RIDGID R84089 User manual

OPERATOR’S MANUAL
JOBSITE RADIO
MANUEL D’UTILISATION
RADIO DE CHANTIER
MANUAL DEL OPERADOR
RADIO PARA LA OBRA
R84089
To register your RIDGID product, please visit: register.ridgidpower.com
Pour enregistrer votre produit de RIDGID, s’il vous plaît la visite : register.ridgidpower.com
Para registrar su producto de RIDGID, por favor visita: register.ridgidpower.com
WARNING:
To reduce the risk of injury, the
user must read and understand the
operator’s manual before using this
product.
Important Safety Instructions..........2-4
Symbols...........................................4-5
Electrical..........................................5-6
Assembly............................................6
Operation.........................................6-8
Maintenance.......................................8
Illustrations ....................................9-10
Parts Ordering/
Service ................................Back page
Consignes de sécurité importantes 2-4
Symboles.........................................4-5
Caractéristiques électriques............5-6
Assemblage........................................6
Utilisation.........................................6-8
Entretien .............................................8
Illustrations ....................................9-10
Commande de pièces/
dépannage ........................Page arrière
Instrucciones de seguridad
importantes.....................................2-4
Símbolos .........................................4-5
Aspectos eléctricas.........................5-6
Armado...............................................5
Funcionamiento...............................6-8
Mantenimiento....................................8
Ilustraciones ..................................9-10
Pedidos de repuestos/
servicio.......................... Pág. posterior
AVERTISSEMENT :
Pour réduire les risques de blessures,
l’utilisateur doit lire et veiller à bien
comprendre le manuel d’utilisation
avant d’utiliser ce produit.
ADVERTENCIA:
Para reducir el riesgo de lesiones, el
usuario debe leer y comprender el
manual del operador antes de usar
este producto.
INCLUDES: Radio, AC/DC adaptor,
Operator’s Manual
TABLE OF CONTENTS
****************
INCLUT : Radio, adaptateur CA/CC,
manuel d’utilisation
TABLE DES MATIÈRES
****************
INCLUYE : Radio, adaptador de
CA/CC, manual del operador
ÍNDICE DE CONTENIDO
****************
SAVE THIS MANUAL
FOR FUTURE REFERENCE
CONSERVER CE MANUEL
POUR FUTURE RÉFÉRENCE
GUARDE ESTE MANUAL
PARA FUTURAS CONSULTAS

2 - English
IMPORTANT SAFETY INSTRUCTIONS
WARNING!
READ THESE INSTRUCTIONS. Failure to follow
all instructions listed below, may result in electric
shock, fire and/or serious personal injury.
KEEP THESE INSTRUCTIONS
HEED ALL WARNINGS
FOLLOW ALL INSTRUCTIONS
Do not use this apparatus near water.
Clean only with dry cloth.
Do not block any ventilation openings. Install in ac-
cordance with the manufacturer’s instructions.
Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug
has two blades and a third grounding prong. The wide
blade or the third prong are provided for your safety. If
the provided plug does not fit into your outlet,consult an
electrician for replacement of the obsolete outlet.
Protect the power cord from being walked on or
pinched particularly at plugs, convenience recepta-
cles, and the point where they exit from the apparatus.
Only use attachments/accessories specified by the
manufacturer.
Unplug this apparatus during lightning storms or when
unused for long periods of time.
Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally,
or has been dropped.
When servicing a product, use only identical replace-
ment parts. Follow instructions in the Maintenance
section of this manual. Use of unauthorized parts or
failure to follow Maintenance instructions may create a
risk of shock or injury.
Know your product. Read operator’s manual care-
fully. Learn its applications and limitations, as well as
the specific potential hazards related to this product.
Following this rule will reduce the risk of electric shock,
fire, or serious injury.
Do not operate products in explosive atmospheres,
such as in the presence of flammable liquids, gases,
or dust. Products create sparks which may ignite the
dust or fumes.
ELECTRICAL SAFETY
A battery operated product with integral batteries or
a separate battery pack must be recharged only with
the specified charger for the battery. A charger that
may be suitable for one type of battery may create a risk
of fire when used with another battery.
Use battery operated product only with specifically
designated battery pack. Use of any other batteries
may create a risk of fire.
Use this product only with batteries and chargers
listed in tool/appliance/battery pack/charger correla-
tion supplement 988000-302.
WARNING: To reduce the risk of fire or electric shock,
do not expose to water or rain.
PERSONAL SAFETY
Do not use on a ladder or unstable support. Stable
footing on a solid surface enables better control of the
product in unexpected situations.
Do not use the radio to listen to music or other audio
programs while operating machinery. Doing so may
cause distractions that could result in serious personal
injury.
This radio is capable of producing sound levels that
can be dangerous to long-term hearing. Listening to
music at high volume for any period of time may cause
noise-induced hearing loss. The higher the volume, the
less time required before your hearing may be affected.
PRODUCT USE AND CARE
When battery pack is not in use, keep it away from
other metal objects like: paper clips, coins, keys, nails,
screws, or other small metal objects that can make
a connection from one terminal to another. Shorting
the battery terminals together may cause sparks, burns,
or a fire.
Keep the radio and its handle dry, clean and free from
oil and grease. Always use a clean cloth when clean-
ing. Never use brake fluids, gasoline, petroleum-based
products, or any strong solvents to clean the radio.
Following this rule will reduce the risk of loss of control
and deterioration of the enclosure plastic.
Battery products do not have to be plugged into an
electrical outlet; therefore, they are always in operat-
ing condition. Be aware of possible hazards when not
using your battery product or when changing acces-
sories. Following this rule will reduce the risk of electric
shock, fire, or serious personal injury.
Do not place battery products or their batteries near
fire or heat. This will reduce the risk of explosion and
possibly injury.
Do not crush, drop or damage battery pack. Do not
use a battery pack or charger that has been dropped

3 - English
IMPORTANT SAFETY INSTRUCTIONS
or received a sharp blow. A damaged battery is subject
to explosion. Properly dispose of a dropped or damaged
battery immediately.
Batteries can explode in the presence of a source
of ignition, such as a pilot light. To reduce the risk of
serious personal injury, never use any cordless product
in the presence of open flame. An exploded battery can
propel debris and chemicals. If exposed, flush with water
immediately.
Do not charge battery product in a damp or wet lo-
cation. Following this rule will reduce the risk of electric
shock.
Under extreme usage or temperature conditions, bat-
tery leakage may occur. If liquid comes in contact with
your skin, wash immediately with soap and water. If
liquid gets into your eyes, flush them with clean water
for at least 10 minutes, then seek immediate medical
attention. Following this rule will reduce the risk of seri-
ous personal injury.
To reduce the risk of personal injury and electric
shock, the product should not be played with or
placed where small children can reach it.
If the power supply cord is damaged, it must be re-
placed only by the manufacturer or by an authorized
service center to avoid risk.
Save these instructions. Refer to them frequently and
use them to instruct others who may use this product. If
you loan someone this product, loan them these instruc-
tions also.
BLUETOOTH®LICENSE STATEMENT
The BLUETOOTH®word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such
marks by TECHTRONIC POWER TOOLS TECHNOLOGY LIMITED is under license. Other trademarks and trade names are
those of their respective owners.
FCC COMPLIANCE
NOTE: This device complies with part 15 of the FCC RULES. Operation is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this device must accept any interference received, including interference
that may cause undesired operation.
WARNING: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help
Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or
lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the an-
tenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that
necessary for successful communication.
FCC RADIATION EXPOSURE STATEMENT
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment
should be installed and operated with minimum distance of 20 cm between the radiator and your body.
IC ID WARNING
This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two
conditions: (1) this device may not cause interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation of this device.

4 - English
SYMBOLS
Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper inter-
pretation of these symbols will allow you to operate the product better and safer.
SYMBOL NAME DESIGNATION/EXPLANATION
Safety Alert Indicates a potential personal injury hazard.
Read Operator’s Manual To reduce the risk of injury, user must read and understand opera-
tor’s manual before using this product.
Eye Protection Always wear eye protection with side shields marked to comply
with ANSI Z87.1.
Electric Shock Alert Indicates uninsulated material within the unit that may cause
electrical shock. Do not remove product covering.
Wet Conditions Alert Do not expose to rain or use in damp locations.
The following signal words and meanings are intended to explain the levels of risk associated with this product.
SYMBOL SIGNAL MEANING
DANGER: Indicates a hazardous situation, which, if not avoided, will result in death or
serious injury.
WARNING: Indicates a hazardous situation, which, if not avoided, could result in death or
serious injury.
CAUTION: Indicates a hazardous situation, that, if not avoided, may result in minor or
moderate injury.
NOTICE:(Without Safety Alert Symbol) Indicates information considered important, but
not related to a potential injury (e.g. messages relating to property damage).
SUPPLIER’S DECLARATION OF CONFORMITY
RIDGID JOBSITE RADIO Model: R84089
The responsible party declares that this device complies with Part 15 of the FCC Rules. Operation is subject to the follow-
ing two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Responsible Party: Techtronic Cordless GP
Address: 115 Innovation Way, Anderson, SC 29621
Telephone: [phone]
Printed Name/Title: John Collins / Director Regulatory
Signature:
IMPORTANT SAFETY INSTRUCTIONS

5 - English
DOUBLE INSULATION
Double insulation is a concept in safety in electric products,
which eliminates the need for the usual three-wire grounded
power cord. All exposed metal parts are isolated from ener-
gized internal components with protecting insulation.
WARNING:
The double insulated system is intended to protect
the user from shock resulting from a break in the
product’s internal wiring. Observe all normal safety
precautions to avoid electrical shock.
NOTE: Servicing of a product with double insulation requires
extreme care and knowledge of the system and should be
performed only by a qualified service technician. For service,
we suggest you return the product to your nearest authorized
service center for repair. Always use original factory replace-
ment parts when servicing.
ELECTRICAL CONNECTION
This product should be connected to the included 1.5 m
18V AC/DC adaptor.Do not operate this product on direct
current (DC) through the power cord. If the product does
not operate when plugged into an outlet, double-check the
power supply.
EXTENSION CORDS
When using a product at a considerable distance from a
power source, be sure to use an extension cord that has
the capacity to handle the current the product will draw. An
undersized cord will cause a drop in line voltage, resulting in
overheating and loss of power. Use the chart to determine
the minimum wire size required in an extension cord. Only
round jacketed cords listed by Underwriter’s Laboratories
(UL) should be used.
When using this product outdoors, use an extension
cord that is designed for outside use. This type of cord is
designated with “WA” or “W” on the cord’s jacket.
Before using any extension cord, inspect it for loose or
exposed wires and cut or worn insulation.
**Ampere rating (on product data plate)
0-2.0 2.1-3.4 3.5-5.0 5.1-7.0 7.1-12.0 12.1-16.0
Cord Length Wire Size (A.W.G.)
25' 16 16 16 16 14 14
50' 16 16 16 14 14 12
100' 16 16 14 12 10 —
**Used on 12 gauge - 20 amp circuit.
NOTE: AWG = American Wire Gauge
ELECTRICAL
Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper inter-
pretation of these symbols will allow you to operate the product better and safer.
SYMBOL NAME DESIGNATION/EXPLANATION
Recycle Symbol
This product uses lithium-ion (Li-ion) batteries. Local, state, or
federal laws may prohibit disposal of batteries in ordinary trash.
Consult your local waste authority for information regarding
available recycling and/or disposal options.
V Volts Voltage
A Amperes Current
Hz Hertz Frequency (cycles per second)
W Watt Power
min Minutes Time
Direct Current Type or a characteristic of current
Alternating Current Type of current
Class II Tool Double-insulated construction
SYMBOLS
