Battery Eyelets
- Red to positive
- Black to negative
Minimum Fusing
Requirements
SR-Series
(5 amps - 6”)(10 amps - 10”)
(15 amps - 20”, 30”, 40”, 50”)
E-Series
(5 amps - 4”, 6”)(10 amps - 10”)
(15 amps - 20”, 30”, 40”)(20 amps - 50”)
Visit RigidIndustries.com for more accessories!
covers & Accessories
Available!
*Clear covers are also available
Switch Wiring
E-Series 4”-10”
SR-Series 6”-10”
Black wire to gold prong (switch ground)
Red wire to middle prong (black strip) (switch output)
Red wire to remaining prong (switch power)
E-Series 20”-50”
SR-Series 20”-50”
Black wire to gold prong (switch ground)
Blue wire to middle prong (switch output)
Red wire to remaining prong (switch power)
Congratulations on your purchase of Rigid Lights!
For technical support call us at 855-760-5337.
Insert mounting brackets onto light as shown in Diagram
A or B. Secure hardware to a snug position and mount
your light into desired location. The 4”, 6“ & 10”E-Series
and 6“ & 10” SR-Series light bars include bolts that slide
into each side of light housing before compression
spacers and brackets are attached for mounting.
Attach red terminal eyelet to battery positive or any
12V DC source. Secure black terminal to suitable ground
or battery negative. Route harness to desired switch and
mounting locations, secure with zip ties. Beware of sharp
edges, abrasive surfaces and heat sources when wiring.
When installing Rigid lights on a 24V DC system be
sure to use a 24V relay. When installing multiple lights
be sure to have adequate fusing.
Finally, test lights to ensure proper function and then
secure mounting hardware according to your desired
light beam angle.
1.
2.
3.
4.
Rigid Industries always recommends installation from an
industry professional. Be sure to read warranty information on back.
*
Disconnect the negative battery cable from the battery.
5.
Congratulations on your purchase of Rigid Lights!
For technical support call us at 855-760-5337.
Insert mounting brackets onto light as shown in Diagram
A or B. Secure hardware to a snug position and mount
your light into desired location. The 4”, 6“ & 10”E-Series
and 6“ & 10” SR-Series light bars include bolts that slide
into each side of light housing before compression
spacers and brackets are attached for mounting.
Attach red terminal eyelet to battery positive or any
12V DC source. Secure black terminal to suitable ground
or battery negative. Route harness to desired switch and
mounting locations, secure with zip ties. Beware of sharp
edges, abrasive surfaces and heat sources when wiring.
When installing Rigid lights on a 24V DC system be
sure to use a 24V relay. When installing multiple lights
be sure to have adequate fusing.
Finally, test lights to ensure proper function and then
secure mounting hardware according to your desired
light beam angle.
1.
2.
3.
4.
Rigid Industries always recommends installation from an
industry professional. Be sure to read warranty information on back.
*
Disconnect the negative battery cable from the battery.
5.
Battery Eyelets
- Red to positive
- Black to negative
Minimum Fusing
Requirements
SR-Series
(5 amps - 6”)(10 amps - 10”)
(15 amps - 20”, 30”, 40”, 50”)
E-Series
(5 amps - 4”, 6”)(10 amps - 10”)
(15 amps - 20”, 30”, 40”)(20 amps - 50”)
Visit RigidIndustries.com for more accessories!
covers & Accessories
Available!
*Clear covers are also available
Switch Wiring
E-Series 4”-10”
SR-Series 6”-10”
Black wire to gold prong (switch ground)
Red wire to middle prong (black strip) (switch output)
Red wire to remaining prong (switch power)
E-Series 20”-50”
SR-Series 20”-50”
Black wire to gold prong (switch ground)
Blue wire to middle prong (switch output)
Red wire to remaining prong (switch power)
E-Series/E2 4”-10”
plug directly into light. Drill 3/4” Hole
to Install Switch
Drill 3/4” Hole
to Install Switch
E-Series/E2 4”-10”
plug directly into light.
