Retro Roller AP 891 User manual

2
(891AP.003) x1
Instruction manual
Retro roller model
AP 891
Imported by Van der Meulen.
www.retroroller.eu
1
short
or
2
3
HARWARE SET COMPONENTS
No.
*891.8001
*891.8002
*891.8003
*891.8004
*891.8005
*891.8006
*891.8007
*891.8008
Qty
1
16
1
4
8
8
4
4
Description
Hexagon locknut
Hexagon locknut
Machine screw
Machine screw
Self tapping screw
Machine screw
Machine screw
Hub cap
Spec.
M4
Ø3/16”
M4x24mm
Ø3/16” x13mm
Ø4x11mm
Ø3/16” x10mm
Ø3/16” x16mm
Ø10mm
* Standard hardware items may be purchased locally.
(891AP.001) x1
HARDWARE
(891AP.002) x1
(891AP.004) x1
(891AP.005) x1 (891AP.006) x2
(891AP.007) x2 (891AP.008) x3
(891AP.009) x2 (891AP.010) x1
(891AP.011) x2 (891AP.012) x1
(891AP.013) x1 (891AP.014) x1
(891AP.015) x1
(891AP.8001) x1 (891AP.8002) x16 (891AP.8003) x1
(891AP.8004) x4 (891AP.8005) x8 (891AP.8006) x8
(891AP.8007) x4
(891AP.8008) x4
PLEASE NOTE! Assembly must be done by an adult.
Keep out of reach of young children because of the
small parts.
IMPORTANT:
1. For the child’s safety, all assembly steps must be carried
out properly. Incorrect assembly could cause injury.
2. Lubricate moving parts regularly or after long-term
use.
3. Ensure that all nuts and bolts have been tightened be-
fore use. Check nuts and bolts regularly and tighten where
necessary.
4. Components showing signs of wear should be replaced
immediately.
5. The child should never be left unattended when riding in
the vehicle.
Tools required:
Parts no x Qty (some parts may already have
been pre assembled upon receipt.

4
(891AP.8005) x8
short
5
(891AP.8008) x2

6
7
(891AP.8004) x4
(891AP.8006) x8
(891AP.8007) x4 (891AP.8002) x16
(891AP.8001) x1
(891AP.8003) x1
short
short

8
(891AP.8008) x2
Adult supervision is required! Please make certain that anyone who uses this vehicle has been fully instructed as to the
operations of the vehicle.
WARNING: This vehicle does not have a braking system. Do not ride on steep hills, staircases or on or near water. Never
use vehicle on rough terrain, for jumping or other stunts. No more then one child can be on the vehicle at any time (single
passenger only). Shoes and helmet should be worn at all times, to prevent injuries.
Suitable for children over 24 months.
© 2014
