RKC INSTRUMENT DP-700 User manual

IMR01X01-E2
RKC INSTRUMENT INC.
®
Handheld Digital
Thermomete
r
D
P
-70
0
Instruction Manual

All Rights Reserved, Copyright 2003, RKC INSTRUMENT INC.
 Microsoft, Windows, Excel are the registered trademark of Microsoft Corporation.
 Company names and product names used in this manual are the trademarks or registered trademarks of
the respective companies.

IMR01X01-E2 i-1
Thank you for purchasing this RKC instrument. In order to achieve maximum performance
and ensure proper operation of your new instrument, carefully read all the instructions in this
manual. Please place this manual in a convenient location for easy reference.
SYMBOLS
: This mark indicates important information on installation, handling and operating
procedures.
: This mark indicates supplemental information on installation, handling and
operating procedures.
: This mark indicates where additional information may be located.
 Never use this product for medical equipment.
 This product must be used in accordance with the specifications
to prevent fire or damage to instrument and equipment.
 This product is not intended for use in locations subject to
flammable or explosive gases.
 If any abnormality such as smoke, smell of burning or noise was
found, do not use the product. If so, fire may occur.
 RKC is not responsible if this product is repaired, modified or
disassembled by other than factory-approved personnel.
Malfunction can occur and warranty is void under these
conditions.
CAUTION
: This mark indicates precautions that must be taken if there is danger o
f
electric shock, fire, etc., which could result in loss of life or injury.
: This mark indicates that if these precautions and operating procedures
are not taken, damage to the instrument may result.
: This mark indicates that all precautions should be taken for safe usage.
WARNING
!
WARNING
!

IMR01X01-E2
i-2
 All precautions described in this manual should be taken to avoid damage to the
instrument or equipment.
Prevent metal fragments or lead wire scraps from falling inside instrument case to
avoid electric shock, fire or malfunction.
Do not drop nor apply strong impact to the product. If so, failure may result.
Do not use the product while the battery cover is being removed. If so, failure may
result.
Load a battery so that its polarity will meet the indication on the product. If not, the
battery electrolyte may leak or heat be generated to result in injury or failure.
 If the product is not used for a long period of time, remove the battery from the
mainframe. If not, the battery electrolyte may leak to result in failure.
 Battery service life may change depending on battery performance, operating
condition and measuring environment.
 Use this product within the following ambient temperature and ambient humidity.
- Allowable ambient temperature: −20 to +50 °C
- Allowable ambient humidity: −5 to 95 %RH
(Absolute humidity: MAX.W.C 29 g/m3dry air at 101.3 kPa)
 Do not use or store the product in places such as listed below:
- Rapid changes in ambient temperature which may cause condensation.
- Corrosive or inflammable gases.
- Direct vibration or shock to the mainframe.
- Direct water, oil, chemicals, vapor or steam splashes. *
- Excessive dust, salt or iron particles. *
- Excessive induction noise, static electricity, magnetic fields or noise.
- Direct air flow from an air conditioner.
- Exposure to direct sunlight.
- Excessive heat accumulation.
* DP-700A: Equal to IP67, DP-700B: Equal to IP54
Turn off the power supply before cleaning the instrument.
Do not use a volatile solvent such as paint thinner to clean the instrument.
Deformation or discoloration will occur. Use a soft, dry cloth to remove stains from
the instrument.
To avoid damage to instrument display, do not rub with an abrasive material or
push front panel with a hard object.
NOTICE
This manual assumes that the reader has a fundamental knowledge of the principles of
electricity, process control, computer technology and communications.
The figures, diagrams and numeric values used in this manual are only for purpose of
illustration.
RKC is not responsible for any damage or injury that is caused as a result of using this
instrument, instrument failure or indirect damage.
Periodic maintenance is required for safe and proper operation of this instrument. Some
components have a limited service life, or characteristics that change over time.
Every effort has been made to ensure accuracy of all information contained herein. RKC
makes no warranty expressed or implied, with respect to the accuracy of the information.
The information in this manual is subject to change without prior notice.
No portion of this document may be reprinted, modified, copied, transmitted, digitized,
stored, processed or retrieved through any mechanical, electronic, optical or other means
without prior written approval from RKC.
CAUTION

IMR01X01-E2 i-3
CONTENTS
Page
1. OUTLINE.............................................................................. 1
1.1 Checking the Product ......................................................................................1
1.2 Parts Description .............................................................................................2
1.3 LCD Displays...................................................................................................3
1.4 Function Menu Configuration...........................................................................4
2. PREPARATION BEFORE USE............................................ 5
2.1 Loading Battery...............................................................................................5
2.2 Setting Date and Time ....................................................................................6
2.3 Connecting the Temperature Sensor..............................................................7
3. BASIC OPERATION............................................................. 8
3.1 Turn Power On ................................................................................................8
3.2 Measuring Temperatures.................................................................................9
4. JUDGING MEASURED TEMPERATURES [SIMPLIFIED
JUDGING FUNCTION] ....................................................... 10
4.1 Registering Tag Names (Measured Objects).................................................11
4.2 Setting the Judgment Range of High/Low Limit Temperatures......................14
4.3 Judging Measured Temperatures..................................................................15
5. RECORDING MEASURED TEMPERATURES
[LOGGING FUNCTION] ..................................................... 17
5.1 Manual Recording .........................................................................................18
5.2 Automatic Recording .....................................................................................19
5.3 Retrieving Recorded Data .............................................................................21
5.3.1 Retrieving only recorded data with specified tag name (Tag Filter) ................... 21
5.3.2 Retrieving recorded data with specified log registered No. (Log Jump)............. 22
5.4 Deleting Recorded Data ................................................................................23
5.4.1 Deleting only one recorded data item (Delete?)................................................. 23
5.4.2 Deleting all recorded data items (All Clear?)...................................................... 24
5.5 Defragmenting Recorded Data ......................................................................25
6. PEAK HOLD/BOTTOM HOLD ........................................... 26

IMR01X01-E2
i-4
Page
7. REGISTERING USER NAMES [ONLY FOR DP-700B]..... 28
8. INITIAL SETTING ............................................................... 32
 To select the display language (English/Japanese) .......................................32
 To select the date format ...............................................................................32
 To select the sensor type ...............................................................................33
 To select the display unit (°C/°F)....................................................................33
 To select the decimal point position ...............................................................34
 To correct the temperature display value (PV Bias) .......................................34
 To lessen the fluctuation of a display value caused by noise (Digital Filter)...35
 Saving battery consumption (Auto Power OFF) .............................................35
 Locking/Unlocking setting operation (Operation Lock) ...................................36
9. MANAGING DATA BY PC [ONLY FOR DP-700B]............ 37
9.1 Connecting PC to DP-700B...........................................................................37
9.2 Storing Data...................................................................................................38
9.3 Disconnecting DP-700B from PC ..................................................................41
10. APPENDIX ........................................................................ 42
10.1 Replace the Battery .....................................................................................42
10.2 Cleaning ......................................................................................................44
10.3 Troubleshooting...........................................................................................44
10.3.1 Error displays ................................................................................................... 44
10.3.2 Problem and solution ....................................................................................... 46
10.4 Specifications ..............................................................................................47

IMR01X01-E2 1
1. OUTLINE
This Chapter describes features, package contents and model code, etc. The handheld digital
thermometer DP-700 has the following features:
 Wide temperature measurement is possible
Thermocouple K: −200 to +1372 °C (−328 to +2501 °F), −199.9 to +999.9 °C (°F)
Thermocouple J: −200 to +1200 °C (−328 to +2192 °F), −199.9 to +999.9 °C (°F)
Thermocouple T: −50 to +400 °C (−58 to +752 °F), −50.0 to +400.0 °C (−58.0 to +752.0 °F)
RTD (Pt100): −200 to +850 °C (−328 to +1562 °F), −199.9 to +850.0 °C (−199.9 to +999.9 °F)
 Names of measured objects can be registered.
Names of measured objects can be registered using 11 characters maximum.
(DP-700A: maximum 5 tags DP-700B: maximum 99 tags)
 Simplified Judging Function
Judgment can be immediately made for each measured object. (Temperatures to judge the
high/low limits need to be set.)
 Logging Function (Manual logging mode, Automatic logging mode)
Measured object, measured temperature, date, and user name can be manually or automatically
recorded in the memory. (DP-700A: maximum 99 logs DP-700B: maximum 9999 logs)
 Peak and Bottom Hold Function
The maximum and minimum measured-temperatures can always be stored.
 Can be operated for 400 hours continuously using one Type LR6 (based on
IEC and JIS) alkaline battery.
 Data can be controlled using personal computers (Only for the DP-700B)
Measured data can be stored in the file in the CSV format using the USB port of each personal
computer.
1.1 Checking the Product
Before using this product, check each of the following:
Model code
Check that there are no scratch or breakage in external appearance.
Check that all of the items delivered are complete. (See below)
 Model code
DP-700 /
Accessories:
Instruction Manual (IMR01X01-E2)·····1 LR6 (IEC and JIS) Alkaline battery ··············1
Strap ···················································1 USB cable (Only for DP-700B) ···················1
(1) Type
A: Economy type
(No USB, Logging: 99 logs, Backed up by RAM)
B: High performance type
(With USB, Logging: 9999 logs, Backed up by EEPROM)
(1) (2)
(2) Display language
J: Japanese
E: English
If any of the products are missing, damaged, or if your manual is incomplete, please
contact RKC sales office or the agent.

1. OUTLINE
IMR01X01-E2
2
1.2 Parts Description
LCD display
Displays various information on measured
temperature, measured date, set details of
each function and error number.
Operation keys
MENU/POWER key:
• Used to turn on/off the power. Pressing
this key for more than 2 seconds can turn
off the power.
• Can call up or select the function menu
screen while the power is turned on.
• Can display the list of characters in the
message column while characters are being
entered.
SET key:
• Establishes operation during execution.
ESC key:
• Suspends operation during execution. If
suspended, returns to the displayed state or
screen just before being suspended.
UP key ( )/DOWN key ( ):
• Can select measured objects or user names
already registered while the measurement
screen is being displayed.
• Can select the list of characters while
characters are being entered.
Left shift key (<)/Right shift key (>):
• Can select display details in the message
column while the measurement screen is
being displayed.
• Can move to the preceding or next function
menu screen while the function menu (Fn0
to Fn9) screen is being displayed.
• Can move the cursor character by character
while characters are being entered.
REC key:
• When in manual logging mode (manual
recording), records the measured temperature
and date at the time when this key is pressed.
• When in automatic logging mode (automatic
recording), used as a recording START/STOP
key.
DP-700
REC
MENU
/POWER
ESC
SET
LCD
display
Battery cover
Operation
keys
USB connecter
(Only for DP-700B)
Sensor connection jack
Hooks for
carrying the
sensor

1. OUTLINE
IMR01X01-E2 3
1.3 LCD Displays
The following details are displayed on the LCD screen.
(1) (Number display)
• If measured object or user name is displayed,
displays the corresponding registered number.
• When recorded data items are displayed,
displays “Display memory number/Total
memory number of recorded data items of
those data items.
(2) (Log execution display)
• When in manual logging mode (manual
recording), displayed only when the REC
key is pressed.
• When in automatic logging mode (automatic
recording), continues lighting during
recording and continues flashing during
recording stop.
(3) (Burnout display)
Displayed when the sensor is broken, shorted
or imperfectly connected.
(4) ( Remaining battery service life display )
Displays the remaining battery service life
(reference only).
Service life remains long.
Service life is going to shorten.
Service life is going to expire.
(Battery replacement is required.)
Service life has expired. (Immediate
battery replacement is required.)
(5) Measured temperature display
Displays the measured temperature. In addition,
displays information on error number, etc. if an
error occurs.
(6) °C or °F (Temperature unit display)
(7) ( Simplified judgment display )
Symbols to judged the measured temperature. To
judge the measured temperature using these
symbols, it is necessary to set the judgment
points of its high and low limits.
NG
Measured temperature exceeds
judgment point of high limit
temperature.
OK Measured temperature is within
judgment points.
NG
Measured temperature is below
judgment point of low limit
temperature.
(8) Message column
Displays function menu screen name, measured
date 1, measured object 3, user name 2, 3 etc.
1Set the measured date, if necessary. (See P. 6)
2Not displayed if no user name is registered.
3Number of registered characters: 11 maximum
(9) ,
Displays message selection.
このエリアは使用し
ません。
°
C
(1) (2) (3) (4)
(5)
(6)
(7)
(8)
(9)

1. OUTLINE
4IMR01X01-E2
1.4 Function Menu Configuration
The DP-700 is provided with a function menu used to select and then set any function
necessary for measured-temperature judgment and recording (logging). There for, set the
desired function as needed by the customer. For details, refer to the relevant pages.
Measurement
screen
Power ON
MENU/POWER key
ESC key
: Press the MENU/POWER key or >key : Press the
<
key
°C
01/01 00:00
This symbol is always displayed.
When user name is
registered.
SET key
ESC key or
<
key
>key, key or key
Dick
°C
User No.
key
key
FRY1
°
C
Tag No.
key
key
Menu used to check and
retrieve recorded
measured-temperatures.
Menu used to register
measured-object names,
and to set judging
conditions of measured
temperatures.
Menu used to set time
intervals of automatically
recording measured-
temperatures.
Menu used to check
maximum/minimum
measured-temperatures.
Menu used to registe
r
user names.
(P. 28)(P. 32)
Menu used to set
dominical year/month/
day/time and to check
information on versions.
(P. 6)
Fn0 to Fn8 are menus which are not necessary to be used when
only temperatures are measured such as by a thermometer.
(P. 17)
Memory
(P. 10)
TAG Setup
(P. 19)
Logging
(P. 26)
Peak/Bottom
UserName
SetupUtility
Function Memu
Menu used to set items relating to initicalizeing setting.
If unnecessary to be changed, use their factory set
values.
Initial setting items (factory set value): P. 32
Display language:English PV bias: 0.0 °C
Date format: month/day Digital filter: OFF
Sensor type: TC-K Auto power OFF: 3 min.
Display unit: °C Operation lock: 0000 (Unlock)
Decimal point position: 0.1 (One dicimal place)

IMR01X01-E2 5
2. PREPARATION BEFORE USE
This chapter describes preparations necessary for operating this instrument for the first time.
2.1 Loading Battery
 Procedures
1. Loosen the battery cover.
Turn the cover with a coin.
2. Remove the battery cover.
3. Load a battery without mistaking its polarity.
Alkaline battery (LR6)
4. Then, firmly tighten the battery cover.
Insufficient tightening cannot assure the effect of water resistance (DP-700A: Equal to
IP67, DP-700B: Equal to IP54).
After the battery is loaded, the instrument is ready to be
reset-started.
The function menu “Utility (Fn0)” for setting the
dominical year is displayed on the LCD screen. If no
dominical year is set, no calendar function can be used.
Always set the year if the calendar function is used.
Pressing the ESC key twice can display the measurement screen.
For the battery life or replace method, see 10.1 Replace the Battery (P. 42).
Year setting screen
Year
+
−

2. PREPARATION BEFORE USE
IMR01X01-E2
6
: Press the SET
key
2.2 Setting Date and Time
Set the date and time displayed on the measurement screen. This setting is made on the
function menu “Utility (Fn0).” The setting procedure is described using an example where
the instrument is reset-started (from start on the Fn0 screen).
 Setting year
1. Press the <or >key to move the flashing digit.
2. Press the or key to set the “year.”
3. Press the SET key to store the new set value.
Data range: 0000 (Only for Reset start)
2003 to 9999
Factory set value: 0000
 Setting month and day
1. Press the or key to set the “day (month).”
2. Press the <key to move the blinking cursor to “month (day).”
3. Press the or key to set the “month (day).”
4. Press the SET key to store the new set value.
Data range:
Month: 01 to 12
Day: 01 to 31
Factory set value:
01/01 (Month/Day)
 Setting time
1. Press the or key to set the “minute.”
2. Press the <key to move the blinking cursor to “time.”
3. Press the or key to set the “time.”
4. Press the SET key to store the new set value.
Data range: Hour: 00 to 23
Minute: 00 to 59
Factory set value: 00:00
Date
Reset start
A
utomati-
cally
Time
ROM version
Year
Return to Year
Battery setting
Year
Returns to
Measurement
screen
Press the
ESC key
twice
Cursor blinking
Flashing
Day (Cursor blinking)
01/01 mm/dd
(“Month/Day” display)
Month
(“Day/Month” display)*
01/01 dd/mm
Month (Cursor blinking)Day
* To display “Day/Month”, see the date format screen in “Setup (Fn9)” of the Function
menu (P. 32).
01/01 00:00

2. PREPARATION BEFORE USE
IMR01X01-E2 7
2.3 Connecting the Temperature Sensor
Connect the temperature sensor (sold separately) to the DP-700 mainframe.
Firmly connect the sensor cable to the mainframe so as not to cause imperfect
contact.
 Temperature sensor and Accessories (sold separately)
 JB-702 (rounded end type)
Measuring temperature range:
−40 to +250 °C (−40 to +482 °F)
Protective tube size: φ3.2, φ4.8
Protective tube length: 100 mm, 200 mm,
300 mm
Leadwire length: 1000 mm (1 m)
 JB-701 (needle type)
Measuring temperature range:
−40 to +250 °C (−40 to +482 °F)
Protective tube size: φ2.1
Protective tube length: 100 mm
Leadwire length: 1000 mm (1 m)
 A-DP700
Connecting adapter for JB-15 or JB-16
In addition to the above, various types of sensors are available. Contact our sales
office or your nearest RKC sales agent, if required.
Temperature sensor
DP-700
REC
MENU
/POWER
ESC
SET

8 IMR01X01-E2
3. BASIC OPERATION
This chapter describes the basic operation of the instrument for temperature measurement.
3.1 Turn Power On
Press the MENU/POWER key. The power is turned on to display the measurement screen.
When the power is turned on for the first time after preparations before operation are
finished, “Simplified judgment display” is as the above screen example.
For the simplified judgment display, see 4. JUDGING MEASURED
TEMPERATURES [SIMPLIFIED JUDGING FUNCTION] (P. 10).
The power is turned off if no key operation is performed for more than the Auto
power OFF time (factory set value: 3 min.) with the power turned on.
For the Auto power OFF setting, see Saving battery consumption (P. 35).
What screen is displayed when the power is turned off and then is turned on
again?
If the user name is registered to the user number selected, the type of screen
displayed first differs.
For the type of screen displayed, see 1.4 Function Menu Configuration (P. 4).
°
C
11/11 09:00
Measured
temperature
Date and
Time *
Simplified
j
udgment
display
* If the data and time are not set in the
function menu [Utility (Fn0)], the factory
set value is displayed.
[Factory set value: 01/01 00:00]
DP-700
REC
MENU
/POWER
ESC
SET

3. BASIC OPERATION
IMR01X01-E2 9
3.2 Measuring Temperatures
To measure temperatures, insert the sensor into or contact it with the measured object. When
measuring temperatures, handle the sensor as instructed in the following.
 Use the sensor within its temperature measuring range.
 Firmly insert the sensor cable into the sensor connector of the mainframe.
 If the sensor gets stained, wipe it with a clean cloth.
Example of display screen during measurement:
When a measured object is at a surface temperature of 90.0 °C
It is possible to record the measured temperature and date in the memory.
For the data recording (logging) method, see 5. RECORDING MEASURED
TEMPERATURES [LOGGING FUNCTION] (P. 17).
 In order to prevent injuries, never direct the sensor tip toward a
person.
 In order to prevent burning or frostbite, do not touch the sensor
during or just after its use in the high or low temperature
environment.
WARNING
!
CAUTION
°
C
11/11 09:05 Measured date
Measured temperature

10 IMR01X01-E2
4. JUDGING MEASURED TEMPERATURES
[SIMPLIFIED JUDGING FUNCTION]
This chapter describes settings and procedures to judge measured temperatures using the
simplified judging function.
Before using the simplified judging function, register tag names (measured object names) and
also set judgment criteria (judgment points of high and low temperatures). The registration
and setting are made on the function menu “TAG Setup (Fn2).”
Screen Configurations of TAG Setup (Fn2) Menu:
What is the simplified judging function?
This function is for judging whether or not measured temperatures are within the
judgment criteria preset (judgment points of high and low temperatures) and then
check judgment results according to simplified judgment symbols.
* Each tag name before factory
shipment can be used as it is.
When using the tag name
before factory shipment, display
Tag No. in the message column
on the measurement screen.
TAG Setup
SET key
(P. 4)
Character entry (P. 11)
MENU/POWER key
Hi Limit
°C
Judgment point o
f
high limit temp.
setting screen
(P. 14)
SET key
SET key
T
A
G01
The selected tag name
setting screen
(Example: TAG01)
Cursor
blinking
SET key
(P. 11) (P. 14)
Low Limit
°
C
Tag name screen
Maximum number of registration
DP-700A: 5 tags DP-700B: 99 tags
TAG01
Tag name *
Tag No.
key
key
Measurement
screen
Press the
MENU/POWER
key twice
Judgment point o
f
low limit temp.
setting screen
ESC key
ESC key
SET key
ESC key

4. JUDGING MEASURED TEMPERATURES [SIMPLIFIED JUDGING FUNCTION]
IMR01X01-E2 11
4.1 Registering Tag Names (Measured Objects)
Any measured object mane (maximum number of character: 11 characters) can be registered
for each number. The tag name thus registered can be displayed on the measurement screen.
 Character entry screen
Example: When the tag name screen of Tag No. 1 is selected.
Characters list
Numerals 0123456789
Alphabets A B C D E F G H I
JKLMNOPQR
STUVWXYZ
abcdefghi
jklmnopqr
stuvwxyz
Symbols @ ! # $ % & ’ `
+-.;=^_
()[]{}
N
o spaces (no characters)
can be used.
Select the list of
characters by the or
key.
T
A
G01
Cursor
blinking
Tag name setting screen
Delete?
Insert?
STUVWXYZ
Character selecting screen
Screen used to check whether or not the
currently selected character (curso
r
blinking) is deleted.
SET key: To execute deletion
ESC key: To suspend operation
Screen used to check whether to inser
t
space for entering a character in the
p
osition displayed with the currently
selected character (cursor blinking).
SET key: To execute insertion
ESC key: To suspend operation
MENU/
POWER key
MENU/
POWER
key
MENU/
POWER
key
MENU/
POWER
key
(P. 13)
(P. 13)
A list of characters including the currently
selected character (cursor blinking) is
displayed in the message column.
Select the list of characters by the or
key and then select the desired
character by the <or >key.
SET key: To execute selection
ESC key: To suspended operation
Delete check screen
Insert check screen
Returns to
Measurement
screen
Press the
ESC key
three times
SET key
ESC key
SET key
ESC key
SET key
ESC key

4. JUDGING MEASURED TEMPERATURES [SIMPLIFIED JUDGING FUNCTION]
IMR01X01-E2
12
 Procedures
Example: Change the tag name of Tag No. 2 from “TAG02” to “PAN02”
1. Press the SET key at TAG Setup (Fn2)
screen to display the tag name screen.
2. Press the key.
The display goes to the tag name screen
of Tag No. 2.
3. Press the SET key.
The cursor is displayed in the position
displayed with the tag name “T.”
4. Press the MENU/POWER key.
The list of characters is displayed in the
message column.
5. Press the key.
The list of characters including “P” is
displayed.
6. Press the >key to move the cursor to the
position displayed with “P.”
7. Press the SET key to store the new set
value. The screen returns to the tag name
screen of Tag No.2 and the cursor moves
to “A.”
8. Press the >key to move the cursor to the
position displayed with “G.”
TAG01
TAG02
T
A
G02
Blinking
STUVWXYZ
P
A
G02
JKLMNOPQR
JKLMNOPQR
PAG02

4. JUDGING MEASURED TEMPERATURES [SIMPLIFIED JUDGING FUNCTION]
IMR01X01-E2 13
9. Press the MENU/POWER key.
The list of characters is displayed in the
message column.
10. Press the key.
The list of characters including “N” is
displayed.
11. Press the <key to move the cursor to the
position displayed with “N.”
12. Press the SET key to store the new set
value. The screen returns to the tag name
screen of Tag No.2 and the cursor moves
to “0.”
The setting is finished.
When setting the judgment criteria
(judgment points of high and low
temperatures) succeedingly, press the SET
key. (P. 14)
To return to the measurement screen,
press the ESC key three times.
How to change the character without
displaying the list of characters?
1. Move the cursor to the position displayed
with the character to be revised by using
the <or >key.
2. Display the character to be revised by
using the or key.
How to delete one character?
1. Move the cursor to the position displayed
with the character to be deleted using the <
or >key.
2. Press the MENU/POWER key twice to
display the screen for checking the deletion.
3. Press the SET key to delete the character
where the cursor blinked.
How to insert space for entering a
character in any position?
1. Move the cursor to the position where a
character needs to be entered using the <
or >key.
2. Press the MENU/POWER key three times
to display the screen for checking the
entry.
3. Press the SET key to insert space for
entering the character before the character
position where the cursor blinks.
PAN02
JKLMNOPQR
A
BCDEFGHI
JKLMNOPQR

4. JUDGING MEASURED TEMPERATURES [SIMPLIFIED JUDGING FUNCTION]
14 IMR01X01-E2
4.2 Setting the Judgment Range of High/Low Limit Temperatures
Set the judgment points of high and low temperatures for judging measured temperatures.
This setting is made for each tag name. This judgment is conducted from the time when
measurement is started.
 Procedures
Example:When setting a high temperature of 90.0 °C and a low temperature of 50.0 °C
for Tag No.2 (tag name: PAN02)
1. Press the SET key at the tag name screen
of Tag No.2 to display the judgment
point of high limit temperature setting
screen.
2. Press the <key to flash the tens digits.
3. Press the key to change the number to
9.
4. Press the SET key to store the new value.
The display goes to the next screen
(Judgment point of low limit temperature).
5. Press the <key to flash the tens digits.
6. Press the key to change the number to
5.
7. Press the SET key to store the new set
value. The display returns to the tag name
screen of Tag No.2.
The setting is finished.
To return to the measurement screen after the setting is finished, press the ESC key three
times.
Setting range:
Same as input
range
Factory set
value:
0.0 °C [32.0°F]
Hi Limit
°C
Flashing
Hi Limit
°C
Hi Limit
°C
Low Limit
°C
Flashing
Low Limit
°C
Low Limit
°C
Setting range:
Same as input
range
Factory set
value:
0.0 °C [32.0°F]
