Rextron VCAMM-012 User manual

HDMI Audio Extractor
VCAMM-012
User's Manual
RoHS
PP5-RHAA12Z-000
Features and functions may be added or changed
after the manual was written. Please visit our
website to download the latest version of manual
for reference.
◘
◘
E NV
electronic components GmbH
M E D I A T E C H N O L O G Y
Maybachstrasse 39 Tel: [phone] www.evn-components.de
73037 Göppingen Fax: [phone] [e-mail]

Package Contents
Extractor Unit x 1
Power supply set
a. USB Power Cable x 1
b. Power Adapter x 1
User’s Manual x 1
Foot Pad Set x 1
You may also need:
Audio Cable / S/PDIF Cable
HDMI Cable
● Prior to installation, ensure to power off all devices that will be
connected to this system.
● Ensure that all devices you will connect are properly grounded.
machines that are likely to generate electrical noise.
Feature
●Allow to extract audio signals from HDMI source and converts HDMI
audio to digital optical or analog stereo.
● Intelligent EDID handling and processing ensures Plug and Play
operation
● HDCP Compliant and Blu-ray ready
● HDTV Compatibility
● Compliant with HDMI v1.3 , HDCP 1.2
● Supports up to 24bit digital audio
● Supports 3D signals
● Supports 8 / 10 / 12 bit deep color
moorecnerefnocroftaergeratahtsecruosoedivdnaoiduaehttcartxe
presentation, school and corporate training environments
● Multi-color LED Status indicates for easy troubleshooting and
monitoring
E NV
electronic components GmbH
M E D I A T E C H N O L O G Y
Maybachstrasse 39 Tel: [phone] www.evn-components.de
73037 Göppingen Fax: [phone] [e-mail]

Operation
LED indicator
Audio Selection Switch
This switch allows user to select the audio output from HDMI, analog or digital.
By switching the slide switch according to the printing from left to right 2ch,S/
PDIF and HDMI.
Audio
Selection Switch
EDID Audio
Partition
Audio Output Description
Analog HDMI S/PDIF
2ch 2ch Only Output Mute Output
S/PDIF Use Monitor
EDID Output Mute Output
HDMI Use Monitor
EDID Output Output Output
NOTE:Readjust Audio Selection Switch to other postion, the unit needs to
repower again.
LED indicator for output audio status
LED Monitor Detected HDCP
Emits Blue and goes off 3 times HDMI N/A
Emits Blue and goes off 2 times DVI N/A
Emits Purple and goes off 3 times HDMI Yes
Emits Purple and goes off 2 times DVI Yes
Green Power on
(Video signal absent)
Blue Video signal without HDCP
detected
Purple Video signal with HDCP
compliant
NOTE: If users encounter no screen display in computer connection, you may...
1.
2. Set your display device’s (TV, monitor, etc.) input source as HDMI.
3.
4. Connect your video source to the display DIRECTLY to check if the video
signal gets through.

Product Description
Vi HDMI Input Connect to the HDMI Source
S Audio Selection Switch Extract Audio Selection
Ao Audio Output Connect to the speaker
Vo HDMI Output Connect to the HDMI Display
To S/PDIF Output
L LED indicator Power / Status
DC in
Vo
Vi
S
L
ToAo

Connection Pattern
HDMI cable
HDMI Dispay with Audio Function
S/PDIF Audio Output
5.1/ 7.1 Speaker
Analog Audio Output

VCAMM-012
Input HDMI x 1
Output
HDMI x 1
Analog Stereo x 1
S/PDIF x 1
HDMI Audio Format PCM 2 / 5.1 / 7.1, Dolby 5.1, DTS 5.1,
D-TrueHD, DTS-HD
Slide Switch Audio Out 2ch , S/PDIF , HDMI
LED Indicator Power / System Status (Multi-Color)
Video Resolution (max.) Full HD 1080p (1920 x 1080)
HDMI TMDS Clock Rate (Max.) 225 MHz
Power Consumption DC 5V, 550mA
Dimensions H x W x D (mm) 20 x 85 x 58
Weight (g) 150

Installation
1. Adjust Audio Selection Switch to the proper postion.
2. Use a HDMI cable to connect the video source to the input port on the unit.
3. Use a HDMI cable to connect the display to the input port
on the unit.
4. Connect the speaker(s) to 3.5mm earphone jack and / or S/PDIF connector
the display and source devices.
NOTE:
(If the source device is computer)
The unit is required to connect to the computer before the computer is
powered on.

Limited Warranty
IN NO EVENTSHALL THE DIRECTVENDOR'S LIABILITY FOR DIRECTOR INDIRECT,
SPECIAL, INCIDENTIALOR CONSEQUENTIALDAMAGES, LOSS OF PROFIT, LOSS
OF BUSINESS, OR FINANCIALLOSS WHICH MAY BE CAUSED BY THE USE OF THE
PRODUCTEXCEEDS THE PRICE PAID FOR THE PRODUCT.
The direct vendor makes no warranty or representation, expressed or implied with respect to
the contents or use of this documentation,and especially disclaims its quality,performance,
The direct vendor also reserves the right to revise or update the product or documentation
without obligation to notify any user of such revisions or updates.For further information,
please contact your direct vendor.
All the brand names and registered trademarks are the property of their respective owners.
