Resolution Connect O2 RE610P+ User manual

Installation Guide
RE610P+ CryptiX™-Compatible PIR Motion,
T O 60-Pound-Dog-Immune
Features
•PYROFLEX™ IR sensor and HighBar™ signal processing or superior per ormance
•Unparalleled Pet Immunity and Catch per ormance
•44 oot range and 90 degree ield o view (45 degrees to each side)
•Mountable on Flat-wall or in corners
•Optional External Contact
•Cover tamper
•Strong, reliable RF signal
•6-8 year battery li e on CR123A battery
•Low Battery indication
Enrollment
•Place panel in enrollment mode.
•Sensor enrollment signal can be sent by one o the below two ways.
•Remove the battery tab.
•Tamper the device by removing the cover.
•To setup zone and con igure the sensor, log into the web based dealer
portal.
Installation
•Remove the cover o the enclosure by pressing the latch at the top o the
enclosure.
Cover latch
•Remove the PCB rom the bottom o the enclosure.
•Punch out the mounting holes
•Motion sensitivity selection
•Make sure bug foam is installed
•Mount at 7.5 oot height or optimum per ormance between: Catch
per ormance, Pet Immunity and False Alarm prevention.
Mounting holes
PCB latch Enclosure base
Bug foam
7.5 ft
10 ft 20 ft 30 ft 40 ft
0
56
56
56
40
Default: Normal Sensitivity
Jumper on BO H PINS
High Sensitivity
Jumper on ONLY 1 PIN
CONNECT O2

•Use #4 or #6 screws to mount the sensor in place
Optional External Contact
•Optional External contact wiring.
•Optional external contact zone is: normally closed – alarm on open.
•No end-o -line resistors on external contact.
Note: External contact not evaluated by ETL
Operation
•Motion sends wireless transmission a ter 2 or 3 pulses.
•Normal sensitivity (de ault): 3 pulses
•High sensitivity: 2 pulses
•Sensitivity set by the internal jumper block.
•Motion stops (locks out) transmitting ireless sensor alarms for 3 minutes after
sending an alarm transmission. This is to conserve battery li e.
•Tamper, when cover is opened.
•Supervisory signal sent every hour
•LED Walk Test: Press Tamper or 3 minute test:
•LED lights when motion sensed
•Sensor re-calibrates or 10 to 30 seconds a ter each LED blink.
It will not transmit during re-calibration.
So wait about 30 seconds be ore irst test, and 30 seconds between tests.
•Wireless transmissions sent or each detection, so walk test can be used or
panel operation test as well
Ceiling
Floor
Wall
Optio
nal external contact
terminals
Ceiling
Specifications
Specifications subject to change without notice.
Use this model for ALL pet situations.
RE020 Horizontal Beam Lens also available for unique situations.
Notices
Warranty
Resolution Products, Inc. will replace products that are defective in their first five (5) years.
FCC Notice
his device complies with Part 15 of the FCC rules. Operation is subject to the following two
conditions:
his device may not cause harmful interference.
his device must accept any interference that may be received, including interference
that may cause undesired operation.
Changes or modifications not expressly approved by the Resolution Products, Inc. could void
the user's authority to operate this equipment.
FCC ID: U5X-RE310
IC Notice
his device complies with Industry Canada license-exempt RSS standard(s). Operation is
subject to the following two conditions:
(1) his device may not cause interference, and
(2) his device must accept any interference, including interference that may
cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils
radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes :
(1)l'appareil ne doit pas produire de brouillage, et
(2)l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi,
même si le brouillage est susceptible d'en compromettre le fonctionnement.
IC: 8310A-RE310
Manual: 47-0005-08 Rev A
Wall
