Veeder-Root TLS-350 Series User manual

Manual No: 577013-776 l Revision: F
TCP/IP Interface Module
Installation Guide

Notice
Veeder-Root makes no warranty of any kind with regard to this publication, including, but not limited to, the implied warranties of
merchantability and fitness for a particular purpose.
Veeder-Root shall not be liable for errors contained herein or for incidental or consequential damages
in connection with the furnishing, performance, or use of this publication.
Veeder-Root reserves the right to change system options or features, or the information contained in this publication.
This publication contains proprietary information which is protected by copyright. All rights reserved. No part of this publication
may be photocopied, reproduced, or translated to another language without the prior written consent of Veeder-Root.
Contact Red Jacket Technical Support for additional troubleshooting information at 800-323-1799.
DAMAGE GOODS/LOST EQUIPMENT
Thoroughly examine all components and units as soon as they are received. If any cartons are damaged or missing, write a
complete and detailed description of the damage or shortage on the face of the freight bill. The carrier's agent must verify the
inspection and sign the description. Refuse only the damaged product, not the entire shipment.
VR must be notified of any damages and/or shortages within 30 days of receipt of the shipment, as stated in our Terms and
Conditions.
VEEDER-ROOT’S PREFERRED CARRIER
1. Fax Bill of Lading to V/R Customer Service at 800-234-5350.
2. Call V/R Customer Service at 800-873-3313 with the specific part numbers and quantities that were received damaged or
lost.
3. VR will file the claim with the carrier and replace the damaged/missing product at no charge to the customer. Customer
Service will work with production facility to have the replacement product shipped as soon as possible.
CUSTOMER’S PREFERRED CARRIER
1. Customer files claim with carrier.
2. Customer may submit a replacement purchase order. Customer Service will work with production facility to have the
replacement product shipped as soon as possible.
3. If “lost” equipment is delivered at a later date and is not needed, VR will allow a Return to Stock without a restocking fee.
4. VR will NOT be responsible for any compensation when a customer chooses their own carrier.
RETURN SHIPPING
For the parts return procedure, please follow the instructions in the “General Returned Goods Policy” pages of the “Policies and
Literature” section of the Veeder-Root North American Red Jacket Mechanical Products Price Book. Veeder-Root will not accept
any return product without a Return Goods Authorization (RGA) number clearly printed on the outside of the package.
RESPONSIBILITIES OF THE INSTALLER AND STATION OWNER
This installation, operation and service instruction manual shall be left with the owner of the service station at which this equipment
is installed. Retain these instructions for future use and provide them to persons servicing or removing this equipment.
ã Veeder-Root 2021. All rights reserved.

Table of Contents
iii
Introduction
General .............................................................................................................................1
TCP/IP Interface Requirements ........................................................................................1
TCP/IP Kits .......................................................................................................................1
Contractor Certification Requirements ..............................................................................1
Related Manuals ...............................................................................................................2
Safety Precautions ............................................................................................................2
TCP/IP Interface Module Installation
Verifying TCP/IP Interface Module Configuration .............................................................3
Installing the TCP/IP Interface Module in the Console .....................................................4
TLS-300/ProPlus Consoles ......................................................................................4
TLS-350/ProMax Series Consoles ...........................................................................6
TLS Console Setup of the TCP/IP Interface Module ........................................................8
Connect a PC or Laptop to the TCP/IP Interface Module .................................................9
Connecting to the TCP/IP Interface Module Over a Network .................................10
Connecting to the TCP/IP Interface Module Directly ..............................................11
TCP/IP Module IP Address/Configuration Using Telnet
Overview .........................................................................................................................15
Entering the TCP/IP Interface Module’s IP Address .......................................................16
After Network Setup of The TCP/IP Module...........................................................22
Appendix A - TCP/IP Configuration Check List
TCP/IP Card IP Address/Configuration Check List ....................................................... A-1
TCP/IP TLS Setup Check List ...................................................................................... A-2
Figures
Figure 1. TCP/IP interface module component locations .......................................4
Figure 2. TLS-300/ProPlus console battery backup switch location ......................5
Figure 3. Installing TCP/IP module into TLS-300/ProPlus console ........................6
Figure 4. TLS-350/ProMax Series console battery backup switch location ...........6
Figure 5. TLS-350/ProMax Series TCP/IP module installation ..............................7
Figure 6. Installing TCP/IP Module in TLS-350/ProMax Comm Bay Slot 4 ...........8
Figure 7. Network connection ..............................................................................10
Figure 8. Locating network connection/activity LEDs ..........................................10
Figure 9. Direct connect using ethernet crossover cable .....................................11
Figure 10. Network Screen ....................................................................................12
Figure 11. Select Network and Sharing Center .....................................................12
Figure 12. Select Local Area Connection ..............................................................12
Figure 13. Select Properties ..................................................................................13
Figure 14. Select Internet Protocol Version 4 (TCP/IPv4) .....................................13
Figure 15. IP Address/Subnet Mask Entry Example ..............................................14
Figure 16. Telnet Menu Screen .............................................................................18

Table of Contents
iv
Tables
Table 1. Comm Setup Selections - S-SAT board type &
V15 - V20 console software ......................................................................9
Table 2. Comm Setup Selections - S-SAT board type &
V21 & later console software .....................................................................9
Table 3. Network Connection/Activity LED Codes (ref. view in Figure 8) .............10
Table 4. Telnet Setup Menu Settings (Consoles with V15 - 20 Software) ............19
Table 5. Netmasks / # Bits for Host Part ...............................................................20
Table 6. Telnet Setup Menu Settings (Consoles with V21 & Later Software) .......21

1
Introduction
General
This manual contains procedures to install a TCP/IP Interface Module into the following consoles:
• Veeder-Root TLS-3XX consoles
• Red Jacket ProPlus and ProMax consoles
If this is a new installation or if site preparation is necessary, refer to the console’s Site Preparation and Installation
manual, or contact your Veeder-Root representative for assistance.
TCP/IP Interface Requirements
Minimum system requirements for TCP/IP Interface Module operation are listed below:
• Console system software: Version 15 or higher - Version 21 or higher is recommended.
• Network connection to a PC requires a hub. Connecting to a hub requires a straight CAT 5 cable.
•Direct connection to a laptop requires an ethernet crossover cable.
• Connection to a LAN or WAN.
• Knowledge of networking.
TCP/IP Kits
• TLS-300/ProPlus console kit (P/N 330020-424):
- Installation Guide (P/N 577013-776)
• TLS-350/ProMax console kit (P/N 330020-425):
- Installation guide (P/N 577013-776)
3330020-424 includes the screws. 330020-425 includes the wiring harness.
Contractor Certification Requirements
Service Technician Certification (Previously known as Level 2/3): Contractors holding valid Technician
Certifications are approved to perform installation checkout, startup, programming and operations training, system
tests, troubleshooting and servicing for all Veeder-Root Series Tank Monitoring Systems, including Line Leak
Detection.
TLS-3xx Technician Certification: Contractors holding valid TLS-350 Technician Certifications are approved to
perform installation checkout, startup, programming and operations training, troubleshooting and servicing for all
Veeder-Root TLS-300 or TLS-350 Series Tank Monitoring Systems, including Line Leak Detection and associated
accessories.
All service personal on site must comply with all recommended safety practices identified by OSHA and your
employer.
Review and comply with all the safety warnings in this and any related documents, and any other Federal, State or
Local requirements.
Warranty Registrations may only be submitted by selected Distributors.

Introduction Related Manuals
2
Related Manuals
576013-623 TLS-3XX/ProPlus/ProMax Series System Setup manual
576013-879 TLS-3XX/ProPlus/ProMax Series consoles Site Prep and Installation Guide
Safety Precautions
The following safety symbols are used throughout this manual to alert you to important safety hazards and
precautions
EXPLOSIVE
Fuels and their vapors are extremely explosive if
ignited.
ELECTRICITY
High voltage exists in, and is supplied to, the device.
A potential shock hazard exists.
TURN POWER OFF
Live power to a device creates a potential shock
hazard. Turn Off power to the device and asso-
ciated accessories when servicing the unit.
READ ALL RELATED MANUALS
Knowledge of all related procedures before you begin
work is important. Read and understand all manuals
thoroughly. If you do not understand a procedure, ask
someone who does.
WARNING
Heed the adjacent instructions to avoid equip-
ment damage or personal injury.
WARNING
You are working with a device in which potentially lethal voltages may be
present.
Death or injury may result if safety precautions are not followed.
1. Read all instructions and warnings.

3
TCP/IP Interface Module Installation
Installation of the TCP/IP Interface module consists of:
1. Verifying the module’s configuration (Complete the checklist in Appendix A at this time),
2. Installing the module in the TLS-300 console (page 4) or the TLS-350 console (page 6),
3. Performing setup of the module in the TLS (page 8), and
4. Setting up the module’s IP Address/Configuration using either Telnet (page 15) or a browser (page 23).
Verifying TCP/IP Interface Module Configuration
Key components of the TCP/IP Interface module are shown in Figure 1.
IMPORTANT! Write down the ethernet address from the label on the back of the TCP/IP
board. You will need to enter this number for the TCP/IP board’s hardware address in the
module’s IP Address/Configuration procedure later in this manual (also record the rev of the
board as it may also be needed).

TCP/IP Interface Module Installation Installing the TCP/IP Interface Module in the Console
4
Installing the TCP/IP Interface Module in the Console
TLS-300/PROPLUS CONSOLES
1. Open the left door of the console (see Figure 2). Verify that the battery backup switch is in the On position,
then turn Off power to the console.
2. Remove knockout blank from left bottom of console. Slide in the configured TCP/IP Interface Module until the
motherboard connector is snugly seated and the left edge of the module’s bracket is in the notch cutout in the
left side of the console. Attach securing screw from kit (see Figure 3). Leave the console door open.
Figure 1. TCP/IP interface module component locations
Legend for numbered boxes in Figure 1
1. End plate for TLS-300/ProPlus console TCP/IP module.
2. RJ-45 Connector (typical both end plates)
3. Reset button access (typical both plates)
4. End plate for TLS-350/ProMax console TCP/IP module
5. Network connection/activity LEDs (typical both end plates)
6. J1 Connector
7
. J2 Jumper - Interrupt
8. J3 Jumper - Chip Select
9. Write down the ethernet address from the label on the LTRX XPort module (in this example, 00-20-4A-82-54-CD). You
will need this address for the TCP/IP module setup.
10. Also record the rev number (in this example A11). It may be needed for the TCP/IP module setup.

TCP/IP Interface Module Installation Installing the TCP/IP Interface Module in the Console
5
Legend for numbered boxes
in Figure 2
1. Battery backup switch (S1)
shown in ‘On’ position (to
left)
2. Remove knockout blank to
install TCP/IP module.
3. Connector for TCP/IP
module
Figure 2. TLS-300/ProPlus console battery backup switch location

TCP/IP Interface Module Installation Installing the TCP/IP Interface Module in the Console
6
TLS-350/PROMAX SERIES CONSOLES
1. Open the left door of the console. Verify that the battery backup switch (SW1) is in the ‘On’ position (see
Figure 4), then turn off power to the console.
Legend for numbered boxes
in Figure 3
1. TX (red)
2. RX (green)
3. Bracket secured in notch
4. Remove blank in console
base for access to module's
plug-in connector
5. #4-40 x 0.312” taptite
screw - T-10 Torx drive
6. Module bracket
7. Module plugs into male
connector on motherboard
Figure 3. Installing TCP/IP module into TLS-300/ProPlus console
Legend for numbered
box in Figure 4
1. Battery backup switch
(S1) shown in ‘On’
position (up).
Figure 4. TLS-350/ProMax Series console battery backup switch location

TCP/IP Interface Module Installation Installing the TCP/IP Interface Module in the Console
7
2. Installing the TCP/IP module in slots 1 - 3 (Preferred Location)
The TCP/IP module can be installed in any empty slot of the Comm bay card cage, but the module’s default
settings require that it be installed in slots 1 - 3.
If your console has a snap connector which secures the cover plate in the card cage, pull it out and lift out the
cover plate. If your console has “knockout” cover plates, open the printer door and insert a flat blade screw
driver in the slot provided in the front of the cover plate you are removing and twist it to break the front set of
metal securing tabs (ref item 2 in Figure 5). Once the front tabs are broken, carefully move the loosened end
of the plate up and down until the rear set of securing tabs break. Remove and discard the cover plate. Slide
the module into the open slot until the motherboard connector is snugly seated. Do not apply excessive force
when installing the module. With your thumb, push in the black retaining fastener on the end plate until it
snaps into the hole in the card cage.
3. Installing the TCP/IP module in slot 4 (Alternate Location)
If slots 1 - 3 are in use, or if you want to free up slots 1 - 3 for other modules, the TCP/IP module can be in-
stalled in slot 4. To use slot 4, you must move jumpers J2 and J3 on the module onto the 2 top pins, and con-
nect the cable from the kit (P/N 330020-425) to connector J1 on the TCP/IP module and to connector J6 on
the console’s ECPU board (see Figure 6).
If the TCP/IP module is installed in slot 4, the displayed slot number (X) will be 5.
4. Verify that the RJ-45 plug in the module’s bracket is accessible through the slot opening in the bottom of the
console.
Legend for numbered
boxes in Figure 5
1. Comm bay card cage
2. Comm slot cover plate
3. Module slots 1 - 4
4. 24-pin board connector on
TCP/IP module
Figure 5. TLS-350/ProMax Series TCP/IP module installation

TCP/IP Interface Module Installation TLS Console Setup of the TCP/IP Interface Module
8
5. When you are finished, make sure any unused slots in the Comm cage have a blank end plate installed. Leave
the console door open.
TLS Console Setup of the TCP/IP Interface Module
1. Close and secure the console front door. Restore power to the console.
2. You will need to know what version software is installed in the console to properly setup the TCP/IP module.
Press the front panel MODE key to access Diag Mode. Press FUNCTION key to access System Diagnostic:
Press the STEP key to view the software revision level:
Where YY equals the console’s installed software. For example, if the version is 123.02, the software version
is 23.
Legend for numbered
boxes in Figure 6
1. J2/J3 jumper positions if
installing TCP/IP module
in slots 1-3 (default
positions)
2. Move jumpers J2/J3 onto 2
top pins if installing TCP/
IP module in slot 4
3. J1 connector
4. Interconnecting cable from
the kit (P/N 330020-425)
5. J6 on ECPU board
Figure 6. Installing TCP/IP Module in TLS-350/ProMax Comm Bay Slot 4
SYSTEM DIAGNOSTIC
PRESS <STEP> TO CONTINUE
SOFTWARE REVISION LEVEL
VERSION XYY.XX

TCP/IP Interface Module Installation Connect a PC or Laptop to the TCP/IP Interface Module
9
3. Press the front panel MODE key to access the Setup Mode. Press the FUNCTION key to access
Communications Setup.
4. In Communications Setup, press STEP until you see Port Settings, then press ENTER to display the
message::
If necessary, press the TANK/SENSOR key until you see the message above, where X = the slot number in
which you installed the TCP/IP Interface Module, and Type = S-SAT.
For TLS-350/ProMax consoles only - if the TCP/IP module was installed in slot 4 of the
Comm Bay card cage, the displayed slot number (X) will be 5.
5. Depending on displayed board type (S-SAT) and the console’s installed software revision level, select the
Comm board setup parameters shown in Table 1 or Table 2 as applicable.
Connect a PC or Laptop to the TCP/IP Interface Module
There are two ways you can connect a PC to the module:
• Over a network (LAN, WAN), or
• Directly (requires a crossover cable)
Table 1. Comm Setup Selections - S-SAT board type & V15 - V20 console software
Comm Setup Parameter Setting
Baud Rate 9600
Parity NONE
Stop Bit 1 STOP
Data Length 8 DATA
RS-232 END OF MESSAGE DISABLED
Table 2. Comm Setup Selections - S-SAT board type & V21 & later console software
Comm Setup Parameter Setting
Baud Rate 9600
Parity NONE
Stop Bit 1 STOP
Data Length 8 DATA
Code (security) DISABLED
DTR NORMAL STATE HIGH
RS-232 END OF MESSAGE DISABLED
COMM BOARD: X (Type)
BAUD RATE: 1200

TCP/IP Interface Module Installation Connect a PC or Laptop to the TCP/IP Interface Module
10
CONNECTING TO THE TCP/IP INTERFACE MODULE OVER A NETWORK
1. Connect the desktop or laptop to the TCP/IP Interface Module as shown in Figure 7. Insert the RJ-45 plug of
the network CAT 5 cable into the RJ-45 connector in the end plate of the TCP/IP module.
2. Locate the 2 LEDs on the top edge of the RJ-45 connector on the module’s end plate (see Figure 8).
3. Depending on network connection speed, the left or right LED on the top edge of the RJ-45 connector should
remain ‘On’ when a proper connection is made (ref. Table 3).
Legend For Numbered Boxes
In Figure 7
1. PC
2. Plugs into PC Ethernet card
3. Ethernet cable
4. Hub
5. Do not use uplink connector
6. Tank Gauge
7
. Plugs into RJ45 connector in
end plate of TCP/IP module
8. Ethernet cable
Figure 7. Network connection
Legend for numbered box in
Figure 8
1. Network connection/
activity LEDs
Figure 8. Locating network connection/activity LEDs
Table 3. Network Connection/Activity LED Codes (ref. view in Figure 8)
Left LED Right LED Meaning
Off Off No link
Off Solid amber 100Base-T half-duplex link
Off Blinking amber 100Base-T half-duplex; activity
Off Solid green 100Base-T full-duplex link

TCP/IP Interface Module Installation Connect a PC or Laptop to the TCP/IP Interface Module
11
4. After confirming a successful link between the PC and the TCP/IP module, proceed to the either the IP
Address/Configuration section using Telnet or using a browser as desired.
CONNECTING TO THE TCP/IP INTERFACE MODULE DIRECTLY
1. Connect the laptop to the TCP/IP Interface Module as shown in Figure 9. Insert the RJ-45 plug of the ethernet
crossover cable into the RJ-45 connector in the end plate of the TCP/IP Interface Module.
Important! you must use an ethernet crossover cable.
2. Locate the 2 LEDs on the top edge of the RJ-45 connector on the module’s end plate (see Figure 8 on
page 10).
3. Depending on the network card installed in the laptop, the left or right LEDs on the top edge of the RJ-45
connector should remain ‘On’ when a proper connection is made as shown in Table 3.
4. Before entering the TCP/IP Interface Module’s IP Address enter a static IP Address in your connected laptop.
IP Address setup procedures for both Windows 7 and 10 are discussed in this section.
Setting Your PC’s IP Address for Direct Connect (Windows 7 and 10)
1. Connect your laptop to the TCP/IP card as shown in Figure 9 above. Go to your laptop’s Control Panel folder
and select Network and Internet to display the Network screen (Figure 10):
Off Blinking green 100Base-T full-duplex; activity
Solid amber Off 10Base-T half-duplex link
Blinking amber Off 10Base-T half-duplex; activity
Solid green Off 10Base-T full-duplex; link
Blinking green Off 10Base-T full-duplex; activity
Legend For Numbered Boxes In
Figure 9
1. Plugs into RJ45 Ethernet
Adaptor in Laptop
2. Laptop
3. You MUST use an Ethernet
crossover cable!
4. Plugs into RJ45 connector in
end plate of TCP/IP module
5. Tank Gauge
Figure 9. Direct connect using ethernet crossover cable
Table 3. Network Connection/Activity LED Codes (ref. view in Figure 8)
Left LED Right LED Meaning

TCP/IP Interface Module Installation Connect a PC or Laptop to the TCP/IP Interface Module
12
Figure 10. Network Screen
2. Select Network and Sharing Center (Figure 11):
Figure 11. Select Network and Sharing Center
3. Select Local Area Connection (Figure 12):
Windows 10 computers display Ethernet instead of Local Area Connection
Figure 12. Select Local Area Connection


TCP/IP Interface Module Installation Connect a PC or Laptop to the TCP/IP Interface Module
13
4. Select Properties (Figure 13):
Figure 13. Select Properties
5. Select Internet Protocol Version 4 (TCP/IPv4): (Figure 14).
Figure 14. Select Internet Protocol Version 4 (TCP/IPv4)


TCP/IP Interface Module Installation Connect a PC or Laptop to the TCP/IP Interface Module
14
6. Click the Use the following IP Address radio button and enter an IP Address and Subnet. Use an IP address
that is one digit off from the customer supplied IP Address that will be assigned to the console’s TCP/IP
Interface Module.
For example, if the IP Address for the TCP/IP module is 10.2.1.51, enter 10.2.1.50 for the laptop’s IP
Address. For the subnet mask, use 255.255.255.0, as shown in Figure 15. Leave the Default Gateway blank.
Figure 15. IP Address/Subnet Mask Entry Example
Prior to reconnecting your laptop to a network, select the Obtain an IP address automatically
radio button.
7. You are now ready to enter the TCP/IP Interface Module’s IP Address.
8. Proceed to the Section entitled ’TCP/IP Module IP Address/Configuration Using Telnet’ on page 15.


15
TCP/IP Module IP Address/Configuration Using Telnet
Overview
Telnet and ARP are utilities available in Windows operating systems and are used in the TCP/IP addressing
procedure:
Telnet - Telnet is a terminal emulation program for TCP/IP networks such as the Internet. The Telnet program runs
on your computer and connects your PC to a server on the network. You can then enter commands through the
Telnet program and they will be executed as if you were entering them directly on the server console. This enables
you to control the server and communicate with other servers on the network.
ARP - ARP is a TCP/IP protocol used to convert an IP address into a physical address (called a DLC address),
such as an Ethernet address. A host wishing to obtain a physical address broadcasts an ARP request onto the
TCP/IP network. The host on the network that has the IP address in the request then replies with its physical
hardware address. ARP will only work when the console and PC share the same subnet.
Port Number - This setting represents the source port number in TCP connections. It is the number that identifies
the channel for remotely initiating connections. The range of permissable port numbers is 1 - 65535, except for the
following reserved port numbers:
Do not use any of the reserved port numbers on any version of the TCP/IP board.
In addition to the IP address configuration instructions provided in this manual, it may also
be possible to use the Lantronix device installer found in the Lantronix website
(www.lantronix.com) to configure your TCP/IP module’s IP address.
Reserved Port Numbers
1 - 1024
9999
14000-14009
30704
30718

TCP/IP Module IP Address/Configuration Using Telnet Entering the TCP/IP Interface Module’s IP Address
16
Entering the TCP/IP Interface Module’s IP Address
1. On new computers, Telnet must be manually turned before the TCP/IP Interface Module can be configured. If
Telnet has already been activated, continued to step 2.
a.Go to your laptop’s Control Panel folder and select Programs:
b.Select Turn Windows features on or off:

