Ries Highly WHP03300PSV-F8JUN User manual

HitachiHighly
Rollkolbenverdichter
Rotary Compressors
Spezifikation
Installation Manual
RIES GmbH, Rudolf-Diesel-Str. 10, D 64569 Nauheim, GERMANY
Phone: [phone], Fax: [phone], Email: [email protected], Website: www.ries-gmbh.de
R 290
14,0 cm3/rev
WHP03300PSV-F8JUN
220-240V/1/ 50Hz

Table of contents
1.WHP03300PSV-F8JUN Sp ecifications ————————1～4
1.
Application range
2.
Compressor Specifications
3.
List of parts and drawings
4.
general characteristics
2. Benchmarks for Rotary Compressors ———————5～10
1.
System Design Constraints
2.
Process limitations
3.
O t h e r
3. acceptance —————————11
1.
Acceptance basis
2.
Acceptance rules
——————————12～21
4.D r aw i ng
5. Modification experience
——————————22

SUBJECT
Model WHP03300PSV-F8JUN SPECIFICATION
PAGE：1/22
1.
SCOPE
This specification is applied to SHANGHAI HIGHLY rotary
compressor.
2.
SPECIFICATION OF COMPRESSOR
2.1 Model
WHP03300PSV-F8JUN
2.2 Rated Voltage-Frequency-Phase 220V～240V/50Hz/
2.3 Application Heat pump water heater
2.4 Refrigerant R-290
2.5 Compressor Cooling
Forced air
2.6 Displacement
17.0ml/rev
single-cylinder
2.7 Rated capacity(see*) 3442W
2.8 Motor input(see*) 792W
2.9 COP 4.34
2.10 Current 3.70A
2.11 Allowable amount of
refrigerant charge
2.12 Amount of oil charge
750g
180±20ml (Initial)
2.13 Oil Synthetic oil or equivalent
2.14 Space volume of inner case
2.15 Net weight
1000ml
9.7kg incl. oil

SUBJECT
Model WHP03300PSV-F8JUN SPECIFICATION
PAGE：2/22
1/4”quick connect type 1/
2.16 Hermetic Terminal
2.17 Motor
Permanent Split Capacitor
25μF /400 V
21.0A (at 240V)
Rated voltage±10%
3.74/4.35 Ω(at 20℃)
Type
Capacitor
Locked rotor amps
Approved voltage range
Winding resistance(M/S)
2.18 Rated conditions
220V
7.2℃
54.4℃
46.1℃
35.0℃
35.0℃
Voltage
Evaporating temp.
Condensing temp.
Liquid temp. entering expansion valve.
Return gas temp.
Ambient temp.
2.19 Noise(see appendix)
66dB(A)
2.20 Vibration(see appendix) 15m/s2
2.21 Starting performance (1) The starting voltage should be as follows.
(2) The starting pressure should be balanced
between the suction and discharge of the
compressor and should be adjusted to the
following table.
(3) The temperatures of the compressor encl-
osure should be more than 20℃continuously
at the following table.

SUBJECT
Model WHP03300PSV-F8JUN SPECIFICATION
PAGE：3/22
TABLE 1
Starting Conditions
Spec
Motor temperature
Pressure
MPa{kgf/
cm2G}
Starting voltage
(V2)**
Cold-Starting
Cold state (room temperature)
1.027{9.46}
Below 85% of
rated voltage
Hot-Starting(Standard)
Hot state after operated under
standard load condition
0.984{9.02}
Below 85% of
rated voltage
Hot-starting(Overload)
Hot starte after operated under
overload Condition
1.069{9.88}
Below 90% of
rated voltage
*. Rated capacity and motor input are measured by secondary Refrigerant
calorimeter Methods of JIS B8606 by Shanghai Highly Electrical Appliances Co.,
Ltd. Allowable capacity should be more than 97% of the rated capacity and
Allowable motor input should be less than 103% of rated motor input.
**. V2means minimum voltage measured between pins
of hermetic terminal at the compressor starts. V2
***. The sucti
on pressure is measured on the position above the filte
r of accumulator.

SUBJECT
Model WHP03300PSV-F8JUN SPECIFICATION
PAGE：4/22
3.
PARTS AND DRAWING LIST
PARTS NAME
QTY/SET
DRAWING NO.
REMARKS
Compressor
1
Dimensioned sketch
Mounting
parts
Mount Assy
Rubber mount
1
3
SC01DA55
SC01DA68
*
Electrical
parts
Terminal cover
Packing
Flange nut
Run capacitor
1
1
1
4CYC01233
4CYC01234
SC01D430
SC01D352H18
*
4CYC01235
Lead routing
Performance curve
*. Out of supply，for reference.
4. CHARACTERISTICS
4.1 Residual moisture 120mg MAX
4.2 Residual impurities 60mg MAX

ROTARY COMPRESSOR CRITERIA FOR LONG LIFE
REFRIGERATION SYSTEM
PAGE：5/22
1. SYSTEM DESIGN LIMITATIONS
1.1 Powersource and Voltage
Voltage applied to hermetic terminal should be within the range mentioned
in this specification.
In the case of three phase, the phase imbalance should be within 3% among
the compressor terminals. The phase imbalance should be calculated
according to the follow formula.
(V)max-(V)mean
The phase imbalance=
×100%
(V)mean
(V)max: maximum voltage among the three terminals
(V)mean: average voltage among the three terminals.
1.2 Operating Temperatures and Pressures
The operating temperatures and pressures of the compressor should be
within the range shown in the table 2.
1.3 Operating and Shut-off Period
The compressor should be operated continuously at least for 5 minutes after
being turned ON.
3 minutes shut-off time should be ensured at least until restarting.
1.4 Liquid Refrigerant Back
When knocking noise, current increase and undesirable vibration are caused,
another accumulator should be equipped to the compressor and/or refrigerant
charge should be reduced to prevent liquid refrigerant back.

ROTARY COMPRESSOR CRITERIA FOR LONG LIFE
REFRIGERATION SYSTEM
PAGE：6/22
Table 2
Item
Operating Envelope
Discharge pressure
MPa{kgf/cm2G}
3.13 {30.91}MAX
（condensing temperature :80℃）
（see graph 1）
Suction Pressure
MPa{kgf/cm2G}
0.168~0.95 {0.678~8.67}
(Evaporation Temperature ：
-30℃~25℃)
Compressor case
bottom temp
99℃or below and 6 degrees
higher than condensing temperature
Motor winding temp. Voltage ±10% 127℃MAX
Motor winding temp.
under locked-rotor
condition
under stable condition:
OLR
OFF
Temp Highest
Average
165℃MAX
Highest
190℃MAX Average
OLR ON
time
Accumulator temp Higher than outlet pipe of
evaporator

ROTARY COMPRESSOR CRITERIA FOR LONG LIFE
REFRIGERATION SYSTEM
PAGE：7/22
Graph 1
P1
P2
P3
P4
P5
P6
P7
P8
Condensing temperature
75℃
25℃
10℃
10℃
65℃
80℃
80℃
80℃
Evaporation Temperature
25℃
25℃
10℃
-30℃
-30℃
-10℃
-5℃
10℃

ROTARY COMPRESSOR CRITERIA FOR LONG LIFE
REFRIGERATION SYSTEM
PAGE：8/22
The system should not flood back liquid to the compressor under all
conditions.
There should be superheated gas returned to the compressor under all normal
operating conditions.
1.5 Allowable Incline
The allowable incline should be less than 5during operation.
1.6 Pipe Vibration
The displacement of the pipes, which connect from the compressor to other
parts of the refrigerator systems, should be less than 0.8mm(1/32”)when
the compressor is operating at rated frequency +10Hz/ -10Hz and voltage range
of rated ±10%.
Displacement in excess of 0.8mm(1/32”) will require changing tube length
and/or routing.
1.7 Connecting Tube Design
In designing and routing tubing that connect from the compressor to the
other parts of the air conditioner, following should be considered.
Moving tubes to the moving parts; minimum clearance 12.7mm(1/2”)
Moving tubes to non-moving parts; minimum clearance 9.5mm(3/8”)
Moving tubes never touch to lead wire.
1.8 Water pressure resistance
16.2Mpa[G]{165.2Kgf/cm2[G]}的压力 1
Keep 16.2Mpa[G] {165.2Kgf/cm2[G]} (over 1 minute)，confirm if there is someplace broken
and note the pressure data.
