ring Stick Up Cam Operating and safety instructions

Setup and
Installation Guide
STICK UP CAM

Step 1
Download the Ring App
The Ring app will walk you through setting
up and managing your Stick Up Cam.
The Ring app is available for iPhone, iPad,
Mac Desktop, Android, and Windows 10.
Search for “Ring” in one of the app stores
above, or visit: ring.com/app
We have an online guide with videos
and tutorials at: ring.com/setup
Download from
Windows Store
2

Step 2
Meet the Back of your Stick Up Cam
Setup Button – You’ll be instructed to push
this during the in-app setup.
Charging Port – This port is for charging
your Stick Up Cam. Use the orange cable
we’ve provided.
Status Light – This light will pulse when
your Stick Up Cam is in setup mode.
For more, visit: ring.com/cam-charging
3

Perform setup inside near your router.
You’ll need your network name and Wi-Fi password.
Step 3
Perform the In-App Setup
Select the plus sign in the Ring app to set
up a new device.
When prompted, select Stick Up Cam.
4

Repeat this test outside. If video quality is not as
good, you may need to invest in a Wi-Fi extender.
Learn more at: ring.com/extender
Step 4
Test the Video Quality
Before mounting your Stick Up Cam let’s
run a quick test. Double press the orange
button. This will send an alert to your
mobile device. Smile you’re on camera.
5

Step 5
Charge your Stick Up Cam (optional)
If you’ll be running Stick Up Cam
off its internal battery, charge it
fully before mounting it outside.
You’ll also need to charge your
Stick Up Cam every 6–12 months
using the supplied orange cable.
If you receive
frequent motion
events you may
need to charge
your Stick Up Cam
more often.
The status light
will quickly pulse
twice every second
while charging.
You can power your Stick Up Cam directly from a
power source via the USB cable (plug not provided)
or purchase Ring Solar Panel from ring.com
6

Step 6
Select the Mount You’d Like to Use
You have two mounts to choose from.
There’s the quick release mount and the
security mount.
Quick Release
Mount
This mount makes it
easy to take your Stick
Up Cam off the wall for
charging.
Security Mount
This mount offers
a more permanent
solution.
7

Step 7
Remove the Swivel Arm From the
Security Mount
A) Loosen the screw on the side.
B) Remove the screw completely to set the
swivel arm free and set this screw aside
for now.
8

Step 8
Select the Mounting Point You’d Like to Use
The swivel arm can attach to
any of the three points on the
back of your Stick Up Cam.
THE TOP MOUNTING
POINT is great for
installing Stick Up
Cam on a ceiling.
THE MIDDLE
MOUNTING POINT
is great for installing
Stick Up Cam on a
wall at eye level.
THE BOTTOM
MOUNTING POINT
is great for installing
Stick Up Cam high on
a wall, or placing it on
a table.
9

Screw the bolt into the swivel arm
on the side with the recess
Step 9
Attach the Swivel Arm to your Stick Up Cam
Use the bolt that was provided in the
small bag to attach the swivel arm to
the mounting point you selected in the
previous step.
10

Step 10
Install the Mount
Take everything to where you’ll be
installing your Stick Up Cam.
If you’re installing on stucco, brick or
concrete, use the quick release mount as
a template to mark the location of 4 holes
that you’ll drill in the next step.
Quick
Release
Mount
11

On wood or siding, skip this part, and
screw the bracket directly into your wall.
Installing the Mount (continued)
On stucco, brick, or concrete use the
provided drill bit to drill the 4 holes
that you marked in the previous step.
Then insert the wall anchors.
12

Installing the Mount (continued)
Use the Phillips head side of the Ring
screwdriver and the provided screws to
screw in the bracket you selected in step 6.
13

Step 11
Attach Your Stick Up Cam to the
Security Mount
Use the screw you set aside in step 7 to
attach the camera to the security mount.
14

Step 12 (if using the quick
release mount)
Snap Your Stick Up Cam into the Quick
Release Mount
Push gently down on the tab and snap
your Stick Up Cam into place.
Double-press the orange button on the back of your
Stick Up Cam to trigger an alert in the Ring app. Use
this to find the best point of view for the camera.
15

Step 13
Bask in the pride of having installed
your Stick Up Cam!
Select your Stick Up Cam in the
Ring app to add Shared Users
and customize Motion Settings.
Shared Users
You can add friends and family by
selecting the Shared Users option
on the Settings Screen.
Enter the email addresses for those you want
to add. Shared users can answer live events
and view recordings (if you have Cloud Video
Recording enabled). They won’t be able to
delete events or change settings.
Motion Detection
To enable and customize motion
detection, select Motion Settings
on the Settings Screen.
16

Using Stick Up Cam
When Stick Up Cam detects motion, you
can perform the following actions:
Disable/enable your
microphone
Mute/unmute sound
in the Ring app
Zoom in/out
Access the Ring Plus menu
Turning off motion alerts:
If you don’t want to
receive notifications, you
can toggle motion alerts
off in the Ring app.
on
off
17

Cloud Video Recording
This optional feature saves events
captured by your Stick Up Cam.
You can access these events on any device
running the Ring app, or by logging into
your Ring account at: ring.com/activity
To learn more about Cloud
Video Recording, visit:
ring.com/cloud-recording
With Ring, You’re Always Home
18

Add Ring Solar Panel for
Ultimate Convenience
Ring Solar Panel connects to your Stick Up
Cam via a micro USB cable, and with only
a few hours of direct sunlight, keeps your
Stick Up Cam continuously charged.
Order now at ring.com/solarpanel
19

Protect the device from direct sunlight. Install the device at dry locations and protect
it against rain and humidity. The device may not get contact to salt water or other
conductive liquids. The device must be charged only within a building in a dry state.
© 2016 Bot Home Automation, Inc.
RING and ALWAYS HOME are trademarks of Bot Home
Automation, Inc., registered in the U.S.
Stick Up Cam and CHIME are trademarks of Bot Home
Automation, Inc.
Last updated: 04/13/16
For additional help, visit:
ring.com/help
For immediate assistance, we’re
available 7 days a week at:
DOMESTIC: 1-800-656-1918
INTERNATIONAL: [phone]
[e-mail]
1523 26th St.
Santa Monica, CA
90404
Hereby, Bot Home Automation,
declares that this consumer electronic
is in compliance with the essential
requirements and other relevant provisions
of Directive 1999/5/EC. The declaration of
conformity may be consulted at www.ring.
com/DoC.pdf.
