Ritelite K9 LED User manual

EN | DE | ES | FR
www.riteliteportablelighting.co.uk
Rechargeable LED Worklight
Quick Start Guide

Quick Start Guide 4 EN
Schnellstartanleitung 10 DE
Guía de Inicio Rápido 16 ES
Guide de mise en marche rapide 22 FR
3

4
EN K9 LED
Rechargeable LED Worklight
QUICK START GUIDE
SAFETY INFORMATION
• Only recharge in a well ventilated area.
• Do not stare directly into the light head or LEDs when switched on.
• Do not submerse the unit in water / liquids.
• Do not switch the light head on in close proximity to flammable materials. Ensure that
the front of the light head is at least 0.5m away from the nearest object or surface when
switched on. Failure to do so could result in heat build up and fire.
IMPORTANT
• Recharge battery immediately aer use. Do not leave in a discharged state. Failure to do
this will significantly reduce the lifespan and performance of the battery.
• Only use approved batteries and chargers. Use of other batteries and chargers may
cause damage and/or reduce the performance of equipment.
OPERATING MODES
Torch Worklight

5
EN
OPERATION
FOCUSSING
Spot light Flood light
1x = Switch on
2x = Switch off
0x = White
1x = White Flashing
2x = SOS Flashing
3x = Alternate flashing
(inner and outer LED arrays)
4x = White
0x = Inner and outer LED arrays
1x = Inner LED array only
2x = Outer LED array only
3x = Inner and outer LED arrays
0x = 100%
1x = Boost mode
2x = 8%
3x = 25%
4x = 50%
5x = 75%
6x = 100%

6
EN BATTERY STATUS
CHARGING STATUS
SEALED LEAD ACID (SLA) K9
SEALED LEAD ACID (SLA) K9
WITH VEPAC
LITHIUM K9 WITH VEPAC
CHARGING
LED Green = Ok
LED Amber = Low
LED Red = Warning
LED Flashing Red = Low power saver mode
~0 % - 80 %: LED = Red
~80 % - 100 %: LED = Amber
~100 %: LED = Green
~0 % - 80 %: LED = Red
~80 % - 100 %: LED = Flashing Red
~100 %: LED = Green
~0 % - 80 %: LED = Red
~80 % - 100 %: LED = Amber
~100 %: LED = Green
Charge Standby: LED = Flashing Green
Vehicle Charger
For VEPAC equipped units
12 – 30V DC
A
B
C
Mains Charger* (Optional)
For units without VEPAC
100 – 240V AC
For SLA K9 units without an in-built VEPAC charger.
If the unit does not have an LED at the position
shown above it will need to be charged with a mains
charger (C). Charging status colours are shown on the
external charger.
* Only for SLA battery equipped units
For SLA K9 units with an in-built VEPAC charger.
If the unit has an LED at the position shown
above the in-built charger can be powered by either
a mains adaptor (B) or a vehicle charger (A). Charging
status colours are shown on the K9 at the position
shown above.
For Lithium K9 units which all have an in-built VEPAC
charger as standard. The in-built charger can be
powered by either a mains adaptor (B) or a vehicle
charger (A). Charging status colours are shown on the
K9 at the position shown above.
Mains Adaptor (Optional)
For VEPAC equipped units
100 – 240V AC
LED
VEPAC LED

7
EN
INTEGRATED TRIPOD
45º 45º 45º
1.8m

8
EN TECHNICAL DATA
Lamp Type 30 x High Power / Flux SMD LED's
Colour Temperature 6500 Kelvin
Lumen output at 100% setting 4,800 Lumens
Lumen output in boost mode 6,600 Lumens
Nominal life expectancy of LED's 50,000 Hours
Power consumption 30 watts in 100% mode, 45 watts in boost mode
Operating modes Choice of 4 main modes
1. Worklight 7 brightness levels
2. Flashing signal 2 channel LED - simultaneous flashing
3. SOS signal International SOS signal
4. Flashing signal - alternating 2 channel LED - alternating flashing
Focusing system Variable intensity from spot to full flood
Circuit protection MCB circuit breaker - 10A thermal circuit breaker
Protection class IP54
Dimensions (L x W x H) 430mm x 215mm x 255mm
* Battery duration is subject to ambient temperatures.
Battery type SLA LiFePO4 LITHIUM DUAL LITHIUM
Battery voltage / amp hour 12V / 22AH 12.8V / 22AH 14.8V / 20.8AH 14.8V / 41.6AH
* Brightness level / approx duration
8% 110 hours 110 hours 110 hours 220 hours
50% 16 hours 15 hours 15 hours 30 hours
100% 8 hours 8 hours 30 mins 8 hours 30 mins 17 hours
125% 6 hours 7 hours 7 hours 14 hours
Recharge times approx
Integrated intelligent charging system
12V - 30V DC input / 12V 4A max output 6 hours 7 hours 7 hours 15 hours
Optional 230V mains adapter
100 - 240V AC input / 19V 3.4A max output 6 hours 7 hours 7 hours 15 hours
Nominal operating voltage 12V DC 12.8V DC 14.8V DC 14.8V DC
Weight (including extension poles) 11.8 Kg 8.7Kg 7.8Kg 9.0Kg

9
CAUTION
• Always read the manual fully before use.
• Use the Ritelite approved chargers only, other chargers may cause a
detrimental effect on the performance of this unit.
• Ensure adequate ventilation for this unit whilst charging.
• Do not stare directly into the light head when powered up.
• Do not completely submerse the unit in water.
• No user serviceable parts inside. Leave servicing to a qualified person.
The contents of this manual are subject to change without prior notice.
We take no responsibility for errors or admissions.
ADVICE ON DISPOSAL OF RITELITE PRODUCTS AT END OF LIFE
For our latest advice on the disposal of Ritelite products at end of life please visit the link below.
https://www.ritelite.co.uk/disposal-advice
DISCLAIMER OF WARRANTY
For details about the warranty offered on Ritelite products please visit the link below.
https://www.ritelite.co.uk/warranty-information
EN
Setup Video & Resources

10
DE
K9 LED
AKKU LED-Beleuchtungssystem
SCHNELLSTARTANLEITUNG
SICHERHEITSHINWEISE
• Bitte stellen Sie beim Aufladen sicher, dass das Gerät ausreichend belüet ist.
• Schauen Sie nie direkt in den Lichtkopf oder die LEDs wenn das Gerät
eingeschaltet ist.
• Das Gerät nicht in Wasser oder andere Flüssigkeiten eintauchen.
• Schalten Sie den Lichtkopf nicht in der Nähe brennbarer Materialien ein. Stellen
Sie sicher, dass die Vorderseite des Lichtkopfes mindestens 0,5 m von anderen
Gegenständen oder Oberflächen entfernt ist, wenn er eingeschaltet ist. Andernfalls kann
es zu Hitzeaufbau und Feuer kommen.
WICHTIG!
• Ein Wiederaufladen der Batterie ist nach jedem Einsatz unbedingt erforderlich. Lassen
Sie das Gerät nie in einem entladenem Zustand. Bei Missachtung wird die Lebensdauer
und Leistung der Batterie deutlich verringert.
• Bitte verwenden Sie nur zugelassene Batterien und Ladegeräte. Der Gebrauch anderer
Batterien und Ladegeräte kann Schäden hervorrufen und/oder die Leistung des Gerätes
beeinträchtigen.
BETRIEBSARTEN
Handlampe Arbeitslampe
