Rexing PK2 User manual

User Manual
PK2 Projector
The information in this manual is subject to change without notice.
Rexing All Rights Reserved
www.rexingusa.com

We hope you love your new products as much as we do. If you need assistance, or
have any suggestions to improve it, please contact us.
Our support team will respond you as soon as possible.
Always a surprise in Rexing.
•https://www.facebook.com/rexingusa/
•https://www.instagram.com/rexingdashcam/
•https://www.rexingusa.com/support/registration/
Overview
Thank you for choosing REXING!
Check us out here.
Facebook Instagram Site Product Support
[email protected]
[phone]
1

User Manual
PK2 Projector
Theinformation in this manual is subject to change without notice.
RexingAll Rights Reserved
www.rexingusa.com
2
What's in the Box?
1. PK2 Projector
2. Remote Control
3. Power Cable
4. Tripod Stand
安全ガイド
www.rexingusa.com
Safety Guide
5. HDMI Cable
6. User Manual
7. Safety Guide
1
4 5 6 7
23

3
Product Overview
Air Outlet Lens
Infrared Signal
Receiving Windows
DC IN Power
Supply Interface HDMI Interface Audio Interface
USB 2.0
Interface
USB 2.0
Interface
DC IN
POWER
LED
BOOT
USB 1 HD IN USB 2

4
Power Supply
Focusing
OK
Left
Down
Focusing+
Home Button
Focusing-
Menu Button
Power Button
Return Button
OK Button
Return
Volume Down
Acoustic Pattern
3D
Mute
Up
Right
Homepage
Menu
Volume Up
Note:
1. Please keep the remote control aiming at the picture.
2. Please take out the battery if the remote control is not used for a long time.
Mouse Operations
The mouse (optional) can control the intelligent
projector conveniently.
1. Please keep the remote control aiming at the picture.
2. Please take out the battery if the remote control is not
used for a long time.

5
Turn On / Turn Off Device:
Turn on the device by long pressing the Power button on the projector. Choose to
turn off the device by pressing the Power button on the projector for once, or choose
to turn off the device by pressing the Power button on the remote control.
Basic Operations
Power Supply
Power Button

Focusing+
Focusing-
6
Focusing Method
Focusing for Remote Control Focusing for Buttons on Device
Focusing

7
Text Input
You can enter text through the keyboard on screen, which provides the layout similar
to the keyboard of a desktop computer. Some applications will automatically open
the soft keyboard, and you can choose to open the soft keyboard manually if you
www.google.com
Rexing projectors
Google
q
a
z x c v b
English (US)
n m
s d f g h j k l
w e r t y u i o p
Go
“
/
@
?123
1:00

8
Select a Language
Languages
Sound output
Language Typewriting Wallpaper Apps
System settings
General settings
Key tone Sound effect
Boot signal Device info System update Boot mode Restore factory
English
English
Japanese
French
German
Italian
Spanish

9
1. Please confirm your Windows System and PK2 Projector IP addresses are
connected to the same LAN
2. Use the following link to download and install:
http://cdn.sharemax.cn/app/EShareClient-STD.ex
3. Click Esharecent-STD, and the name and IP adress of the device will appear.
Click “Start Screen Transmission” to begin using the wireless screen.
Wireless Screen (Windows)
Display Operations
SELECT DEVICE:
EQUIPMENT NAME IP ADDRESS
EShare
EShare-7556 172.18.1.145
START SCREEN
EShare-3624 172.18.1.74

10
1. Connect your device to “Ding Talk”
2. Visit “http://172.18.1.74:8000” with web browser or scan the QR-code to download app.
3. Launch EShare and click “EShare-3624” to connect.
Live Bigger
Transform the way you control and engage with large-screen devices.

11
iPhone Airplay Mirror Operations
Supported by the following devices: iPhone 5 and above, iPad 2 and above, iPod
Touch (5th generation and above).
1. Connect your iPhone and projector to the same Wi-Fi network (5G first).
2. Click to open the projected Airplay, and then Eshare-**** will displayed in the
lower left corner.
3. Slide your finger from the bottom of the iPhone screen to the top, bringing up a
new menu, and the iPhone control center (Slide from the top down for iPhone X).
4. Click Airplay Mirroring and the device list will automatically search for the
projected devices within the same network.
Wi-Fi
Wi-Fi
WIFI
Search network...
Wi-Fi On
Ding Talk
Ding Talk
Wireless
Wireless
Wireless
Wireless
Wireless
OTHER NETWORS
MY NETWORKS
Wireless
Wireless
Wireless
Wireless
Wireless
90%
11:45

12
5. From the device list, click the name of the projected device you want to connect
(Eshare-****) to successfully cast the screen.
90%
11:45
Higth Shift: On
AirDrop
Receiving Off
AirPlay
Mirroring
EShare-2366
EShare-7556
1. Connect your device to “Ding Talk”
2. Visit “http://172.18.1.74:8000” with web browser or scan the QR-code to download app.
3. Launch EShare and click “EShare-7556” to connect.
Everything is Under Control
Use your phone as the wireless mouse, keyboard, touchpad, gamepad, remote control, air mouse and wireless camera

13
AirPlay Mirroring by Using Mobile Hot Spot
1. For use without having a LAN or Wi-Fi available, first turn on “Settings”--”Personal
Hot Spot”-- “Allow others to join” on the iPhone, select and turn on.
2. Click “Settings” of the projector-- turn on “Wi-Fi”, search for the hotspot name of
iPhone, and find and connect.
3. Swipe your iPhone from the bottom up and open the iPhone control center (Slide
from the top down for iPhone X).
4. Click “Airplay Mirroring” and the device list will automatically search for the
internal projection device in the same network.
5. From the device list, click the name of the projected device you want to connect
to (Eshare-****) to successfully cast the screen.
WIFI
Search network...
Wi-Fi On
iPhone
Wireless
Wireless
Wireless
Wireless
Personal Hotspot
Personal Hotspot
WLAN Password 13528792046
Now Discoverable
Other users can look for your shared network using WLAN and
Bleutooth under the name” ****IPhone”
TO CONNECT USING WLAN
1 Choose”****iPhone” from the WLAN settings on
your computer or other device.
2 Enter the password when prompted.
TO CONNECT USING WLAN
1 Choose”****iPhone” from the WLAN settings on
your computer or other device.
2 Enter the password when prompted.
TO CONNECT USING USB
1 Plug iPhone into computer.
2 Choose iPhone from the list of network services
in your settings.
Settings
90%
11:45

14
iPhone AirPlay Reverse Operations
1. Click to open the proected Airplay, then follow the prompts on the page to scan
the QR code of your iPhone, download and install the corresponding Eshare APP.
1. Connect your device to “Ding Talk”
2. Visit “http://172.18.1.145:8000” with web browser or scan the QR-code to download app.
3. Launch EShare and click “EShare-7556” to connect.
Live Bigger
Transform the way you control and engage with large-screen devices.
2. Open the Eshare APP on the mobile phone, and the device list will automatically
search for the internal projection device of the same network.
3. Click the projection device (Eshare-****), “one-click screen transmission” and
“Reverse screen transmission” will appear simultaneously.
4. Click “Reverse Screen Transmission”.
EShare-7556
EShare
90%
11:45
Synchronous Screen Display through Wireles Connection
(for Android Mobile Phone)
Course of Synchronous Screen Display for Android Mobile Phones with
Multi-Screen Interaction
1. The mobile phone and the projector must connect to a same Wi-Fi.
2. Click Setting>Screen Projection for Android>Click Scanning, Retention Interface.
One-click screen
transmission
Reverse Screen
Transmission
Photos Videos Documents Wireless
Camera
Smart Control

15
WIFI connections
System settings
Network settings
General settings
WIFI hotspots Wired network
Brightness mode Kestone Pojection mode Nonpolar zone Video mode
Bluetooyh Miracast
Miracast
click to discovery
Available devices
OPPO R15
MCast_b2eb Search

16
90% 11:45
3. Open “More Connection”/”Screen Projection for Mobile Phone” on the phone
(there are variety of models of Android mobile phone which may have different
names.
4. After of model of mobile phone searched trough the multi-screen interaction is
consistent with the model displayed in the “synchronous screen display of mobile
phone”, the mobile phone will be connected automatically (the projector cannot
be connected automatically), and then the synchtonous screen display can be
achieved after several second.
Miracast
click to discovery
Available devices
OPPO R15
MCast_b2eb Search
Mobile
More connections
NFC
Huawei Share
Easy Projection
Printing
VPN
Private DNS
Off
Off
Off
90% 11:45
Mobile
Easy Projection
Wireless projection
AVAILABLE DEVICES
MCast_802c
Support Desktop mode, Phone mode
DESKTOP-8C2NRM3
Support Desktop mode, Phone mode

17
Android with multi-screen interactive models with screen tutorial (Android phone)
•Connect to Wi-Fi and Set up Hotspot
•Select Wi-Fi that you are intended to connect and click “Finish” after entering the
password (the device will connect automatically to the Wi-Fi network selected in
last time within the available connection range)
•It can select the wireless hotspot to set the sharing hotspot network when
connecting to the cable network.
Wi-Fi Connect
Note:
It is recommend to use the built-in Android screen and Eshare android screen.
The voice cannot be transmitted (the system audio acquisition permmission
cannot be obtained).
WIFI connections
System settings
Network settings
General settings
WIFI hotspots Wired network
Brightness mode Kestone Pojection mode Nonpolar zone Video mode
Bluetooyh Miracast

18
Connect to a Bluetooth device (Homepage>Settings>Bluetooth>Open Bluetooth)
Bluetooth Connection
WIFI connection
Search network...
WIFI On
rongliang
Wireless
Wireless
Wireless
Wireless
WIFI connections
System settings
Network settings
General settings
WIFI hotspots Wired network
Brightness mode Kestone Pojection mode Nonpolar zone Video mode
Bluetooyh Miracast

19
Bluetooth
Available devices
ANDROID BT On
Aicare Y1
Aicare Y1
Aicare Y1
Aicare Y1
Aicare Y1
Search for devices
1. Homepage> Settings> System Settings> System Upgrade. WIFI must be kept
smooth and the power supply must be kept stable during the upgrade, otherwise,
the update will fail or the system will crash.
2. If there is no reaction by click during the upgrade, please click by switching to the
mouse model of remote control, and then the system will be downloaded and
upgraded automatically, wich only takes ten minutes.
3. When an error is displayed by clicking system upgrade, it proves that the current
version is the latest version and there is no need to upgrade.
Online Upgrade
Device Settings
