Ricoh WG-20 User manual

0
Thank you for purchasing this RICOH WG-20 Digital Cam ra.
This cam ra is wat rproof, dustproof, and shockproof, as
shown b low, so you can us it in a wid rang of outdoor
activiti s.
Wat rproof/dustproof: JIS grad 8 wat rproof and grad 6
dustproof (IP68)
Shockproof: Satisfi s our drop t st (1.5 m h ight onto a 5 cm
thick plywood surfac ) complying with MIL-Standard 810F
M thod 516.5-Shock t sting.
* Wat rproof p rformanc is not guarant d if th cam ra is
xpos d to impact such as b ing dropp d or hit.
* Th cam ra is not guarant d to b fr of troubl or
damag und r v ry condition.
PentaxWG20_QSG.book Page 0 Tuesday, February 4, 2014 11:36 AM

To us rs of this cam ra
•Do not use or store this device in the vicinity of equipment that generates
strong electromagnetic radiation or magnetic fields. Strong static charges or
the magnetic fields produced by equipment such as radio transmitters could
interfere with the monitor, damage the stored data, or affect the product’s
internal circuitry and cause camera misoperation.
•The liquid crystal panel used in the display is manufactured using extremely
high precision technology. lthough the level of functioning pixels is 99.99%
or better, you should be aware that 0.01% or fewer of the pixels may not
illuminate or may illuminate when they should not. However, this has no
effect on the recorded image.
• band of light may appear on the display if the camera is aimed at a bright
subject. This is known as a smear, but it is not a malfunction.
•There is a possibility that the illustrations and the display screen in this
manual are different from the actual product.
•In this manual, SD Memory Cards, SDHC Memory Cards and SDXC
Memory Cards are referred to as SD Memory Cards.
•In this manual, the generic term “computer(s)” refers to either a Windows
PC or a Macintosh hereafter.
•In this manual, the term “battery(ies)” refers to any type of batteries used for
this camera and accessories.
PentaxWG20_QSG.book Page 0 Tuesday, February 4, 2014 11:36 AM

1
We have paid close attention to the safety of this product. When using this
product, we request your special attention regarding items marked with the
following symbols.
Warning
•Do not attempt to take the camera apart or modify the camera. High
voltages are present within the camera, and there is a danger of electric
shock if the camera is taken apart.
•If the inside of the camera should become exposed as a result of,
for example, the camera being dropped, please do not under any
circumstances touch such exposed portions, as there is a danger of
receiving an electric shock.
•Wrapping the strap of the camera around your neck is also dangerous.
Please take care that small children do not hang the strap around their
necks.
•If any irregularities occur during use, such as smoke or a strange odor, stop
use immediately, remove the battery or the C adapter, and contact your
nearest service center. Continuing to use the product can cause a fire or
electric shock.
Caution
•Do not place your finger on the flash when it is discharging as there is a risk
of burns.
•Do not discharge the flash while it is touching your clothing as there is a risk
of discoloring.
•Some portions of the camera heat up during use, so please take care,
as there is a risk of low temperature burns if such portions are held for
long periods of time.
•Should the LCD be damaged, be careful of glass fragments. lso,
be careful not to allow the liquid crystal to get on your skin, in your eyes,
or in your mouth.
Warning This symbol indicates that violating this item could
cause serious personal injuries.
Caution This symbol indicates that violating this item could
cause minor or medium personal injuries, or loss of
property.
About the Camera
Using Your Camera Safely
PentaxWG20_QSG.book Page 1 Tuesday, February 4, 2014 11:36 AM

2
•Depending on your individual factors or physical condition, the use of the
camera may cause itching, rashes or blisters. In case of any abnormality,
stop using the camera and get medical attention immediately.
Warning
•lways use the battery charger and C adapter exclusively developed for
this product, with the specified power and voltage. Using a battery charger
or C adapter not exclusive to this product, or using the exclusive battery
charger or C adapter with an unspecified power or voltage can cause a
fire, electric shock, or camera breakdown. The specified voltage is 100-
240V C.
•Do not disassemble or modify the product. This can cause a fire or electric
shock.
•If the generation of smoke or strange odor from the product or other
abnormality occurs, immediately discontinue its use and consult your
nearest service center. Continuing to use the product can cause a fire or
electric shock.
•If water should happen to get inside the product, consult your nearest
service center. Continuing to use the product can cause a fire or electric
shock.
•If a thunder storm should occur while using the battery charger or C
adapter, unplug the C plug cord and discontinue use. Continuing to use
the product can cause damage to the equipment, fire, or electric shock.
•Wipe off the plug of the C plug cord if it becomes covered with dust.
Dust on the plug may cause a fire.
Caution
•Do not place heavy objects on the C plug cord, allow heavy objects to drop
onto it or allow the C plug cord to become damaged due to excessive
bending. If the C plug cord becomes damaged, consult your nearest
service center.
•Do not short or touch the output terminals of the product while it is still
plugged in.
•Do not plug in the C plug cord with wet hands. This can cause an electric
shock.
•Do not subject the product to strong impacts or allow it to drop onto a hard
surface. This can cause a malfunction.
About the Battery Charger and the AC Adapter
PentaxWG20_QSG.book Page 2 Tuesday, February 4, 2014 11:36 AM

3
•Do not use the battery charger to charge a battery other than a
rechargeable lithium-ion battery D-LI92. This can cause overheating,
explosion, or battery charger failure.
•To reduce the risk of hazards, use only a CS /UL certified power supply
cord set, cord is Type SPT-2 or heavier, minimum NO.18 WG copper, one
end with a molded-on male attachment plug cap (with a specified NEM
configuration), and the other is provided with a molded-on female connector
body (with a specified IEC nonindustrial type configuration) or the
equivalent.
Warning
•Be sure to store the battery out of the reach of small children. Placing it in
their mouths may cause an electric shock.
•If any leakage from the battery should come in contact with your eyes,
it may cause a loss of sight. Flush your eyes with clean water and get
medical attention immediately. Do not rub them.
Caution
•Only use the specified battery with this camera. Use of other batteries may
cause an explosion or fire.
•Do not disassemble the battery. Disassembling the battery may cause an
explosion or leakage.
•Remove the battery from the camera immediately if it becomes hot or
begins to smoke. Be careful not to burn yourself during removal.
•Keep wires, hairpins, and other metal objects away from the + and -
contacts of the battery.
•Do not short the battery or dispose of the battery in fire. This can cause an
explosion or fire.
•If any leakage from the battery should come in contact with skin or clothes,
it may cause irritation to the skin. Wash the affected areas thoroughly with
water.
•Precautions for D-LI92 Battery Usage:
B TTERY M Y EXPLODE OR FIRE IF MISTRE TED.
-DO NOT DIS SSEMBLE OR DISPOSE OF IN FIRE.
-DO NOT CH RGE EXCEPT SPECIFIED CH RGING CONDITION.
-DO NOT HE T BOVE 140°F / 60°C, OR SHORT CIRCUIT.
-DO NOT CRUSH OR MODIFY.
About the Battery
PentaxWG20_QSG.book Page 3 Tuesday, February 4, 2014 11:36 AM

4
Warning
•Be sure to keep the camera and its accessories out of the reach of small
children.
1. Injuries may result from the product falling or from unexpected
movement.
2. Suffocation may result from wrapping the strap around the neck.
3. Small accessories such as battery or an SD Memory Card may be
swallowed. Seek medical attention immediately if an accessory is
accidentally swallowed.
Keep the Camera and Accessories Out of the Reach of Small
Children
PentaxWG20_QSG.book Page 4 Tuesday, February 4, 2014 11:36 AM

5
•When traveling, take the Worldwide Service Network listing that is included
in the package. This will be useful if you experience problems abroad.
•When the camera has not been used for a long time, confirm that it is still
working properly, particularly prior to taking important pictures (such as at
a wedding or when traveling). Contents of the recording cannot be
guaranteed if recording, playback or transferring your data to a computer,
etc. is not possible due to a malfunction of your camera or recording media
(SD Memory Card), etc.
•The lens on this camera is not interchangeable. The lens is not removable.
•Storing the battery fully charged may decrease the battery performance.
void storing it especially in high temperatures.
•If the battery is left inserted and the camera is not used for a long time,
the battery will over-discharge and shorten the battery’s service life.
•Charging the battery a day before use or on the day of use is
recommended.
•The C plug cord supplied with the camera is for exclusive use with the
battery charger D-BC92. Do not use it with any other equipment.
•Hot and humid places should be avoided. Particular care should be taken
regarding vehicles, which can become very hot inside.
•Ensure that the camera is not subjected to substantial vibrations, shocks,
or pressure as this may cause damage, malfunction, or a loss in waterproof
performance. Place the camera on a cushion for protection when the
camera is subjected to the vibrations of a motorbike, car, ship, etc.
If the camera is subjected to substantial vibrations, shocks, or pressure,
take your camera to your nearest service center and have it checked.
•The temperature range in which the camera can be used is -10°C to 40°C
(14°F to 104°F).
•The liquid crystal display will become black at high temperatures but will
return to normal at normal temperatures.
•The response speed of the liquid crystal display becomes slow at low
temperatures. This is due to the properties of the liquid crystal and is not
a malfunction.
Before Starting Use
About the Battery and Battery Charger
Cautions when Carrying and Using the Camera
Care to be Taken During Handling
PentaxWG20_QSG.book Page 5 Tuesday, February 4, 2014 11:36 AM

6
•If the camera is subjected to rapid temperature changes, condensation may
form on the inside and outside of the camera. Therefore put the camera in
a bag or plastic bag and take the camera out when the difference in
temperature has subsided.
•void contact with garbage, mud, sand, dust, water, toxic gases, or salts.
These could cause the camera to breakdown. Wipe the camera to dry off
any rain or water drops.
•Please do not press forcefully on the display. This could cause it to break
or malfunction.
•Be careful not to sit down with the camera in your back pocket as this may
damage the exterior of the camera or the display.
•When using a tripod with the camera, be careful not to overtighten the
screw in the tripod socket on the camera.
•Do not clean the product with organic solvents such as thinner, alcohol or
benzene.
•Use a lens brush to remove dust accumulated on the lens. Never use a
spray blower for cleaning as it may damage the lens.
•void storing the camera where pesticides and chemicals are handled.
Remove the camera from its case and store it in a well-ventilated place
to prevent the camera from becoming moldy during storage.
•void using or storing the camera where it may be exposed to static
electricity or electrical interference.
•void using or storing the camera in direct sunlight or in locations where it
may be exposed to rapid changes in temperature or to condensation.
•Periodic checks are recommended every 1 to 2 years in order to maintain
high performance.
About Repairs
About Storage
PentaxWG20_QSG.book Page 6 Tuesday, February 4, 2014 11:36 AM

7
•The SD Memory Card is equipped with a
write-protect switch. Setting the switch to
LOCK prevents new data from being
recorded on the card, the stored data
from being deleted, and the card from
being formatted by the camera or
computer.
r appears on the display when the card
is write-protected.
•Care should be taken when removing the SD Memory Card immediately
after using the camera, as the card may be hot.
•Keep the battery/card cover closed and do not remove the SD Memory
Card or turn the camera off while the data is being played back or saved
to the card, or the camera is connected to a computer with the USB cable,
as this may cause the data to be lost or the card to be damaged.
•Do not bend the SD Memory Card or subject it to violent impact. Keep it
away from water and store away from high temperature.
•Do not remove the SD Memory Card during formatting as this may damage
the card and render it unusable.
•The data on the SD Memory Card may be lost in the following
circumstances. We do not accept any liability for data that is deleted
(1) when the SD Memory Card is mishandled by the user.
(2) when the SD Memory Card is exposed to static electricity or electrical
interference.
(3) when the SD Memory Card has not been used for a long time.
(4) when the SD Memory Card is ejected or the batteries are removed
while the card is being accessed.
•If it is not used for a long time, the data on the card may become
unreadable. Be sure to regularly make a backup of important data on a
computer.
•Be sure to format SD Memory Cards that are unused or have been used on
another camera.
•Please note that deleting data, or formatting the SD Memory Cards or the
built-in memory does not completely erase the original data. Deleted files
can sometimes be recovered using commercially available software. It is
user’s responsibility to ensure the privacy of such data.
Others
Write-protect
switch
PentaxWG20_QSG.book Page 7 Tuesday, February 4, 2014 11:36 AM

8
OK
O KOK
MENU
C a n c e lCancel
For capturing landscape
views. Enhances colors
of sky and foliage
L a n d s c a p eLandscape 1 / 21/2
Checking the Contents of the Package
Check that your camera comes complete with the items listed
below.
PCamera (RICOH WG-20) PSoftware (CD-ROM) S-SW147
PUSB cable (I-USB7) PRechargeable lithium-ion battery
(D-LI92)
PBattery charger (D-BC92) PC plug cord
PStrap (O-ST104)
POperating Manual
PMacro stand (O-MS1)
OQuick Guide (this guide)
PentaxWG20_QSG.book Page 8 Tuesday, February 4, 2014 11:36 AM

9
ront
Back
Flash
Power switch/Power lamp (green)
Shutter release button
Lens
Speaker/Microphone
Self timer lamp/
Focus assist
Remote control
receiver
Macro light
Terminal cover
Display
HDMI terminal
Terminal cover lock lever
Battery lock lever
Tripod socket
Battery/card cover
lock lever
Battery/card cover
PC/ V terminal
Names of Parts and Monitor Indicators
In this Quick Guide, the arrow keys
to be pressed are indicated as
shown on the right.
PentaxWG20_QSG.book Page 9 Tuesday, February 4, 2014 11:36 AM

10
Monitor Indicators
Following indicators are displayed in the still picture capture mode.
Battery Level Indicator
You can check the battery level by the indicator on the display.
Screen Display Battery Status
(green) Adequate power remains.
(green) Battery is running low.
(yellow) Battery is running very low.
(red) Battery is exhausted.
[Battery depleted] The camera turns o a ter this message appears.
Normal display in the Still Picture Capture Mode
38
P
14:21 4 : 2 504/04/'140 4 / 0 4 / ' 1 4
04/04/'14 14:25
+1.0
1/250
F3.5
DATE
Focus mode
+Built-in memory
(without card)
?SD Memory Card
rCard is write-protected
No icon : Hometown
: Destination
Eye-Fi communication status
Memory status
Flash mode
Shooting mode
Battery level
Face Detection
Camera shake
reduction
Aperture
Drive mode
EV compensation
Date imprint
setting
emaining image
storage capacity
World Time setting
D- ange Setting
Focus frame Date and
time
Digital zoom icon
Shutter speed
PentaxWG20_QSG.book Page 10 Tuesday, February 4, 2014 11:36 AM

11
Prepare your camera for use before you begin using it.
Attaching
the Strap
Attach the strap supplied
with the camera as shown
in the illustration.
Installing the Battery and S Memory Card
Install the battery and SD
Memory ard as shown in
the illustration.
* The SD Memory Card is sold separately.
Battery/card cover
Battery
Battery
lock lever
Th insid of th batt ry/card and t rminal cov rs ar not wat rproof
•In locations where the camera is exposed to water or dirt such as
underwater, at the beach, in a kitchen, etc., make sure that the
battery/card and terminal cover lock levers are firmly locked so that
they won't open unexpectedly. Do not open the covers in such
locations.
•When removing the battery or card, avoid surroundings where the
camera may be exposed to water or dirt, and make sure the camera,
battery, card, and your hands are completely dry.
Preparing the Camera for Use
1
1
Battery/card cover lock lever
SD Memory Card socket
SD Memory Card
PentaxWG20_QSG.book Page 11 Tuesday, February 4, 2014 11:36 AM

12
Press the Power Switch
The camera turns on and is ready to take still
pictures. Press the power switch again to turn
the camera off.
Make the Initial Settings
The [Language/ ] screen appears when the camera is turned on
for the first time. Select the desired language and then set the date
and time.
Use the four-way controller
(2345) to select the desired
language.
Press the 4 button.
The [Initial Setting] screen
appears.
If you accidentally select the wrong
language and press the 4 button,
press the four-way controller (5), use
the four-way controller (2345) to
select the desired language, and then
press the 4 button. The [Initial
Setting] screen appears in the
selected language.
MENU OK
Cancel OK
1
2
2
Memo
MENU
Cancel
Initial Setting
Hometown
New York
Settings complete
English
DST
OFF
OFF
OFF
Turning the Camera On
2
2
PentaxWG20_QSG.book Page 12 Tuesday, February 4, 2014 11:36 AM

13
Press the four-way controller (3)
to move the frame to
[WHometown].
Press the four-way controller (5).
The [WHometown] screen
appears.
Use the four-way controller (45)
to choose a city.
Press the four-way controller (3)
to move the frame to [DST] (Daylight Saving Time).
Use the four-way controller (45) to select O or P and press the
4 button.
The [Initial Setting] screen reappears.
Press the four-way controller (3) to select [Settings complete]
and press the 4 button.
The [Date Adjustment] screen appears.
Press the four-way controller (5)
to select [mm/dd/yy], then use the
four-way controller (23) to
choose the date format.
Press the four-way controller (5) to select [24h], then use the
four-way controller (23) to select [24h] (24-hour display) or
[12h] (12-hour display).
MENU
Cancel
Initial Setting
Hometown
New York
Settings complete
English
DST
OFF
OFF
OFF
3
MENU
Cancel
City
DST
New York
Hometown
OK
OK
4
5
6
7
8
MENU
Cancel
Date Adjustment
Date Format
mm /dd/yy 24 h
Date
Time
01/01/2014
00:00
Settings complete
9
10
PentaxWG20_QSG.book Page 13 Tuesday, February 4, 2014 11:36 AM

14
Press the four-way controller (5), then press the four-way
controller (3) to move the frame to [Date].
Press the four-way controller (5) to select [01] (month),
[01] (day) or [2014] (year), then use the four-way controller (23)
to set the current date and time.
Press the four-way controller (5), then press the four-way
controller (3) to move the frame to [Time].
Set the time in the same manner as in . Then press the
four-way controller (5).
Press the four-way controller (3)
to select [Settings complete] and
press the 4 button.
11
12
13
14
12
MENU
Cancel
Date Adjustment
Date Format
mm /dd/yy
24 h
Date
Time
01/01/2014
00:00
Settings complete
OK
OK
15
15
PentaxWG20_QSG.book Page 14 Tuesday, February 4, 2014 11:36 AM

15
Formatting an S Memory Card
Use this camera to format (initialize) an SD Memory ard that is
unused or has been used on another camera or digital device.
Be aware that formatting will delete all the data stored in the
SD Memory ard.
PentaxWG20_QSG.book Page 15 Tuesday, February 4, 2014 11:36 AM

16
Aim the camera at the subject, then press the shutter release button.
The flash discharges automatically depending on the brightness.
Frame the subject using the focus frame on the display.
Press the w/x button to change the captured area.
Press the shutter release button halfway.
The focus frame on the display turns green if the subject is in
focus.
Press the shutter release button
fully.
The picture is taken.
2
1
2
2
Widens the area
that is captured by
the camera
Enlarges the
subject
2
3
F4.6
1/250
38
2
4
Taking Pictures
3
3
PentaxWG20_QSG.book Page 16 Tuesday, February 4, 2014 11:36 AM

17
Selecting the Flash Mode
Each time you press the four-way controller (4), the flash mode
switches between the following modes.
•The functions available in apture mode may be different.
Selecting the rive Mode
Each time you press the four-way controller (2), the drive mode
switches between the following modes.
Auto
lash Off
lash On
Auto + Red-eye
lash On + Red-eye
Memo
Standard (single-frame)
10 sec. Self-timer
3-sec Remote Control
PentaxWG20_QSG.book Page 17 Tuesday, February 4, 2014 11:36 AM

18
•The functions available in apture mode may be different.
•You can select Z (2 sec. Self-timer) by pressing the four-way
controller (3) and then (5) after selecting g (10 sec. Self-timer).
•You can select h (0-sec Remote ontrol) by pressing the four-way
controller (3) and then (5) after selecting i (3-sec Remote
ontrol).
Selecting the Focus Mode
Each time you press the four-way controller (5), the focus mode
switches between the following modes.
Memo
Standard
Macro
Pan ocus
Infinity
Manual ocus
1cm Macro
PentaxWG20_QSG.book Page 18 Tuesday, February 4, 2014 11:36 AM
