RetroSound Model One Quick start guide

1M
Model One
Owner's & Installation Guide
Model One AM I FM Radio wi USB MP3 Playback
and Infinimount Shaft/Bracket System
Copyright ©2008 RetroSound USA
No text, illustrations
or format of this
manual in printed or electronic form
may be copied without written permission
from Retro Sound USA &Retro Manufacturing.
All Rights Reserved.
°Retro Manufacturing
13831 Roswell Ave, Unit #J
Chino, California 91710
Phone: [phone]
Fax: [phone]
www.retrosoundusa.com
Version 1.0
Jan 2008

1.
This equipment has been tested and found to comply with the limits for aClass Bdevice,
pursuant to Part 15
of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference
in aresidential installation. This equipment
generates, uses, and can radiate radio frequency energy, and, ifnot installed and used
in
accordance with instructions, may· c.ause harmful interference with radio
communications. However, there is no guarantee that radio
int~rference will not occur in
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can
be determined by turning the equipment off and on, the
useris encouraged to consultthe dealeror
an experienced radio/TVtechnician forhelp.
You are cautioned that any changes or modifications not expressly approved in this
manual could void yourauthorityto operatethis equipment.
Precautions "~>'
•Avoid installing the unit where it would be subject to high temperatures, such as in
direct sunlight or ahot air stream from the heater, or where it would be subject to dust,
dirt, or excessive vibration.
•Do not turn
on the unit if the temperature inside the car is very high. Always cool
down the unit before usage. Parking your car
in direct sunlight will result in a
temperature rise.
•Ifthe unit does not turn on, check the connections first. Then check whether the fuse
in your vehicle's fuse box is blown or check the fuse at the unit's wiring harness.
•Carefully read this manual before using the unit. If you encounter any problems that
are not covered
in this manual, please consult the dealer where you purchased the
unit or the dealer nearest
to you. You may also email us at:
[email protected]
Thank you for your purchase
of the Retrosound Model One Radio. We hope it will
provide you with years ofenjoyment, below are just some of the features that this
unit is capable of:
•LCD Display wi enhanced viewing angle &daylight compatible
•LCD Display shows MP3IWMAtrack names
•AM/FM PLL tuner
wi 30 presets
•60W x 4 (Integrated amplifier)
•2pr RCA pre amp outputs to add
an external amplifier
•Onboard CD Changer controller output (to control optional 10 Disc changer)
•Front mounted USB port, plug
in any USB flash drive and play MP3 IWMAIAAC files directly off the drive
•Patent Pending INFINIMOUNT adjustable shaft system
wi removable Universal bracket (included)
•Insulated bracket system and external shaft system reduces electrical noise inherent
in older vehicles
•Front Aux input, plug in any MP3 player or other portable device, (cell phone, etc)
•Full Function 18 key remote control
•Main unit
is remote mountable and comes with "un bracket for mounting under the seat or a'jlove box
•Optional external IR sensor
wi 94" cable, allows for easy remote operation via the included remote control
•Adjustable faceplate angle, allows mounting offaceplate display to virtually any dash

Page Number
Warning, Precautions &Welcome 1
Table
of Contents 2
Installation &Use Warnings 3
Location
of Controls 4-7
What's in the
box 8
Preparing
to Install your unit. 9-13
Model One
~pecifications &Dimensions 14
Using Your Unit 15-22
Setting the Clock 15
Turning the
unit on/off 15
Volume Adjustment 15
Selecting
your listening Source 15
Adjusting the Sound Properties 16
Special Modes
of Operation/Initial Setup 17
Selected Source Mode: Radio 18
Selected Source Mode: USB 18-20
Selected Source Mode: Optional
CD Changer 21
Selected Source Mode: Auxiliary Input 22
Limited Warranty 23

Installation &Use Warnin s ~r:~X ~~;
." ~~
3.
Observe the following warnings when using
this unit.
DThe
driver should neither watch the display nor
operate the system while driving.
Watching the display or operating the system will distract
the driver from looking ahead ofthe vehicle and can cause
accidents. Always stop the vehicle
in asafe location and use
the parking brake before watching the display or operating
the system.
DUse the
proper power supply.
This product is designed for operation with anegative
grounded
12 V DC battery system. Never operate this product
with other battery systems, especially a24 V
DC battery
system.
DKeep batteries and
insulation film out of reach of
infants.
Batteries and insulation film can
be ingested, so keep them
out ofthe reach of infants. If
an infant ingests abattery or
insulation film, please seek immediate medical attention.
DProtect the Deck Mechanism.
Do not insert any foreign objects into the slot ofthis unit.
DDo not disassemble or modify the unit.
Do not disassemble, modify the unit or attempt to repair the
product yourself. Ifthe product needs
to be repaired, consult
your dealer or
an authorized Panasonic Servicenter.
DDo not use the unit when it is out of order.
Ifthe unit
is out oforder (no power, no sound) or in an
abnormal state (has foreign objects in it, is exposed to
water,
is smoking, or smells)., turn it off immediately and
consult your dealer.
DThe remote
control unit should not lie about in the
car.
If the remote control unit lies about, it could fall on the floor
while driving, get wedged under the brake pedal, and lead to
atraffic accident.
DRefer fuse replacement
to qualified service personnel.
When the fuse blows out, eliminate the cause and have it
replaced with the fuse prescribed for this unit by aqualified
service engineer. Incorrect replacement of the fuse may lead
to smoke, fire, and damage to the product.
Observe the
following cautions when using this
unit.
DKeep the sound volume at an appropriate level.
Keep the volume level low enough to
be aware of road and
traffic conditions while driving.
DDo not insert or allow your hand or fingers to be
caught in the unit.
To prevent injury, do not get your hand or fingers caught in
moving parts or in the disc slot. Especially watch out for
infants.
Observe the
following cautions when installing.
~ Refer wiring and installation to qualified service
personnel.
Installation ofthis unit requires special skills and experience.
For maximum safety, have it installed
by your dealer.
Panasonic is not liable for any problems resulting from your
own installation ofthe unit.
Follow the instructions to install and wire the product.
Not following
the instructions to properly install and wire the
product could cause an accident or fire.
c.JTake care not to damage the leads.
When wiring, take care not to damage the leads. Prevent
them from getting caught in the vehicle chassis, screws, and
moving parts such as seat rails. Do not scratch, pull, bend or
twist the leads.
Do not run them near heat sources or place
heavy objects
on them. If leads must be run over sharp
metal edges, protect the leads by winding them with vinyl
tape or similar protection.
DUse the designated parts and
tools for installation.
Use the supplied or designated parts and appropriate tools
to install the product. The use
of parts other than those supplied
or designated may result
in internal damage to the unit.
Faulty installation may lead to an accident, amalfunction or
fire.
DDisconnect the lead from the negative (-) battery
terminal before installation.
Wiring and installation with the negative
(-) battery terminal
connected may cause electrical shock and injury due to a
short circuit.
Some cars equipped with the electrical safety system have
specific procedures ofbattery terminal disconnection.
FAILURE
TO FOLLOW THE PROCEDURE MAY LEAD TO THE
UNINTENDED ACTIVATION
OF THE ELECTRICAL SAFETY
SYSTEM RESULTING
IN DAMAGE TO THE VEHICLE AND
PERSONAL INJURY
OR DEATH.
DNever use safety-related
components for installation,
grounding, and other such functions.
Do not use safety-related vehicle components (fuel tank,
brake, suspension, steering wheel, pedals, airbag, etc.) for
wiring or fixing the product or its accessories.
Installing the
product on the air bag cover or in a
location where it interferes with airbag operation is
prohibited.
DCheck
for piping, gasoline tank, electric wiring, and
other items before installing the prodUCt.
If you need to open ahole
in the vehicle chassis to attach or
wire
the product, first check where the wire harness, gasoline
tank,
and electric wiring are located. Then open the hole
from outside if possible.
DNever install the
product in a location where it interferes
with your field of vision.
DNever have the
power cord branched to supply other
equipment with power.
DAfter installation and wiring, you should check the
normal operation
of other electrical equipment.
The continuation of their using
in abnormal conditions may
cause fire, electrical shock or atraffic accident.
Din the case of installation to an airbag equipped car,
confirm warnings and cautions of the vehicle manufacturer
before installation.
DMake sure the leads
do not interfere with driving or
getting in and out of the vehicle.
Dlnsulate all exposed wires to prevent short circuiting.
DThis unit is designed for use exclusively in automobiles.
DDo not operate the unit for a prolonged period with
the engine turned off.
Operating the audio system for along period of time with the
engine turned offwill drain the battery.
DDo not expose the unit to direct sunlight or excessive
heat.
Otherwise these will raise the interior temperature of the
unit, and it may lead to smoke, fire, or other damage to the
unit.
DDo not use the product where it is exposed to water,
moisture,
or dust.
Exposure of the unit to water, moisture, or dust may lead to
smoke, fire, or other damage to the unit. Make especially
sure that the unit does not get wet
in car washes or on rainy
days.

Please review this section for quick reference, as it contains information on the location of controls and
basic 0erations. For secific details on the articular 0eration, please look
in the table of contents.
OTurning The center Left Shaft left or right, controls the volume attenuation
up and down function.
Note: Volume range is 0-30, factory default
is set at 15.
~ Pressing the center Left shaft inward activates the SEL function, press this repeatedly to cycle
"~through the DSP EO, Bass, Treble, Balance &Fader Function(s).
~ Pressing the "1" button allows for selection of aradio preset or when aCD Changer is connected,
~ or adigital file is played in USB Mode, this becomes the play/pause button.
~ Pressing the "2" button allows for selection of aradio preset or when aCD Changer is connected,or
~ adigital file is played in USB Mode- pressing this button, the unit will play 10 seconds of each track
on the CD you have selected, Press again to cancel this function.
~ Pressing the "3" button allows for selection of aradio preset or when aCD Changer is connected,
Wor adigital file is played in USB Mode,pressing this button will allow you to repeatedly play the present
track.
~ Pressing the "4" button allows for selection of aradio preset or when a CD Changer is connected,
Wor adigital file is played in USB Mode,pressing this button will allow you to randomly play all tracks
on the current disc or track selected. .
6JJIJA Pressing the "5" button allows for selection of aradio preset or when aCD Changer is connected,
.. or adigital file is played in USB Mode,pressing this button will allow you to select the previous disc
in the changer's magazine. Note: The disc selected will not appear on the display until it loads the
selected disc.
In USB mode, this button allows you to play the first track ofthe previous folder.
~ Pressing the "6" button allows for selection of aradio preset or when aCD Changer is connected,
Wor adigital file is played in USB Mode,pressing this button will allow you to select the Next disc in
the changer's magazine. Note: The disc selecte<;l will not appear on the display until it loads the
selected disc.ln USB mode, this button allows you to play the first track of the Next folder.
~AUX Input, Allows for you to plug in any device with aheadphone 1/8"(3.5mm) output, (Example:
~ Walkman, CD Player, Tape recorder, Mp3 Player, etc) Use the MODE button to select the Aux In
mode.
~ POWER on/off Press the Right Center Knob to turn the unit on, Press and hold the Right center
'l!I knob for 2seconds to turn the unit off.
~ Turning the Right Center knob to the right &left allows you to tune to the next or previous am/fm
., frequency. When playing aCD( if aCD changer is attached), this center shaft will allow you to
change tracks up or down, also this shaft will allow you to change tracks when listening to mp3 /
wma files
on an attached USB flash drive.

5.
Please review this section for quick reference, as it contains information on the location of controls and
basic 0erations. For secific details
on the articular 0eration please look in the table of contents.
«0 T/F Button, Press this to view the clock, Note: when playing Mp3/WMAfiles from the attached USB
~ Drive, this function allows you to view the track, album, artist info (ld-3) information from these files.
~ MODE Function, Pre.ss this button to switch between all modes of operation, Radio/USB/AUX-
'lY In/CD Changer
~ BAND Function, Press this button to switch between 3 FM BANDS (FM 1/FM 2/ FM 3) 2AM
qv BANDS (AM-1 AM-2) 30 PRESETS TOTAL To save your preset, simply hold the preset button
down, listen for the confirming beep, preset will be then saved.
4D)IR RECEIVER: Point the included IR remote at this area to operate your unit remotely.
~ USB INPUT: This mini USB input allows you to connect (via the included mini USB to Female
~ standard USB adapter) any USB flash/thumb drive and when the unit is in USB mode, you can play
Mp3 &unprotected (no DRM) WMAlAAC files off ofthe USB drive!
46 Display Window
Included IR Remote
Control Legend •Press to turn
on unit, press ~ Press UP to increase Volume'
and hold to turn unit off W
APress MODE to cycle through
~ Press lEO to select preset DSP
~ Radio,Aux-in,CDC,USB modes ~ sound modes: Normal(Flat), Rock,
APress BAND to cycle through Pop, Classic
VAM/FM band (Fm-1-3, Am-1-2) ~ Press this in Radio mode to scan
8
~ stations/presets, in USB mode
~ Press 1to access preset in Radio use to change tracks, in CDC
mode,
in CDC mode, used to access Mode use to select CD Tracks
Play/Pause
APress 2to access preset in Radio ~ Press SEL repeatedly to cycle
Vmode, in CDC mode, used to access ~~ through the Bass, Treble,
10 second preview of CD Tracks Balance &Fader Function(s).
APress 3to access preset in Radio ~ Press this in Radio mode to scan
\9' mode, in CDC mode, used to access ~ stations/presets, in USB mode
10 second preview
of CD Tracks use to change tracks, in CDC
aPress 4to access preset in Radio ~ Mode use to select CD Tracks
.. mode, in CDC mode, used to access WJ Press this to MUTE Volume
RANDOM mode when playing CD
~
APress 5to access preset in Radio ~ Press DW/DN to decrease Volume
~ mode, in CDC mode, used to select ~ .
aprevious CD
in your CDC Magazine ~ ~ress DISP to VI~W clock, and wh~n
~ Press 6to access preset in Radio In USB mod~, ~hls allo~s you to .vlew
Vmode, in CDC mode, used to select mp3/WMA file Information (ID-3 Info)
the next CD in your CDC Magazine
trr Press A.PS to scan Radio Presets
~ and Radio stations (this will allow you
to hear 5seconds of the preset
on the
band group selected

Left Side View of Model One
This 4 pin molex connector is
for the Infinimount Shaft system,
one of these connectors is
located on each side of the
Model One Main Unit.
1/8" External #
IR Connector # #
(#"
~
~
~
~
~
~
~
~
Above is an optional 94" IR sensor that can be mounted in the dash of the car
if you want to totally hide the unit and operate it only from the remote control.

REAR View of Model One
Underdash "u" Bracket
(included)
--~
CD Changer
DIN Cable Port
(10
CD Changer is Optional)
Threaded mount for Metal backstrap (included)
Used
for Rear support of main body
4RCA Outputs
for adding on external
amplification
7.
Female ISO wire harness connector
w/1 Male Power/Ground harness
& 1 Male Speaker lead Harness

8.
What's in the box:
o(1) Retro Sound Model One unit
~ (1) Chrome Face Plate Adapter
~ (1) 18 key Remote Control (Includes CR2025 Battery/already installed)
o(2) Infinimount Brackets
~ (4) Chrome Radio knobs
<B (2) Infinimount Shaft System
o(1) Metal backstrap used to secure main unit behind dash
fD (2) ISO Wiring harness to connect to Model One
~ (1) Rubber Gasket Adapter
i) (1) "U" bracket for underdash / under seat installation
•(1) Mini USB to Female Standard USB cable
•
Rubber shaft covers
i) (mise) Screws, washers & parts to mount Infinimount Shafts & Brackets

1. Familiarize yourself with the Model One
Wiring harness (Note: There are 2plug connectors, designated
as
Plug "A" which contains the speaker leads &Plug "B" which contains
your power/ground connections) .
A-B
-
Side View of plug
L..- __ ~ (l) (2)
HOUSING: ISO TAB 16P
TERMIKAL: ISO REG
~ ~
~~ ~~
~~ ~~
~~ ~~
~~
~~
Plug #Color Function
of Plug lead
Al
Blue
( +) FR + speaker
A2
Blue/black
( - ) FR- speaker
A3
Gray (
+) RR+ speaker
A4
Gray/black
( -) RR- speale
A5
White
( +) RL+ speaker
A6
White/black ( -) RL-speaker
A7
Green ( +) FL+ speaker'
A8
Green/black
( -) FL- speaker
BI -
B2
-
B3
-
B4 Yellow
To +12V battery power
Terminal (for constant power)
85
Blue/white
(PowerAntenna Turn on lead)
B6
-
B7
Red
To Ace/Ignition switch lead
(if no ignition/ace lead. connect to +12V
B8
Black
GND To The metal surface of the car
or to - terminal on battery
Installation Notes:
To prevent damage to the unit,
do not connect the power
connector until you have
completed the wiring process
9.

2. Next: Assemble the Model One unit's Infinimount Bracket and shaft system
using the supplied screws and shaft nuts.
3. Find the Infinimount Shafts &Brackets (2 of each enclosed)
X2
4. Due to the flexibility of installation variations this system offers, in order
to match the Infinimount shaft & bracket system to the proper shaft width
of your vehicle, simply measure the distance between your existing shaft
holes center to center, then mount the shaft system to the bracket using
the suppled shaft nuts and shaft mounting guide and finger tighten to prepare
for the final installation (see figure Abelow). once you are sure of proper width,
then tighten prior to final installation, be sure to plug the shafts into the side of
the main unit to activate the shaft control functions (see figure Bbelow).
A.
( .......
.,~ -
Mount Shaft
to Bracket Plug Shaft into
Side of Main Unit
B.

11.
5. Next: Prepare (if needed) set your vehicle specific kit
(Optional 64-66 Mustang faceplate shown for this portion of the manual.)
6. Next: Once shafts are lined up to the shaft openings on the vehicle specific
faceplate adapter, use a
nut and washer to hold the faceplate in place on the
shafts
so the Model One's face is flush with the opening of the faceplate (see
photos below).
Use supplied Nuts &washers
to align faceplate onto shaft
Vehicle specific adapter &Model One
face should be flush
for professional appearance
~::::~~~.~:~: Optif)nal:
Ii 64-66 Mustang Faceplate shown above
Tighten shaft nuts and make sure that shaft depth works with
your dash configuration, the Retrosound Infinimount bracket system and shafts
are extremely adjustable and care
should be taken to ensure proper final fit
for the perfect installation.

7. The Retrosound Model One comes complete with a set of knobs and a
chrome faceplate adapter that fits over the main face, this configuration
out of the box will fit many American and European cars, please consult us at
[email protected] regarding a universal or vehicle specific face-
plate & knob kit for your car. Below is aRetro Model One shown with an
optional 67-68 Camaro faceplate & knobs.
Optional:
67-68 Camaro Faceplate
shown above
8. The Retrosound Model One also comes with an under dash bracket so you
can mount the unit under the dash or in a glove box, hidden away from view.
This hidden type of installation is important if you want to leave the original
radio in place, but enjoy the modern sound and features of the Retrosound
Model One system! Below is a photo showing the model One with the
Under dash bracket attached, please note that in this type of installation, due
to the fact that the included wireless remote duplicates all functions cf the unit
you DO NOT have to connect the shafts to operate the unit, as the included
remote will operate all functions. Also shown in the photo is an optional 94"
IR sensor that can be mounted in the dash of the car if you want to totally hide
the unit and operate it only from the remote control. .
Optional 94"
IR Remote Eye Cable
System

13.
9. NOTE: The following installation option is for advanced knowledgeable custom
installation specialists: The Retrosound Model
One faceplate is removable
to allow
for unique angled installations, canted angles, upside down mounting
and other unique configurations limited only
to your installation skills. Below
is aphoto illustrating what the unit looks like with the faceplate removed,
connected by cables from the body
of the main unit to the faceplate.
Model One wI
Advanced removable
Faceplate
for unique applications
10. After preparing for your installation and have figured out your installation
configuration, proceed to install the unit and connect the wiring, and make sure
you use the metal back strap to support the main body
of the the unit from the
rear.
Install Metal Backstrap behind
unit for rear support of the main body
•

SPECIFICATIONS:
Specs
Radio
Frequency
FM:
87.5 r--J 107.9MHz, AM:
530r--J 1710KHz
Sensitivity
10 dB
llV
Stereo Separation >30dB
Signal INoise ratio
>60dB
USB/CDC
Signal IN oise ratio >90dB
Stereo Separation
>50dB (1KHz)
Audio frequency
20Hz~20KHz
Distortion
~O.5%
LINE-OUT
Voltage Output
2000mV
Line-out impedence
10KQ
Main Unit
Power source
DC 10.5~16V
Max current <lOA
Stand-by current <lO.OmA
Max-power output
60 WX4(22 X4rms)
Speaker impedence
4Q
All Unit Specs Are Subject To Change without notice

•15.
Setting the Clock:
Press the rtF Button on the face of the unit when the unit is turned on.
Press and
hold the T/F button when tt)e clock is seen on screen blinking, turning the
volume control shaft right will adjust the minutes & turning it to the left will
adjust the hours. Note: Cycling through the 24 hour time period will allow
you to also selectAM or PM as well. Press the SEL button on the left control shaft
to confirm the clock setting.
Press and hold to activate
clock setting mode ..... ---- .....
'Ti'F
III
M'O'DE
nm
, ,r
1-0 ,
,-C'='
BAND
USB
AUX
1 ~I
21NT
3 RPT
4 ROM
5 T 6 A
--::rtF
.s<
'MOoE
r. rlr r
.- ,-:.
-I. -,
BAND
use
AU'
1 ~I
2INT 3
RPT 4 ROM
5..,
6.
Turning The Unit On/off:
Press the Right Center Knob to turn the unit on, look for "RETROSOUND" on power up.
Press and hold the Right center knob for 2 seconds to turn the unit off, the LCD display
will show "GOODBYE" for your confirmation.
Volume Adjustment:
Turning The center Left Shaft left or right, controls the volume attenuation up and down function.
Note: Volume range is 0-30, factory default is set at 15. Use the included remote to activate "mute"
function
Select Your Listening Source:
MODE Function, Press this button to switch between all modes of operation,
Radio/USB/AUX-ln/CD Changer (CDC)
Press MODE to switch between
modes of operation·-------
--::rtF
II'
t.1oD'E
,-r.,-
'_L"_
BANii
US8
"Vl(
1 ~I
2INT 3
RPT
4 ROM
5..,
6.

Adjusting the Sound Properties:
The Retrosound Model One has many sound adjustment modes to help you tailorthe radio to
your preference. To access these modes of adjustment, press the left knob (SEL) in and turn the
knob to the right
or left to adjust, then press SEL again to cycle through the choices
When you have completed
your adjustments, simply stop adjusting the mode and it will revert
back
to your current setting. Below are photos of the various sound adjustment modes available
in all playback modes, Radio, CDC,Aux, USB.
-riF tH
l.iOiiE nl-n nl-'-
_ '_I =11- '_1,- ,-
BAND J""
1... 2 'NT 3 APT 4RD. 5 Y 6 4
When you first acces the SEL menu,
DSP is off, turn the left shaft knob right
to cycle through the presets or press
SEL to move to the Bass &treble settings.
'TiF al
"iiO'D£ nnn
_ ,-,-,,-
BU.lD J~"
1... 2 INT 3 RPT 4 RO". .5" 6.
The POP DSP setting accentuates
the bass
and treble settings, this is
suitable for Bass heavy popular music.
T'i'f' •
MODE Tn,- .-'
- '-1- -,",-
llA"O "- - ,,<
1 ... 2 IN'" 3 RPT <I RD!I.' 5y 6.
The Treble adjustment function allows you to
boost or cut
the High frequencies from -7 to +7.
Press &hold
BAND button ....
to activate loudness
function
TiF t::
MODE C' OT
- "_II'
B'NO
...
",
1 ... 2 'NT 3 RPT 4 ROU 5 Y 6 4
The FLAT DSP setting offers
no bass ortreble adjustment.
-m (I
"iiCcE O'-l'-'L' '
_ ,,'_"_I I
8"'40 ,
..
I ... 2 'NT 3'" 4R1l. 5Y 64
The ROCK DSP setting accentuates
the treble settings, this is suitable
for Rock Music
"T"iF. .
l.iOiiE nn, II 1
~ onL "-1_ "
1 ... 2 INT 3 API 4 RON 5 Y 6 4
The Balance adjustment function allows you to
adjust
or Pan the stereo sound from the left or
right, this
is helpful to compensate for the
position ofthe driver in relation to the speaker
10cation.Adjustment range is 0-15.
l"iF ~~
'iiCOe Cl DC CI
_ 'I ~_I._I I
E14.~O u
1" 2iNl 3 RPT 4 ROM 5 .. 6 ..
-rif III
'"i;i'OOE ,-I OCCI,-
_ '_'_'1_'_'11_
BAND ""ct
1 ... 2 lHT 3 APT .. RD" 5" 6 ...
The CLASSIC DSP setting offers
sonic adjustments that lend themselves
to Classical Music.
-m fH
"iiO'D£ nn,- ,-'
_ nn-, -,- ,-
BANO - - - ~II:
1'" 2 'N1 3 RPT 4 ROM 5 Y 6 4
The Bass adjustment function allows you to
boostor cut the low frequencies from
-7 to +7.
T7F •
"iiO'D£ ,-nn ,- ,-,
IiAN!i ,- n L' ,- - " ..
1 ... 2lNT 3RPT 4 ROt.4 5" 64
The Fader Control allows you to fade the sound
from the front pair of speakers to your rear
pair of speakers. Adjustment range is 0-15.
To Activate the LOUDNESS function press and HOLD
the BAND Button to activate the Loudness function.
This function
allows you to have boosted bass &treble
at low listening volume and should be turned off
at higher volumes. You will know this function is active
when you see "LOUD" lit up on your display.

17.
Special Modes of Operation/Initial Setup:
To modify the audible confirmation Beep on or off (factory default is "BEEP ON"),
press and
hold the SEL (Left Knob) and turn the knob to the Right to turn the confirmation beep
off to "BEEP 2ND". See below for what the screens look like when the Changes are made.
-:riF :=
-UOriE rt r ,- l=t rt ,,'
"ii:Nii ClCCI- ,-'" "'"
'"'
---
t ... 2 INT 3 APT .. ROW 5 .. 6 ..
Beep Off
•
-vF flI:l
UciiiE Ct C C Ct :J "11-:
WiD '=' '- L , 1- I "_ ,.,
'.<
1... 2 INT 3RP'T 4 RDU 5. 6...
To modify the Initial volume level (factory default is 15),
press and hold the SEL (Left Knob) until you see "1- VOL" and turn the knob to the Right to select
the desired initial volume level (0-45 range) Press SEL to move on to the next selection.
See
below for what the screens look like when the Changes are made.
17F l:
i:iOOE •I Irt. 1r
BANi) '-VUL I:J .-
, ... 21N1 3R'T 4RDL4 5\" 66
The Retrosound Model One has the capability to receive FM brodcast frequencies in other
countries. To modify the default setting (USA) to EUR {Europe}, press and hold the SEL (Left Knob)
until you see "AREA USA" turn the knob to the Right to selectAREA USA or AREA EUR ,Then
press &HOLD the BAND Button on the
front of the unit to confirm the change, you will see EUR
display the change and the freqencies will work for Europe. Press SEL to move to the next function
or don't press anything and the menu will revert back to the current source display.
(Please note that USA
or EUR will be seen on the top of the display when in Radio mode to denote
the frequency selection you have made.)
TiF •
1iOiiE Cl Cl CCl •ICCl
WiD ' u,,_, I'-'_II t ,.
, ... 21~T 3RPT 4 ROLl 5'Y 6.
"T'iF EUII
i:iOOE 1:J Ct C Ct CI I Ct
WiD I U'I::.I I ,_,_", "
1.. 2 IHT 3 RPT 4 ROM 5'" 6 A

Selected Source: Radio
Once you've selected ~he Radio function, you can start storing your presets or tuning to
your preferred station.
Press "BAND" to
select FM1 ,2,3 or AM1,2 ----~~
for atotal of 30 Presetsf
l7F
m
MODE
r~ nr r
J- ,
~~.~
BAND
USB
AUX
_ .. ,- _...
1 ~I
21NT
3 RPT
4 ROM
5"-
6 A
To Save apreset, tune to the station using the right shaft knob then choose the preset number you
wish
to assign to that station, press and hold the button, listen for a confirming Beep and now
you have saved that preset. NOTE: turning the right shaft knob to the right or left will allow the
tuner
to select the next or previous strong station, this is known as the SEEK or "AUTO" function.
To manually tune, press the right shaft knob in and you will see "MANU" appear in the lower right
hand corner
of the screen(see photo below): this will allow you to manually tune into any station
you want,
strong or weak.
When a strong FM station
is selected the@
indicator will light up
...........,
T/r:
(II)
IU
1Aci'DE
r~
OC C
-
,- ,.=I..J•..J
BAND
IWIU ",SB
AUX
1 ~I
21NT
3 RPT
4 ROM
5..- 6A
Band Preset
Indicator(shows you the
Preset #you have assigned
to the preset button)
Indicator
showing Manual
tuning selected
Selected Source: USB
USB INPUT: The front mounted mini USB input allows you to connect
(via the included mini USB
to Female standard USB adapter) any USB flash/thumb drive,
when the
unit is in USB mode, you can play Mp3 &unprotected (no DRM) WMA files IAAC files
off of the USB drive!
Press "MODE" to
select USB MODE
~.I
CUSS Drivel
Connect USB Drive
to USB input by using
included Wired adapter.
USB MODE:
Once you've connected your flash drive to the mini USB input on the front of the unit, the Model
One will
find your songs instantly and automatically start playing them. To change Songs, use
the right shaft
knob and turn it to the right or left to access the next or previous song. Please note
that the
function buttons on the front of the faceplate will allow you to Play/pause, listen to 10
seconds of each song(INT) or repeat the track you're listening to (RPT) or randomly select from
all songs on the attached thumb/flash drive. NOTE:
The unit MUSTbe in USB mode for it to
read the USB files on
your flash/thumb drive, if your drive has alight, it should indicate that the
drive
is powered up by the Model One's USB port.

19.
Selected Source: USB (All About MP3 WMA &AAC files
MP3 (MPEG Audio Layer-3), WMA (Windows Media™ Audio), and Me (Advanced Audio Coding) is a
format for compressed audio files.
Common Facts about these compressed sound formats:
High bit rate and high sampling frequencies are recommended for high sound quality.
Selecting VBR (Variable Bit Rate)
is not recommended because playing time is not displayed properly
and there may be some audible skipping artifacts. The playback sound quality differs depending on
the encoding circumstances. For details, refer to the user manual
of your own encoding software.
Be sure to put an extension compatible with the format.
MP3 Notes:
It is recommended to set the bit rate to "128 kbps or more" and "fixed".
WMA Notes:
It is recommended to set the bit rate to "64 kbps or more" and "fixed". Do not set the copy protect
attribute
on the WMA file to enable this unit to play back.
AAe Notes:
It is recommended to set the bit rate to "128 kbps or more" and "Stereo". Files with the extension of
".m4a" encoded using iTunes version 6or later, are playable on this unit. Some of the files using other
encoders are not playable. Files encoded using Apple Lossless Encoder are not playable.
Files with copyright protection are not playable.
Caution! Except for private use, duplicating audio data (including MP3IWMAlAAC data) or distributing,
transferring
or copying it, whether for free for if it is paid for without permission of the original copyright
holderis strictlyprohibited by the Copyright
Act and international treaty.
Viewing the MP3IWMAlAAC Song information
When playing Mp3/WMA/MC files frQm the USB input, this function allows you to view the track name,
album, artist info (id-3) information from these files. Below are examples
of what you will view when
pressing the T/F button
in USB mode:
File Mode (Once selected, the track name will scroll accross the screen)
Press "T/F" to
View the currently played
song's 10 information
Artist, Album, etc
...
...- ..
CUSS Drivel
Connect USB Drive
to USB input by using
included Wired adapter.
File Mode (Once selected, the Song Title name will scroll accross the screen)
Press "T/F" t~
View the Song Title
Artist Mode (Once selected, the Track's Artist name will scroll accross the screen)
Press "T/F" t~
View the Artist Name
