SPECIALIZED USER MANUAL
CHARGER (SBC-C04 / SBC-C05 / SBC-C06 / SBC-C07)
THIS BRIEF USER MANUAL CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ CAREFULLY AND STORE IN A SAFE PLACE.
This user manual is specific to your Specialized Turbo (e-bike) charger. It contains important safety, performance, and technical information, which you should
read before your first use and keep for reference. You should also read the entire user manual specific to your Specialized Turbo bicycle, including instructions and
information regarding the battery and the charging thereof, and the Specialized Bicycle Owner’s Manual (“Owner’s Manual”), because they have additional important
general information and instructions which you should follow. If you do not have a copy of these documents, you can download them at no cost at www.specialized.
com, or obtain them from your nearest Authorized Specialized Retailer or Specialized Rider Care.
When reading this manual, you will note various important symbols and warnings, which are explained below:
WARNING! The combination of this symbol and word indicates a potentially hazardous situation which, if not avoided, could result in serious
injury or death. Many of the Warnings say “you may lose control and fall.” Because any fall can result in serious injury or even death, we do not
always repeat the warning of possible injury or death.
CAUTION: The combination of the safety alert symbol and the word CAUTION indicates a potentially hazardous situation, which, if not
avoided, may result in minor or moderate injury, or is an alert against unsafe practices.
The word CAUTION used without the safety alert symbol indicates a situation which, if not avoided, could result in serious damage to the
bicycle or the voiding of your warranty.
INFO: This symbol alerts the reader to information which is particularly important.
INSTRUCTIONS PERTAINING TO THE RISK OF FIRE OR ELECTRIC SHOCK
ALWAYS ADHERE TO THE FOLLOWING INSTRUCTIONS WHEN HANDLING OR CHARGING THE BATTERY:
Only use Specialized chargers with specialized batteries that fit into Specialized Turbo bicycles. Do not use Specialized chargers with any other bicycle or any other
charger with Specialized Turbo bicycles, even if it fits. Refer to the table in the BATTERY TECHNICAL DATA section to ensure compatibility of your charger and
battery.
Turn off the battery, unplug the charger from the battery and remove the battery from the bicycle before performing work of any kind on the bicycle (e.g.
maintenance, repair, cleaning) or during transportation.
Only use the Specialized charger supplied with the bicycle or other chargers approved by Specialized.
Do not leave the charger connected to the battery overnight or after the battery has reached full charge.
Make sure the charging socket and plug are clean and dry before connecting and charging the battery.
Regularly inspect the charger before every use for possible damage to the charger itself, the cable, or the charging plug. Never use a charger which you suspect is
damaged or know is broken.
Only use the supplied charger cord. Ensure the cord plug is fully inserted in the charger before plugging the charger into a power outlet.
Always turn the bicycle off before connecting or disconnecting the charger from the charge port.
Refer to your bicycle’s user manual for instructions and information regarding your battery.
To reduce the risk of injury, close supervision is necessary when the product is used near children.
Do not modify, open, or disassemble the charger. Modification or disassembly may result in a short circuit, fire, or malfunction.
Do not allow the charger to overheat.
Protect the battery from excessive sun exposure.
Do not expose the charger to an open fire or radiator heat.
Do not submerge the charger in water.
Do not expose to rain or snow. This charger is designed for indoor use only.
Do not use this charger on non-rechargeable batteries.
Do not use this product if the flexible power cord or output cable is frayed, has broken insulation, or any other signs of damage.
The hardwired charger cable cannot be replaced. If the cable is damaged, the charger must be replaced in its entirety.
Non EU Countries:
This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning the use of the appliance by a person responsible for their safety. Children should be supervised
to ensure that they do not play with the appliance.
EU Countries:
This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning the use of the appliance in a safe way and understand the hazards involved. Children shall
not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.
WARNING! Failure to follow the instructions in this section may result in damage to electrical components on your bicycle and will void your
warranty, but, most importantly, may result in serious personal injury or death. If your battery or charger exhibits any signs of damage, do not
use it and immediately bring it to your Authorized Specialized Retailer for inspection.

2
CLEANING AND MAINTENANCE
Always remove the charger from the charge port and wall socket before cleaning the charger.
Do not use alcohol, solvents, or abrasive cleaners to clean the charger. Instead, use a dry or slightly damp cloth.
Make sure connectors are dry and clean before reconnecting and riding. Ask your Authorized Specialized Retailer for additional information about cleaning your bicycle.
DISPOSAL
Batteries and chargers must not be disposed of in your household trash! All batteries and chargers must be disposed of in an
environmentally friendly manner, in accordance with the battery disposal regulations in your country or state. Ask your Authorized
Specialized Retailer for information about how to dispose of a battery or charger and any applicable take-back program.
BATTERY AND CHARGER LABEL
WARNING! Before using the charger, read the label / information on the charger itself, the battery, and the relevant sections in the manuals supplied
with your bicycle.
SAFETY SYMBOLS
Read instruction manual
Indoor use only
For your own protection and
for the protection of your
charger pay attention to
all parts of the text that are
marked with this symbol!
Dispose the charger via the
designated take-back system
CE: checkmark, device
is compliant to European
standards
Class II appliance, does not
require a safety connection
to ground
Device contains T 2.5A fuse
for overcurrent protection
INSTALLATION AND OPERATION OF THE CHARGER
SBC - C06
1 2 3
SBC - CO6
120V / 230V
SBC - CO6
SBC - CO4
SBC - CO5
SBC - CO4
SBC - CO5
SBC - C07
230V
SBC - CO7
CHARGING
CHARGER IMAGE FOR REFERENCE ONLY
FULLY CHARGED ERROR
1
Plug the charger power cable into the socket on the charger, then plug the charger’s plug into an outlet using the appropriate plug for the country’s standards.
Never use extension cords.
Power off your Turbo bicycle then insert the charging plug into the charging socket on your Turbo bicycle.
For more information specific to your Specialized Turbo bicycle, such as charging socket location, how to maintain, operate, and charge your Turbo bicycle, please
refer to the bicycle user manual specific to your Specialized Turbo bicycle.
During the charging process, the LED light on the charger will glow red. When the battery is fully charged, the LED light on the charger will turn green.
When charging is complete, disconnect the charging plug from the charging socket and unplug the charger from the wall socket.
INFO: The battery can be charged whether installed in the bicycle or not. Refer to the appropriate instructions regarding removing and installing the
battery. Only charge the battery at an ambient temperature as listed in the charger technical data table. If the battery is too hot, it will not charge.

3
WARNING!Place the charger (and battery if removed from the frame) on a stable, level surface unaffected by heat. You should charge the battery in
a dry, well ventilated area and make sure the charger is uncovered during the charging process. Ensure that the battery and charger are not exposed to
any flammable or dangerous substances. Plug the charger’s plug into an outlet, using the appropriate plug for the country’s standards, then connect the
charging plug with the charging socket on the battery. Specialized recommends charging the battery in an area with a smoke detector.
CAUTION: If the red LED flashes during the charging process (fig.1), a charging error has occurred. In that case, immediately remove the
charger from the socket, discontinue use of the motor support and contact your Authorized Specialized Retailer.
CHARGER TECHNICAL DATA
DESCRIPTION UNIT
SPECIFICATION
SBC-C04 SBC-C05 SBC-C06 SBC-C07
CHARGING VOLTAGE (DC) VOLT 42 42 54 42
RATED VOLTAGE (AC) VOLT 100 - 240 100 - 240 100 - 240 230 - 240
CHARGING CURRENT AMP 4 2 3 4
FREQUENCY Hz 50/60 50/60 50/60 50 / 60
WEIGHT Kg 1111
OPERATING TEMPERATURE
°C 0 — +40 0 — +40 0 — +40 -10 - +40
°F +32 — +104 +32 — +104 +32 — +104 14 - +104
STORAGE TEMPERATURE
°C -20 — +65 -20 — +65 -20 — +65 -20 - +70
°F -4 — +149 -4 — +149 -4 — +149 -4 - +158
DIMENSIONS MM 177 x 78 x 38.5 177 x 78 x 38.5 177 x 78 x 38.5 179 x 86 x 50.5
BATTERY TECHNICAL DATA
DESCRIPTION UNIT
BATTERY
SBC-B01 SBC-B02 SBC-B03 SBC-B04 SBC-B05 SBC-B06 SBC-B07 SBC-B08 SBC-B09 SBC-B10 SBC-B11 SBC-B12 SBC-B13 SBC-B15 SBC-B16 SBC-B17 SBC-B19 SBC-B20 SBC-B21 SBC-B22
OPERATING
VOLTAG E VO LT 36 36 36 36 36 36 36 36 36 36 36 36 36 48 48 36 36 36 36 36
RATED
CAPACITY AH 11 14 13 15 19 11.5 12.5 14 16.8 14 12.5 14 19.5 7 3.5 11.5 14.7 19.6 13.4 19
ENERGY WH 396 504 468 562 691 400 460 500 600 500 460 500 700 320 160 400 530 710 500 700
NUMBER OF
CELLS 50 50 50 60 40 40 40 40 40 40 40 40 40 26 13 40 30 40 40 40
CHARGE TIME
(SBC-C04) HRS 3:00 3:50 3:35 4:20 5:20 3:15 3:30 3:50 4:35 3:50 3:30 3:50 5:15 X X 3:15 4 5 3.5 5:15
CHARGE TIME
(SBC-C05) HRS 6:00 7:40 7:10 8:40 10:40 6:30 7:00 7:40 9:10 7:40 7:00 7:40 10:30 X X 6:30 4 5 3.5 5:15
CHARGE TIME
(SBC-C06) HRS XXXXXXXXXXXXX2:353:20XXXXX
CHARGE TIME
(SBC-C07) HRS 3:00 3:50 3:35 4:20 5:20 3:15 3:30 3:50 4:35 3:50 3:30 3:50 5:15 3:15 4 5 3.5 5:15
WARRANTY
Please refer to the written warranty provisions provided with your bicycle, or visit www.specialized.com. A copy is also available at your Authorized Specialized
Retailer.

4
EC – DECLARATION OF CONFORMITY
The manufacturer:
Specialized Bicycle Components Inc.
15130 Concord Circle
Morgan Hill, CA 95037, USA
Tel: [phone]
Hereby confirms for the following products:
Product description: Li-ion Battery Charger
Model designation: SBC-C04 / SBC-C05 / SBC-C06 / SBC-C07
Comply with all of the relevant
requirements of the directives:
Electromagnetic Compatibility (2004/108/EC)
Low Voltage (2014/35/EU)
The following standards were
applied to the product:
EN 55014-1 Electromagnetic compatibility - Requirements for household appliances, electric tools and similar apparatus
Part 1: Emission
Part 2: Immunity
EN 61000-3-2 Electromagnetic compatibility (EMC)
Part 3-2: Limits - Limits for harmonic current emissions
Part 3-3: Limits - Limitation of voltage changes, voltage fluctuations and flicker in public low-voltage supply systems
EN 60335-1 Household and similar electrical appliances - safety
EN 60335-2-29 Safety of household and similar appliances
Part 1: General requirements
Part 2: Particular requirements for battery chargers
Serial number: Printed on the decal located on the charger body
Technical documentation by: Specialized Europe GmbH
Werkstattgasse 10 6330 Cham, Switzerland
Signature:
Jan Talavasek
(Sr. Director Turbo)
Specialized Europe GmbH, 6330 Cham, Switzerland, April 1st, 2021
NOTE: THIS DECLARATION OF CONFORMITY APPLIES ONLY TO BICYCLES SOLD IN COUNTRIES FOLLOWING THE CE MARKING DIRECTIVES.
We may occasionally issue updates and addendums to this document. Please periodically check www.
specialized.com or contact Rider Care to make sure you have the latest information.
