ring Flood User manual

•
ring
Flood/Freeze Sensor
F-or Ring Alarm

Prevent wate-- and ice damagP
at home.
Ring Flood/Freeze Sensor is a smart
sensor for your Ring Alarm system. Place
it anywhere you want to monitor for
flooding or freezing conditions.
On the bottom of the Sensor, you'II
see flood sensors that can tell when
water is present. Inside, a temperature
sensor keeps watch for dangerously low
temperatures (around 40 °For 4.4 ° C).
When either of these conditions occur,
the Ring app notifies you so you can take
care of the issue.

Contents
1. Diagram
2. ln-app Setup
3. Physical Installation
4. Additional Information

Diagram
---------- Flood Sensors
)

2.
Set up your
Ring Food/
Freeze Sensor
in the Ring app.

Begin the setup process near
your Ring Alarr11 Base Station.
In the Ring app
1
tap Set Up a Device.
Choose Security Devices, then Sensors,
then Ring Flood/Freeze Sensor1 then tap
Add Device.
To complete the setup process, follow
the in-app instructions.
0 7
---
-
-
--
>

When pro111ptedJ scan the QR
Code or enter tt1e PIN .
This begins the pairing process.The QR
Code and PIN are on the back of your
sensor and in the product packaging.
~1·
· ,!
[!1 .
1"345

Can)t sca11 the QR code?
No problem! In the app, on the scanning
screen, tap Not working? Enter number
instead.
Then, enter the 5-digit PIN code you'll see
below the QR code. Next, you1 II put your
Sensor in manual pairing mode.
To do this, open the Sensor, then remove
and reinstall the battery. Finally, press the
Setup Button to begin pairing.
Setup
Button

When prompted, opct'") the l:d and
OLJ II ou: tr1e clear tab.
Twist the lid to the left to unlock
1 then lift it
to remove. Next, pull out the clear battery
tab. This turns on the Sensor.
Your Base Station finds it automatically.

Watch your Sensor connect.
As your Sensor pairs to your Base Station1
its LED ring blinks slowly, then quickly.
Once the Sensor is paired, the LED glows
blue for three seconds.
If the Sensor does not pair successfully/
• the
LED ring glows red. To try the pairing
process again, remove and reinstall the
battery inside the Sensor.

Test your Flood/Free1e Sensor.
Now that your Sensor is set up, bring it to
the area you want to monitor. To ensure
it remains connected to your Alarm Base
Station in its new location, test the Sensor.
To do this, push the Setup button inside
the Sensor. If the LED blinks blue, the
Sensor is connected and ready to place.
If it blinks red, try the test again.You may
find that repositioning the Sensor (even
just a few inches) can improve reception.
0
If the Sensor cannot connect
1 try
installing a
Ring Range Extender between your Sensor
and Base Station.

Close the l id.
Place the lid back on the Sensor, takir1g
care to line up the semi-circle on the rim
of the lid with the "open1 ' semi-circle on
the base. Twist the lid clockwise to lock
it in.
C
t • .._ t l J

Place the Sensor on the ground.
Choose a spot next to a possible source
of flooding) such as your water heater)
sink1 or refrigerator. Take care to place
the Sensor in a location where it wonJt be
kicked or moved unintentionally.
0
If the surface you're placing on is not flat, try
to place your Sensor at the lowest point.

How to remove this Sensor from
your system:
Open the side menu in the Ring app and
tap Devices, then Base Station. Next,
select your Sensor, then tap the gear-
shaped icon, and tap Remove Device.
When prompted, open the sensor and
remove and reinstall the battery to
complete the removal.
Having trouble with your Sensor?
If your Flood/Freeze Sensor stops
working or can't connect (even with a
good battery), try a factory reset.
To do this, press and hold the Setup
button for 10 seconds. When the LED
ring stops blinking, the Sensor has reset.
This process disconnects the Sensor from
8 Ring A arm. To begin using the Sensor again,
repeat the setup process in the Ring app.

How to replace the battery:
Twist the licJ 011 the Sensor counter-
clockwise and lift to remove. Replace the
battery with a fresh CR 123A cell.
The Sensor then reconnects to your Ring
Base Station automatically.
LED status patterns:
Water or low o
temperature Blue Blink (1 x)
detected
Sensor
tampered
Red Blinks (3x)
For info on other LED patterns,
visit ring.com/l1elp .
Cl 2018 Ring LLC or •ts affihales.
RING,ALWAYS HOME, and all related logos are trademarks of Ring LLC or its affthates.
Last updated 10/30/ 18

•
ring
1 523 26th St.
Santa Monica
1 CA
90404
This dev ice complies with Part 15 of the FCC Rules. Operation is subject to the
following two condi t io n s: (1) Th is device may not cause harmful i nterfere nce,
and (2) this device must accept any interferen ce received, i ncluding in ter ference
that may cause undesired operation.
Thisdevice compl ies with I nd ust ry Can ada 's lic ence-exempt RSSs . Operation
is subject to the fol l owing two conditions : (1) This device may not cause
interference; and (2) This device mus t accept any interference, including
in terference that may cause undesired operation of the dev ice.
CAN I CES -3 (B )/ NMB-3(6) - Th isClass B digita l apparatus complies wi th
Canadian ICES - 003 .
Cet appa reil numerique de la classe Best conforme ala norme NMB-003 du
Canada.
The FCC ID of the dev ice in thispackagecan be found on the back or bottom
of the device.
CAUTION
Danger of explosion if battery is incorrect ly replaced. Replace only with the
same of equiv a lent type recommended by t he manufacturer .Dispose of the
used ba tt eries according to the manufacturer'sinstructions.
WARNING: Changes or modifications to this unit not expressly approved by
the pa rty responsible for compliance could void the user's authority to operate
the eq ui pment .
NOTE : This eq u ipment ha s been tested and found to co mply wi th the l imit s
for a Class B dig ital dev ice, pursuant to Part 15 of the FCC Rules.These limi ts
are design ed to prov id e reasonable protection against harmfu l in te rference
in a resi dential insta ll ati on. This equipment generates, uses, and can radiate
radio frequency energy and, if not ins talled and used in accordance w ith the
i nstru c ti ons, may cause h arm ful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular
installation. If this equipment do es cause harmful interference to radio or
television reception, which can be determined by tu rn ing the equ i pmen t off and
on, the useris encouraged to try to correct the interference by one or more of
the following measures:
, Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment in to an outle t on a circuit different from that to wh ich
the receiver is connec ted .
• Consu lt the dealer or an experienced radio/TV technician for help .
Le present apparei l est conforme aux C NR d' lndustrie Canada appl i cab les
aux a ppareil s radio exempts de licence. L'e xpl oi tatio n est autorisee aux deux
cond ition s suivantes :(1) l'appareil ne doit pas produire de brouillage , et (2)
l'utilisateur de l'appareil doit accepter tout brouillage radioelec tr ique subi,
meme si le brouillage est susceptible d' en compro mettre le fonctionnement .
Protect the device from direct sun light . Install th e device at dry lo c ation s, and
protect it against rain and humidity. The device may not get in contact to salt
wat er or other conducti ve li qu i ds .The device mu st be charged only w it hin a
bu i lding in a dry sta te .
This device may not be disassembled and used for any other purpose .This
unit , and all the compo nent s are configured for the sole purpose of providing
a security system. They are not approved for individual cellular use, batt ery use
or other mishandling .
2012/19 / EU (WEEE directive) :
Products marked w ith th is symbol should not be mixed w ith
general household waste. For proper recycling, return this
product to your local su pp lie r upon the pur chase of equivalent
new eq uipment, or dispose of it at designated col le ction points.
A mobile app must be used to set up the dev ice.
This dev ice is not an Access point or Hotspot and should not be used as one.
To revi ew your wa rranty coverage, please visit www ,rjng ,com/warr anty.
Patents: www rjng,com/patents
Version 1.2
