Revo RBULRJCAM User manual

TITLE
SIZE REV.
SCALE
MATERIAL
UNLESS OTHERWISE SPECIFIED
ALL DIMENSIONS ARE IN MM.
- TOLERANCE
LABEL +/- 3
MANUAL +/- 5
GUIDE +/- 5
COLOR
DATE
DRAWN
CHKED
APPROVALS
PARTS LIST
DESCRIPTION/MATERIAL
ITEM QTY
A4
DO NOT SCALE
2
PRODUCTION RELEASE & REVISION
REV DESCRIPT'N/BUYER DWG No PARTS No. BY CHK DATE
A
MANUAL INSTRUCTION
5030xxxx
03-19-M8
A INITIAL ------------------- 5030xxxx A.K.HAN N.C.PARK 03-19-M8
NOTES
1.MODEL:
2.MATERIAL: ART PAPER
BIND : STAPLES-2
3.COLOR: TEXT- BLACK
4.SIZE: 105(+/-5)mm x 148(+/-5)mm
5.LABEL: 50201270(81mm x 24mm)
6.ANY CHANGE OR ALTERNATION MUST BE
APPROVED BY HITRON DESIGN TEAM.
WHITE
03-19-M8
105(+/-5)mm
148(+/-5)mm
MANUAL LABEL : 50201270
3
임우철
주임 03-19-M8
03-19-M8
520TV Lines
Super High Resolution Color Camera
INSTRUCTION MANUAL
Model: RBULRJCAM (Bullet)
RDOMRJCAM (Dome)
A.K.HAN
N.C.PARK
W.S.CHOI

520TV Lines
Super High Resolution Color Camera
INSTRUCTION MANUAL
Model: RBULRJCAM (Bullet)
RDOMRJCAM (Dome)

LIMITATION OF LIABILITY
THE INFORMATION IN THIS PUBLICATION IS BELIEVED TO BE ACCURATE IN
ALL RESPECTS, HOWEVER, WE CANNOT ASSUME RESPONSIBILITY FOR ANY
CONSEQUENCES RESULTING FROM THE USE THEREOF. THE INFORMATION
CONTAINED HEREIN IS SUBJECT TO CHANGE WITHOUT NOTICE. REVISIONS
OR NEW EDITIONS TO THIS PUBLICATION MAY BE ISSUED TO INCORPORATE
SUCH CHANGES.
ii

WARNINGS AND CAUTIONS:
CAUTION:
CAUTIONCAUTION
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER(OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
EXPLANATION OF GRAPHICAL SYMBOLS
The lightning flash with arrowhead symbol, within an equilateral triangle, is
intended to alert the user to the presence of uninsulated "dangerous voltage"
within the product's enclosure that may be of sufficient magnitude to constitute a
risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to
the presence of important operating and maintenance (servicing) instructions in the
literature accompanying the product.
Should any liquid or solid object fall into the cabinet,
unplug the unit and have it checked by the qualified
personnel before operating it any further.
Unplug the unit from the wall oulet if it is not going to
be used for several days or more. To disconnect the
cord, pull it out by the plug. Never pull the cord itself.
Allow adequate air circulation to prevent internal heat
build-up. Do not place the unit on surfaces (rugs,
blankets, etc.) or near materials(curtains, draperies)
that may block the ventilation holes.
Height and vertical linearity controls located at the
rear panel are for special adjustments by qualified
personnel only.
Do not install the unit in an extremely hot or
humid place or in a place subject to excessive
dust, mechanical vibration.
The unit is not designed to be waterproof.
Exposure to rain or water may damage the unit.
Clean the unit with a slightly damp soft cloth.
Use a mild household detergent. Never use
strong solvents such as thinner or benzine as
they might damage the finish of the unit.
Retain the original carton and packing
materials for safe transport of this unit in the
future.
Safety ----------------------------------------- Installation -----------------------------------
Cleaning --------------------------------------
PRECAUTIONS
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR
MOISTURE. DO NOT INSERT ANY METALLIC OBJECTS THROUGH THE VENTILATION GRILLS OR
OTHER OPENINGS ON THE EQUIPMENT.
iii

FCC INFORMATION : THIS EQUIPMENT HAS BEEN TESTED
AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS A DIGITAL
DEVICE, PURSUANT TO PART 15 OF THE FCC RULES. THESE
LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION
AGAINST HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS
OPERATED IN A COMMERCIAL ENVIRONMENT. THIS EQUIPMENT
GENERATES, USES, AND CAN RADIATE RADIO FREQUENCY
ENERGY AND IF NOT INSTALLED AND USED IN ACCORDANCE WITH
THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL INTERFERENCE
TO RADIO COMMUNICATIONS. OPERATION OF THIS EQUIPMENT IN
A RESIDENTIAL AREA IS LIKELY TO CAUSE HARMFUL
INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO
CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.
CAUTION : CHANGES OR MODIFICATIONS NOT EXPRESSLY
APPROVED BY THE PARTY RESPONSIBLE FOR COMPLIANCE
COULD VOID THE USER'S AUTHORITY TO OPERATE THE EQUIPMENT.
THIS CLASS A DIGITAL APPARATUS COMPLIES WITH CANADIAN
ICES-003.
NORME NMB-003 DU CANADA.
WARNING
This is a Class A product. In a domestic environment this product
may cause radio interference in which case the user may be required
to take adequate measures.
CE COMPLIANCE STATEMENT
FCC COMPLIANCE STATEMENT
iv

1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the
manufacturer's instructions.
8. Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers) that
product heat..
9. Do not defeat the safety purpose of the polarized or grounding-type
Plug. A polarized plug has two blades with one wider than the other.
A grounding type plug has two blades and a third grounding prong.
The wide blade or the third prong are provided for your safety. If the
provided plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point where
exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Unplug this apparatus during lightning storms or when unused for
long periods of time.
13. Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way, such
as power-supply cord or plug is damaged, liquid has been spilled or
objects have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally, or has been
dropped.
14. CAUTION - THESE SERVICING INSTRUCTIONS ARE FOR USE
BY QUALIFIED SERVICE PERSONNEL ONLY. TO REDUCE THE
RISK OF ELECTRIC SHOCK DO NOT PERFORM ANY SERVICING
OTHER THAN THAT CONTAINED IN THE OPERATING
INSTRUCTIONS UNLESS YOU ARE QUALIFIED TO DO SO.
15. Use Certified/Listed Class 2 power supply transformer only.
thy
IMPORTANT SAFEGUARDS
v

vi
INTRODUCTION
CAMERA CONNECTION
INSTALLING & ADJUSTING CAMERA MODULE
BASE INSTALLATION
TROUBLESHOOTING AND MAINTENANCE
SPECIFICATIONS
EXTERNAL DIMENSION
OPTIONAL ACCESSORIES
TABLE OF CONTENTS
1
2
3
4
5
6
7
8

1
The camera provides high-quality images using sharp CCD technology especially
designed for closed-circuit television (CCTV) and security surveillance
applications.
Features:
High resolution and high performance 1/3" Sharp CCD
Technology
Excellent picture quality
520 lines(Color) of resolution
1.0 lux(Color) @ F1.2 Sensitivity (Dome)
1.0 lux(Color) , 0 lux (BW at IR ON) @ F1.2 Sensitivity (Bullet)
Auto electronic shutter [1/60(1/50) ~ 1/100,000]
Auto trace white balance mode
BLC (Back Light Compensation)
AGC (Auto Gain Control)
Video Out (RJ12)
3.6
Operates in 12VDC (from DVR)
Camera Mount : camera mount directily to the wall or ceiling
mm Fixed Lens
INTRODUCTION

CAMERA CONNECTIONS
REMINDER:
Never aim the camera directly into the sun.
1. Lens : 3.6mm Fixed Lens for wide area monitoring.
2. Power Input / Video Output / Audio Output : 6pin Modular Connector.
Power source from DVR.
2
2
1
2
1

INSTALLING & ADJUSTING CAMERA MODULE
Use the following drawings to install the camera module to the housing.
3
Camera lens can be moved
horizontally or vertically and
freely swiveled any angle.
3-Axis Camera Construction
360
360
180
M2.6 X 5mm Tapping Screw

BASE INSTALLATION
Fasten Camera Fix screw(1X) and align the dome camera
with it like above picture.
Fasten Camera Fix Screws (2X) and align the bullet camera
with it like above picture.
1
Finally, lock dome window with locking screw(M3X20mm)
in a accessory kit.
2
4
M3X20mm Tapping Screws
Camera Fix Screw
M3X20mm Tapping Screws
Camera Fix Screw
Maximum recommended load is 1.5kg.(Bullet Camera)

5
PROBLEM CHECK
If you experience difficulties operating your camera, refer to the following. If the
guidelines do not enable you to solve the problem, contact an authorized
technician.
Nothing appears on
the screen.
Is the cable connected between the
camera and monitor?
Is there power to the monitor?
The image on the screen
is dim.
Is the lens dirty? If so, clean the lens
with a soft, clean cloth.
The contrast on the
screen is too weak.
Adjust the contrast feature of the monitor.
Is the camera exposed to strong light?
If so, change the camera position.
The image on the screen
flickers.
Does the camera face directly into the
sun or fluorescent lighting?
If so, reposition camera.
Following the preventive maintenance schedule allows detection and correction
of minor faults before they become serious and cause equipment failure.
Every three months, perform the following:
1. Inspect all connecting cables for deterioration or other damage.
2. Clean components with a clean damp cloth.
3. Verify that all the mounting hardware is secure.
PREVENTIVE MAINTENANCE
TROUBLESHOOTING

6
Power source
Power consumption
Image sensor
Total Pixels
Scanning system
Scanning frequency
Sync. system
Electronic shutter
Resolution
Min. illumination
IR LED / SENSOR
Power input
S/N Ratio
Lens mount
2:1 interlace
15.734KHz(H) x 59.94Hz(V)
Internal
1/60 ~ 1/100,000 sec.
520 TV lines
1.0 lux(Color), 0 lux(BW at IR ON)
@ F1.2, 50 IRE
f3.6mm Fixed mount
811(H) x 507(V)
RJ12
Fixed mount
RBULRJCAM
Max 3.0 Watts (IR LED ON)
811(H) x 507(V)
MODEL
LED Lighting Distance
Video Output
SPECIFICATIONS
Power
Lens
Connector
&
etc.
RDOMRJCAM
Video output
Operating Temperature
1.0 Vp-p (75 ohm, composite)
RJ12
General
Operating humidity 0 ~ 96% (non-condencing)
1/3" Color CCD
RJ12
Audio output
14 C ~ 122 C (-10 C~ +50 C)
F
u
n
c
t
i
o
n
Auto Exposure
White Balance
Gain Control
Gamma
BLC
Day & Night
External dimension
Weight
Max 1.5 Watts
1/3" Color CCD
2:1 interlace
15.734KHz(H) x 59.94Hz(V)
Internal
1/60 ~ 1/100,000 sec.
520 TV lines
1.0 lux(Color)
@ F1.2, 50 IRE
IR LED 12EA(850nm/30degree),
Sensor 1EA
-
Max 8m(Indoor)
-
1.0 Vp-p (75 ohm, composite)
more than 50dB(AGC off) more than 50dB(AGC off)
ON
AUTO
AUTO
0.45
ON
AUTO
f3.6mm Fixed mount
RJ12
Fixed mount
RJ12
0 ~ 96% (non-condencing)
RJ12
32 C ~ 104 C (0 C~ +40 C)
ON
AUTO
AUTO
0.45
ON
-
55.0(W) x 55.0(H) x 76.5(D) mm
360 g
Ø85.0(W) x 71.0(H)mm
(Bubble Diameter Ø72.0)
95 g

33
71
72
EXTERNAL DIMENSION
Dimensions
Unit: mm
85
7
55
55 88
75

The following accessories are available to add to your existing system
CAMERA
ADAPTOR CABLES
CAMERA
EXTENSION CABLES
OPTIONAL ACCESSORIES
8
<PRJBNCCOUP> <PRVPWRSUP>
<R60RJ12C, R100RJ12C,
R200RJ12C, R300RJ12C>
CAMERA
ADAPTOR

5030xxxxA
520TV Lines
Super High Resolution Color Camera
PRINTED IN KOREA
