device is not recommended. They may
result in increased emissions or decreased immunity of the device.
• Portable RF communications equipment (including peripherals such as antenna cables and
external antennas) should be used no closer than 30 cm to any part of the device, including
cables specified by the manufacturer. Otherwise, degradation of the performance of this
equipment could result.
• The RCM device has not been tested or certified for use in the vicinity of X-ray, CT or MRI
equipment. Do not bring the RCM device within 4 m of X-ray or CT equipment. Never bring
the RCM device into an MR environment.
CAUTION
Do not use RCM outdoors.
Note: For any serious incidents that occur in relation to this device, these should be reported to
ResMed and the competent authority in your country.

2
Note: For assistance and reporting of issues associated with the RCM device, contact your Health
Care Provider or authorised ResMed representative.
RCM at a glance
Refer to illustration B.
1.
Stand
6.
Wall mount
2.
Wall mounting socket
7.
Power Supply Unit (PSU)
3.
Indicator panel
8.
Plug blade attachments
4.
Micro-USB port
9.
USB cable (not shown)
5.
Power inlet
Indicators
Refer to illustration C.
RCM provides indication of the current operating state. When the Power and Vent. Input indicators
illuminate and you have network reception, RCM is ready to use.
Indicator
Status
1 Power – Green
Indicates whether RCM is powered on. On: The power is on.
Off:The power is off.
2 Vent. Input – Blue
Indicates whether RCM is connected to the powered-on
ventilation device.
On: Connected to the ventilation device.
Off: Disconnected from the ventilation device.
Blinking: Establishing connection to the ventilation device.
3 Signal – Blue
Indicates connectivity to the cellular network and the signal
strength.
On: Connected to the cellular network. The signal strength
is indicated by the number of blue dots (more dots mean a
stronger signal).
Off: No cellular network detected.
4 Error – Yellow
Indicates whether RCM has an error.
On: An error has occurred.
Off: No error
Note: The Vent. Input and Signal indicators will dim in 5 minutes and will return to full brightness when RCM is
connected to the ventilation device or powered on again.

English 3
Assembling the PSU
Refer to illustration D.
1. Insert the plug blade attachment suitable for your region into the PSU.
2. To remove the plug blade attachment from the PSU, press the button under the arrow and slide
it out.
CAUTION
• Do not leave the plug blade attachment in a power outlet alone.
• Do not plug the PSU upside down into a power outlet. Ensure that the power cord extends
downward.
Setup
Refer to illustration E.
RCM can only be connected to one ventilation device at a time.
1. Connect the RCM to the power using the PSU. Ensure that the Power indicator illuminates.
2. Position RCM where the Signal indicator shows that you have network reception, and ensure
that RCM is:
• more than 2 cm away from the body during operation.
• in an area that will not be affected by moisture.
• ideally 1 m away from the ventilation device or other electrical equipment and 30 cm from
mobile communication devices.
3. Ensure that the RCM is secured with the stand or wall mount. Refer to the Using the stand/wall
mount section.
4. Connect one end of the USB cable to the micro USB port of RCM, and the other end to the mini
USB port at the rear of the powered-on ventilation device (refer to the illustration). Ensure that
the Vent. Input indicator illuminates.
5. To ensure correct times are shown in AirView, ensure that the clock on the ventilation device is
correct (change if appropriate).
Notes:
• For further assistance, contact your care provider or ResMed representative.
• To stop RCM, unplug the power cord from the power outlet.
Using the stand/wall mount
Stand
Refer to illustration F.
1. Place the stand on a stable level surface.
2. Insert the longer edge of the stand into RCM, ensuring that it clicks into place.
3. To remove the stand, release the clip on the stand.

4
Wall mount
Refer to illustration G.
Use appropriate fittings to attach the wall mount. For example, use the round holes or the slots of
the wall mount for screws or cable ties (not provided).
The RCM is only suitable for mounting at heights ≤ 2 m.
WARNING
Ensure that the wall mount is securely fixed in place.
1. Hold RCM at an angle and push it onto the wall mount. Adjust the angle to fit RCM in place.
2. Turn RCM clockwise until it clicks into place.
3. To remove RCM from the wall mount, turn it counterclockwise.
Sending data to AirView
RCM automatically sends the previous 24 hours of data to AirView once at approximately 12 pm
(based on the clock of the connected ventilation device), and once an hour after therapy has
stopped.
If automatic data transmission is missed or interrupted, it will resume when the connection is
re-established. No data will be lost.
To ensure daily automatic data transmission, ResMed recommends you to connect RCM once a day
for one hour, with the Vent. Input and Signal indicators on.
Note: Data more than seven calendar days old will not be sent to AirView.
Cleaning and maintenance
The exterior of RCM and the PSU can be cleaned with a damp cloth and an approved mild cleaning
solution.
The following cleaners and disinfectants are compatible for use when cleaning external surfaces of
RCM:
• isopropyl alcohol*
• bleach (1:10)* (may also be known as ‘diluted hypochlorite’).
*Suitable for weekly use
Always follow the manufacturer's recommended cleaning instructions.
WARNING
Ensure that the RCM and PSU are dry before reconnecting to the power outlet and ventilation
device.
Troubleshooting
Problem/possible cause
Solution
The Power indicator does not illuminate. Check that the PSU is connected correctly to the power outlet and the
rear of RCM.
Check that the plug blade attachment is inserted into the PSU correctly.
Check that the PSU is the one provided with RCM.
The Vent. Input indicator does not illuminate. Check that the ventilation device is turned on.
Check that the USB cable is connected correctly to the rear of RCM and

English 5
Problem/possible cause Solution
the ventilation device.
The Signal indicator does not illuminate. Change the position of RCM.
Check that you have network reception.
Ensure that RCM is ideally 30 cm away from the ventilation device or
other electrical equipment.
The Error indicator is on. Switch RCM off, then on again, to see if this removes the error. If the
Error indicator displays again, contact your care provider or ResMed
representative.
Automatic data transmission was interrupted or
missed at 12 pm (eg, no signal,
RCM/ventilation device disconnected or
powered off).
Re-establish the connection between RCM, ventilation device, and
AirView (refer to the Setup section). Automatic data transmission will
resume to send any outstanding data.
If the problem cannot be solved, contact your care provider or ResMed representative.
Technical specifications
Dimensions (H x W x L)
RCM only: 134 mm x 44 mm x 150 mm
The stand will add 3 mm to the height and 6 mm to the width.
Weight
RCM only: 280 g
The stand will add 30 g and the wall mount will add 10 g.
Power supply unit (PSU) AC 100–240 V, 0.35–0.70 A, 50–60 Hz
DC 24 V, 1.25 A
Cable length 1.8 m
Class II, suitable for continuous operation
Typical power consumption; <3W
Maximum power consumption: <5W
Housing construction
Flame retardant engineering thermoplastic and silicone
Environmental conditions
Operating temperature:
Operating humidity:
Operating altitude:
Storage and transport temperature:
Storage and transport humidity:
+0oC to +40oC
10%–95% non-condensing
Sea level to 3000 m
--25oC to +70oC
10%–95% non-condensing
Electromagnetic compatibility
Product complies with all applicable electromagnetic compatibility
requirements (EMC) according to IEC60601-1-2, for residential, commercial and
light industry environments. It is recommended that mobile communication
devices are kept at least 12" (30 cm) away from the device.
Information regarding the electromagnetic emissions and immunity of this
ResMed device can be found on www.resmed.com/downloads/devices.
IEC 60601-1 classification
Non-transit operable, portable equipment
Compatible software versions
AirView: 4.1 or higher
Astral: SX544-0401 or higher
Stellar: SX483-0250 or higher
Wireless module Technology used: 4G/2G
Declaration of Conformity (DoC to the
Radio Equipment Directive)
ResMed declares that the ResMed Connectivity Module (model 27202) is in
compliance with the essential requirements and other relevant provisions of
Directive 2014/53/EU (RED). A copy of the Declaration of Conformity (DoC) can
be found on Resmed.com/product support.

6
This radio equipment operates with the following frequency bands and
maximum radio-frequency power:
GSM 850/ 900: 33 dBm
GSM 1800/ 1900: 30 dBm
UMTS 850/ 900/ 1700/ 1900/ 2100: 24 dBm
All ResMed devices are classified as medical devices under the Medical
Device Regulation. Any labelling of the product and printed material,
showing , relates to the Regulation (EU) 2017/745 of the European
Parliament and the Council of 5 April 2017.
Separation
The RCM device should be used at a minimum distance of 2 cm from the body
and ideally 1 m from the ventilation device during operation.
Design life
5 years
The RCM and PSU do not contain any serviceable parts.
Note: The manufacturer reserves the right to change these specifications without notice.
Symbols
The following symbols may appear on the product or packaging:
Follow instructions for use. Manufacturer. European Authorized Representative.
Batch code. Catalog number. Serial number. Direct current.
Humidity limitation. Temperature limitation. Prescription only (In the US, Federal
law restricts these devices to sale by or on the order of a physician). European RoHS.
Protection against insertion of fingers and against vertically dripping water. Keep dry.
Fragile, handle with care. RCM certification. Canadian Standards Associations. Non-
ionising radiation. USB connector. Power indicator. Vent. Input (Ventilator Input)
indicator. Signal indicator. CE labelling in accordance with EC directive 93/42/EEC and
R&TTE Directive 1999/5/EC. Polarity of DC power connector. Indicates a warning or
caution. Medical device. Importer.
See symbols glossary at ResMed.com/symbols.
Environmental information
This device should be disposed of separately, not as unsorted municipal waste. To dispose of your
device, you should use appropriate collection, reuse and recycling systems available in your region.
The use of these collection, reuse and recycling systems is designed to reduce pressure on natural
resources and prevent hazardous substances from damaging the environment.
If you need information on these disposal systems, please contact your local waste administration.
The crossed-bin symbol invites you to use these disposal systems. If you require information on
collection and disposal of your ResMed device please contact your ResMed office, local distributor
or go to ResMed.com/environment.
Limited warranty
ResMed Pty Ltd (hereafter 'ResMed') warrants that your ResMed product shall be free from defects
in material and workmanship for a period of 12 months from the date of purchase by the initial
consumer. This warranty is not transferable.
If the product fails under conditions of normal use, ResMed will repair or replace, at its option, the

English 7
defective product or any of its components.
This Limited Warranty does not cover: a) any damage caused as a result of improper use, abuse,
modification or alteration of the product; b) repairs carried out by any service organization that has
not been expressly authorized by ResMed to perform such repairs; c) any damage or contamination
due to cigarette, pipe, cigar or other smoke; and d) any damage caused by water being spilled on or
into an electronic device.
Warranty is void on product sold, or resold, outside the region of original purchase.
Warranty claims on defective product must be made by the initial consumer at the point of
purchase.
This warranty replaces all other expressed or implied warranties, including any implied warranty of
merchantability or fitness for a particular purpose. Some regions or states do not allow limitations on
how long an implied warranty lasts, so the above limitation may not apply to you.
ResMed shall not be responsible for any incidental or consequential damages claimed to have
resulted from the sale, installation or use of any ResMed product. Some regions or states do not
allow the exclusion or limitation of incidental or consequential damages, so the above limitation may
not apply to you.
This warranty gives you specific legal rights, and you may also have other rights which vary from
region to region. For further information on your warranty rights, contact your local ResMed dealer
or ResMed office.
