RIDGID wd7000 User manual

WD7000
SMARTCART
11 U.S. GALLONS/41 LITERS
SMARTCART WET/DRY VAC
FOR QUESTIONS OR INFORMATION CONTACT US AT
CALL 1-800-4-RIDGID (1-800-474-3443) OR
www.ridgidvacs.com
Part No. SP6659 Printed in Mexico
OPERATOR’S MANUAL
SAVE THIS MANUAL FOR FUTURE REFERENCE
WARNING:
To reduce the risk of injury, the user must read and understand the operator’s
manual before using this product.
!
Thank you for buying a RIDGID product.
SP6659-3 WD7000 ES.qxd 3/26/08 9:44 AM Page 1

Safety is a combination of common sense,
staying alert, and knowing how your
wet/dry vacuum cleaner (“Vac”) works.
Safety Signal Words
DANGER: Indicates an imminently
hazardous situation which, if not avoided,
will result in death or serious injury.
WARNING: Indicates a potentially
hazardous situation which, if not avoided,
could result in death or serious injury.
CAUTION: Indicates a potentially
hazardous situation which, if not avoided,
may result in minor or moderate injury, or
property damage.
When using your Vac, always follow basic
safety precautions including the following:
WARNING - To
reduce the risk of fire, electric shock,
or injury:
• Read and understand this operator’s
manual and all labels on the Wet/Dry
Vac before operating.
• Use only as described in this manual.
• Do not leave Vac running while
unattended.
• Sparks inside the motor can ignite
flammable vapors or dust. To reduce
the risk of fire or explosion, do not
vacuum or use near flammable or 2
Table of Contents
Section Page
Important Safety Instructions. . . . . . . . . 2
Introduction . . . . . . . . . . . . . . . . . . . . . . 4
Unpacking and Checking
Carton Contents . . . . . . . . . . . . . . . . . 5
Removing/Installing/Storing
The Metal Handle. . . . . . . . . . . . . . . . 6
Replacement Filter Assembly . . . . . . . . 7
Wet/Dry Vac Assembly . . . . . . . . . . . . . 8
Dust Drum Assembly . . . . . . . . . . . . . 8
Insert Hose . . . . . . . . . . . . . . . . . . . . . 8
Wheel Assembly . . . . . . . . . . . . . . . . . . 9
Operation. . . . . . . . . . . . . . . . . . . . . . . 10
Vacuuming Dry Materials . . . . . . . . . 11
Vacuuming Liquids . . . . . . . . . . . . . . 11
Emptying the Drum. . . . . . . . . . . . . . 11
Moving the Wet/Dry Vac. . . . . . . . . . 12
Section Page
Blowing Feature . . . . . . . . . . . . . . . . 12
Storage . . . . . . . . . . . . . . . . . . . . . . . . 13
Hose Storage . . . . . . . . . . . . . . . . . . 13
Accessory Storage . . . . . . . . . . . . . . 13
Cord Wrap . . . . . . . . . . . . . . . . . . . . 13
Handle Storage . . . . . . . . . . . . . . . . 13
Maintenance . . . . . . . . . . . . . . . . . . . . 14
Filter . . . . . . . . . . . . . . . . . . . . . . . . . 14
Cleaning & Disinfecting
the Wet/Dry Vac . . . . . . . . . . . . . . 15
Casters & Wheels . . . . . . . . . . . . . . 15
Frame & Handles . . . . . . . . . . . . . . . 15
Filter Replacement . . . . . . . . . . . . . . . 16
Repair Parts. . . . . . . . . . . . . . . . . . . . . 18
Warranty . . . . . . . . . . . . . . . . . . . . . . . 20
IMPORTANT SAFETY INSTRUCTIONS
!
!
!
!
combustible liquids, gases, or
explosive dusts, such as gasoline or
other fuels, lighter fluid, cleaners, oil-
based paints, natural gas, hydrogen,
coal dust, magnesium dust, aluminum
dust, grain dust, or gun powder.
• Do not vacuum anything that is burning
or smoking, such as cigarettes,
matches, or hot ashes.
• Do not vacuum drywall dust or cold
fireplace soot or ash with standard
filter. This is a very fine dust which may
be exhausted back into the air. Use a
fine dust filter instead.
• To reduce the risk of health hazards
from vapors or dust, do not vacuum
toxic materials.
• Do not use or store near hazardous
materials.
•WARNING: The power cord on this
product contains lead, a chemical
known in the State of California to
cause birth defects or other
reproductive harm.
Wash hands
after handling.
• To reduce the risk of electric shock, do
not expose to rain or allow liquid to
enter motor compartment. Store
indoors.
SP6659-3 WD7000 ES.qxd 3/26/08 9:44 AM Page 2

CAUTION:
• To reduce the risk of hearing damage,
wear ear protectors when using for
extended hours or using in a noisy area.
• For dusty operations, wear dust mask.
NOTE: Static shocks are common in
dry areas or when the relative humidity of
the air is low. Vacuuming fine debris with
your Vac can deposit static charge on the
hose or on the Vac. The best remedy to
reduce the frequency of static shocks in
your home or when using this Vac is to
add moisture to the air with a humidifier.
!
• Do not allow to be used as a toy. Close
attention is necessary when used by or
near children.
• Do not use with a torn filter or without
the filter installed except when
vacuuming liquids as described in the
Operation section of this manual. Dry
debris ingested by the impeller may
damage the motor or be exhausted into
the air.
• Do not leave Vac when plugged in.
Unplug from outlet when not in use and
before servicing.
• Turn off Vac before unplugging.
• To reduce the risk of injury from
accidental starting, unplug power cord
before changing or cleaning filter.
• Do not unplug by pulling on cord. To
unplug, grasp the plug, not the cord.
• Do not use with damaged cord, plug or
other parts. If your Vac is not working
as it should, has missing parts, has
been dropped, damaged, left outdoors,
or dropped into water, return it to an
Authorized Service Center.
• Do not pull or carry by cord, use cord
as handle, close a door on cord, or pull
cord around sharp edges or corners.
Do not run Vac over cord. Keep cord
away from heated surfaces.
• Do not handle plug, switch, or the Vac
with wet hands.
• Do not put any object into ventilation
openings. Do not vacuum with any
ventilation openings blocked; keep free
of dust, lint, hair or anything that may
reduce air flow.
• Keep hair, loose clothing, fingers, and
all parts of body away from openings
and moving parts.
• To reduce the risk of falls, use extra
care when cleaning on stairs.
• To reduce the risk of back injury or
falls, do not lift a Vac that is heavy with
liquid or debris. Partially empty the
Vac by scooping or draining liquid to
make it comfortable to lift.
• To reduce the risk of personal injury or
damage to Vac, use only Ridgid
recommended accessories.
• When using as a blower:
- Direct air discharge only at work
area.
- Do not direct air at bystanders.
- Keep children away when blowing.
- Do not use blower for any job except
blowing dirt and debris.
- Do not use as a sprayer.
- Wear safety eyewear.
• To reduce the risk of eye injury, wear
safety eyewear. The operation of any
utility Vac or blower can result in
foreign objects being blown into the
eyes, which can result in severe eye
damage.
• To reduce the risk of being struck by, or
pulled down by, a rolling Vac, block the
casters when using on any uneven or
sloped surface.
• This Wet/Dry Vac is double-insulated,
eliminating the need for a separate
grounding system. Use only identical
replacement parts. Read the
instructions for Servicing Double-
Insulated Wet/Dry Vacs before
servicing.
• Use only extension cords that are rated
for outdoor use. Extension cords in
poor condition or too small in wire size
can pose fire and shock hazards.
To reduce the risk of these hazards,
be sure the cord is in good condition
and that the liquid does not contact the
connection. Do not use an extension
cord with conductors smaller than 16
gauge (AWG) in size. To reduce power
loss, use a 14 gauge extension cord if
25 to 50 ft. long and 12 gauge for 50 ft.
or longer.
3
SP6659-3 WD7000 ES.qxd 3/26/08 9:44 AM Page 3

4
Introduction
This SMARTCART Wet/Dry Vac is
intended for household use. It may be
used for vacuuming wet or dry media and
may be used as a blower.
Read this operator’s manual to familiarize
yourself with the product features and to
understand the specific usage of your
new Vac.
WARNING: For your own safety,
read and understand operator’s
manual. Do not run unattended. Do
not pick up hot ashes, coals, toxic,
flammable or other hazardous
materials. Do not use around
explosive liquids or vapors.
WARNING: To reduce the risk of
electric shock - do not expose to
rain - store indoors.
!
WARNING: To reduce the risk of
electric shock, always install float
before any wet pick-up operation.
!
WARNING: 50 Lb. weight limit.
Do not stand or sit on vac. Improper
use may cause injury.
!
To reduce the risk of fire or other
damage, do not use onboard
storage compartments to store oily
rags or containers with flammable,
explosive, corrosive or toxic
materials.
!
!
SAVE THIS MANUAL
Observe the following warnings that
appear on your Vac:
DOUBLE INSULATED
GROUNDING NOT REQUIRED.
WHEN SERVICING USE ONLY
IDENTICAL REPLACEMENT PARTS.
SP6659-3 WD7000 ES.qxd 3/26/08 9:44 AM Page 4

Unpacking and Checking Carton Contents
5
Refer to the assembly sketch for
positioning of parts.
Remove contents of carton. Check each
item against the Carton Contents List.
Call 1-800-4-RIDGID (1-800-474-3443) or
E-mail us at [email protected] if any parts
are damaged or missing.
9/16” Socket & Ratchet
Tools Required
Mallet9/16” Wrench
Carton Contents List
Key Description Qty
A Wet/Dry Vac Assembly.................1
B* Filter Nut ......................................1
C* Filter Plate....................................1
D* Filter 2-Stage ...............................1
E* Filter Support Assembly...............1
F Hose Assembly ............................1
G Utility Nozzle ................................1
H Wet Nozzle...................................1
ICrevice Nozzle.............................1
J Claw Nozzle.................................1
K Dusting Brush ..............................1
L Extension Handle.........................2
M 8” Wheel.......................................2
N Metal Handle................................1
O Operator’s Manual .......................1
Bag of Loose Parts “A”:
P 3” Caster ......................................2
Q Wheel Hub Adapter......................2
R Wheel Caps .................................2
Bag of Loose Parts “B”:
S 3/8” x 4” Bolt ................................2
T 3/8” x 1-1/2” Spacer.....................2
U Jam Nut........................................2
V Lock Washer ................................2
W Flat Washer..................................6
X Locknut ........................................2
* These items may come preassembled.
If they are not present in the carton,
check inside the drum to see if they are
preassembled.
J
I
N
O
L
SMARTCART
H
P
R
Q
S
T
U
V
W
X
M
A
K
G
F
*B
*C
*D
*E
SP6659-3 WD7000 ES.qxd 3/26/08 9:44 AM Page 5

Removing/Installing/Storing
The Metal Handle
6
Your metal handle comes packaged in
the dust drum. You must remove the
metal handle from the dust drum and
install the handle in the correct direction,
bent area facing away from the back of
the vac, before continuing. (Also remove
the 8” wheel and set aside for
installation).
Installing Handle
Press and hold release buttons while
installing handle into handle receptacles
in drum (See illustration).
NOTE: An audible snap of release
buttons indicates successful engagement
of handle.
Lowering Handle for Storage
To store Wet/Dry Vac, press and hold
release buttons while firmly sliding handle
down.
Removing Handle
Press and hold release buttons, as
shown. While firmly pushing in release
buttons, pull handle upwards to remove.
Press and
Hold Release
Buttons
Handle
Receptacle (2)
Release
Button (2)
Handle
SMARTCART
Pull Down and
Slide Dust Drum
Out of Wet/Dry
Vac Unit
Latch (2)
SP6659-3 WD7000 ES.qxd 3/26/08 9:44 AM Page 6

7
NOTE: The filter is accessed by
unlatching and removing the dust drum.
The filter support assembly can be
removed by grasping the filter support as
shown in the illustrations below.
1. Carefully slide the filter over the center
ring until the filter stops against the
filter support.
2. Place the filter plate and the filter nut
onto the threaded stud and tighten it
down. Finger tighten only.
NOTE: Lever of filter nut should be away
from plate as shown.
IMPORTANT: Do not overtighten as this
may deform or crack the filter plate,
center ring or filter.
Replacement Filter Assembly
WARNING: For your own safety,
never connect plug to power source
outlet until all assembly steps are
complete and you have read and
understood the safety and operation
instructions. Do not operate vac
with any parts damaged or missing.
Filter
Support
Center Ring
THIS SIDE
TOWARDS LID
Open End
of Float
Filter
Filter Nut
Filter Nut
Lever
Filter Plate
WARNING: To reduce the risk of
personal injury or damage to vac be
sure to keep hands, fingers, or any
other foreign objects out of the
center opening when assembling
the float.
!
!
SMARTCART
Pull Down and
Slide Dust Drum
Out of Wet/Dry
Vac Unit
Latch (2)
Dust
Drum
Filter Support
Assembly
SP6659-3 WD7000 ES.qxd 3/26/08 9:44 AM Page 7

8
Wet/Dry Vac Assembly
WARNING: To avoid ingesting
debris or water in the impeller and
damaging vac, never operate
without filter support assembly in
place.
!
SMARTCART
Pull Down and
Slide Dust Drum
Out of Wet/Dry
Vac Unit
Dust Drum
Wet/Dry
Vac Unit
Slot
Dust Drum Wheel
Latch
Latch
Holder Latch Unlocked
Latch Locked
Dust Drum Assembly
1. Slide the dust drum into the front of the
wet/dry vac unit when filter assembly is
complete. Position the dust drum
wheels into the drum area slots and
glide into place.
NOTE: When reinstalling the dust drum
and filter support assembly, ensure that
the front of the dust drum is flush with the
lid and motor cover assembly. The dust
drum should fit snugly into place. There
are two pins in the Wet/Dry vac unit that
must fit into the slots in the drum. This
ensures proper alignment. The dust drum
must be installed properly to ensure the
Wet/Dry vac functions correctly.
2. Pull the two latches on the front of the
dust drum up and over the latch
holders and press down firmly until
they snap in place. If the pins from the
lid and motor cover assembly are not
aligned, the latches will not lock.
Insert Hose
Insert the push button end of the hose
assembly into the inlet of the vac. The
hose should snap into place. To remove
the hose from the vac, press the release
button in the hose assembly and pull the
hose out of the vac inlet, as shown.
SMARTCART
Push
Button
Inlet Hose
SP6659-3 WD7000 ES.qxd 3/26/08 9:44 AM Page 8

Jam Nut
Lock Washer
Flat Washer
3/8" Bolt
Flat Washer
3/8" Bolt
Jam Nut
8" Wheel
Wheel Hub
Adapter
Wheel Ribs
Wheel Hub
Adapter Slots
Wheel
Lock
8" Wheel
Spacer
Flat Washer
Locknut
Wheel Cap
Locknut
9
Wheel Assembly
If any parts are missing or damage,
contact customer service. Do not attempt
to assemble unit until you have all the
parts.
1. Pull the dust drum clear of the
Wet/Dry Vac. Locate the two 8”
diameter wheels and the two bag
assemblies.
2. Prop a 2 x 4 wood block
approximately 12” long, under the
rear of the vac.
3. Place one flat washer onto the 3/8”
bolt and install into the hole in rear
panel. Push the bolt all the way
through wheel hub.
4. Place one flat washer and one lock
washer onto the bolt.
5. Screw on one jam nut and tighten
with a 9/16” wrench. You will need to
hold the head of the bolt with the
9/16” socket to securely tighten the
jam nut.
6. Insert the wheel hub adapter onto the
8” wheel. Make sure that the slots on
the wheel adapter fits snugly into the
ribs of the wheel. Place adapter and
wheel onto bolt.
7. Insert one spacer on the bolt and
push through the wheel opening.
8. Install one flat washer and one
locknut. Tighten locknut securely.
9. Using a rubber mallet, gently tap the
wheel caps onto each wheel. This is
required on both the left and right
sides.
10. Lock the rear wheels by stepping
down on the wheel locks to secure
unit. Tilt vac back to expose the front
wheel area.
2 x 4 Wood Block
Back of Vac
SP6659-3 WD7000 ES.qxd 3/26/08 9:44 AM Page 9

10
Caster Stem
Socket
Caster Ball
Caster
Operation
WARNING
To reduce the risk of fire or explosion, do not operate this vac in areas with
flammable gases, vapors or explosive dust in the air. Flammable gases or
vapors include but are not limited to; lighter fluid, solvent type cleaners,
oil-base paints, gasoline, alcohol or aerosol sprays. Explosive dusts include
but are not limited to; coal, magnesium, aluminum, grain or gun powder.
Do not vacuum explosive dust, flammable or combustible liquids or hot
ashes. Do not use this vac as a sprayer. To reduce the risk of health hazards
from vapors or dusts, do not vacuum toxic materials.
To reduce the risk of electric shock, this
appliance has a polarized plug (one
blade is wider than the other). This plug
will fit in a polarized outlet only one way.
If the plug does not fit fully in the outlet,
reverse the plug. If it still does not fit,
contact a qualified electrician to install the
proper outlet. Do not change the plug in
any way.
Familiarize yourself with the accessories
included with the vac. Each accessory may
be used in various ways for vacuuming
and blowing debris. Here is a list of the
accessories and their uses.
CAUTION: To reduce risk of
hearing damage, wear ear
protectors when using the vac for
extended hours or when using it in
a noisy area.
WARNING: The operation of any
utility vac can result in foreign
objects being blown into the eyes,
which can result in severe eye
damage. Always wear safety
eyewear complying with ANSI Z87.1
(or in Canada, CSA Z94.3) before
starting operation. Safety eyewear
are available at many local retail
stores.
!
!
!
=OFF =ON
11. Push the caster on until the ball on
the caster stem is inserted all the way
onto the socket. You will hear the ball
snap into the socket and the caster
will swivel easily when positioned
correctly.
After you plug the power cord into the
outlet, turn the unit on by pushing the
switch from position "O" to position "l". The
symbols used on the switch actuator are
international "On & Off" symbols. "O" is the
symbol for "OFF" and "l" is the symbol for
"ON".
SMARTCART
WARNING: To avoid ingesting
debris or liquids in the impeller and
damaging vac, never operate
without filter support assembly in
place.
!
Utility Nozzle - General purpose nozzle for
most vacuuming applications.
Wet Nozzle - Used for wet pickup on
smooth surfaces to pick up liquid and dry
the surface in one stroke.
SP6659-3 WD7000 ES.qxd 3/26/08 9:44 AM Page 10

11
1. The vac comes equipped with a drain
for easy emptying of liquids. Simply
unscrew the drain cap and lift the
opposite side slightly to empty the
drum.
2. Another option is to remove the drum
from the vac.
3. Pull the drum out from the vac by
pulling down and sliding the drum on
the axle support under the drum.
WARNING: To reduce the risk of
injury from accidental starting,
unplug power cord before emptying
the drum.
WARNING: To reduce the risk of
back injury or falls, do not lift a vac
heavy with liquid or debris. Scoop
or drain enough contents out to
make the vac light enough to lift
comfortably.
Emptying the Drum
Hose - Provides transfer of vacuum or
blowing capability to work site. Provides
the means of attaching extension handles
and nozzles.
Crevice Tool - Use to pick up debris in
hard to reach locations.
Vacuuming Dry Materials
1. The filter must always be in correct
position to reduce the risk of leaks and
possible damage to vac.
2. Your Wet/Dry Vac comes with the
VF5000 Filter installed. When using
your vac to pick up very fine dust, it will
be necessary for you to empty the
drum and clean the filter at more
frequent intervals to maintain peak vac
performance.
NOTE: A dry filter is necessary to pick up
dry material. If you use your vac to pick
up dust when the filter is wet, the filter will
clog quickly and be very difficult to clean.
Vacuuming Liquids
1. When picking up small amounts of
liquid the filter may be left in place.
2. When picking up large amounts of
liquid we recommend that the filter be
removed. If the filter is not removed, it
will become saturated and misting may
appear in the exhaust.
3. When the liquid in the drum reaches a
predetermined level, the float
mechanism will rise automatically to cut
off air-flow. When this happens, turn off
the vac, unplug the power cord, and
!
!
WARNING: To reduce the risk of
fire or electric shock, do not run vac
unattended.
!
empty the drum. You will know that the
float has risen because vac airflow
ceases and the motor noise will become
higher in pitch, due to increased motor
speed.
4. After using the vac to pick up liquids,
allow the filter to dry to reduce the risk of
mildew and damage to the filter.
IMPORTANT: To reduce the risk of
damage to the vac do not run motor with
float in raised position.
Axle
Support
Dust
Drum
Drain
SMARTCART
Pull Down and
Slide Dust Drum
Out of Wet/Dry
Vac Unit
Claw Nozzle - Used for wet or dry pickup.
Dusting Brush - Dry pickup of dust and
dirt debris.
Car Nozzle (not provided) - Dry pickup
nozzle for car interiors and most
upholstery cleaning.
Extension Handles - These handles can
be connected together and provides
additional length for more reach.
SP6659-3 WD7000 ES.qxd 3/26/08 9:44 AM Page 11

12
1. Locate blowing port of your vac.
2. Insert the locking end of the hose
assembly into the blowing port of the
vac. The hose should snap into place.
To remove the hose from the vac,
press the release button in the hose
assembly and pull the hose out of the
vac inlet.
Pull Up to Unlock
Wheel Locks
Blowing Port
4. Dump the drum contents into the
proper waste disposal container.
5. Replace the drum by reinserting into
the cavity and push until it snaps into
place.
Moving the Wet/Dry Vac
To maneuver the vac, the metal handle in
the rear of the unit should be positioned
in the upright position for ease of
movement. Be sure to unlock the back
wheels by pulling up on the wheel locks
before moving the vac.
Blowing Feature
Your vac features a blowing port. It can
blow sawdust and other debris. Follow
the steps below to use your vac as a
blower.
WARNING: Always wear safety
eyewear complying with ANSI Z87.1
(or in Canada, CSA Z94.3) before
using as a blower.
CAUTION: Wear a dust mask if
blowing creates dust which might
be inhaled.
CAUTION: To reduce the risk of
hearing damage wear ear protectors
when using the vac/blower for
extended hours or when using in a
noisy area.
WARNING: To reduce the risk of
injury to bystanders, keep them
clear of blowing debris.
!
!
!
!
Locking End
Hose
Assembly
Operation (continued)
3. (Optional) Attach extension handle to
opposite end of hose, then place the
crevice tool on the wand.
4. Turn vac on and you are ready to use
your vac as a blower.
SP6659-3 WD7000 ES.qxd 3/26/08 9:44 AM Page 12

Hose Storage
The hose may be stored by placing in the
top removable tray. You may also open the
hinged top to access the hose storage.
Accessory Storage
Your wet/dry vac accessories may be stored
in the removable lower tray. Cleaning
supplies may be stored in the storage area
on the back of the unit between the wheels.
The extension handles snap into place at
the the back of the vac in the extension
handle storage areas.
13
Storage
Hose Storage Tray
Hinged Top Access
to Hose Storage
Accessory
Storage Tray
Cleaning
Storage
Area
Cord Wrap Area
Cleaning
Supplies
Extension Handle
Storage
Cord Wrap
When vacuuming is complete, unplug the
cord and wrap it around the cord wrap
area located on the back of the unit.
Press and
Hold Release
Buttons
While Sliding
Handle
Downward
Handle
Handle Storage
When storing the Wet/Dry Vac, press and
hold release buttons while firmly sliding
handle down.
SP6659-3 WD7000 ES.qxd 3/26/08 9:44 AM Page 13

14
Maintenance
Filter Cleaning
Your filter should be cleaned often to
maintain peak vac performance.
Be sure the filter is dry before storing or
picking up dry debris.
IMPORTANT: After cleaning, check the
filter for tears or small holes. Do not use
a filter with holes or tears in it. Even a
small hole can cause a lot of dust to
come out of your vac. Replace it
immediately.
Filter Removal
To remove the filter for cleaning or
replacement, unscrew the filter nut from
the filter support assembly and lift off filter
and filter plate.
WARNING: To reduce the risk of
injury from accidental starting,
unplug power cord before changing
or cleaning filter.
NOTE: The filter is made of high quality
paper designed to stop very small
particles of dust. The filter can be used
for dry pick up or small amounts of liquid.
Handle the filter carefully when removing
to clean or installing it. Creases in the
filter pleats may occur from installation
but will not affect the performance of the
filter.
Filter IMPORTANT: To avoid damage to the
blower wheel and motor, always reinstall
the filter before using the vac for dry
material pick-up.
Cleaning A Dry Filter
1. Some removal of dry debris can be
accomplished without removing the
filter from the vac. Slap your hand on
top of the lid while the vac is turned
off.
2. For best cleaning results due to
accumulated dust, clean the filter in an
open area. Cleaning SHOULD be
done outdoors and not in the living
quarters.
3. After filter removal from vac, remove
the dry debris by gently tapping filter
against the inside wall of your dust
drum. The debris will loosen and fall.
4. For thorough cleaning of dry filter with
fine dust (no debris), run water
through it as described under
"Cleaning A Wet Filter".
WARNING: Do not operate with
the float removed. It prevents liquid
from entering the impeller and
damaging the motor.
!
!
Cleaning A Wet Filter
After filter is removed, run water through
the filter from a hose or spigot. Take care
that water pressure from the hose is not
strong enough to damage filter.
Installation
Refer to page 7 "Replacement Filter
Assembly" Section of this manual.
Allow the filter to dry before reinstalling
and storing the vac.
SP6659-3 WD7000 ES.qxd 3/26/08 9:44 AM Page 14

Cleaning and Disinfecting the
Wet/Dry Vac
To keep your Wet/Dry Vac looking its
best, clean the outside with a cloth
dampened with warm water and mild
soap.
To clean the drum:
1. Dump debris out.
2. Wash drum thoroughly with warm
water and mild soap.
3. Wipe out with dry cloth.
Before prolonged storage or as needed
(i.e.; after waste water pick up) the drum
should be disinfected.
To disinfect the drum:
1. Pour 1 gallon of water and 1 teaspoon
chlorine bleach into the drum.
2. Let solution stand for 20 minutes,
carefully swishing every few minutes,
making sure to wet all inside surfaces
of the drum.
3. Empty drum after 20 minutes. Rinse
with water until bleach smell is gone.
Allow drum to dry completely before
sealing the motor on the drum.
WARNING: To assure product
SAFETY and RELIABILITY, repairs
and adjustments should be
performed by Authorized Service
Centers, always using RIDGID
replacement parts.
Casters and Wheels
Should your cart squeak or become hard
to roll, you should place two or three
drops of general purpose oil on each
wheel at the axle. If your casters are
noisy, you may put a drop of oil on the
roller shaft to make them quieter.
Frame and Handles
Your metal handle is painted to prevent
rust, however, liquids and corrosive
debris should be wiped off with a soft
cloth should they come in contact with
the handle.
!
15
SP6659-3 WD7000 ES.qxd 3/26/08 9:44 AM Page 15

Filter Replacement
Which Replacement Filter Meets Your Needs?
Choosing a filter is as easy
as 1, 2, 3...
Standard
Filter
Filter System with
antimicrobial product protection
Fights and inhibits the growth
of mold, mildew and bacteria
that can shorten filter life
Microban®
Filter System with
antimicrobial product protection
Fights and inhibits the growth
of mold, mildew and bacteria
that can shorten filter life
Microban®
STEP UP STEP UP
Microban®
Microban®
HEPA
HEPA
HEPA
TRAPS 99.97%
OF PARTICLES
DOWN TO
.3 MICRONS
16
Applications VF4000 VF5000 VF6000
• Sawdust  
• Wet Pick-up  
• Typical Basement,  
Garage or Car Dirt
• Drywall Dust 
• Cold* Ashes
- BBQ Grill 
- Fireplace
* DO NOT VACUUM ANYTHING THAT IS BURNING OR SMOKING, SUCH AS CIGARETTES, MATCHES OR HOT ASHES.
• Antimicrobial
Protection
• Fine Indoor Particles
- Pet Dander
- Furnace Filter
- Dryer Lint
- Upholstery
• Cement Dust
• Pollen/Allergens
MICROBAN is a registered trademark of Mircoban Products Company
MAXIMIZE VACUUM PERFORMANCE WITH A NEW FILTER
Typical Replacement Frequency is 2 Times Per Year
SP6659-3 WD7000 ES.qxd 3/26/08 9:44 AM Page 16

Notes
17
SP6659-3 WD7000 ES.qxd 3/26/08 9:44 AM Page 17

Key
No. Part No. Description
1 510013 Actuator Assembly
2 832328 Power Head Assembly
3 832119 Filter Support Assembly
4 832120 Handle Assembly
5 832113 Dust Drum Assembly
6 832116 Drum Latch
7 73185 Drain Cap
8 830598 8” Wheel
9 VF5000 Filter - 2-Stage
10 73317 Filter Plate
11 73316 Filter Nut
12 VT1789 Utility Nozzle
13 VT2540 Claw Nozzle
14 VT1710 Wet Nozzle
15 829792 Crevice Tool
16 VT1701 Dusting Brush
17 831337-8 Hose Assembly
18 VT1708 Extension, Handle
19 509950 Bag Assembly (Casters)
20 509949 Bag Assembly (8” Wheel Hardware)
21 SP6659 Operator’s Manual
Repair Parts
11 Gallon SMARTCART Wet/Dry Vac
Model Number WD70000
RIDGID parts are available on-line at www.ridgidparts.com
Always order by Part Number - Not by Key Number
† These replacement parts may be available where you purchased your vac.
18
†
†
†
†
†
†
†
†
SP6659-3 WD7000 ES.qxd 3/26/08 9:44 AM Page 18

RIDGID parts are available on-line at www.ridgidparts.com
19 20
8
17
18
11
10
9
3
1
2
5
7
6
4
12
13
14
15
21
16
WARNING
SERVICING OF DOUBLE-INSULATED WET/DRY VAC
In a double-insulated Wet/Dry Vac, two systems of insulation are provided
instead of grounding. No grounding means is provided on a double-insulated
appliance, nor should a means for grounding be added. Servicing a double-
insulated Wet/Dry Vac requires extreme care and knowledge of the system,
and should be done only by qualified service personnel. Replacement parts
for a double-insulated Wet/Dry Vac must be identical to the parts they replace.
Your double-insulated Wet/Dry Vac is marked with the words "DOUBLE
INSULATED" and the symbol (square within a square) may also be
marked on the appliance.
To reduce the risk of injury from electrical shock, unplug power cord before
servicing the electrical parts of the Wet/Dry Vac.
!
19
SP6659-3 WD7000 ES.qxd 3/26/08 9:44 AM Page 19

Part No. SP6659 Form No. SP6659-3 Printed in Mexico 04/08
• What is covered
RIDGID® Wet/Dry Vacs are warranted to be free of defects in workmanship and material.
• How long coverage lasts
This warranty lasts for the lifetime of the RIDGID® Wet/Dry Vac.
• How to obtain service
To obtain the benefit of this warranty, please call 1-800-4-RIDGID (1-800-474-3443).
• What we will do to correct problems
Warranted Wet/Dry Vacs will be repaired or replaced, at Ridge Tool Company's option, and returned
at no charge; or, if after three attempts to repair or replace during the warranty period the Wet/Dry
Vac is still defective, you can elect to receive a full refund of your purchase price.
• What is not covered
Failures due to misuse, abuse or normal wear and tear are not covered by this warranty. RIDGE
TOOL COMPANY SHALL NOT BE RESPONSIBLE FOR ANY INCIDENTAL OR
CONSEQUENTIAL DAMAGES.
• How local laws relate to the warranty
Some states do not allow the exclusion or limitation of incidental or consequential damages, so the
above limitation or exclusion may not apply to you. This warranty gives you specific rights, and you
may also have other rights which vary from state to state, province to province, or country to
country.
• No other express warranty applies
This FULL LIFETIME WARRANTY is the sole and exclusive warranty for RIDGID® Wet/Dry Vacs.
No employee, agent, dealer, or other person is authorized to alter this warranty or make any other
warranty on behalf of Ridge Tool Company.
QUESTIONS OR COMMENTS? CALL
1-800-4-RIDGID (1-800-474-3443)
www.ridgidvacs.com
Please have your Model Number and Serial Number on hand when calling.
Professional Tools
Emerson Tool Company
A Division Of
Emerson Electric Co.
Stock No. WD7000
Model No. WD70000
Serial Number
Model and serial numbers may be found on the rear panel. You should record both
model and serial numbers in a safe place for future use.
c 2008 Emerson
SP6659-3 WD7000 ES.qxd 3/26/08 9:44 AM Page 20
