Ress DP5 User manual

Manual
Leakage Tester DP5
RESS
The Producer
Visual Inspection Sweep Instruments Measuring Instruments

RESS Page 3
Leakage Tester DP5
Summary
1. Specification
- Differential pressure measuring channel
- Volume flow measuring channel
- Specifications
- Working with the device
2. Working with the device
2.1 Leak test
2.2 Device connections
2.3 Simpe 4/8 Pa-Test
2.4 Detailed 4/8 Pa-Test
2.5 Air supply test recording
2.6 Printout
2.7 N1-measurement (optional)
3. Troubleshooting
4. Language setting
5. Notification of fault
6. Working with the device
7. Declaration of conformity
Page 4
Page 5
Page 6
Page 7
Page 8
Page 9
Page 9
Page 10
Page 11
Page 11
Page 11
Page 12
Page 12

Page 4 RESS Leakage Tester DP5
1. Specification
Differential pressure - measuring channels:
Measuring range 1: 0 up to ±125 Pa
Resolution: 0,1 Pa
Measuring principal: silicon low pressure measuring cell
Accuracy: ±5% measured value
Measuring range 2: 0 up to 5000 Pa
Resolution: 1 Pa
Measuring principal: piezoresistive ceramic low pressure sensor
Accuracy: ±5% measured value
Volume flow - measuring channels:
Measuring range 1: 0,1 up to 10 NL/min
Measuring range 2: 0 up to 60 Nm³/h
Resolution: 0,01 NL/min
Measuring principle: Hot film anemometer
Accuracy: ±0,1 l/min in range 0,1 up to 1,00 l/min
±5 % measured value in range 1,00 up to 10,00 l/min
Technical data:
Power supply: Netzbetrieb 230 V, 50 Hz oder Akkubetrieb NiMH 3,2 Ah bei 24 V
Storage temperature: -20 bis +50 °C
Operating temperture: 5 bis 40 °C
Weight: 3800 g
Overall dimensions: ca. 22x31x8,5 cm
The Leakage Tester DP5 is also suitable for carrying out the 4/8 Pa-test, to check the negative
pressure limiting value, in a simple and detailed procedure (according to the DVGW worksheet
G 625 / 2010).
The device is TÜV tested and approved for: "Guidelines for suitability test of leak testing
devices and for checking exhaust gas systems operated under excess pressure".
The Leakage Tester DP5 measures the leakage rate of exhaust systems with over- and
underpressure. A test pressure of 40, 200, 1500 or 5000 Pa (class N1, P1, M1, H1) can be set
according to the pressure classes of EN 1443.
The Leakage Tester DP5 measures the volume flow, which is necessary to maintain the test
pressure.
Working with the device:
-
The Leakage Tester is also suitable for measurements on roofs. Prevent water from entering.
The device can be used by battery or electricity. Do not plug or unplug the power cord during
operation. Changing the voltage during operation will lead to measurement errors. The
following message will be displayed: "User information: malfunction / fault".

2. Working with the device
2.1 Leak test
Note:
on-/off switch
Before testing the leakage of exhaust gas systems, seal both ends with sealing bladders.
The device is switched on/off at the front panel. The main menu will appear. Selection via the
touch display. Now the test pressure can be selected.
Enter measurements of the pipe. It is possible to enter up to three different pipe sections.
if possible, measure from roof to prevent water from entering.
Hold the device horizontally, maximum 45° degrees in each direction. Then the sealing bladder
with the device hose can be connected to the measuring device.
Connecon for the
sealing bladder.
The plate must be
screwed ghtly!
RESS Page 5
Leakage Tester DP5

2.2 Device connections
measuring channel
for detailed
4/8 Pa-Test
switch for monitoring the
measuring channels
measuring channel
for leak test
on / off switch
power supply
Flattened connector
side up!
Pull plug sleeve backwards
to remove!
Hold
onto cable!
The plate must be
screwed tightly to
protect the device
during transportation!
pressure ports
charging account lamp
Infrared interface
+ -
USB interface
After selecting the pipe measurements, press "continue" to start the actual measurement. The
device will then self-test and calibrate. Then the measurement menu appears. After the test
pressure has been built up, the measurement will start over a period of 1 minute and finally
shows the result as an average value.
The volume flow is shown as I/min on the display, as well as the test pressure. In addition,
the leakage is given in percent. The maximum permissible leak rate is 100%.
Via menu item "print" the values can be printed wirelessly. The infrared printer (accessories)
must be held in front of the interface.
After the measurement the device can be switched off.
Page 6 RESS Leakage Tester DP5

2.3 Simple 4/8 Pa-Test
- Open an outside window or a door to the reference room and test proper operation of the
appliance. Ensure that there are no backdraft conditions.
- Select 4Pa-Test, device will calibrate
- Lead the hose outside: through a window seal, into the stairways, through the door rebate
or the keyhole (+installation room / -outside)
- Switch on appliance and all air conditioning (fan, dryer) with maximum power
- Start measurement
- Follow instructions on display: alternately open and close windows/doors
- The DP5 device records the measurement process over 4 minutes
After switching on the DP5 device, the measurement can be selected in the main menu. Before
the measurement, both capillary tubes and the front plate must be connected. The negative
pressure connection serves as a reference pressure and should be outside of the building. The
positive pressure connection remains in the installation room.
Before each measurement please make sure, that the battery has enough voltage. Do not plug
or unplug the power cord during operation! Changing the voltage during operation will lead to
measurement errors.
Hoses can be detached by pressing the blue discs.
Two measurements (each 4 minutes) will be carried out and the result displayed. A tip is issued
for the measurement result. Under "Graphics" a graphical history can be displayed.
Before the beginning of the measurement, the pressure curve is displayed and it will move to
the left hand side. The measurement can be saved as a PDF file.
RESS Page 7
Leakage Tester DP5

2.4. Detailed 4/8 Pa-Test
- Remove the connecting piece of the fireplace and connect the suction hose with a suitable
Sealing Element to the exhaust gas system.
- Open an outside window or a door to the reference room and test proper operation of the
appliance. Ensure that there are no backdraft conditions.
- Select 4Pa-Test, device will calibrate
- Lead the hose outside: through a window seal, into the stairways, through the door rebate
or the keyhole (+installation room / -outside)
- Switch on appliance and all air conditioning (fan, dryer) with maximum power
- Start measurement
- Follow instructions on display: alternately open and close windows/door
After switching on the DP5 device, the measurement can be selected in the main menu.
Please wait until calibration is completed. Then both capillary tubes must be connected to the
front plate. The negative pressure connection serves as a reference pressure and should be
outside of the building. The positive pressure connection remains in the installation room.
Hoses can be detached by pressing the blue discs.
The Detailed 4/8 PA-Test can be used as proof of adequacy air supply. The test measures the
differential pressure between the indoor and outdoor air. The device simulates a chimney and is
used as a controlled suction system.
In addition, the fuel throughput can be entered for fireplaces with solid fuels (for example:
Stoves - how many Kilograms of wood per hour). The air requirement is calculated from this.
Before measurement, the rated power of the system must be entered and when the
Temperature is below 0°C.
Before each measurement please make sure, that the battery has enough voltage. Do not plug
or unplug the power cord during operation! Changing the voltage during operation will lead to
measurement errors.
Page 8 RESS Leakage Tester DP5
Screw the suction hose
to the device
Capillary tubes

2.5. Air supply test recording
2.6. Printout
Two measurements (each 4 minutes) will be carried out and the result displayed. Before the
beginning of the measurement, the pressure curve is displayed and it will move to the left hand
side. Under "Graphics" a graphical history can be displayed.
The measurement can be printed or saved as a PDF file. A tip is issued for the measurement
result.
To transfer the files, the DP5 device must be connected to the computer via USB port. The USB
port is behind the plastic cover the front plate.
Via menu item "print" the values can be printed wirelessly. The printer (accessories; art.-no.
4007-C) must be placed with the IR-interface in front of the front plate of the DP5.
By pressing "save" a PDF file is created. A maximum of 10 measurements can be saved. The
oldest file will be overwritten. The numbering is continuous.
RESS Page 9
Leakage Tester DP5

on/off switch
Leakage test
Before starting a Leakage test, the chimney must be sealed with suitable sealing elements.
The hose with the connection plate must be screwed tightly onto the DP5.
Then plug the capillary hose into the "-" connection.
First pass the capillary hose through the sealing element and then through the tube. Important:
the capillary hose must be fixed minimum 5cm behind the hose end. Then insert the sealing
element into the stove connection piece or into the fireplace door.
Switch on the DP5. The measurement is started via the menu item "40 pa".
After entering the dimension, press "Next" to start the measurement. The device will self-test
and then calibrate. The measurement menu will appear. After the test pressure has been built
up, the measurement will start, duration approximately 1 minute, and finally show the result as
an average. The volume flow is shown with l/min in the display as well the test pressure.
The leakiness is shown in percent. The maximum still permissible leak rate corresponds to
100%.
plug for
capillary hose „-“
plug for hose
2.7 N1-measurement (optional)
Page 10 RESS Leakage Tester DP5

3. Troubleshooting / Maintenance / Service
5. Notification of fault
- Battery voltage too low, battery must be charged
- Pressure self-test error, pressure fluctuations too large
- Flow self-test error, defective flow sensor
- Temperature too high, let the device cool down
- Use power pack, battery voltage too low for measurement
- Pressure sensor 125 Pa, switch device off and on again
- Pressure sensor 5000 Pa, switch device off and on again
A bulge is not a defect or an impairment in functionality. This can occur due to the material.
4. Language setting
Go to the “Function Selection” main menu and press the “Setup” button. Press on “Language”
to select the desired language.
Do not inflate the bladder above the specified diameter, otherwise there is a risk of bursting.
They must not be pulled over sharp edges, otherwise there is a risk of damage.
It must be avoided that condensate from the exhaust pipe can enter the inside the device!
A special calibration Functional test for Leakage Tester must be used.
The flawless functioning of the device must be determined by a regular six-monthly
inspection.
Sealing bladders:
RESS Page 11
Leakage Tester DP5
Detailed 4/8 Pa-Measurements should be carried out with a power supply unit or the device
should be charged to at least 80%. When the battery is charged 100% it will be able to handle 2-3
measurements, depending on the amount of air movement.
When the power supply unit or the charger are connected, the Leakage Tester is still mainly
working in battery mode.When the battery, during a measurement, reaches a certain battery
voltage the device will automatically switch to main operation. The battery will then not be
charged!
The battery is only charged when the device is switched off. To do this, the battery/the charger
must have been disconnected from the device for at least 30 seconds.
A full battery charge takes approximately 3 hours.
Important: before each measurement, make sure that the battery has enough voltage. While
a measurement is in progress, the charger cannot be connected to the device. The
measurement would have to be repeated.

6. Working with the device
Manufacturer:
RESS GmbH & Co. KG
Am Hasselbruch 28
D-32107 Bad Salzuflen
declares that the product
Product: Leakage Tester
Model: RESS DP5
complies with the key safety requirements set down in the guidelines of the Council for the
Harmonization of the Legal Requirements of the Member States in relation to the electro-
magnetic compatibility 2014/30/EU and the low voltage 2014/35/EU.
The following standards were availed of to evaluate the product in respect of the electro-
magnetic compatibility:
EN 61326-1 (Chart 1 - Immunity - EMC requirement)
EN 55011, Unit 1, category A
EN 61000-3-2, EN 61000-3-3
Volker Buhr
Managing director
Bad Salzuflen, 07.01.2020
7. Declaration of Conformity
The Leakage Tester can lead to malfunctions when used in residential areas. T h e e l e c t r o -
magnetic radiation can interfere with the radio and television relay reception, unless special
measures are made to reduce the electromagnetic radiation.
SERVICE-Hotline: ++49 5208/9127-0
Page 12 RESS Leakage Tester DP5

RESS GmbH & Co. KG
Am Hasselbruch 28
D-32107 Bad Salzuflen
Tel. ++49 (0) 52 08 / 91 27 0
Fax ++49 (0) 52 08 / 80 30
[e-mail]
Internet-store: www.ress.de 19.11.2020
RESS
The Producer
Visual Inspection Sweep Instruments Measuring Instruments
