Riverside Furniture Windward Bay User manual

6/0-6/6 King Storage Bed
42880 -- 6/0-6/6 Arch Headboard
42872 -- 5/0-6/6 Bed Rails
or---42882 -- 6/0 Bed Rails
42883 -- 6/0-6/6 Low Storage Footboard
Windward Bay
King Storage Bed
Assembly Instructions
Made in Viet Nam
email: [e-mail]
FURNITURE
Riverside
8 pcs. 8 pcs.
8 pcs.
2 pcs.
8 pcs.
2 pcs.
8 pcs.
1 pc.
2 pcs.
6 pcs.
6 pcs. 1 pc.
3 pcs. 2 pcs. 4 pcs. 6 pcs.
1 pc.
Page 1 of 7
2 pcs.
1 pc.
1 pc.

Windward Bay
King Standard Bed
Assembly Instructions
Made in Viet Nam
email: [e-mail]
FURNITURE
Riverside
8 pcs. 8 pcs.
8 pcs. 8 pcs. 8 pcs.
1 pc.
8 pcs.
2 pcs. 1 pc.
4 pcs. 2 pcs. 2 pcs.
Page 2 of 7
2 pcs.
1 pc.
6/0-6/6 King Storage Bed
42880 -- 6/0-6/6 Arch Headboard
42872 -- 5/0-6/6 Bed Rails
or---42882 -- 6/0 Bed Rails
42881 -- 6/0-6/6 Low Footboard w/Slats
2 pcs.
2 pcs.

Page 3 of 7
ASSEMBLY STEPS :
1. Place the Headboard Panel (H-A) face down on a clean and soft surface.
2. Attach the Left and Right Headboard Posts (H-B) to the back of the Headboard Panel,
using the Flat Washers (H-F), Spring Washers (H-E) and Bolts (H-D). Do not fully
tighten until after next step. (see Detail A).
3. Attach the Back Stretcher (H-C) to the Headboard Posts using the same Washers and
Bolts as previous step. Tighten Bolts connecting Stretcher with the Allen Wrench (H-G).
(see Detail B). Tighten Bolts connecting Headboard Posts to Headboard Panel.
Gently lean the back of the assembled Headboard against the wall where the Bed will be
located in the room.
Windward Bay
Bedroom
Assembly Instructions
Made in Viet Nam
email: [e-mail]
FURNITURE
Riverside

Page 4 of 7
Windward Bay
Bedroom
Assembly Instructions
Made in Viet Nam
email: [e-mail]
FURNITURE
Riverside
ASSEMBLY STEPS :
1. Remove both drawers from the Storage Footboard. Refer to the steps above.
2. Place the Footboard Panel (F-A) face down on a clean and soft surface.
3. Attach the Footboard Bun feet (F-B) to the bottom of the Footboard, using the Flat Washers
(F-J), Spring Washers (F-I) and Bolts (F-G). Tighten with the Allen Wrench (F-K).
4. Attach the Drawer Box Support Legs (F-D) using the Flat Washers (F-J), Spring Washers
(F-I) and Bolts (F-H). Tighten with the Allen Wrench (F-K).
To remove the drawer:
A. Pull the drawer fully open so the
black latch is visible in the inside
channel of the guides.
B. Release the latches by
simultaneously pushing one lever up
and the other down.
C. At the same time, pulling the
drawer forward until the slides
release.

Page 5 of 7
Windward Bay
Bedroom
Assembly Instructions
Made in Viet Nam
email: [e-mail]
FURNITURE
Riverside
ASSEMBLY STEPS :
To prevent possible damage to furniture and personal injury, it is recommended that two people are used
to perform the following steps.
5. Install two All-Thread Bolts (R-B) into each metal plate installed onto the Headboard Posts and into the
metal plates on the Storage Footboard.
6. Carefully position one end of one Bed Rail (R-A) onto the All-thread Bolts on the Headboard and
connect using the Flat Washers (R-E), Spring Washers (R-D), and Hex Nut (R-C). Only partially tighten
the Nuts until the Footboard has been connected. Repeat for other Bed Rail.
7. Position and connect the Storage Footboard (F-A) to the other end of the Bed Rails attaching as in the
previous Steps.
8. Carefully align the Storage Footboard to be 'square' with the Headboard. Using the Open Wrench (R-F)
tighten all Hex Nuts attaching the Side Rails to the Headboard and Storage Footboard. (See Detail E ).
9. Attach the three Support Legs (F-E) to the bottom side of three Wood Support Panels with Blocks (F-F).
The Panel Support Legs must be installed into the 6" x 6" x 1/2" blocks mounted on the bottom side of the
panels. (See Detail F). The Support Panel (F-M) used above the drawer compartment does not have a
support leg.
10. Position and attach the Support Panels to the Bed Rails using the Wood Screws (F-L) and your Phillips
Screwdriver.
The levelers located at the bottom of the Support Legs can be adjusted if necessary to support the panels.
11. Reinstall the Drawers into the Footboard by aligning the metal channels of the guides and push back
into the Footboard.
6 pcs.
3 pcs. 1 pc.

Page 6 of 7
Windward Bay
Bedroom
Assembly Instructions
Made in Viet Nam
email: [e-mail]
FURNITURE
Riverside
ASSEMBLY STEPS :
To prevent possible damage to furniture and personal injury, it is recommended that two people are used
to perform the following steps.
5. Install two All-Thread Bolts (R-B) into each metal plate installed onto the Headboard Posts and into the
metal plates on the Footboard.
6. Carefully position one end of one Bed Rail (R-A) onto the All-thread Bolts on the Headboard and
connect using the Flat Washers (R-E), Spring Washers (R-D), and Hex Nut (R-C). Only partially tighten
the Nuts until the Footboard has been connected. Repeat for other Bed Rail.
7. Position and connect the Footboard (F-A) to the other end of the Bed Rails attaching as in the previous
Steps.
8. Carefully align the Footboard to be 'square' with the Headboard. Using the Open Wrench (R-F) tighten
all Hex Nuts attaching the Side Rails to the Headboard and Footboard. (See Detail E ).
9. Attach the eight Support Legs (F-E) to the bottom side of Wood Slats (F-F). (See Detail F).
10. Position and attach the Slats to the Bed Rails using the Wood Screws (F-L) and your Phillips
Screwdriver.
The levelers located at the bottom of the Support Legs can be adjusted if necessary to support the Slats.
8 pcs.
4 pcs.

Riverside
FURNITURE
email [e-mail]
USE THESE HOLES FOR ATTACHING AN EASTERN KING SIZE (6/6)
METAL BED FRAME
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
CUSTOMER TO PROVIDE 5/16 X 3-1/2" LONG BOLTS, NUTS &
WASHERS TO CONNECT THE METAL BED FRAME
USE THESE HOLES FOR ATTACHING A CALIFORNIA
KING SIZE (6/0) METAL BED FRAME
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
CUSTOMER TO PROVIDE 5/16 X 1-1/2" LONG BOLTS, NUTS
& WASHERS TO CONNECT THE METAL BED FRAME
USE THESE HOLES FOR ATTACHING WOOD SIDE RAILS.
ALL HARDWARE IS INCLUDED WITH THE SIDE RAILS
EASTERN
KING RAILS
CALIFORNIA
KING RAILS
#42880
King Size Headboard 42880 -- 6/0-6/6 Arch Headboard
42872 -- 5/0-6/6 Bed Rails
42882 -- 6/0 California Bed Rails
42883 -- 6/0-6/6 Low Storage Footboard
Page 7 of 7
The Headboard may be used alone with
an Eastern or California King Size
Metal Bed Frame
42880 -- 6/0-6/6 Arch Headboard
42872 -- 5/0-6/6 Bed Rails
42881 -- 6/0-6/6 Low Footboard with Slats
