RightWay GPS Car Kit User manual

USER MANUAL
RIGHTWAY
car kit

Getting Started
Place mount against windshield or on
top of dash.
Secure mount by pushing the lever
towards the base into the lock position.

Place your iPhone or iPod touch in
the dock.
Adjust RW GPS Car Kit position for
either vertical or horizontal viewing.

Activating the RW GPS Car Kit
To operate the RW GPS Car Kit, plug in the 5V USB power cable; both GPS and Bluetooth functions
can then be used. When your iPhone or iPod touch is plugged into the RW GPS Car Kit with power
present, it will immediately charge the device.

Volume Control Bluetooth Control

Hands Free Calling via Bluetooth
Initial Set-Up (Bluetooth Pairing)
Hands free calling on your iPhone using the
RW GPS Car Kit requires a Bluetooth connection.
Once a connection is established, your iPhone will
automatically pair itself with the RW GPS Car Kit
when it is in range and powered.
1. Tap Settings on the main screen of
your iPhone.
2. Tap General, then Bluetooth.
3. Switch on Bluetooth.
4. RW GPS Car Kit will appear on the list of
Bluetooh devices found. Tap RW GPS Car
Kit, then Done.
Making & Receiving Calls
Your iPhone's calling functions work as they normally do
while your iPhone is docked in the RW GPS Car Kit.
1. Enter the phone number and press Call.
2. Hear and converse with the call recipient-hands
free-through the RW GPS Car Kit.
3. Press End when you have finished your
conversation.
Disabling Bluetooth
Hold the Bluetooth button down for five seconds.

Making Voice Activated Calls
(not a function of your iPhone 3G)
1. Click the Bluetooth Button once to activate
your iPhone voice dialing function.
2. Make your dialing request. (Double click to
redial the number.)
3. Hear and converse with the call recipient
through the RW GPS Car Kit.
4. Click the Bluetooth button once to end
the call.
Receiving Calls
Click the Bluetooth button on the RW GPS Car Kit:
• 1x to accept a call
• 2x to ignore a call
Ending Calls
Click the Bluetooth button on the RW GPS Car Kit
1x to end a call.
Advanced Functions for Your iPhone 3G, 3GS, & 4
Your iPhone 3G, 3GS or 4 does NOT have to be in the RW GPS Car Kit to work. Your iPhone could be in your
pocket, purse, backseat, etc. and it will connect with the RW GPS Car Kit via Bluetooth.

Music playback through your stereo
For music playback on your iPhone or iPod touch via your car stereo, connect the RW GPS
Car Kit to your stereo using a 3.5mm mini stereo audio cable (sold separately).

Releasing your iPhone or iPod touch
To release your iPhone or iPod touch
from the RW GPS Car Kit, press the
button on the upper left corner of
the kit. This will release the upper
clamp, enabling you to easily remove
your iPhone or iPod.

Support
Customer Service
At RightWay we believe that the customer deserves
the best possible service and support. We look
forward to assisting you in making the most of your
RightWay product.
On-Line: rightwaygps.com/support
E-Mail: [email protected]
Telephone: [phone]
Service Hours: Monday - Friday, 8:30 a.m. to
4:30 p.m. CST, excluding national holidays
Warranty: rightwaygps.com/RW/warranty-info.html
RightWay GPS Car Kit Tool
Before calling customer service, please download
the RW GPS Car Kit Tool App. This utility app will help
determine:
• if a proper connection has been established
• whether a satellite signal is being received
• the strength of a satellite signal
This information can be helpful in identifying
performance problems.
This application may be downloaded for FREE on your
iPhone or iPod touch via the App Store
GPS Kit has been paired with your iPhone,
but is not connected.
If the RW GPS Car Kit is paired but does not connect,
press and hold the Bluetooth button for 1 second.
Your iPhone or iPod touch is in the RW GPS
Car Kit, but not receiving satellite data.
Remove your iPhone or iPod touch from the RW GPS
car kit and re-seat it on the connector.
You hear alternator noise or a hum when
using the 3.5mm stereo audio cable and
the vehicle is running.
Consider using a ground loop isolator (sold
separately). By installing a ground loop isolator the
alternator noise will be filtered.

GPS Kit has been paired with your iPhone,
but is not connected.
If the RW GPS Car Kit is paired but does not connect,
press and hold the Bluetooth button for 1 second.
Your iPhone or iPod touch is in the RW GPS
Car Kit, but not receiving satellite data.
Remove your iPhone or iPod touch from the RW GPS
car kit and re-seat it on the connector.
You hear alternator noise or a hum when
using the 3.5mm stereo audio cable and
the vehicle is running.
Consider using a ground loop isolator (sold
separately). By installing a ground loop isolator the
alternator noise will be filtered.
TroubleShooting FCC Part 15 Compliance Statement
Changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates uses and can
radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
•
Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
•
Consult the dealer or an experienced radio/TV technician for help

www.rightwaygps.com
®
“Made for iPod” and “Made for iPhone” mean that an electronic accessory has been designed to connect specifically to iPod touch or
iPhone, respectively, and has been certified by the developer to meet Apple performance standards. Apple is not responsible for the
operation of this device or its compliance with safety and regulatory standards. Please note that the use of this accessory with
iPod touch or iPhone may affect wireless performance.
iPhone and iPod touch are trademarks of Apple Inc., and registered in the U.S. and other countries.
©2010 RightWay GPS, RightWay® and the RightWay logo are trademarks of Noetic inc.
