Riva RC1202HD User manual

1
Fehler! Unbekannter Name für Dokument-Eigenschaft.
www.rivatech.de
RC1202HD
Installation Guide

2
www.rivatech.de
INFORMATION TO USER
CAUTION
RISK OF ELECTRIC SHOCK,
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE THE DEVICE COVER (OR BACK).
CONTACT QUALIFIED SERVICE PERSONNEL FOR INTERNAL
PART SERVICES.
This symbol is intended to alert the user the presence of un-insulated
“dangerous voltage” within the product’s enclosure, which may be
sufficient magnitude to constitute a electric shock risk to persons.
This symbol is intended to alert the user the presence of important
operating and maintenance (servicing) instructions within the guide
manual
!
!

3
www.rivatech.de
Table of Contents
1.FEATURE………………………………………………………………………………….4
2. PACKAGE CONTENTS.........................................................................5
3. PART NAMES…………………………………………………….…..….…………....6
3.1. Rear View…………………………………………………………………..……………….6
3.2. Side View…………………………………………………………………………………....6
3.3. Front View………………………………………………………………………….………..7
4.INSTALLATION…………………………………………………………………………9
4.1. Installing a Lens………………………………………………………………………….9
4.2. Installing the Mounting Adaptor…………………………………………………..….10
4.3. Connecting Cables……………………………………………………………..…….….11
4.4. Setting the Image Attribute…………………………………………...…………….15
5.CONFIGURATION……………………………………………………..….…………….16
5.1. Set up network environment…………………………………..……….………………16
5.1.1. Generic IP Environment……………………………….…………………………..16
5.1.2. Custom IP Environment…………………………….……………………………..17
5.2. View video on web page……………………………..………………………………….19
5.2.1. View video using IPAdmin Tool………….……………………………………….21
5.3. Reset………………………………………………………………………………………..22
5.4. Factory Default................................................................................... 22
APPENDIX (A): SPECIFICATIONS………………………………………………………24
Summary ................................................................................................. 24
Electrical Characteristics............................................................................. 25
Environment Condition ................................................................................ 25
Mechanical Condition ................................................................................. 25
APPENDIX (B): POWER OVER ETHERNET……………………………………………26
APPENDIX (C): DIMENSIONS…………………………………………………………..28
APPENDIX (D): HEXADECIMAL-DECIMAL CONVERSION TABLE…………………28
REVISION HISTORY……………………………………………………………………….29

4
www.rivatech.de
1.FEATURES
Camera
Box type full-HD IP camera
1/2.7” 1080p CMOS Image Sensor
CS mount, DC auto iris control output
Streaming
Dual streaming mode (such as different codec/resolution/bit rate and so
on.)*
Burnt-in text support
Unicast/Multicast support
Video/Audio
Video compression: H.264/MJPEG, up to 30FPS@1080p*
Audio compression: G.711(µLaw, aLaw)/PCM
Analog video out (for installation only)
Video motion detection supported
Two-way mono audio supported
Network
RTSP/ HTTP protocol support
10/100 Base-T Ethernet
Additional Features
RS-485 support
MicroSD card slot support (Local storage)
PoE support
Built-in Video Content Analysis
Burnt-in text support
SDK (Software Development Kit) support
* When VCA is activated, frame rate is limit to max15fps@1080p. Limitations are
based on V.1.5.0 firmware release and could be changed without notice.

5
www.rivatech.de
2. PACKAGE CONTENTS
The package contains main camera, DC power adaptor, DC jack cable, camera lens,
terminal block, power adaptor jack, screws, mounting adaptor, clamping core, and
quick installation guide. Unpack carefully and handle the equipment with care.
Camera
DC power adaptor
Lens
Terminal block
Power adaptor jack
Screws
Adaptor for mounting the camera
Quick installation guide
Clamping core
To prevent electromagnetic interference
The above contents are subject to change without prior notice.
Note
i

6
www.rivatech.de
3. PART NAMES
3.1. Rear View
3.2. Side View
⑩
⑥
⑤
①
②
④
③
⑦
⑧
-+
⑨

7
www.rivatech.de
3.3. Front View
1. Power Adaptor Connect
The camera requires DC 12V for power supply. Refer to the section “ 4.3. Connecting
Cables ”for more specific information
2. PAL/NTSC button
Press the PAL/NTSC button to set video output as PAL or NTSC. The default is no
video output. Each time pressing the button cycles through PAL, NTSC, and no video
output mode: No video output -> PAL->NTSC Please note that the analog video signal
is only 3 minutes present and go back automatically to none video output mode (only
installation process).
3. 11 pin terminal block for D/I, D/O, audio, and serial communication
Refer to the section “ 4.3. Connecting Cables ”for more specific information.
4. Analog Video Out Connector
Use BNC cable (not supplied) to connect between the camera and monitor to verify
image focuses at the installation site. Users must cycle through button (no video
output -> PAL -> NTSC) to select the video output. Once the PAL/NTSC button is
pressed, the video displays for 3 minutes before returns back to ‘no video output’
status.
⑪

8
www.rivatech.de
5. Reset Button
Use the reset button to restart or reset the camera back to factory default settings.
Refer to the section “Fehler! Verweisquelle konnte nicht gefunden werden.”for more
pecific information.
6. RS-485 Termination Switch (120ohm)
Select ON or OFF for RS-485 termination register. The default is off.
7. Network Port
Use the RJ45 LAN connector for connecting the camera to network or supplying PoE
power.
8. USB 2.0 Port
Plug an USB flash drive or wireless LAN device.
9. SD Card Slot
Support memory cards up to 32GB.
10. Auto Iris Lens Connector
The 4-pin connector for an DDC drive auto iris lens.
11. Light Sensor
The light sensor is used to detect the level of ambient light detect intensity of light. The
sensor should not be blocked by cable or any other objects.

9
www.rivatech.de
4.INSTALLATION
4.1. Installing a Lens
High definition (HD) lenses are recommended on the camera to utilize the full
resolution of a megapixel camera. Installing a standard definition (SD) lens to a
megapixel camera may exacerbate camera noises and possibly introduce traditional
edge effects.
If a camera is exposed to harsh temperature environment (ex. diurnal temperature
variations higher than ±10˚C), condensation or thermal expansion are likely to occur in
camera and lens parts, causing lens focus to shift time to time. Be advised to
consider the environment condition impact when installing the device in a long term.
To mount a DC auto iris lens,
1. Place the lens mount to the camera and tighten the mount by turning clockwise.
2. Connect the lens cable to the 4-pin auto iris connector on the side of the
camera. Refer to the figure above for more details about the connector.
Light Sensor
Auto Iris Lens Connector

10
www.rivatech.de
3. Manually adjust the zoom and focus of the image with the zoom lever and focus
lever on the lens mount. (Refer to the manual provided with your lens.)
4.2. Installing the Mounting Adaptor
The provided mounting adaptor is designed for installing an IP camera device on a
bracket or tripod. Tripod screw holes are available on both top and bottom of the
camera. Refer to the following image for instruction.
Mounting screws that are longer than 7mm may damage the
camera’s inside parts.
Note
i
2
1
4
3
PIN
DC Auto Iris Lens
1
Damp-
2
Damp+
3
Drive+_
4
Drive-
4 pin connector
