RE224DT DSC®-to-2GIG® Wireless Translator™
Features
• Listens to DSC protocol wireless devices: DWS, PIR, Glass Break, ob, Panic.
• Transmits Honeywell protocol wireless (directly usable by 2GIG panels).
• No sensor enrollment required.
• All sensor alarm, supervisory and trouble signals are passed through.
• Main device has its own unique ID for supervisories, complete reporting
of main device tamper, external power supply fault and low battery.
• Dual antennas for both Receive and Transmit diversity for reliable range.
• Back-up battery protects during loss of external power.
Key Instructions
• WILL NOT HEAR OLD DSC 900MHz SENSORS such as: WLS907 WLS915
WLS914 WLS909 WLS929. Key hint is if old DSC system had the PC5132-900
PC5132-RS (900) or PC5349 (900 & 433) Receiver.
• External supply: 12V DC at least 50 mA. NON-SWITCHED outlet.
Wire polarity DOES NOT matter!
• Mount Translator at least 20 feet from Control Panel’s receiver.
• 3 AAA Alkaline batteries give 72 hours backup if external supply fails.
INSTALL BATTERIES ONLY WHEN EXTERNAL SUPPLY IS READY TO CONNECT.
• Enrolling:
 Power the Translator. It starts translating immediately.
Sensors are NOT enrolled in the Translator.
 To enroll any sensor:
• On panel go to ENTER R SENSOR SERIAL NUMBER.
• Press SHI T then LEARN.
• Trip the DSC sensor to enroll it in the panel.
 Enroll the Translator into a zone, because it sends check-in
supervisories, cover tamper and low battery messages.
• Sensor Type: (08) 24 Hour Aux Alarm
• Equipment Code: (0873) TAKE 345
• On panel go to ENTER R SENSOR SERIAL NUMBER.
• Press SHI T then LEARN.
• Trip Translator tamper switch to enroll it in panel
Loop 2 (although Loop # actually doesn’t matter)
Operation
• Existing DSC protocol sensors transmit as usual. Translator passes
information on to control panel as if they were 2GIG or Honeywell
transmitters.
• DSC ob buttons: Off/Home/Away/Panic
translate to 2GIG unctions: Disarm/Stay/Away/Aux
RE224DT_DSC-to-2GIG_Translator
Page 2 of 4 24-Hour Tech Support Line: [phone] 15-Oct-14
www.ResolutionProducts.com
• Translator Main Zone wireless transmission ( unique ID):
Tamper, when cover opened. Also sends restore.
Low battery, when low battery. Also sends restore.
Supervisory every hour. Supervisory stopped if 12V DC power absent.
• LED Operation
 Green LED
• On if 12V DC power present.
• Blinks on receipt of DSC-compatible packets.
 Red LED
• On if device low battery (unless there’s no 12V DC
power).
• Blinks on transmit of 2GIG-compatible packets.
• Application Diagram
 Because the Translator has two antennas, for both receive
and transmit diversity, it will generally have better range
than all sensors, and many panels (particularly those with
internal antennas).
 Place the Translator generally in the center of the all the
existing sensors it needs to hear. It will have no problem
reaching the control panel.
New 2GIG
System
New 2GIG or
Honeywell
Wireless
Sensors
Existing DSC
Wireless
Sensors

RE224DT_DSC-to-2GIG_Translator
Page 3 of 4 24-Hour Tech Support Line: [phone] 15-Oct-14
www.ResolutionProducts.com
Specifications
DSC Device Types: Hears and translates DWS, PIR, Glass Break,
ob, Panic.
Receiver and Transmitter: Listens to SAW and crystal transmitters. Talks
to SAW receivers.
Backup batteries: Three AAA Alkaline.
External supply: 8.5 to 13 VDC or 6-9 VAC
Standard: Resolution RE012: 12VDC, 50mA.
Optional: GE 60-898-ITI, for securing screw
Wire connection polarity DOESN’T matter!
Current draw with supply: 4mA, normal operation.
Power ail Conditions: 12V DC gone. Translator device ID
supervisories (including low battery reports)
are stopped during 12V DC loss.
Back-up Battery Life on 12V DC ail: 72 hours (cumulative).
Device Low Battery: When approximately 48 hours remain in back-up.
Housing dimensions: 4x6x1 inches
Specifications subject to change without notice.
Internal Picture
Power
Terminals
POLARITY DOESN’T MATTER
Tamper Switch & spring
Unused:
Device Type Indicator LEDs
and Enrollment button
Battery bucket for 3 AAA alkalines
Indicator LEDs & buzzer
2 Antennas for:
Dual Diversity Receive and
Dual Diversity Transmit
Note: Antennas mounted
on outer terminals
RE224DT_DSC-to-2GIG_Translator
Page 4 of 4 24-Hour Tech Support Line: [phone] 15-Oct-14
www.ResolutionProducts.com
Notices
“GE”, “Honeywell”, “2GIG” and “DSC” are trademarks owned by General Electric Com any,
Honeywell International Inc., 2GIG Technologies, Inc., and Tyco Safety Products Canada LTD,
res ectively.
Resolution Products, Inc. roducts will function with one of either GE, DSC, 2GIG or Honeywell
systems. However, no Resolution roduct is roduced by, endorsed by, nor is officially
associated with GE, Honeywell, 2GIG or DSC. Resolution recommends verifying ro er
enrollment and o eration, er control anel installation instructions, at installation.
Do not use Translator for life safety devices, such as smoke or CO sensors.
Patent Pending
Warranty
Resolution Products, Inc. will re lace roducts that are defective in their first five (5) years.
FCC Notice
This device com lies with Part 15 of the FCC rules. O eration is subject to the following
two conditions:
(1)This device may not cause harmful interference.
(2)This device must acce t any interference that may be received, including
interference that may cause undesired o eration.
Changes or modifications not ex ressly a roved by the Resolution Products, Inc. could
void the user's authority to o erate this equi ment.
FCC ID: U5X-RE224
IC Notice
This device com lies with Industry Canada license-exem t RSS standard(s). O eration is
subject to the following two conditions:
(1)This device may not cause interference, and
(2)This device must acce t any interference, including interference that may cause
undesired o eration of the device.
Le résent a areil est conforme aux CNR d'Industrie Canada a licables aux a areils
radio exem ts de licence. L'ex loitation est autorisée aux deux conditions suivantes:
(1)l'a areil ne doit as roduire de brouillage, et
(2)l'utilisateur de l'a areil doit acce ter tout brouillage radioélectrique subi,
même si le brouillage est susce tible d'en com romettre le fonctionnement.
IC: 8310A-RE224
Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and
maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio interference
to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated po er
(e.i.r.p.) is not more than that necessary for successful communication.
Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut fonctionner avec une
antenne d'un type et d'un gain maximal (ou inférieur) approuvé pour l'émetteur par Industrie Canada. Dans le but de
réduire les risques de brouillage radioélectrique à l'intention des autres utilisateurs, il faut choisir le type d'antenne
et son gain de sorte que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité nécessaire à
l'établissement d'une communication satisfaisante.
This radio transmitter (identify the device by certification number, or model number if Category II) has been
approved by Industry Canada to operate ith the antenna types listed belo ith the maximum permissible gain
and required antenna impedance for each antenna type indicated. Antenna types not included in this list, having a
gain greater than the maximum gain indicated for that type, are strictly prohibited for use ith this device.
Le présent émetteur radio (identifier le dispositif par son numéro de certification ou son numéro de modèle s'il fait
partie du matériel de catégorie I) a été approuvé par Industrie Canada pour fonctionner avec les types d'antenne
énumérés ci-dessous et ayant un gain admissible maximal et l'impédance requise pour chaque type d'antenne. Les
types d'antenne non inclus dans cette liste, ou dont le gain est supérieur au gain maximal indiqué, sont strictement
interdits pour l'exploitation de l'émetteur.
- Resolution-su lied 8.5" mono ole antenna
