Ricoh P5 User manual

1
Battery Charger P5
Operating Instructions
Introduction
This product is a lithium-ion battery charger for SG 3120B SFNw. Before using
this product, read this leaflet carefully in order to use the product safely. Keep
this leaflet in a handy place for quick reference.
For details about handling the battery, see the Getting Started.
Disclaimer
Contents of this manual are subject to change without prior notice.

2
Safety Information
Safety During Operation
In this manual, the following important symbols are used:
WARNING:
Indicates a potentially hazardous situation which, if instructions are not followed,
could result in death or serious injury.
CAUTION:
Indicates a potentially hazardous situation which, if instructions are not followed,
may result in minor or moderate injury or damage to property.
R
R
Safety Precautions to Be Followed
Environments where the machine can be used
WARNING:
Do not use flammable sprays or solvents in the vicinity of this ma-
chine. Also, avoid placing these items in the vicinity of this machine.
Doing so could result in fire or electric shock.
•
WARNING:
Do not place vases, plant pots, cups, toiletries, medicines, small metal
objects, or containers holding water or any other liquids, on or close
to this machine. Fire or electric shock could result from spillage or if
such objects or substances fall inside this machine.
•
CAUTION:
Keep the machine away from humidity and dust. Otherwise a fire or an
electric shock might occur.
•
CAUTION:
Do not place the machine on an unstable or tilted surface.If it topples over,
an injury might occur.
•
CAUTION:
Do not place heavy objects on the machine. Doing so can cause the ma-
chine to topple over, possibly resulting in injury.
•
CAUTION:
Do not place the power cord and connection cable in a way that might
cause someone to trip and fall.The product might fall over and cause an
injury.
•
R
R
R
R
R
R

3
CAUTION:
For safety, be sure to disconnect the power plug from the wall outlet after
using the product or when the product is not going to be used for some
time.
•
CAUTION:
For safety, be sure not to use the product with a blanket or cloth over it.•
Handling power cords and power plugs
WARNING:
Do not use any power sources other than those that match the speci-
fications shown in this manual. Doing so could result in fire or electric
shock.
•
WARNING:
Do not use any frequencies other than those that match the specifica-
tions shown. Doing so could result in fire or electric shock.
•
WARNING:
Do not use multi-socket adaptors. Doing so could result in fire or
electric shock.
•
WARNING:
Do not use extension cords. Doing so could result in fire or electric
shock.
•
WARNING:
Do not use power cords that are damaged, broken, or modified. Also,
do not use power cords that have been trapped under heavy objects,
pulled hard, or bent severely. Doing so could result in fire or electric
shock.
•
WARNING:
It is dangerous to handle the power cord plug with wet hands. Doing
so could result in electric shock.
•
WARNING:
Touching the prongs of the power cable's plug with anything metallic
constitutes a fire and electric shock hazard.
•
WARNING:
The supplied power cord is for use with this machine only. Do not use
it with other appliances. Doing so could result in fire or electric shock.
•
R
R
R
R
R
R
R
R
R
R

4
WARNING:
If the power cord is damaged and its inner wires are exposed or
broken, contact your service representative for a replacement. Use of
damaged power cords could result in fire or electric shock.
•
WARNING:
Be sure to disconnect the plug from the wall outlet at least once a
year and check for the following:
There are burn marks on the plug.
The prongs on the plug are deformed.
If any of the above conditions exist, do not use the plug and consult
your dealer or service representative. Use of the plug could result in
fire or electric shock.
•
•
•
•
WARNING:
Be sure to disconnect the power cord from the wall outlet at least
once a year and check for the following:
The power cord's inner wires are exposed, broken, etc.
The power cord's coating has a crack or dent.
When bending the power cord, the power turns off and on.
Part of the power cord becomes hot.
The power cord is damaged.
If any of the above conditions exist, do not use the power cord and
consult your dealer or service representative. Use of the power cord
could result in fire or electric shock.
•
•
•
•
•
•
•
CAUTION:
When disconnecting the power cord from the wall outlet, always pull the
plug, not the cord. Pulling the cord can damage the power cord. Use of
damaged power cords could result in fire or electric shock.
•
CAUTION:
Be sure to push the plug of the power cord fully into the wall outlet. Par-
tially inserted plugs create an unstable connection that can result in unsafe
buildup of heat.
•
CAUTION:
Be sure to disconnect the plug from the wall outlet and clean the prongs
and the area around the prongs at least once a year.Allowing dust to build
up on the plug constitutes a fire hazard.
•
CAUTION:
If this machine is not going to be used for several days or longer at a time,
disconnect its power cord from the wall outlet.
•
CAUTION:
When performing maintenance on the machine, always disconnect the
power cord from the wall outlet.
•
R
R
R
R
R
R
R
R

5
Handling the main machine
WARNING:
The following explains the warning messages on the plastic bag used
in this product's packaging.
Keep the polythene materials (bags, etc.) supplied with this machine
away from babies and small children at all times. Suffocation can
result if polythene materials are brought into contact with the mouth
or nose.
•
•
WARNING:
Be sure to locate the machine as close as possible to a wall outlet.
This will allow easy disconnection of the power cord in the event of
an emergency.
•
WARNING:
If the machine emits smoke or odor, or if it behaves unusually, discon-
nect the power cord plug from the wall outlet.Then contact your ser-
vice representative and report the problem. Do not use the machine.
Doing so could result in fire or electric shock.
•
WARNING:
If metal objects, water or other fluids fall inside this machine, discon-
nect the power cord plug from the wall outlet.Then contact your ser-
vice representative and report the problem. Do not use the machine.
Doing so could result in fire or electric shock.
•
WARNING:
Do not touch this machine if a lightning strike occurs in the immedi-
ate vicinity. Doing so could result in electric shock.
•
WARNING:
Do not touch the terminals with your hand or a metal object. Doing so
may cause a short circuit, resulting in smoke or fire.
•
CAUTION:
Unplug the power cord from the wall outlet before you move the machine.
While moving the machine, take care that the power cord is not damaged
under the machine.Failing to take these precautions could result in fire or
electric shock.
•
Handling the machine's interior
WARNING:
Do not attempt to disassemble or modify this machine. Doing so risks
burns and electric shock.
•
R
R
R
R
R
R
R
R

6
Handling AC adapter
WARNING:
Do not use any power sources other than those that match the speci-
fications shown. Doing so could result in fire or electric shock.
•
WARNING:
Do not damage, break, or modify the AC adapter or cord of the AC
adapter. Also, do not place heavy objects on the cord of the AC
adapter, or pull the cord or bend it severely. Doing so could result in
fire or electric shock.
•
WARNING:
The supplied AC adapter is for use with this machine only. Do not use
it with other appliances. Doing so could result in fire or electric shock.
•
WARNING:
Do not use the AC adapter or cord of the AC adapter if it is deformed,
cracked, or damaged. Doing so could result in fire or electric shock.
If the AC adapter or cord of the AC adapter is deformed, Cracked, or
damaged, contact your service representative to request a replace-
ment cable.
•
CAUTION:
Push the AC adapter all the way into the power outlet.Do not use a power
outlet with a loose connection. Doing so may result in heat buildup. Plug
the AC adapter and cord of the AC adapter in the correct direction into the
base.If they are not plugged in correctly, it could result in smoke, fire, or
electric shock.
•
CAUTION:
When disconnecting the plug of the AC adapter from the wall outlet, always
pull the AC adapter, not the cord of the AC adapter.Pulling the cord can
damage the cord. Use of damaged cords of the AC adapter could result in
fire or electric shock.
•
CAUTION:
Do not disassemble or modify the AC adapter. Doing so may result in burns
or electric shock. Contact your service representative if the AC adapter
needs repaired.
•
CAUTION:
Do not wrap the AC adapter cord around the AC adapter. If the cord is
damaged or the inner wire is exposed, it may result in fire, electric shock, or
burns.
•
R
R
R
R
R
R
R
R

7
CAUTION:
It is recommended that you do not touch the AC adapter when using the
product. Possible heat buildup in the AC adapter may cause burns.
•
About the Batteries
WARNING:
For safe operation, follow the warnings below regarding the battery. If
you use a battery incorrectly, it may result in fire or injury due to bat-
tery leaking or exploding.
Do not leave the battery in a place where the temperature is likely
to be high, such as in a vehicle or strong sunlight. Doing so may
cause abnormal heating, rupture, or fire.
Do not place the batteries in fire or water.
Do not place the battery in an induction heating cooker or a micro-
wave oven.
Do not use batteries other than the ones supplied.
Do not use the battery with devices other than the specified ma-
chine.
Do not recharge the battery using a method other than the speci-
fied recharging method.
Do not disassemble, modify or solder the battery.
Do not use the battery if it has received an impact—for example, by
being dropped.
Do not nail, hammer, or crush the battery.
Do not connect the connecting terminals on a battery with a wire.
Do not carry or store the battery with a metal object, such as a
necklace or hairpin. Doing so may cause the battery to short-cir-
cuit, resulting in abnormal heating, rupture, or fire.
If abnormal heating or deformation of the battery occurs during
recharging, discharging, or storage, immediately stop using the
battery and remove it from the machine.
If the machine is to be left unused for a long time, remove the bat-
tery and store it in a cool, dry place.
Keep the batteries out of the reach of children.
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
R
R

8
WARNING:
What to do if a battery has leaked.
If leakage from a battery adheres to your skin, rinse it with water
immediately, and then contact a doctor.
Wipe off the leakage with tissue paper while being careful not to
touch it.
Soak the tissue paper that you used in water, and then throw it
away as burnable trash.
•
•
•
•
CAUTION:
Risk of explosion if battery is replaced by an incorrect type. Dispose of
used batteries according to the instructions.For details, see "About the Bat-
tery" in Getting Started.
•
Notice
To move the battery charger, first remove the battery and insulate the bat-
tery terminals with tape or put the battery in the plastic bag or the box it was
delivered in. Moving the battery charger with the battery may result in a short
circuit, causing smoke or fire.
To maximize the battery life, recharge, use, and store it in an environment with
an ambient temperature of 10 to 32°C. Be careful about recharging, using, or
storing the battery in an environment with an ambient temperature of 40°C or
above. Doing so will cause the battery to deteriorate.
To prevent condensation, install the machine in an area where temperature and
humidity conditions do not exceed those indicated in the diagram below.
CFT065
: Permissible Range
: Recommended Range
R
R
•
•

9
Information for This Machine
Notes to USA Users of FCC Requirements
Part 15 of the FCC Rules
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference
that may cause undesired operation.
This transmitter must not be co-located or operated in conjunction with any
other antenna or transmitter.
Note:
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
Consult the dealer or an experienced radio /TV technician for help.
Caution:
Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
❖
•
•
•
•
❖

10
For users in the state of California
Perchlorate Material - special handling may apply. See: www.dtsc.ca.gov/haz-
ardouswaste/perchlorate
Notes to Canadian Users of ICES-003 Conformance
CAN ICES-3 (B)/NMB-3(B)
Remarques à l'attention des utilisateurs canadiens
CAN ICES-3 (B)/NMB-3(B)
Guide to Components
5
4
3
2
1
DAN056
1. Terminal
2. Battery indicator
3. AC adapter port
4. AC adapter
5. Power cord

11
Names of Battery Indicator Parts
1
2
3
4
DAN050
1. LED battery status indicator
This displays the battery's operating status.
Lit continuously: The machine is operating under battery power.
Unlit: Completed battery charging
2. LED battery level indicator
This displays how much charge is left in the battery in six levels accord-
ing to the number of lamps lit.
5: 81-100 %; 4: 61-80%; 3: 41-60 %; 2: 21-40 %; 1: 1-20 %; 0: 0 %
The LED battery level indicator merely gives a rough indication of the
battery level. The battery level will be slightly higher than it actually is
while the battery is being charged.
3. Battery level check button
Press this to check the charge level.
4. Battery alert LED
This flashes when the battery cannot be charged if a battery malfunction
or the temperature rises higher than the temperature limit allowed for
charging. For details, see page 14 " Troubleshooting".

12
Charging the Battery
Use the battery in an environment with an ambient temperature of 0 to
40°C. If the battery temperature exceeds 60°C, charging automatically stops.
Do not touch the terminals of the battery or battery charger. Doing so may
cause a malfunction.
Attach the power cord to the AC adapter.
DAN005
Connect the cord of the AC adapter to the battery charger.
DAN051
Plug the power plug fully into the wall outlet.
DAN052
•
•

13
Mount the battery on the battery charger so that the side with the ter-
minal and the battery faces up.
DAN053
Pull the battery out while lifting it slightly.
DAN055

14
Troubleshooting
The battery alert LED lights up.
The battery temperature may have exceeded the battery limit. If the
battery temperature drops below 0°C or rises above 60°C, charging
automatically stops. Use the battery in an environment with an ambi-
ent temperature of 0 to 40°C.
Charging does not start. / The LED battery status indicator does not light
up.
Check that the power cord, AC adapter connector, and power plug
are all connected correctly. If they are connected correctly, the LED on
the AC adapter lights.
Check that the battery is mounted correctly.
Battery charging is not complete.
The battery's life (5 years) may have expired. Replace the battery
with a new one.
The battery remaining battery level is not indicated even when the bat-
tery level check button is pressed.
Check that the power cord, AC adapter connector, and power plug
are all connected correctly.
Check that the battery is mounted correctly.
If the problem persists, mount the battery on the SG 3120B SFNw. If the opera-
tion panel's LEDs do not light, the battery or battery charger may be faulty.
Stop using it immediately and contact your sales or service representative.

•

•
•

•

•
•

15
Cleaning
To clean the exterior of the machine, wipe it with a soft, dry or damp cloth. If
the dirt does not come off, wipe the machine first with a cloth moistened with
a neutral detergent, then with a damp cloth, and finally with a dry cloth.
Do not use volatile chemicals like benzene or thinner, or insecticides on the
machine. Using these chemicals could deform, crack, or change the color of
the machine.
When wiping the machine with a cloth moistened with detergent, be sure to
wipe only the exterior.
•
•

16
© 2014
Printed in China
EN US
J345-6611
Specifications
Power source
100-240V 50/60Hz 1.5A
Use a power source whose output voltage is within ±10% of the rated
voltage.
Power consumption
Standby: 0.5 W
During charging: 50 W
Battery charging time
Approximately three hours
External dimensions
(W × D × H) 214 × 137 × 82 mm (8.6 × 5.5 × 3.3 inches)
Weight
Battery charger: 0.5 kg
AC adapter: 0.5 kg
❖
❖
❖
❖
❖
