Rhopoint Instruments NG Flex 60 User manual

Thank you for purchasing this Rhopoint product.
Please read these instructions carefully before operating this product and retain them for
future reference.
The images shown in this manual are for illustrative purposes only.
English
Operating Instructions

1
This instruction manual contains important information about the setup and use of
your Rhopoint NG Flex 60. It is essential that the contents be read before powering
up and operating the instrument.
If this instrument is passed to other users, you must ensure that the instruction
manual is supplied with the instrument. If you have any questions or require additional
information about the Rhopoint NG Flex 60 please contact the Rhopoint Authorised
Distributor for your region.
The technology and components used in the device are based on state-of-the-art
optics and electronics. As part of Rhopoint Instruments’ commitment to continually
improve the technologies used in their products, they reserve the right to change
information included in this document without prior notice.
© Copyright 2016 Rhopoint Instruments Ltd. All Rights Reserved.
Rhopoint Novo-Gloss™ and Rhopoint™ are registered trademarks of Rhopoint
Instruments Ltd. in the UK and other countries.
Other product and company names mentioned herein may be trademarks of their
respective owner.
No portion of the software, documentation or other accompanying materials may be
translated, modified, reproduced, copied or otherwise duplicated (with the exception
of a backup copy), or distributed to a third party, without prior written authorization
from Rhopoint Instruments Ltd.
Rhopoint Instruments Ltd.
Enviro 21 Business Park
Queensway Avenue South
St Leonards on Sea
TN38 9AG UK
Tel: [phone]
Fax: [phone]
Email: [email protected]
Website: www.rhopointinstruments.com
Revision A
April 2016

2
Contents
Storage and Handling 3
Accessories 5
Functional Overview 6
Power 7
Switching on the unit 7
Operation 8
Menu Screen 11
Batching Options 12
Setup Screen 13
Calibration Screen 15
Calibrating the Novo-Gloss Flex 60 16
Measurement Screen 18
Pass/Fail Setup Screen 19
Control Screen 20
Bluetooth Communication and Pairing 20
Instrument Setup Screen 26
Maintenance Screen 27
Technical Specification 29

3
Storage and Handling
This instrument contains precision optics and electronics. You should avoid
knocking or dropping the device as the resulting impact could cause serious
damage.
In some circumstances the optical components in the instrument could
become misted as a consequence of temperature change. It is recommended
that the instrument is not used until it has stabilised to the ambient
temperature.
Ensure that the instrument is not exposed to moisture, chemicals or any
corrosive vapours.
Do not interfere or place any objects inside the measuring aperture as damage
to the measuring system could occur.
The instrument housing and screen are resistant to a variety of solvents
however it is not possible to guarantee resistance to all chemicals, therefore
the surfaces of the instrument should only be cleaned using a soft, moist cloth.
Prevent exposure of the instrument to direct sunlightfor prolonged periods and
to continuous humidity and condensation.

4
About the Rhopoint NG Flex 60
The Rhopoint NG Flex 60 is used to quantify the gloss of difficult to access mid-low
gloss surfaces. The instrument measures using the 60° geometry specified for
measuring mid gloss surfaces 10-70GU.
To improve the measurement performance on low gloss surfaces (0-10 GU) the
instrument has a GUh range: gloss unit high resolution. The GUh range gives x10
resolution and improved repeatability and accuracy on low gloss surfaces. Any
surface from 0-125 GU can be measured using this device.
The GUh low gloss high resolution range uses an additional high gain amplifier for
improved measurement on matt surfaces.

5
Accessories
The instrument is supplied as a standard package complete with all accessories
required to calibrate and recharge the unit including:
Rhopoint NG Flex 60 Glossmeter.
Rhopoint NG Flex magnetic measurement adapter.
Rhopoint NG Flex standard adapter.
Rhopoint NG Flex 60 measuring head and remote connecting cable.
BAM traceable high gloss calibration adapter including certificate.
BAM traceable low (GUh range) gloss calibration adapter including certificate.
Cleaning cloth for calibration tile.
BAM traceable instrument certificate.
USB mains charger with four selectable mains input connectors (UK / Europe
/ US / Australia).
USB PC cable.
Quick start operating instructions.
Protective instrument carry case.

6
Functional Overview
The instrument is controlled by pressing the relevant touch sensitive button.
Functionality is dependent on whether the instrument is in menu or operate mode as
detailed in the operation sections that follow.
Label No
Function
1
Measurement button
2
High resolution graphic display
3
Up/Down/Left/Right buttons
4
Calibration tile
5
6
7
8
Operate / Enter button
Remote measurement head
Remote measurement button
Magnetic measurement adapter
6
5
3
1
4
7
8
2

7
Power
The Rhopoint NG Flex 60 is powered by an integrated high capacity lithium ion cell.
Fully charged the instrument will operate continuouslyfor >17 hours or>20,000
readings.
A mains powered USB charger is provided with the instrument. This will fully charge the
instrument when connected to the unit’s USB input (6) using the USB cable provided in
under 4 hours.
The Rhopoint NG Flex 60 can also be powered and charged using the USB cable
attached to any compatible USB host(e.g. laptop) however due to the lower current
available from these devices the charge time would be a minimum of 6 – 8 hours.
Do not operate the instrument whilst it is charging.
Switching on the unit
To switch on the unit, touch the On/Off button located at the back of the instrument near
the USB socket.
The instrument will display the Rhopoint NG Flex 60 logo and then enter into the home
screen displaying measurement parameters according to the instrument’s default
settings or those previously configured.
Similarly, the instrument can be powered off (dependent on configuration – see
Instrument Setup) by pressing the On/Off button for three seconds.
Label No
Function
6
Mains / USB charger
input connector
7
On / Off button
6
7

8
Operation
The Rhopoint NG Flex 60 has the ability to flip its screens according to its
measurement orientation.
It automatically displays measurement data in either portrait mode:
Or landscape mode:
Note: The Main Menu, Statistics and Main Measurement screen are available in
portrait view. Other menus and graphs can only be accessed when the instrument is
held in a landscape orientation. The flip function is disabled when landscape only
screens are shown and when an on screen prompt is visible.

9
When the instrument is switched on and initialised it will display the home screen as
shown below:
In this mode, measurements can be made by simply pressing the measurement
button (1) on the side of the instrument, remote head button (7) or operate button (4)
on the instrument keypad.
Pressing the right button in the home screen the NG statistics screen is shown for
the current batch. Memory must be switched on to access the statistics screen.
Label No
Function
i
Navigation options
ii
Geometry banner
iii
60° gloss measurement
iv
Batch name and number
v
vi
vii
viii
ix
Battery meter
Instrument status and Bluetooth icons
Batch iteration
High resolution 60° gloss measurement (GUh)
Date and time
v
i
vi
vii
ii
iii
iv
viii
ix

10
Pressing the left button returns the display to the home screen.
Pressing the right button in the NG statistics screen will access the NG graph screen
providing a graphical representation of the statistics data. The same screen is
available for gloss statistics when in the NG statistics screen.
When pressing the up / down buttons NG data can be displayed either all together or
individually.
Pressing the up button in the NG graph screen accesses the gloss graph screen.
Measurements can be taken whilst in this screen and the graph will be updated after
each reading.
Pressing the left button returns the display to the Statistics Screen.
Pressing the right button the instrument returns the display to the Home Screen.

11
Menu Screen
The Menu screen is used to quickly access often used options. Pressing the up and
down buttons navigates through the options. Pressing the enter button selects that
option.
Selectable settings in the menu screen are:
Memory: Set to ON: This enables the storage and batching of
measurement results. The amount of available storage
memory is also displayed.
Set to OFF: Thisdisables the result storage.
With Memory ON:
Delete last reading – delete the last measurement, the no. of measurements and
statistics data updated to previous values.
Start new batch – start new batch of readings: batch name is incremented by 1.
Clear current batch – delete entire batch of measurements for current batch.
Delete all batches – delete all stored batches and measurements.
Batch name – default name is BATCH. A maximum of 8 user defined batch
names can be used asdetailed in the BatchingOptions section.
Calibrate instrument– perform a calibration of the instrument as detailed under
Operation.
Switch off – turn off the instrument.
Pressing the left button returns the display to the home screen.
Pressing the right button will access the setup screen.

12
Batching Options
The batching feature allows the userto group measurements together in batches. Each
batch has associated statistics; the data for each batch can be accessed byconnecting
the instrument to a PC.
The current batch name is displayed on the home screen in the bottom left corner, the
sample number within that batch is shown in the top right of the screen indicated with
n=(sample number).
A new batch is started using the start new batch option in either the menu screen or the
data menu, note that the batch name will increment as will the ‘n’ indicator.
The current batch can be cleared in the either the menu screen or the data menu. The
batch name will remain the same but the ‘n’ indicator will reset to zero.
Auto batch size is user defined using the auto batch option in the data menu. When the
number of readings in the current batch reach the numberset by the user the instrument
will automatically increment the batch name and set the ‘n’ indicator to zero.
Viewing Batch Data
To access the stored batch information connect the instrument to a PC using the USB
data cable supplied.
A new device name NG-METER can be viewed and accessed via MY COMPUTER, in
this device open the DATA folder. Thisfolder contains subfolders which contain the data
foreachindividualsavedbatch.Eachreadingissavedasanindividualcommaseparated
value (.csv) containing the gloss, time and date of reading, the serial number &
calibration/servicing information.
Each reading also contains the statistics for the batch up to and including that reading.
To access the STATISTICS for the whole batch, the last reading in the batch should be
examined.
User Defined Batch Names
Batch namesare user definable.With theinstrument connected to a PC, open the folder
named CONFIG.Within this folder there is adocument named Batches.This is a .csvfile
that can be opened in Notepad, Excel orWordpad.
User defined names should be saved in this document with each name listed on a
separate line. Ensure that the final line is terminated with a carriage return.
The format of these names should only contain letters. Numbers, spaces or other
characters cannot be used.

13
Once completed save the file then switch the instrument off and on again to initialize the
new batch names.
Setup Screen
The setup screen is used to customize the instrument to the user’s preference. Pressing
the up and down buttons navigates through the options, pressing the Enter button
selects that option.
Data and Batch Menu - Batch / Data options (See Data & Batch Menu Screen).
Calibration Menu - Calibration options (See Calibration Menu Screen).
Measurement Menu - Geometry setup (See Measurement Menu Screen).
Control Menu - Bluetooth setup (See Control Menu Screen).
Instrument Setup - Language, Date / Time and Power options (Setup Menu
Screen).
Factory Menu - Pin locked menu options for Rhopoint authorised service
centres.
Pressing the left button returns the display to the home screen.

14
Data & Batch Screen
The Data Screen is similar in functionality to that of the menu screen but also allows the
selection and setting of the Auto Batch size.
ByselectingAutoBatchtoONthebatchsizecanbeselectedbetween1-999bypressing
the Left and Right buttons to select the relevant digit and the Up and Down buttons to
increment / decrement the value. Pressing theEnter button saves the batch size.
If Batch names have been user defined, as detailed under Batching Options, selection of
the Batch Name required is achieved byrepeatedly pressing the Enter button with Batch
Name selected.
Pressing the Left button returns the display to the home screen.

15
Calibration Screen
The Calibration Screen is used to setup the instrument calibration to the user’s
preference. Pressing the Up and Down buttons navigates through the options, pressing
the Enter button selects that option.
Selectable settings in the Calibration screen are: -
Calibrate instrument– Performs an instant calibration of the instrument; a dialogue box
being displayed upon completion to either “Cancel” or “Confirm”.
Calibrate to - GU - a traceable high gloss tile is used to calibrate GU ran
GUh - a traceable low gloss tile is used to calibrate GUh range.
Tile Value - Set the calibration values for either standard being used for
calibration. Pressing the Enter button selects the value. Pressing the Left and Right
buttons selects the relevant digit and the Up and Down buttons increment / decrement
the value. Pressing the Enter button again saves the value.

16
Calibrating the Novo-Gloss Flex 60
The Rhopoint Novo-Gloss Flex 60 is supplied with 2 calibration standards for the GU &
GUh ranges. The standards are magnetically enclosed which protects the glass
reference tiles from contamination and damage. The holder can be opened for
inspection and cleaning.
The calibration tiles are enclosed in a magnetically sealed holder.
To calibrate the instrument, remove the measurement adapter and attach the
calibration holder. The instrument serial number on the calibration holder and
instrument must be matched.
Place the measurement head and calibration holder on a flat surface and initiate calibration.
Select the correct calibration range in the calibration menu - the range is indicated on
labelson the top and bottom of each holder. If the incorrect range is selected for the
attached tile Calibration Error will be shown on the screen. Cancel the calibration and
select the correct range then restart the procedure.

17
The Calibrate To field indicates which tile must be used for the calibration. If the wrong
range or tile is selected an error message is shown. Cancel the calibration, change the
tile or range and begin the calibration process again.

18
Measurement Screen
The Measurement Screen is used to configure the instruments measurement
parameters to the user’s preference. Pressing the Up and Down buttons navigates
through the options, pressing the Enter button selects that option.
Selectable settings in the Measurement screen are:
Pass/Fail - Displays the Pass/Fail set up screen.
Auto Measure - Enables or disables automatic measurement mode, used for monitoring
surfaces for changes over a period of time. Pressing the Enter button selects the
required measurement frequency of either 2, 5 or 10 seconds. When auto measure
mode isactivated a dialogue box is displayed after the Enterbutton is pressed and
before the beginning of the measurement sequence indicating that it is activated. To
stop auto measure simply press the Enter button once again at any time during the
sequence.
Geometry- The following measurements are selected to be displayed on measurement
screen:
GU/GUh-Both ranges are displayed on the measurement screen.
GU – The standard gloss scale only is displayed.
GUh – The high resolution gloss scale only is displayed.
Pressing the Left button returns the display to the home screen.

19
Pass/Fail Setup Screen
The Pass/Fail setup screen is used to enable/disable on-screen pass/fail indication and
set min / max tolerances.
The down key should be used to navigate to the Pass/Fail option and the center button
pressed to toggle the feature on and off.
Pressing the right navigation button allows the user to edit the pass & fail criteria.
Once the Pass/Failfeature is enabled, any measurement which falls between the max
and min values will be considered a pass and its header text will be coloured green.
Readings above the max value or below min value will be deemed a fail and header
text will be coloured red. Saved data and data transmitted byBluetooth will also contain
a pass/fail field.
Select the done option to complete this process.
