RGB Technology PS25-4 Guide

TECHNICAL DOCUMENTATION
Price module PS25-4 with module PS25U in a mounting frame
Product code:
302-13-02
*Explanatory figure

2 DTR_302-13-02-001_EN_d
Table of contents
1 Manufacturer ..................................................................................................................................................................... 3
2 Specifications......................................................................................................................................................................3
3 Transport and storage ........................................................................................................................................................3
4 Device construction ............................................................................................................................................................3
5 Mounting the device ..........................................................................................................................................................4
5.1 Price module PS25-4..................................................................................................................................................4
5.1.1 Dimensions of price module PS25-4 .................................................................................................................4
5.1.2 Dimensions of mounting frame RAM-001 ........................................................................................................4
5.1.3 Installation of price modules.............................................................................................................................5
5.1.4 Diagram of electric connections PS25-4, option with 10 price modules............................................................... 6
5.1.5 Cable connections in the controller box ...........................................................................................................6
6 PYLON controller ................................................................................................................................................................ 6
7 LED module automatic brightness control .........................................................................................................................7
8 Power supply unit...............................................................................................................................................................7
9 Initial start-up .....................................................................................................................................................................7
10 Disposal and recycling ........................................................................................................................................................7
10.1 Recycling of packing materials...................................................................................................................................7
10.2 Disposal of the device................................................................................................................................................7
11 Most common errors during the installation .....................................................................................................................7

DTR_302-13-02-001_EN_d 3
1Manufacturer
RGB Technology Sp. z o. o.

76-
POLAND
2Specifications
Price module PS25-4 (3 modules PS25 + module PS25U)
Dimensions of the device 1[mm]:
899 x 278 x 28.5
Digit height:
25cm
Power supply:

Device operation temperature (ambient):
-
Device operation temperature (device surface)
-
Average power consumption of the device:
18W
Casing tightness rating2IP:
67
Weight:
6.5kg
3Transport and storage
Care should be taken to properly protect the devices so as to eliminate any damage during transport. It is forbidden to
transport the devices in a collective package without adequate amortisation - each device must be packed
separately and cannot have freedom of movement during transportation.
Due to the protective packing the module should be stored in the temperature not lower than -  

4Device construction
The figure shows price module PS25-43.
det. A power supply unit; det. B mounting frame; det. C LED module PS25U; det. D LED modules PS25; det. E junction box
Fig. 1
1Dimension without a mounting frame.
2Specified on the basis of EN 60529.
3Explanatory figure.

4 DTR_302-13-02-001_EN_d
5Mounting the device
NOTICE!
Before any installation or maintenance operations you should refer to the manual supplied by the
manufacturer. Improper connection to the mains power supply, incautious device installation, or improper use
may cause property damage, loss of health or death from electrical shock! In addition, any failure to follow the
may void your warranty.
NOTICE!
Keep in mind that all the components should be mounted with the leads facing down.
NOTICE!
It is forbidden to make any additional mounting points or any holes in the device assembly components.
5.1 Price module PS25-4
The PS25-4 device is composed of three LED modules PS25, one LED module PS25U, power supply unit ZR-50
and a junction box, which are mounted on the mounting frame. All the components form one price module
PS25-4.
5.1.1 Dimensions of price module PS25-4
All the dimensions shown in the drawings are given in [mm].
Fig. 2
5.1.2 Dimensions of mounting frame RAM-001
Fig. 3

DTR_302-13-02-001_EN_d 5
5.1.3 Installation of price modules
To facilitate the installation, each price module PS25-4 has its number (Fig. 4). The number of a price module
facilitates quick mounting of the module in the price pylon. The number consists of a digit denoting the price
line (where 1 denotes the highest price line) and a letter denoting the side of the pylon.
Fig. 4
Price pylon with price modules PS25-4 (Fig. 5)4.
Fig. 5
A price pylon may include maximum 6 prices on each side, and each price module may be composed of
maximum 6 digits. Each single LED module PS25 has a dot in the bottom right-hand corner (Fig. 6). Due to the
fact that a dot appears in each LED module, it may be edited from the software level to appear in any LED
module. Module PS25U Upper index (Fig. 7) has no dot, because it appears as the last.
Fig. 6
Fig. 7
4Explanatory figure.

6 DTR_302-13-02-001_EN_d
5.1.4 Diagram of electric connections PS25-4, option with 10 price modules
Legend:
1A,1B.... price module numbers,
S controller,
Red -1- 3 x length 5m (core markings: blue, brown, yellow-and-green) power cord to
supply power to the price modules and the S controller,
Red -230V- power supply 230V,
Blue -2- length 5m (core markings: white, green) signal cables connecting the price
modules with the controller,
Dark blue -3-  length 2m (core markings: black, red) lighting sensor input,
Dark blue -4- 3 x 0.2length 5m (core markings: black, red, orange) input signal lead (RS485)
Fig. 8
5.1.5 Cable connections in the controller box
Fig. 9
6PYLON controller
The controller is a unit responsible for displaying the set content by the LED modules. The unit has 3 ports, and
each of them is able to serve up to 4 price modules. The detailed description of the PYLON controller can be
found in the DTR manual of the number in conformity with the catalogue index number of the controller.

DTR_302-13-02-001_EN_d 7
7LED module automatic brightness control
In the standard version, a lighting sensor is included (Fig. 10). The controller, in response to the intensity of
daylight, adjusts the brightness of the price pylon LED modules. To make the sensor function properly, you
should locate it in a place where daylight is present. Pay special attention to whether another source of light is
not directed onto the sensor, as it can interfere with the reading of the sensor. A detailed description of the
sensor is available in DTR of the sensor.
Fig. 10
8Power supply unit
Each price module has an individual power supply which is mounted on dedicated frame. Detailed description of
the power supply is available in the power supply DTR.
9Initial start-up
Step 1: Make sure that all the price modules are properly located in the pylon (see point 5.1.4, Fig. 7),
Step 2: Make sure that all the price modules have been installed in the correct orientation (leads down),
Step 3: Connect the modules and the controller to the 230V power source,
Step 4: If properly connected, the system should display random digits on the LED modules until the user changes
the displayed content.
10 Disposal and recycling
10.1 Recycling of packing materials
The packaging materials must be segregated , then recycled in accordance with local regulations for
waste disposal regulations.
10.2 Disposal of the device
The device can not be disposed with regular household waste!
According to Directive 2002 / 96 / EC ( WEEE ) , when repair is not economically reasonable, user is
obligated to hand over damaged or destroyed device to an appropriate disposal facility .
11 Most common errors during the installation
1. Boxes mounted contrary to the manual, e.g. with leads up,
2. LED modules installed contrary to the diagram, eg. exchanged sequence of the price module addresses.
3. Drilling additional mounting holes or holes in junction boxes.
4. Connecting the signal anode and cathode (white and green cores) to two different ports of the controller.
5. Connecting improper cores in the WAGO connectors (eg. connecting the white and green cores of the
signal cable to the same WAGO connector)
