Retriev-R-Trainer Lucky Launcher II User manual

1. Assemble the ‘T’ portion of the stock onto the launcher. Refer to below
photo of location of handle. You MUST be sure that the handle is fully
seated and the silver depression tab is fully locked into the drilled hole
position. NEVER FIRE/LAUNCH WITH OUT SHOULDER STOCK
EXTENSION FULLY ASSEMBLED. Failure to properly assemble the
shoulder stock extension may result in serious injury or death.
2. Side the launcher dummy onto the launcher shaft
3. Open the breech by depressing the breech thumb latch and tip the shaft
assembly down to gain access to the chamber
4. Insert a Specialty Products/Vawter Ammunition .22 caliber blank
cartridge into the chamber. Make certain the cartridge is fully seated
5. Close the unit and press the thumb latch in to assure it is fully closed
6. Aim the unit in the direction you wish to fire the dummy. Place the
shoulder stock firmly on your hip, thigh or shoulder
7. Pull back the bolt to the locked position
8. The launcher is now ready to fire. Pull the trigger when ready
9. To remove the spent cartridge, depress the breech lock thumb latch and
tip the shaft assembly down to gain access to the extracted shell casing.
The extractor will not eject the shell but raise it enough to be easily
removed
10. Always remove the dummy from the barrel when not in use
BLANK POWER CHARGES
MAINTENANCE
Lucky Launcher INSTRUCTIONS
PLEASE READ CAREFULLY BEFORE ATTEMPTING TO OPERATE
_________________________________________________________________________
Choose your power charge based on the distance you wish to throw the dummy. Use
only those charges intended for the Lucky Line Launcher that are available at a certified
Retriev-R-Trainer retailer.
Light Green Load—Distance of approximately 150’
Medium Yellow Load—Distance of approximately 200’
Heavy Red Load—Distance of approximately 300’
DISCLAIMER
PREPARATION FOR FIRING
—
BARREL
-—
User must thoroughly clean the barrel, chamber, and hinge areas with a
good gun cleaning solvent after each use. Improper maintenance and
failure to properly and firmly position the stock of the RL Series Lucky
Line Launcher may result in serious injury or death.
You may purchase the RRT Cleaning Kit at any of our retailers listed on our website
www.RRTlauncher.com. A small amount of gun oil applied to the hinge area after
cleaning will help to insure smooth operation. Cleaning of the chamber can be enhanced
by using a .22 caliber wire brush.
Also, thoroughly clean and dry the inside of the dummy
tube after each launch, be certain that prior to each time
you launch the dummy from you launcher that it is free of
debris both internally and externally. Failure to properly
maintain the aluminum insert tube in your dummy may
result in serious injury or death. A rubber “O” Ring in a
grove near the outer end of the barrel provides a seal for the
release gases of the power charge. This “O: Ring will wear
causing some of the gases to escape, thereby reducing the
flight distance of the dummy. Apply a thin coat of Vaseline, or any other lubricant safe
for use on rubber components, to prevent drying and cracking of the o-ring. Replacement
“O” Rings are available from our retailers on our website.
Your Lucky Launcher is not a firearm, but the same handling, care ,
and safety precautions must be exercised. Your Lucky Launcher is pro-
vided with certain built-in safety features, but are not substitutes for
safe handling practices, which include the use of ear and eye protection
as well as the use of heavy leather gloves.
Any use or modification of the Lucky Launcher not in conformity with the
manufacturer’s instructions as described in this user’s manual is AT THE
SOLE RISK AND RESPONSIBILITY of the individual performing such
unauthorized use and/or modification. Direct any inquires regarding use to
Specialty Products Company prior to use or continued use of this product.
The Lucky Launcher is guaranteed for 3 years of the date of purchase to be free of manu-
facture defects. This guarantee is void if other than the recommended power charges are
used or if the product is not used in conformance with these instructions.
Dummies are guaranteed for a period of one year from the date of purchase to be free of
manufacture defects.
Please contact Specialty Products Company listed on the following page prior to sending
you launcher for repair. We will provide you with an estimate for repair and shipping
costs.
NON-WARRANTY REPAIRS—LAUNCHERS ONLY
WARRANTY
O-RING
‘T’ SHOULDER STOCK EXTENSION HANDLE
——-
—
THUMB LATCH
BREECH
—–—

TLB Industries, Inc.
292 Dunn Road, Honesdale, PA 18431 USA
570-729-7192 570-729-7193 (FAX)
Email: [email protected]
VISIT OUR WEBSITE FOR MORE GREAT PRODUCTS AND ACCESSORIES FOR
YOUR Lucky Launcher at
WWW.RRTLAUNCHER.COM
OPERATING INSTRUCTIONS
Please read BEFORE attempting to operate product!
AMERICAN MADE AND BACK BY A 3 YEAR WARRANTY
WARNING!
LUCKY LAUNCHER II
-NEVER insert a live load into the chamber
-NEVER use a load other than those specifically designed and recommended for use
in the Lucky Launcher II
-NEVER use a load heavier than #5 red heavy load. Heavy recoil should be expected
from all power charges
-NEVER aim or fire the launcher at anyone or anything
-NEVER use a dummy not specifically designed for use with a Lucky Launcher II
-NEVER cock the bolt until you are ready to fire
-NEVER use a dummy that has debris of any kind inside the tube, including but not
limited to, mud, grass, water or rust
-NEVER cock and fire the launcher without a cartridge in the chamber
-NEVER fire the launcher if the exhaust hole in the shaft is
obstructed in any way
-NEVER operate the launcher without proper ear, eye and hand protection
-NEVER place a load in the chamber before placing a dummy on the shaft
-NEVER store dummy on barrel of launcher when not is use
-NEVER allow the launcher to be accessible to children
WITH BODY PARTS OR WRAP AROUND A PERSONS NECK.
-NEVER DRY FIRE THE LAUNCHER WITHOUT A DUMMY AND POWER
CHARGE IN PLACE. DOING SO MAY DAMAGE THE PRODUCT AND
CAUSE CATASTROPHIC FAILURE WHEN FIRED IN THE FUTURE.
NEVER FIRE/LAUNCH WITH OUT SHOULD STOCK EXTENSION FULLY
ASSEMBLED.
THE LAUNCHER IS NOT A TOY AND SHOULD NOT BE TREATED AS SUCH!
THE LUCKY LAUNCHER IS NOT A LIFE SAVING DEVICE!
Failure to follow these warnings may result in serious
injury or death.
